Microsoft Corporation is an equal opportunity employer August 10, 2015 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Cover Letter for FCC application for Certification of FCC ID: C3K1721 TO WHOM IT MAY CONCERN This Model 1721 is radio device operating in the 2400-2483.5 MHz ISM band and designed to operate in the Bluetooth and BTLE mode. It also contains a GPS receiver. It charges and downloads data via the USB charging cable. This is to seek an original certification on this Model 1721, as compliant with FCC 15.247 and 15.207. Sincerely, Kitty Tam Compliance Engineer, Microsoft Corporation.

Microsoft Corporation is an equal opportunity employer Subject: Authorized signatories May 18, 2015 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 A G E N C Y A U T H O R I Z A T I O N L E T T E R F O R M I C R O S O F T E M P L O Y E E S To whom it may concern, We, the undersigned, Microsoft® Corporation hereby authorize the following, to act on our behalf, as our agent, in all matters relating to all processes required according to FCC Part 15 for Microsoft® Corporation products (Grantee Code:C3K): Hasnain Syed Kitty Tam Anindita Mitra David Johnson Michael Boucher Pamela Galvan Sajay Jose Jennifer Liu Joseph Dizon Elaine Reeves Jojo Malliyakal Wei Sun Zachary Gray Daniel Salinas Shoaib Khan Johnny Deng Robert Towne Chip Schulman Andy Jia Lang Shen Eugene Wong Bill Huang Albert Huang Tim Calland Joy Alegria Ellis Lee Angus McGill If you have any questions regarding the authorization, please don’t hesitate to contact me. Sincerely, Stephen M. Stegner Compliance Engineer Microsoft Corporation

Microsoft Corporation is an equal opportunity employer August 10, 2015 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Subject: Short-term confidentiality request regarding application for Certification of FCC ID: C3K1721 TO WHOM IT MAY CONCERN Pursuant to CFR 47, Sections 0.457 and 0.459, we request short-term confidential treatment for the following information until Feb 10, 2016 in order to ensure sensitive business information remains confidential until the actual marketing of the device: • External Photos • Test Setup Photos • User’s Manual • Internal Photos Sincerely, Kitty Tam, Compliance Engineer Microsoft Corporation.

Microsoft Corporation is an equal opportunity employer August 10, 2015 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Subject: Confidentiality request regarding application for certification of FCC ID: C3K1721 TO WHOM IT MAY CONCERN Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below:  Block Diagram  Schematics  Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Kitty Tam Compliance Engineer, Microsoft Corporation.

Model 1721 FCC ID: C3K1721 IC: 3048A-1721 External Pictures Large Size Medium Size Small Size Additional pictures – clasp open

Microsoft Corporation is an equal opportunity employer. August 10, 2015 Subject: E-Label implementation on Model 1721 FCC ID: C3K1721 To Whom It May Concern: The E-label implemented on the device is secured and protected from modification by third-parties. The E-label is loaded on the device at the factory after which device is then locked through a One Time Programmable (OTP) setting which disables the ability to change the E-Label. After being locked the device will ignore all attempts to modify the E-Label. In addition the E-Label is not modifiable through a firmware update. Best Regards, Kitty Tam, Compliance Engineer Microsoft Corp.

Model: 1721 Label & Location Proposed E-Label Design Label Location Users can access the above E-label without special access code or permission. The E-label is accessible on the device’s display. Here are the steps after device powers up to main menu: 1. Go to setting Tile 2. Then Information Tile The following will be displayed on device’s screen. Device Name Serial Number

Model 1721 FCC ID: C3K1721 IC: 3048A-1721 Internal Pictures Display Board Folded with display Board unfolded from display, showing back of Flex Board Main Board – Front and Back Battery, Motor and Sensors Bluetooth antenna and Flex cable Flex cable molded in plastic and standalone for picture GPS antenna and Flex cable Flex cable molded in plastic and standalone for picture

