C3K1345Microsoft Wireless Laser Keyboard 7000

 Contents Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 用户手册 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 快速入門 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 사용 설명서 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 Microsoft Product Guide Read this guide for important safety and health information that applies to the Microsoft ® device that you have purchased. Warning Failure to properly set up, use, and care for this product can increase the risk of serious injury or death, or damage to the device or devices. Read this guide and keep all printed guides for future reference. For replacement guides, go to www.microsoft.com/hardware or refer to the Customer Support Options section for contact information. This document includes important information about many Microsoft products. Refer to sections that apply to the features of your device: Important Safety Information AC-Powered Devices Battery-Powered Devices Headset Devices Wireless Devices Statement of Compliance with EU Directives Keyboard and Mouse Devices Devices with Laser Pointers All Devices Laser and LED Specifications Regulatory Information Radio Frequency Technical Specifications Disposal of Waste Electrical and Electronic Equipment Patent Information Customer Support Options This symbol identifies safety and health messages in this Product Guide and other product manuals . 0607 PartNo.X2- 6902-05 M X121690205mnl.indb 16/15/07 5:02:12 PM 2 Important Safety Information AC-Powered Devices These precautions apply to all products that plug into a standard wall power outlet. Failure to take the following precautions can result in serious injury or death from electric shock or fire or in damage to the device. To select an appropriate power source for your device: ● Use only the power supply unit and AC power cord that came with your device or that you received from an authorized repair center. ● Confirm that your electrical outlet provides the type of power indicated on the power supply unit (in terms of voltage [V] and frequency [Hz]). If you are not sure of the type of power supplied to your home, consult a qualified electrician. ● Do not use non-standard power sources, such as generators or inverters, even if the voltage and frequency appear acceptable. Only use AC power provided by a standard wall outlet. ● Do not overload your wall outlet, extension cord, power strip, or other electrical receptacle. Confirm that they are rated to handle the total current (in amps [A]) drawn by the device (indicated on the power supply unit) and any other devices that are on the same circuit. To avoid damaging the power cords and power supply: ● Protect the power cords from being walked on. ● Protect cords from being pinched or sharply bent, particularly where they connect to the power outlet, the power supply unit, and the device. ● Do not jerk, knot, sharply bend, or otherwise abuse the power cords. ● Do not expose the power cords to sources of heat. ● Keep children and pets away from the power cords. Do not allow them to bite or chew on them. ● When disconnecting the power cords, pull on the plug—do not pull on the cord. If a power cord or power supply becomes damaged in any way, stop using it immediately. Unplug your device during lightning storms or when unused for long periods of time. For devices with an AC power cord that connects to the power supply, always connect the power cord according to the following instructions: 1 Plug the AC power cord into the power supply until it stops. 2 Plug the other end of the AC power cord into the wall outlet. X121690205mnl.indb 26/15/07 5:02:12 PM  Battery-Powered Devices These precautions apply to all products that use rechargeable or disposable batteries. Improper use of batteries may result in battery fluid leakage, overheating, or explosion. Released battery fluid is corrosive and may be toxic. It can cause skin and eye burns, and is harmful if swallowed. To reduce the risk of injury: ● Keep batteries out of reach of children. ● Do not heat, open, puncture, mutilate, or dispose of batteries in fire. ● Do not mix new and old batteries or batteries of different types (for example, carbon-zinc and alkaline batteries). ● Do not allow metal objects to touch the battery terminals on the device; they can become hot and cause burns. ● Remove the batteries if they are worn out or before storing your device for an extended period of time. ● Always remove old, weak, or worn-out batteries promptly and recycle or dispose of them in accordance with Local and National Disposal Regulations. ● If a battery leaks, remove all batteries, taking care to keep the leaked fluid from touching your skin or clothes. If fluid from the battery comes into contact with skin or clothes, flush skin with water immediately. Before inserting new batteries, thoroughly clean the battery compartment with a damp paper towel, or follow the battery manufacturer’s recommendations for cleanup. Disposable (non-rechargeable) batteries only: ● Caution Risk of explosion if battery is replaced by an incorrect type. Use and replace only with the correct size and type (alkaline, zinc-carbon, or zinc-chloride) of batteries. Rechargeable batteries only: ● Caution Risk of explosion if battery is replaced by an incorrect type. Use and replace only with the same type and rating as the batteries provided. ● Charge only with the recharger provided with the product. Headset Devices Extended exposure to high volumes when using a headset may result in temporary or permanent hearing loss. Wireless Devices Before boarding any aircraft or packing a wireless device in luggage that will be checked, remove the batt…

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division Date: December 6, 2007 FCC ID: C3K1345 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Brian Jiang, Lead EMC and Safety Engineer MICROSOFT CORPORATION Tel: +86 755-86118641 Fax: +86 755-26551121 e-mail: [email protected]

Federal Communications Commission Authorization and Evaluation Division Date: December 6, 2007 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia , Maryland 21046 Subject: Short-term confidentiality request regarding application for certification of FCC ID: C3K1345 TO WHOM IT MAY CONCERN Pursuant to DA 04-1705 of the Commission’s public notice, we request short-term confidential treatment for the following information until 45 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External Photos Test Setup Photos User’s Manual Internal Photo Sincerely, Brian Jiang, Lead EMC and Safety Engineer MICROSOFT CORPORATION Tel: +86 755-86118641 Fax: +86 755-26551121 e-mail: [email protected]

