2. English 10. Français 20. Español WindoWs 8 Pro and WindoWs rT TM WindoWs 8 Pro y WindoWs rT WindoWs 8 Pro e T WindoWs rT 2 3 • If a power cord or power supply becomes damaged in any way, stop using it immediately. • Unplug your device during lightning storms or when unused for long periods of time. • For devices with an AC power cord that connects to the power supply, always connect the power cord according to the following instructions: 1 Plug the AC power cord into the power supply until it seats fully. 2 Plug the other end of the AC power cord into the wall outlet. Warning: Battery safety This device contains a built-in battery, improper use of which may result in explosion. Do not heat, open, puncture, mutilate, or dispose of the product in fire. Do not leave the device in direct sunlight for an extended period of time, which could cause melting or battery damage. The battery in this device is not user replaceable and should only be replaced by Microsoft or a Microsoft Authorized Service Provider. See www.microsoft.com/surface/support for additional details. Warning: Use near Water To reduce the risk of fire or shock, do not use this device near water and do not expose it to rain or moisture. Do not attempt to dry device with a hair dryer or a microwave oven. Warning: Hearing safety Set the volume loud enough to hear clearly in quiet surroundings, and no louder. Do not increase the volume after you start listening. Your ears can adapt over time so that high volume sounds normal, but the high volume may still damage your hearing. • Do not increase the volume to block out outside noise. The combination of outside noise and sound from your headphones can damage your hearing. Sealed or noise-canceling headphones can reduce outside noise so that you don’t have to turn up the volume. If you can’t understand someone nearby speaking normally, turn down the volume. Sound that drowns out normal speech can damage your hearing. Even with sealed or noise- canceling headphones, you should be able to hear nearby people speak. Minimize your Time Listening to Loud sound The more time you spend exposed to loud sound, the more likely you are to damage your hearing. The louder the sound, the less time it takes to damage hearing. • Minimize your time listening to loud sound. At maximum volume, listening to music on he device with headphones can permanently damage your hearing in 15 minutes. • Even lower volumes can damage hearing if you are exposed for many hours. • All of the sound that you are exposed to during a day adds up. If you are exposed to other loud sound, it takes less time listening at high volumes to cause hearing damage. • To safely use the device with no time limit, keep the volume low enough that you can carry on a conversation with people nearby. Be aware of Hearing Loss symptoms Stop using this device and have your hearing checked if you experience: • Any hearing loss. • You hear ringing in your ears. • Your speech sounds muffled. • Sound seems dull or flat. It is a good idea to have your hearing checked regularly by an audiologist. For more information, see www.microsoft.com/surface/support Warning: Be aware of your surroundings In order to reduce the potential risk of injury due to distractions while using this device, be careful and attentive while driving, riding a bicycle, or walking. Use of the device alone or with headphones (even if used only in one ear) while driving a vehicle or riding a bicycle is not recommended and is illegal in some areas. Check and obey the laws and regulations on the use of mobile devices in the areas where you drive or ride. Using a mobile device while driving or riding may be distracting. Give full attention to driving or riding and to the road. Always keep the volume low enough to hear people talking and sounds that might indicate danger, like fire alarms. sUrface WindoWs 8 Pro and WindoWs rT cL eaning & Usage ins TrUcTions Always handle your device with care to maintain its appearance. To clean, wipe the outer surface with a soft, lint-free cloth. This symbol identifies safety and health messages in this Device Guide Warning: read safety & Health info Read this guide for important safety and health information and the terms of the Limited Warranty that apply to the Microsoft ® device that you have purchased. Keep all printed guides for future reference. Failure to follow instructions and properly set up, use, and care for this product can increase the risk of serious injury or death, or damage to the device or devices. For an online version of this guide go to: www.microsoft.com/surface/support Warning: do not attempt repairs Do not attempt to take apart, open, service, or modify the product, accessories, or power supply. Doing so could present the risk of electric shock or other hazard. Any evidence of any attempt to open and/or modify this device, including any peeling, puncturing, or removal of any of the labels, will void the Limited Warranty. Warning: ac adapter safety Failure to take the following precautions can result in serious injury or death from electric shock or fire or in damage to the device. To select an appropriate power source for your device: • Use only the power supply unit and AC power cord that came with your device or that you received from an authorized Microsoft retailer. • Do not use non-standard power sources, such as generators or inverters, even if the voltage and frequency appear acceptable. Only use AC power provided by a standard wall outlet. • Do not overload your wall outlet, extension cord, power strip, or other electrical receptacle. Confirm that they are rated to handle the total current (in amps [A]) drawn by the device (indicated on the power supply unit) and any other devices that are on the same circuit. • On devices where the AC prongs may be folded for storage, before plugging the AC adapter into a power outlet, make sure its prongs are fully extended. • On devices where the AC prongs are removable and w…

Text truncated - open the document above for the full version.