This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. This Report may only be duplicated in its entirety Microsoft Corporation 1721 FCC 2.1093:2015 Report # MCSO1732 NVLAP Lab Code: 200629-0 CERTIFICATE OF EVALUATION 2014-12-10 Product compliance is the responsibility of the client; therefore, the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. This report reflects only those tests from the referenced standards shown in the certificate of test. It does not include inspection or verification of labels, identification, marking or user information. Last Date of Evaluation: July 27, 2015 Microsoft Corporation Model: 1721 Radio Equipment Evaluation Standards Specification Method FCC 2.1093:2015 FCC KDB 447498 D01 v05r02 Results Method Clause Evaluation Description Applied Results Comments 4.3.1 Standalone SAR Test Exclusion Yes Pass Deviations From Standards Approved By: Don Facteau, IT Manager Report No. MCSO17322/7 REVISION HISTORY REV 2014.10.14 Revision Number Description Date Page Number 00 None Report No. MCSO17323/7 ACCREDITATIONS AND AUTHORIZATIONS REV 2015.2.19 United States FCC - Designated by the FCC as a Telecommunications Certification Body (TCB). Certification chambers, Open Area Test Sites, and conducted measurement facilities are listed with the FCC. A2LA - Accredited by A2LA to ISO / IEC 17065 as a product certifier. This allows Northwest EMC to certify transmitters to FCC and IC specifications. NVLAP - Each laboratory is accredited by NVLAP to ISO 17025 Canada IC - Recognized by Industry Canada as a Certification Body (CB). Certification chambers and Open Area Test Sites are filed with IC. European Union European Commission – Validated by the European Commission as a Conformity Assessment Body (CAB) under the EMC directive and as a Notified Body under the R&TTE Directive. Australia/New Zealand ACMA - Recognized by ACMA as a CAB for the acceptance of test data. Korea MSIP / RRA - Recognized by KCC’s RRA as a CAB for the acceptance of test data. Japan VCCI - Associate Member of the VCCI. Conducted and radiated measurement facilities are registered. Taiwan BSMI – Recognized by BSMI as a CAB for the acceptance of test data. NCC - Recognized by NCC as a CAB for the acceptance of test data. Singapore IDA – Recognized by IDA as a CAB for the acceptance of test data. Israel MOC – Recognized by MOC as a CAB for the acceptance of test data. Hong Kong OFCA – Recognized by OFCA as a CAB for the acceptance of test data. Vietnam MIC – Recognized by MIC as a CAB for the acceptance of test data. SCOPE For details on the Scopes of our Accreditations, please visit: http://www.nwemc.com/accreditations/ http://gsi.nist.gov/global/docs/cabs/designations.html Report No. MCSO17324/7 FACILITIES REV 2015.2.19 California Labs OC01-13 41 Tesla Irvine, CA 92618 (949) 861-8918 Minnesota Labs MN01-08, MN10 9349 W Broadway Ave. Brooklyn Park, MN 55445 (612)-638-5136 New York Labs NY01-04 4939 Jordan Rd. Elbridge, NY 13060 (315) 554-8214 Oregon Labs EV01-12 22975 NW Evergreen Pkwy Hillsboro, OR 97124 (503) 844-4066 Texas Labs TX01-09 3801 E Plano Pkwy Plano, TX 75074 (469) 304-5255 Washington Labs NC01-05 19201 120 th Ave NE Bothell, WA 9801 (425)984-6600 NVLAP NVLAP Lab Code: 200676-0 NVLAP Lab Code: 200881-0 NVLAP Lab Code: 200761-0 NVLAP Lab Code: 200630-0 NVLAP Lab Code:201049-0 NVLAP Lab Code: 200629-0 Industry Canada 2834B-1, 2834B-3 2834E-1 N/A 2834D-1, 2834D-2 2834G-1 2834F-1 BSMI SL2-IN-E-1154R SL2-IN-E-1152R N/A SL2-IN-E-1017 SL2-IN-E-1158R SL2-IN-E-1153R VCCI A-0029 A-0109 N/A A-0108 A-0201 A-0110 Recognized Phase I CAB for ACMA, BSMI, IDA, KCC/RRA, MIC, MOC, NCC, OFCA US0158 US0175 N/A US0017 US0191 US0157 Report No. MCSO17325/7 PRODUCT DESCRIPTION 2014-12-10 Client and Equipment Under Evaluation (EUT) Information Company Name: Microsoft Corporation Address: One Microsoft Way City, State, Zip: Redmond, WA 98052 Evaluation Requested By: Kitty Tam Model: Model 1721 Evaluation Date: July 27, 2015 Information Provided by the Party Requesting the Evaluation Functional Description of the EUT: Bluetooth Radio Device Evaluation Objective: To demonstrate compliance with FCC RF Exposure requirements for 2.1093 portable devices Report No. MCSO17326/7 SAR TEST EXCLUSION WTD.2014.12.17 OVERVIEW The device is excluded from SAR evaluation and therefore deemed compliant with FCC RF exposure requirements as described below: COMPLIANCE WITH FCC KDB 447498 D01 General RF Exposure Guidance v05r02 KDB 447498 D01 General RF Exposure Guidance v05r02, Section 4.3.1 “The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison  3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion.” METHOD OF EVALUATION The SAR Test Exclusion Threshold is summarized in the following table: The device has a maximum output power of 2.185 mW at 2480 MHz. The closest spacing of the antenna to the user’s torso is 5 mm. The table below shows the re…