MICROSOFT CORPORATION ONE MICROSOFT WAY REDMOND, WA 98052-6399 POWER OF ATTORNEY We, the undersigned, Microsoft Corporation., hereby authorize Advance Data Technology Corporation (ADT) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by ADT on our behalf shall have the same effects as acts of our own. Product Name Model FCC ID Microsoft ® Wireless Laser Keyboard 7000 1345 C3K1345 If you have any questions regarding the authorization, please don’t hesitate to contact us. This Letter of Authorization will expire on Dec. 1, 2008, unless earlier revoked in writing Sincerely yours, ------------------------------------------------- Brian Jiang, Lead EMC and Safety Engineer MICROSOFT CORPORATION Tel: +86 755-86118641 Fax: +86 755-26551121 e-mail: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT

FCC ID: C3K1345 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

Page 2 Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9

FCC ID: C3K1345 Report No.: RF961112A02 Operational Description The transmitter of the EUT (Microsoft ® Wireless Laser Keyboard 7000) is powered by 3Vdc batteries. The type of antenna is Strip antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: RF961112A02 1 Report Format Version 2.0.6 FCC TEST REPORT REPORT NO.: RF961112A02 MODEL NO.: 1345 RECEIVED: Nov. 12, 2007 TESTED: Nov. 12 ~ 13, 2007 ISSUED: Dec. 10, 2007 APPLICANT: MICROSOFT CORPORATION ADDRESS: ONE MICROSOFT WAY REDMOND, WA 98052-6399, U.S.A ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. This test report consists of 26 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF, A2LA or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF961112A02 2 Report Format Version 2.0.6 Table of Contents 1. CERTIFICATION..........................................................................................3 2. SUMMARY OF TEST RESULTS..................................................................4 2.1 MEASUREMENT UNCERTAINTY...............................................................4 3. GENERAL INFORMATION..........................................................................5 3.1 GENERAL DESCRIPTION OF EUT............................................................5 3.2 DESCRIPTION OF TEST MODES..............................................................6 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.........................................6 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.............7 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................8 3.4 DESCRIPTION OF SUPPORT UNITS........................................................8 4. TEST TYPES AND RESULTS......................................................................9 4.1 CONDUCTED EMISSION MEASUREMENT..............................................9 4.2 RADIATED EMISSION MEASUREMENT...................................................9 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.................................9 4.2.2 TEST INSTRUMENTS..............................................................................10 4.2.3 TEST PROCEDURES...............................................................................11 4.2.4 DEVIATION FROM TEST STANDARD.....................................................11 4.2.5 TEST SETUP ...........................................................................................12 4.2.6 EUT OPERATING CONDITIONS..............................................................12 4.2.7 TEST RESULTS........................................................................................13 4.3 FREQUENCY TOLERANCE MEASUREMENT........................................19 4.3.1 LIMITS OF FREQUENCY TOLERANCE MEASUREMENT......................19 4.3.2 TEST INSTRUMENTS..............................................................................19 4.3.3 TEST PROCEDURE.................................................................................19 4.3.4 DEVIATION FROM TEST STANDARD.....................................................19 4.3.5 EUT OPERATING CONDITION................................................................19 4.3.6 TEST RESULTS........................................................................................20 4.4 BAND EDGES MEASUREMENT..............................................................21 4.4.1 LIMITS OF BAND EDGES MEASUREMENT............................................21 4.4.2 TEST INSTRUMENTS..............................................................................21 4.4.3 TEST PROCEDURE.................................................................................21 4.4.4 DEVIATION FROM TEST STANDARD.....................................................21 4.4.5 EUT OPERATING CONDITION................................................................21 4.4.6 TEST RESULTS........................................................................................21 5. PHOTOGRAPHS OF THE TEST CONFIGURATION.................................24 6. INFORMATION ON THE TESTING LABORATORIES...............................25 7 APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB.......................................................26 Report No.: RF961112A02 3 Report Format Version 2.0.6 1. CERTIFICATION PRODUCT: Microsoft ® Wireless Laser Keyboard 7000 BRAND NAME: Microsoft ® MODEL NO.: 1345 APPLICANT: MICROSOFT CORPORATION TESTED: Nov. 12 ~ 13, 2007 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249), ANSI C63.4-2003 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Dec. 10, 2007 ( Annie Chang / Senior Specialist ) TECHNICAL ACCEPTANCE : , DATE: Dec. 10, 2007 Responsible for RF ( Jamison Chan / Senior Engineer ) APPROVED BY : , DATE: Dec. 10, 2007 ( Ken Liu / Deputy Manager ) Report No.: RF961112A02 4 Report Format Version 2.0.6 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD SECTION TEST TYPE AND LIMIT RESULT REMARK 15.207 Conducted Emission Test N/A The EUT power from batteries 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 12.209 PASS Minimum passing margin is –4.64dB at 2483.500MHz 15.249 (b)(2) Frequency Tolerance Limit: ±0.001% PASS Meet the requirement of limit. 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertai…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