Microsoft Corporation is an equal opportunity employer. August 1, 2012 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Agency authorization letter for Microsoft employees To whom it may concern, We, the undersigned, Microsoft® Corporation hereby authorize the following, to act on our behalf, as our agent, in all matters relating to all processes required according to FCC Part 15C for Microsoft® Corporation products (Grantee Code:C3K): Michael Boucher Pam Galvan Albert Huang Bill Huang Joy Alegria Hasnain Syed Tim Calland Brad Sybouts Kitty Tam Eugene Wong Anindita Mitra If you have any questions regarding the authorization, please don’t hesitate to contact me. Sincerely, Stephen M. Stegner Compliance Engineer Microsoft Corporation

Microsoft Corporation is an equal opportunity employer. December 15, 2012 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia , Maryland 21046 Subject: Letter of Attestation regarding application for certification of FCC ID: C3K1514 TO WHOM IT MAY CONCERN: Per RSS 210 Annex 9 and FCC KDB 443999, this device will not transmit in the 5600-5650 MHz band. Per FCC KDB 848637, the client software and associated drivers will not initiate any transmission on DFS frequencies without initiation by a master. This includes restriction on transmissions for beacons and support for ad-hoc peer-to-peer modes. The device complies with the requirements for software configuration control as discussed in KDB # 594280. Sincerely, Michael C. Boucher Compliance Engineer Microsoft Corporation

Microsoft Corporation is an equal opportunity employer. December 15, 2012 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia , Maryland 21046 Subject: Short-term confidentiality request regarding application for certification of FCC ID: C3K1514 TO WHOM IT MAY CONCERN Pursuant to DA 04-1705 of the Commission’s public notice, we request short-term confidential treatment for the following information until May 1, 2013 in order to ensure sensitive business information remains confidential until the actual marketing of the device: • External Photos • Test Setup Photos • User’s Manual • Internal Photos Sincerely, Michael Boucher Compliance Engineer Microsoft Corporation

Microsoft Corporation is an equal opportunity employer. December 15, 2012 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia , Maryland 21046 Subject: Confidentiality request regarding application for certification of FCC ID: C3K1514 TO WHOM IT MAY CONCERN Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: • Block Diagram • Schematics • Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Michael C. Boucher Compliance Engineer Microsoft Corporation

Model 1514 External Photographs Page 1 Model 1514 External Photographs Front Antenna Locations Antenna Locations Model 1514 External Photographs Page 2 Back Top Model 1514 External Photographs Page 3 Left Bottom Right Model 1514 External Photographs Page 4 Front Right with Kickstand Back with Kickstand

Label Content for Model 1514 Label is located on lower back panel. Microsoft Corporation Model: 1514 FCC ID: C3K1514 IC: 3048A-1514

Model 1514 Internal Page 1 Model 1514 Internal Photographs Top, with display attached Top, with display removed Antenna Locations Antenna Locations Model 1514 Internal Page 2 Motherboard Component Side, with shields attached Motherboard Component Side, with shields removed DDR Memory USB 3.0 Antenna Locations Model 1514 Internal Page 3 Motherboard Processor Side, with shields attached Motherboard Processor Side, with shields removed WLAN/Bluetooth IC SSD Model 1514 Internal Page 4 Bucket and Battery assembly Motherboard mounted in bucket with no bezel or collar Model 1514 Internal Page 5 Assembly components Fully unassembled parts Speakers AC Adapter Keyboard Connector Haptic Feedback Audio Jack/Vol+/Vol- Microphone Cameras (front and back)