Text truncated - open the document above for the full version.

This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. This Report may only be duplicated in its entirety Microsoft Corporation 1721 FCC 15.207:2015 FCC 15.247:2015 Report # MCSO1732.1 NVLAP Lab Code: 200629-0 CERTIFICATE OF TEST 2014-12-10 Product compliance is the responsibility of the client; therefore, the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. This report reflects only those tests from the referenced standards shown in the certificate of test. It does not include inspection or verification of labels, identification, marking or user information. Last Date of Test: July 09, 2015 Microsoft Corporation Model: 1721 Radio Equipment Testing Standards Specification Method FCC 15.207:2015 ANSI C63.10:2009 FCC 15.247:2015 ANSI C63.10:2009 Results Method Clause Test Description Applied Results Comments 6.2 Powerline Conducted Emissions Yes Pass 6.5, 6.6 Spurious Radiated Emissions Yes Pass 6.7 Spurious Conducted Emissions Yes Pass 6.9.1 Occupied Bandwidth Yes Pass 6.10.1 Output Power Yes Pass 7.5 Duty Cycle Yes N/A 7.7.2 Carrier Frequency Separation Yes Pass 7.7.3 Number of Hopping Frequencies Yes Pass 7.7.4 Dwell Time Yes Pass 7.7.9 Band Edge Compliance Yes Pass 7.7.9 Band Edge Compliance - Hopping Mode Yes Pass Deviations From Test Standards None Approved By: Rod Munro, Operations Manager Report No. MCSO1732.12/96 REVISION HISTORY REV 2014.10.14 Revision Number Description Date Page Number 00 None Report No. MCSO1732.13/96 ACCREDITATIONS AND AUTHORIZATIONS REV 2015.2.19 United States FCC - Designated by the FCC as a Telecommunications Certification Body (TCB). Certification chambers, Open Area Test Sites, and conducted measurement facilities are listed with the FCC. A2LA - Accredited by A2LA to ISO / IEC 17065 as a product certifier. This allows Northwest EMC to certify transmitters to FCC and IC specifications. NVLAP - Each laboratory is accredited by NVLAP to ISO 17025 Canada IC - Recognized by Industry Canada as a Certification Body (CB). Certification chambers and Open Area Test Sites are filed with IC. European Union European Commission – Validated by the European Commission as a Conformity Assessment Body (CAB) under the EMC directive and as a Notified Body under the R&TTE Directive. Australia/New Zealand ACMA - Recognized by ACMA as a CAB for the acceptance of test data. Korea MSIP / RRA - Recognized by KCC’s RRA as a CAB for the acceptance of test data. Japan VCCI - Associate Member of the VCCI. Conducted and radiated measurement facilities are registered. Taiwan BSMI – Recognized by BSMI as a CAB for the acceptance of test data. NCC - Recognized by NCC as a CAB for the acceptance of test data. Singapore IDA – Recognized by IDA as a CAB for the acceptance of test data. Israel MOC – Recognized by MOC as a CAB for the acceptance of test data. Hong