C3K1698Wireless Input Device

Quick Start Guide (QSG) The quick start guide explains accessory setup and features using illustrations only (no text). Only initial setup and basic features are covered by this guide. Additional detail and troubleshooting steps are available to the user through at URL included in this guide. www.xbox.com/xboxone/gettingstarted

1 XBOX ONE ACCESSORY IMPORTANT INFORMATION This symbol identifi es safety and health messages in this product guide and other product manuals. Read this guide for important safety and health information for the product that you have purchased. WARNING: Failure to properly set up, use, and care for this product can increase the risk of serious injury, death, property damage, or damage to the product or related accessories. Read this guide and keep all printed guides for future reference. For replacement guides, go to xbox.com/xboxone/useinstructions. WARNING: Do Not Attempt Repairs Do not attempt to take apart, open, service, or modify the product, accessories, or power supply. Doing so could present the risk of electric shock, fi re or other hazard, or damage to your Xbox One accessory. Any evidence of any attempt to open and/or modify this device, including any peeling, puncturing, or removal of any of the labels, will void the Limited Warranty and render the Xbox One accessory ineligible for authorized repair. Modifying your accessory can result in a permanent ban from Xbox Live. USING YOUR ACCESSORY Make Sure Children Play Safely Make sure children using any Xbox One accessory together with the Xbox One console play safely and within their limits, and make sure that they understand proper use of the system. Refer to the Xbox One console guide for more information. WARNING: Choking hazard This device may contain small parts that may be a choking hazard to children under 3. Keep small parts away from children. CAUTION: Cables Arrange any cables and cords so that people and pets are unlikely to trip over or accidentally pull on them as they move around or walk through the area. Do not allow children to play with cables and cords. CAUTION: Hearing Safety Extended exposure to high sound volumes when using a headset may result in temporary or permanent hearing loss. To reduce the risk of hearing loss, set the volume loud enough to hear clearly in quiet surroundings, and no louder. • Do not increase the volume after you start listening. Your ears can adapt over time so that high volume sounds normal, but the high volume may still damage your hearing. • Do not increase the volume to block out outside noise. The combination of outside noise and sound from your headphones can damage your hearing. Sealed or noise- canceling headphones can reduce outside noise so that you don’t have to turn up the volume. • If you can’t understand someone nearby speaking normally, turn down the volume. Sound that drowns out normal speech can damage your hearing. Even with sealed or noise canceling headphones, you should be able to hear nearby people speak. Minimize your time listening to loud sound The more time that you spend exposed to high sound volumes, the more likely you are to damage your hearing. The louder the sound, the less time that is required to damage hearing. • Minimize your time listening to loud sound. At maximum volume, listening to music on the device with headphones can permanently damage your hearing in 15 minutes. X18-91804-01 X189180401MNL.indd 15/30/13 3:02 PM 2 • Even lower volumes can damage hearing if you are exposed to it for many hours. • All of the sound that you are exposed to during a day adds up. If you are exposed to other loud sound, it takes less time listening at high volumes to cause hearing damage. • To safely use the device without a time limit, keep the volume low enough that you can carry on a conversation with people nearby. ELECTRICAL SAFETY WARNING: As with many other electrical devices, failure to take the following precautions can result in serious injury or death from electric shock, fire, or damage to Xbox One accessories and console. • Use only an approved charging cable. • Do not allow a wireless device or charging cable to become wet. • Unplug the charging cable during lightning storms or when unused for long periods. • To prevent damage, avoid sitting or stepping on a wireless device, its cable, or the cable plug or connector. Go to xbox.com/xboxone/electricalsafety for more information. BATTERY POWERED DEVICES WARNING: Battery Safety The following precautions apply to all products that use disposable or rechargeable batteries including lithium polymer. Improper battery use may result in series injury, death, property damage, or damage to the product or related accessories as a result of battery fluid leakage, fire, overheating, or explosion. Released battery fluid is corrosive and may be toxic. It can cause skin and eye burns, and is harmful if swallowed. To reduce the risk of injury: • Keep batteries out of reach of children. • Remove the batteries if they are worn out or before storing your device for an extended period. Always remove old, weak, or worn-out batteries immediately and recycle or dispose of them in accordance with local and national disposal regulations. • If a battery leaks, remove all batteries by reversing the installation steps provided for this product, being careful to keep the leaked fluid from touching your skin or clothes. If fluid from the battery contacts skin or clothes, flush skin with water immediately. Before inserting new batteries, thoroughly clean the battery compartment with a dry cloth, or follow the battery manufacturer’s recommendations for cleanup. • Do not open, puncture, mutilate, heat, apply direct heat to, or dispose of batteries in fire. • Do not mix new and old batteries or batteries of different types (for example, carbon-zinc and alkaline batteries). • Do not allow metal objects to touch the battery terminals on the device; they can become hot and cause burns. • Do not carry or place batteries together with necklaces, hairpins or other metal objects. • Do not leave a battery-powered device in direct sunlight for an extended period, such as on the dash of car during the summer. • Do not immerse batteries in water or allow them to become wet. • Do not connect batteries directly to wall outlets or car cigarette-ligh…