Microsoft Corporation 1514 SAR Evaluation Report #: MCSO1635 Evaluated to the following SAR Specifications: FCC 2.1093:2012 Health Safety Code 6:2009 Report Prepared By Northwest EMC Inc. NORTHWEST EMC – (888) 364-2378 – www.nwemc.com California – Minnesota – Oregon – New York – Washington WTD 12.5.23 CERTIFICATE OF EVALUATION Last Date of Test: December 11, 2012 Microsoft Corporation Model:1514 Applicable Standard Test Description Specification Test Method Pass/Fail FCC OET 65C:2001 IEEE Std 1528:2003 FCC KDB 447498 D01 v04 FCC KDB 248227 D01 v01r02 FCC 2.1093:2012 FCC 15.247:2012 FCC 15.407:2012 FCC KDB 616217 D03 v01 Pass FCC KDB 865664 SAR Evaluation Health Safety Code 6:2009 RSS-102, Issue 4:2010 Pass Highest SAR Values Frequency Bands (GHz) Head 1g (W/kg) Body 1g (W/kg) Limit 1g (W/kg) Exposure Environment 2.4 N/A 0.328 5.2, 5.3, 5.6, 5.8 N/A 1.49 1.6 General Population Uncontrolled Deviations From Test Standards None Approved By: Don Facteau, IS Manager NVLAP Lab Code: 200630-0 Test Facility The measurement facility used to collect the data is located at: Northwest EMC, Inc. 22975 NW Evergreen Parkway, Suite 400 Hillsboro, OR 97124 Phone: (503) 844-4066 Fax: 844-3826 This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. Product compliance is the responsibility of the client, therefore the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. This Report may only be duplicated in its entirety. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. REV 2012.08.02 REVISION HISTORY Revision Number Description Date Page Number 00 None Barometric Pressure The recorded barometric pressure has been normalized to sea level. REV 2012.05.24 ACCREDITATIONS AND AUTHORIZATIONS United States FCC - Designated by the FCC as a Telecommunications Certification Body (TCB). Certification chambers, Open Area Test Sites, and conducted measurement facilities are listed with the FCC. A2LA - Accredited by A2LA to ISO / IEC Guide 65 as a product certifier. This allows Northwest EMC to certify transmitters to FCC and IC specifications. NVLAP - Each laboratory is accredited by NVLAP to ISO 17025 Canada IC - Recognized by Industry Canada as a Certification Body (CB). Certification chambers and Open Area Test Sites are filed with IC. European Union European Commission – Validated by the European Commission as a Conformity Assessment Body (CAB) under the EMC directive and as a Notified Body under the R&TTE Directive. Australia/New Zealand ACMA - Recognized by ACMA as a CAB for the acceptance of test data. Korea KCC / RRA - Recognized by KCC’s RRA as a CAB for the acceptance of test data. Japan VCCI - Associate Member of the VCCI. Conducted and radiated measurement facilities are registered. Taiwan BSMI – Recognized by BSMI as a CAB for the acceptance of test data. NCC - Recognized by NCC as a CAB for the acceptance of test data. Singapore IDA – Recognized by IDA as a CAB for the acceptance of test data. Hong Kong OFTA – Recognized by OFTA as a CAB for the acceptance of test data. Vietnam MIC – Recognized by MIC as a CAB for the acceptance of test data. Russia GOST – Accredited by Certinform VNIINMASH, CERTINFO, SAMTES, and Federal CHEC to perform EMC and Hygienic testing for Information Technology products to GOST standards. SCOPE For details on the Scopes of our Accreditations, please visit: http://www.nwemc.com/accreditations/ REV 2012.08.03 LOCATIONS Oregon Labs EV01-EV12 22975 NW Evergreen Pkwy, #400 Hillsboro, OR 97124 (503) 844-4066 California Labs OC01-OC13 41 Tesla Irvine, CA 92618 (949) 861-8918 New York Labs WA01-WA04 4939 Jordan Rd. Elbridge, NY 13060 (315) 685-0796 Minnesota Labs MN01-MN08 9349 W Broadway Ave. Brooklyn Park, MN 55445 (763) 425-2281 Washington Labs SU01-SU07 14128 339 th Ave. SE Sultan, WA 98294 (360) 793-8675 VCCI A-0108 A-0029 A-0109 A-0110 Industry Canada 2834D-1, 2834D-2 2834B-1, 2834B-2, 2834B-3 2834E-1 2834C-1 WTD 12.5.23 PRODUCT DESCRIPTION Client and Equipment Under Test (EUT) Information Company Name: Microsoft Corporation Address: One Microsoft Way City, State, Zip: Redmond, WA 98052-6399 Test Requested By: Mike Boucher Model: 1514 First Date of Test: October 29, 2012 Last Date of Test: December 11, 2012 Receipt Date of Samples: October 29, 2012 Equipment Design Stage: Production Equipment Condition: No Damage Information Provided by the Party Requesting the Test Functional Description of the EUT (Equipment Under Test): The EUT is the Model 1514 tablet computer containing a combination WLAN - Bluetooth radio module. The tablet contains two dual band (2.4 and 5 GHz) antennas. One antenna (MAIN) is used for both WLAN and Bluetooth, while the other (MIMO) antenna is used only for WLAN operation for MCS08 thru MCS15 data rates. The peak gain in the 2.4 GHz band is 3.9 dBi and the peak gain in the 5 GHz band is 6.0 dBi.. The WLAN and Bluetooth radios can transmit simultaneously. The WLAN radio is an 802.11a/b/g/n radio module with 2x2 MIMO and both 20 MHz and 40 MHz channel bandwidths. The two WLAN antennas transmit simultaneously only in “n” (MIMO) modes. The frequency bands of the 802.11 a/b/g/n radio: • 2400 – 2483.5 MHz • 5150 – 5350 MHz • 5470 – 5600 MHz • 5650 – 5725 MHz • 5725 – 5850 MHz The Bluetooth radio is capable of both basic and extended data rates as well as low energy operation. It operates in the 2400 – 2483.5 MHz frequency band. The closest spacing between the WLAN antennas is 9.77 cm. The antennas are near the top edge of the tablet. The closest spacing of the antennas to the user is 2.2 mm. The diagonal screen size is greater than 20cm (7.9) inches therefore KDB 941225 is not applicable; instead, KDB 616217 is applicable. In normal operation, the Mod…