Kong OFCA – Recognized by OFCA as a CAB for the acceptance of test data. Vietnam MIC – Recognized by MIC as a CAB for the acceptance of test data. SCOPE For details on the Scopes of our Accreditations, please visit: http://www.nwemc.com/accreditations/ http://gsi.nist.gov/global/docs/cabs/designations.html Report No. MCSO1732.14/96 MEASUREMENT UNCERTAINTY TMU.2015.07.10 Measurement Uncertainty When a measurement is made, the result will be different from the true or theoretically correct value. The difference is the result of tolerances in the measurement system that cannot be completely eliminated. To the extent that technology allows us, it has been our aim to minimize this error. Measurement uncertainty is a statistical expression of measurement error qualified by a probability distribution. A measurement uncertainty estimation has been performed for each test per our internal quality document WP 342. The estimation is used to compare the measured result with its "true" or theoretically correct value. The expanded measurement uncertainty (K=2) for each test is on each data sheet. Our measurement data meets or exceeds the measurement uncertainty requirements of the applicable specification; therefore, the test data can be compared directly to the specification limit to determine compliance. The calculations for estimating measurement uncertainty are based upon ETSI TR 100 028 (or CISPR 16-4-2 as applicable), and are available upon request. The following table represents the Measurement Uncertainty (MU) budgets for each of the tests that may be contained in this report. Test + MU - MU Frequency Accuracy (Hz) 0.0007% -0.0007% Amplitude Accuracy (dB) 1.2 dB -1.2 dB Conducted Power (dB) 0.3 dB -0.3 dB Radiated Power via Substitution (dB) 0.7 dB -0.7 dB Temperature (degrees C) 0.7°C -0.7°C Humidity (% RH) 2.5% RH -2.5% RH Voltage (AC) 1.0% -1.0% Voltage (DC) 0.7% -0.7% Field Strength (dB) 5.0 dB -5.0 dB AC Powerline Conducted Emissions (dB) 2.4 dB -2.4 dB Report No. MCSO1732.15/96 FACILITIES REV 2015.2.19 California Labs OC01-13 41 Tesla Irvine, CA 92618 (949) 861-8918 Minnesota Labs MN01-08, MN10 9349 W Broadway Ave. Brooklyn Park, MN 55445 (612)-638-5136 New York Labs NY01-04 4939 Jordan Rd. Elbridge, NY 13060 (315) 554-8214 Oregon Labs EV01-12 22975 NW Evergreen Pkwy Hillsboro, OR 97124 (503) 844-4066 Texas Labs TX01-09 3801 E Plano Pkwy Plano, TX 75074 (469) 304-5255 Washington Labs NC01-05 19201 120 th Ave NE Bothell, WA 9801 (425)984-6600 NVLAP NVLAP Lab Code: 200676-0 NVLAP Lab Code: 200881-0 NVLAP Lab Code: 200761-0 NVLAP Lab Code: 200630-0 NVLAP Lab Code:201049-0 NVLAP Lab Code: 200629-0 Industry Canada 2834B-1, 2834B-3 2834E-1 N/A 2834D-1, 2834D-2 2834G-1 2834F-1 BSMI SL2-IN-E-1154R SL2-IN-E-1152R N/A SL2-IN-E-1017 SL2-IN-E-1158R SL2-IN-E-1153R VCCI A-0029 A…

Text truncated - open the document above for the full version.

