C3K1453Wireless Mouse

1 Contents Microsoft Product Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Microsoft 产品指南 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 Microsoft 제품 가이드 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Microsoft 產品指南 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34 Microsoft CËnmX {ZX}{eH$m . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42 คูมือผลิตภัณฑ Microsoft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51 International Technical Support Numbers (Partial List Only) . . . . . . . . .60 0409 PartNo. X15-63623-01 X156362301mnl_en.indd 14/8/09 7:13:55 PM 2 Microsoft Product Guide Read this guide for important safety and health information and the terms of the Limited Warranty that apply to the Microsoft ® device that you have purchased. Warning Failure to properly set up, use, and care for this product can increase the risk of serious injury or death, or damage to the device or devices. Read this guide and keep all printed guides for future reference. For replacement guides, go to www.microsoft.com/hardware or refer to the Microsoft Help and Support section for contact information. This document includes important information about many Microsoft products. Refer to sections that apply to the features of your device: Important Safety Information AC-Powered Devices Battery-Powered Devices Headset Devices Webcam Devices Wireless Devices Game Controllers, Keyboards, and Mouse Devices Devices with Laser Pointers All Devices Laser and LED Specifications Regulatory Information Radio Frequency Technical Specifications Disposal of Waste Batteries and Electrical and Electronic Equipment Patent Information Customer Support Options Limited Warranty This symbol identifies safety and health messages in this Product Guide and other product manuals . Important Safety Information AC-Powered Devices These precautions apply to all products that plug into a standard wall power outlet. Failure to take the following precautions can result in serious injury or death from electric shock or fire or in damage to the device. X156362301mnl.indb 24/8/09 6:56:58 PM 3 To select an appropriate power source for your device: ● Use only the power supply unit and AC power cord that came with your device or that you received from an authorized repair center. ● Confirm that your electrical outlet provides the type of power indicated on the power supply unit (in terms of voltage [V] and frequency [Hz]). If you are not sure of the type of power supplied to your home, consult a qualified electrician. ● Do not use non-standard power sources, such as generators or inverters, even if the voltage and frequency appear acceptable. Only use AC power provided by a standard wall outlet. ● Do not overload your wall outlet, extension cord, power strip, or other electrical receptacle. Confirm that they are rated to handle the total current (in amps [A]) drawn by the device (indicated on the power supply unit) and any other devices that are on the same circuit. To avoid damaging the power cords and power supply: ● Protect the power cords from being walked on. ● Protect cords from being pinched or sharply bent, particularly where they connect to the power outlet, the power supply unit, and the device. ● Do not jerk, knot, sharply bend, or otherwise abuse the power cords. ● Do not expose the power cords to sources of heat. ● Keep children and pets away from the power cords. Do not allow them to bite or chew on them. ● When disconnecting the power cords, pull on the plug—do not pull on the cord. If a power cord or power supply becomes damaged in any way, stop using it immediately. Unplug your device during lightning storms or when unused for long periods of time. For devices with an AC power cord that connects to the power supply, always connect the power cord according to the following instructions: 1 Plug the AC power cord into the power supply until it stops. 2 Plug the other end of the AC power cord into the wall outlet. Battery-Powered Devices These precautions apply to all products that use rechargeable or disposable batteries. Improper use of batteries may result in battery fluid leakage, overheating, or explosion. Released battery fluid is corrosive and may be toxic. It can cause skin and eye burns, and is harmful if swallowed. To reduce the risk of injury: ● Keep batteries out of reach of children. ● Do not heat, open, puncture, mutilate, or dispose of batteries in fire. ● Do not mix new and old batteries or batteries of different types (for example, carbon-zinc and alkaline batteries). ● Do not allow metal objects to touch the battery terminals on the device; they can become hot and cause burns. X156362301mnl.indb 34/8/09 6:56:59 PM 4 ● Remove the batteries if they are worn out or before storing your device for an extended period of time. ● Always remove old, weak, or worn-out batteries promptly and recycle or dispose of them in accordance with Local and National Disposal Regulations. ● If a battery leaks, remove all batteries, taking care to keep the leaked fluid from touching your skin or clothes. If fluid from the battery comes into contact with skin or clothes, flush skin with water immediately. Before inserting new batteries, thoroughly clean the battery compartment with a damp paper towel, or follow the battery manufacturer’s recommendations for cleanup. Disposable (non-rechargeable) batteries only: ● Caution Risk of explosion if battery is replaced by an incorrect type. Use and replace only with correct size and type (alkaline, zinc-carbon, or zinc-chloride) of batteries. Rechargeable batteries only: ● Caution Risk of explosion if battery is replaced by an incorrect type. Use and replace only with the same type and rating as the batteries provided. ● Charge only with the recharger provided with…

Text truncated - open the document above for the full version.