This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government of the United States of America. This Report may only be duplicated in its entirety Microsoft Corporation 1721 FCC 15.207:2015 FCC 15.247:2015 Report # MCSO1732.2 NVLAP Lab Code: 200629-0 CERTIFICATE OF TEST 2014-12-10 Product compliance is the responsibility of the client; therefore, the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. This report reflects only those tests from the referenced standards shown in the certificate of test. It does not include inspection or verification of labels, identification, marking or user information. Last Date of Test: July 09, 2015 Microsoft Corporation Model: 1721 Radio Equipment Testing Standards Specification Method FCC 15.207:2015 ANSI C63.10:2009 FCC 15.247:2015 ANSI C63.10:2009 Results Method Clause Test Description Applied Results Comments 6.2 Powerline Conducted Emissions Yes Pass 6.5, 6.6 Spurious Radiated Emissions Yes Pass 6.7 Band Edge Compliance Yes Pass 6.7 Spurious Conducted Emissions Yes Pass 6.9.1 Occupied Bandwidth Yes Pass 6.10.2 Output Power Yes Pass 6.11.2 Power Spectral Density Yes Pass 7.5 Duty Cycle Yes N/A Deviations From Test Standards None Approved By: Rod Munro, Operations Manager Report No. MCSO1732.22/58 REVISION HISTORY REV 2014.10.14 Revision Number Description Date Page Number 00 None Report No. MCSO1732.23/58 ACCREDITATIONS AND AUTHORIZATIONS REV 2015.2.19 United States FCC - Designated by the FCC as a Telecommunications Certification Body (TCB). Certification chambers, Open Area Test Sites, and conducted measurement facilities are listed with the FCC. A2LA - Accredited by A2LA to ISO / IEC 17065 as a product certifier. This allows Northwest EMC to certify transmitters to FCC and IC specifications. NVLAP - Each laboratory is accredited by NVLAP to ISO 17025 Canada IC - Recognized by Industry Canada as a Certification Body (CB). Certification chambers and Open Area Test Sites are filed with IC. European Union European Commission – Validated by the European Commission as a Conformity Assessment Body (CAB) under the EMC directive and as a Notified Body under the R&TTE Directive. Australia/New Zealand ACMA - Recognized by ACMA as a CAB for the acceptance of test data. Korea MSIP / RRA - Recognized by KCC’s RRA as a CAB for the acceptance of test data. Japan VCCI - Associate Member of the VCCI. Conducted and radiated measurement facilities are registered. Taiwan BSMI – Recognized by BSMI as a CAB for the acceptance of test data. NCC - Recognized by NCC as a CAB for the acceptance of test data. Singapore IDA – Recognized by IDA as a CAB for the acceptance of test data. Israel MOC – Recognized by MOC as a CAB for the acceptance of test data. Hong Kong OFCA – Recognized by OFCA as a CAB for the acceptance of test data. Vietnam MIC – Recognized by MIC as a CAB for the acceptance of test data. SCOPE For details on the Scopes of our Accreditations, please visit: http://www.nwemc.com/accreditations/ http://gsi.nist.gov/global/docs/cabs/designations.html Report No. MCSO1732.24/58 MEASUREMENT UNCERTAINTY TMU.2015.07.10 Measurement Uncertainty When a measurement is made, the result will be different from the true or theoretically correct value. The difference is the result of tolerances in the measurement system that cannot be completely eliminated. To the extent that technology allows us, it has been our aim to minimize this error. Measurement uncertainty is a statistical expression of measurement error qualified by a probability distribution. A measurement uncertainty estimation has been performed for each test per our internal quality document WP 342. The estimation is used to compare the measured result with its "true" or theoretically correct value. The expanded measurement uncertainty (K=2) for each test is on each data sheet. Our measurement data meets or exceeds the measurement uncertainty requirements of the applicable specification; therefore, the test data can be compared directly to the specification limit to determine compliance. The calculations for estimating measurement uncertainty are based upon ETSI TR 100 028 (or CISPR 16-4-2 as applicable), and are available upon request. The following table represents the Measurement Uncertainty (MU) budgets for each of the tests that may be contained in this report. Test + MU - MU Frequency Accuracy (Hz) 0.0007% -0.0007% Amplitude Accuracy (dB) 1.2 dB -1.2 dB Conducted Power (dB) 0.3 dB -0.3 dB Radiated Power via Substitution (dB) 0.7 dB -0.7 dB Temperature (degrees C) 0.7°C -0.7°C Humidity (% RH) 2.5% RH -2.5% RH Voltage (AC) 1.0% -1.0% Voltage (DC) 0.7% -0.7% Field Strength (dB) 5.0 dB -5.0 dB AC Powerline Conducted Emissions (dB) 2.4 dB -2.4 dB Report No. MCSO1732.25/58 FACILITIES REV 2015.2.19 California Labs OC01-13 41 Tesla Irvine, CA 92618 (949) 861-8918 Minnesota Labs MN01-08, MN10 9349 W Broadway Ave. Brooklyn Park, MN 55445 (612)-638-5136 New York Labs NY01-04 4939 Jordan Rd. Elbridge, NY 13060 (315) 554-8214 Oregon Labs EV01-12 22975 NW Evergreen Pkwy Hillsboro, OR 97124 (503) 844-4066 Texas Labs TX01-09 3801 E Plano Pkwy Plano, TX 75074 (469) 304-5255 Washington Labs NC01-05 19201 120 th Ave NE Bothell, WA 9801 (425)984-6600 NVLAP NVLAP Lab Code: 200676-0 NVLAP Lab Code: 200881-0 NVLAP Lab Code: 200761-0 NVLAP Lab Code: 200630-0 NVLAP Lab Code:201049-0 NVLAP Lab Code: 200629-0 Industry Canada 2834B-1, 2834B-3 2834E-1 N/A 2834D-1, 2834D-2 2834G-1 2834F-1 BSMI SL2-IN-E-1154R SL2-IN-E-1152R N/A SL2-IN-E-1017 SL2-IN-E-1158R SL2-IN-E-1153R VCCI A-0029 A-0109 N/A A-0108 A-0201 A-0110 Recognized Phase I CAB for ACMA, BSMI, IDA, KCC/RRA, MIC, MOC, NCC, OFCA US0158 US0175 N/A US0017 …

Text truncated - open the document above for the full version.

POWERLINE CONDUCTED EMISSIONS WTD.2015.05.26 PSA-ESCI 2015.03.03, EmiR5 2015.05.29 photo SRE - FCC (1).JPG SRE - FCC (2).JPG SPURIOUS RADIATED EMISSIONS PSA-ESCI 2015.03.03 Report No. MCSO1732.2 Photos Only2/9 photo SRE - FCC (3).JPG SRE - FCC (4).JPG SPURIOUS RADIATED EMISSIONS PSA-ESCI 2015.03.03 Report No. MCSO1732.2 Photos Only3/9 XMit 2015.01.14 Direct Connect - Benchtop (1).JPG Direct Connect - Benchtop (2).JPG BAND EDGE COMPLIANCE Report No. MCSO1732.2 Photos Only4/9 XMit 2015.01.14 Direct Connect - Benchtop (1).JPG Direct Connect - Benchtop (2).JPG SPURIOUS CONDUCTED EMISSIONS Report No. MCSO1732.2 Photos Only5/9 XMit 2015.01.14 Direct Connect - Benchtop (1).JPG Direct Connect - Benchtop (2).JPG OCCUPIED BANDWIDTH Report No. MCSO1732.2 Photos Only6/9 XMit 2015.01.14 Direct Connect - Benchtop (1).JPG Direct Connect - Benchtop (2).JPG OUTPUT POWER Report No. MCSO1732.2 Photos Only7/9 XMit 2015.01.14 Direct Connect - Benchtop (1).JPG Direct Connect - Benchtop (2).…