Microsoft Corporation is an equal opportunity employer. Subject: Authorized signatories January 7, 2009 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 A G E N C Y A U T H O R I Z A T I O N L E T T E R To whom it may concern, We, the undersigned, Microsoft® Corporation hereby authorize the following, to act on our behalf, as our agent, in all matters relating to all processes required according to FCC Part 15C for Microsoft® Corporation products (Grantee Code:C3K): Michael Boucher San Chen Ted Eckert Pam Galvan Albert Huang Bill Huang Daniel Lamanuzzi Joel Lachance Brad Sybouts Kitty Tam Eugene Wong If you have any questions regarding the authorization, please don’t hesitate to contact me. Sincerely, Stephen M. Stegner E &D Compliance Manager, EMC and Safety Microsoft Corporation TEL: (425) 706-2697 FAX: (425) 936-7329 E-mail: [email protected]

Label

Report No.: RF990415C13 1 Report Format Version 3.0.1 FCC TEST REPORT REPORT NO. :RF990415C13 MODEL NO. :1453 RECEIVED :Apr. 15, 2010 TESTED :Apr. 19 ~ Apr. 20, 2010 ISSUED :Apr. 23, 2010 APPLICANT : Microsoft Corporation ADDRESS : One Microsoft Way, Redmond WA 98052-6399, U.S.A ISSUED BY : Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS : No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION : No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 35 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF990415C13 2 Report Format Version 3.0.1 Table of Contents 1. CERTIFICATION ..................................................................................................... 3 2. SUMMARY OF TEST RESULTS ............................................................................. 4 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 4 3. GENERAL INFORMATION...................................................................................... 5 3.1 GENERAL DESCRIPTION OF EUT........................................................................ 5 3.2 DESCRIPTION OF TEST MODES.......................................................................... 6 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ..................................................... 6 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .......................... 7 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ......................................... 9 3.4 DESCRIPTION OF SUPPORT UNITS .................................................................... 9 4. TEST TYPES AND RESULTS ............................................................................... 10 4.1 RADIATED EMISSION MEASUREMENT ............................................................. 10 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT........................................... 10 4.1.2 TEST INSTRUMENTS .......................................................................................... 11 4.1.3 TEST PROCEDURES ........................................................................................... 12 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 12 4.1.5 TEST SETUP ........................................................................................................ 13 4.1.6 EUT OPERATING CONDITIONS .......................................................................... 13 4.1.7 TEST RESULTS .................................................................................................... 14 4.2 BAND EDGES MEASUREMENT .......................................................................... 30 4.2.1 LIMITS OF BAND EDGES MEASUREMENT ....................................................... 30 4.2.2 TEST INSTRUMENTS .......................................................................................... 30 4.2.3 TEST PROCEDURE ............................................................................................. 30 4.2.4 DEVIATION FROM TEST STANDARD ................................................................. 30 4.2.5 EUT OPERATING CONDITION ............................................................................ 30 4.2.6 TEST RESULTS .................................................................................................... 30 5. PHOTOGRAPHS OF THE TEST CONFIGURATION............................................ 33 6. INFORMATION ON THE TESTING LABORATORIES .......................................... 34 7. APPENDIX A - MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB................................................................................... 35 Report No.: RF990415C13 3 Report Format Version 3.0.1 1. CERTIFICATION PRODUCT: Wireless Mouse MODEL: 1453 BRAND: Microsoft APPLICANT: Microsoft Corporation TESTED: Apr. 19 ~ Apr. 20, 2010 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.4-2003 The above equipment (model: 1453) have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE:Apr. 23, 2010 Pettie Chen / Specialist TECHNICAL ACCEPTANCE : , DATE:Apr. 23, 2010 Responsible for RF Long Chen / Senior Engineer APPROVED BY : , DATE:Apr. 23, 2010 Gary Chang / Assistant Manager Report No.: RF990415C13 4 Report Format Version 3.0.1 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD PARAGRAPH TEST TYPE RESULTREMARK 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 15.209 PASS Meet the requirement of limit. Minimum passing margin is -6.0dB at 2397.50 & 2485.50MHz. 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: MEASUREMENT FREQUENCY UNCERTAINTY 30MHz ~ 200MHz 3.34 dB 200MHz ~1000MHz 3.35 dB 1GHz ~ 18GHz 2.26 dB Radiated emissions 18GHz ~ 40GHz 1.94 dB This uncertainty represents an expanded uncertainty expressed at approxim…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
