C3K1754Wireless Input Device

Safety and Warranty Guide Guide de sécurité et de la garantie PMS 433 U PMS 433 U Micosoft HoloLens clicker This symbol identifes safety and health messages in this Device Guide WARNING: Read Safety & Health Info Read this guide for important safety and health information and the terms of the Limited Warranty that apply to the Microsoft ® device that you have purchased. Keep all printed guides for future reference. Failure to follow instructions and properly set up, use, and care for this product can increase the risk of serious injury or death, or damage to the device or devices. WARNING: Do Not Attempt Repairs Do not attempt to take apart, open, service, or modify the product, accessories, or battery. Doing so could present the risk of electric shock or other hazard. Any evidence of any attempt to open and/or modify this device, including any peeling, puncturing, or removal of any of the labels, will void the Limited Warranty. PMS 433 U CAUTION: Cable and cord safety Arrange all cables and cords so that people and pets are not likely to trip over or accidentally pull on them as they move around or walk through the area. Do not allow children to play with cables and cords. To avoid damaging the USB cable: • Protect the cable from being walked on. • Protect cable from being pinched or sharply bent, particularly where they connect to the devices. • Do not jerk, knot, sharply bend, or otherwise abuse the cable. • Do not expose the cable to sources of heat. • Keep children and pets away from the cable. Do not allow them to bite or chew on them. • When disconnecting the cable, pull on the plug— do not pull on the cord. • If a cable becomes damaged in any way, stop using it immediately. • Unplug your device during lightning storms or when unused for long periods of time. PMS 433 U WARNING: Battery Safety • This device contains a built-in battery, improper use of which may result in explosion. • Do not heat, open, puncture, mutilate, or dispose of the product in fre. • Do not leave the device in direct sunlight for an extended period of time, which could cause melting or battery damage. • Do not leave this product in a vehicle, particularly on a car dash on a hot day. • Do not strike, throw, step on, or subject the product to severe physical shock. Do not wear the device while the battery is charging. The battery in this device is not user replaceable and should only be replaced by Microsoft or a Microsoft Authorized Service Provider. WARNING: Use Near Water This device is not waterproof. To reduce the risk of fre or shock do not expose it to excessive rain or moisture. Do not attempt to charge this device in rain or excessive moisture conditions. Do not attempt to dry device with a hair dryer or a microwave oven. PMS 433 U WARNING: Environmental Conditions In order to reduce the risk of fre or explosion, use of batteries and storage conditions for batteries should not exceed their temperature ratings as shown in the Regulatory Information section of this document. WARNING: Choking Hazard This device may contain small parts which may be a choking hazard to children under 3. Keep small parts away from children. WARNING: Follow Instructions to Avoid Interference Problems Turn off your mobile device in any location where posted notices instruct you to do so. In an aircraft, turn off your device whenever instructed to do so by airline staff, or prior to packing a wireless device in luggage. Please consult airline staff about using it in fight. Caution: Avoid skin irritation This device is made of materials commonly used in wearable consumer electronic devices. However, certain people may develop skin irritation due to allergies or sensitivities. PMS 433 U To reduce the risk of skin irritation: • Wipe your device dry with a cloth if it gets wet. • Clean the fnger strap with isopropyl alcohol if it becomes dirty. • Avoid using lotions or other products under the fnger strap. • Do not wear over injured skin. • Tighten the fnger strap until snug, but not uncomfortably tight. If your skin becomes irritated, stop using the device. If symptoms are severe or persist, consult your physician. See http://support.microsoft.com for more information. CARING FOR YOUR ACCESSORY • Do not use near any heat sources. • Only use attachments/accessories specifed by Microsoft. • Clean the body of the device with a damp cloth, spot clean warm water with mild soap/detergent. Towel/Air dry. PMS 433 U REGULATORY INFORMATION Disposal of Waste Batteries and Electrical & Electronic Equipment This symbol on the product or its batteries or its packaging means that this product and any batteries it contains must not be disposed of with your household waste. Instead, it is your responsibility to hand this over to an applicable collection point for the recycling of batteries and electrical and electronic equipment. This separate collection and recycling will help to conserve natural resources and prevent potential negative consequences for human health and the environment due to the possible presence of hazardous substances in batteries and electrical and electronic equipment, which could be caused by inappropriate disposal. For more information about where to drop off your batteries and electrical and electronic waste, please contact your local city/ municipality offce, your household waste disposal service, or the shop where you purchased this product. Contact [email protected] for additional information on WEEE and waste batteries. This product contains a Lithium- ion Battery. PMS 433 U This device is not intended for use in machinery, medical or industrial applications. Any changes or modifcations not expressly approved by Microsoft could void the user’s authority to operate this device. This product is for use with NRTL Listed (UL, CSA, ETL, etc.), and/or IEC/EN 60950-1 compliant (CE marked) Information Technology equipment. No serviceable parts included. This device is rated as a commercial product for operation at +32ºF (+0…

Text truncated - open the document above for the full version.

Date: January 5, 2016 Federal Communications Commission Equipment Authorization branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our representative, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Steve Stegner, Sr. Compliance Engineer Microsoft 1. This authorization letter will be sent along with your application when filing with UL Verification Services Inc. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database and Industry Canada contact information.

Page 1 of 2 Model 1754 External Pictures Figure 1. Top Figure 2. Back Page 2 of 2 Figure 3. Bottom Edge Figure 4. Side Edge

Model 1754 Label Content Regulatory and compliance markings will be woven into a label on the inside of the fabric loop as shown below:

Page 1 of 3 Model 1754 Internal Pictures Figure 1. Back side of PCB with BT antenna Figure 2. Back side of PCB with BT antenna and Battery removed Page 2 of 3 Figure 3. Battery Figure 4. Back side of PCB with BT antenna with battery removed Page 3 of 3 Figure 5. Top side of PCB with shied can Figure 6. Top side of PCB with shield can removed

Report V2.0 RF Exposure Evaluation Report For MODEL NO. 1754 FCC ID: C3K1754 IC ID: 3048A-1754 Test Report No. R-TR217-FCCIC-MPE-2 Issue Date: 14 January 2016 FCC CFR47 Part 2.1093 Industry Canada RSS-102: Issue 5 Prepared by Microsoft EMC Laboratory 17760 NE 67th Ct, Redmond WA, 98052, U.S.A. 425-421-9799 [email protected] TESTING CERT #3472.01 Report#: R-TR217-FCCIC-MPE-2 Issued: 01/14/2016 Page 2 of 9 Microsoft EMC Laboratory 1 Record of Revisions Revision Date Section Page(s)Summaryof Changes Author/Revised By: 1.0 12/28/2015 All All Version 1.0 Andy Shen 2.0 01/14/2016 4,5,6 6-8. Updated Antenna Gain details. Updated SAR exclusion calculation using max declared power. Andy Shen Report#: R-TR217-FCCIC-MPE-2 Issued: 01/14/2016 Page 3 of 9 Microsoft EMC Laboratory Table of Contents 1 Record of Revisions ............................................................................................................... 2 2 Deviations from Standards .................................................................................................... 5 3 Facilities and Accreditations .................................................................................................. 5 3.1 Test Facility .................................................................................................................... 5 3.2 Accreditations ................................................................................................................. 5 4 Product Description ............................................................................................................... 6 4.1 Test Configurations ........................................................................................................ 6 5 Peak Conducted Output Power Measurements .................................................................... 7 5.1 Test Method .................................................................................................................... 7 5.2 Test Equipment List ........................................................................................................ 7 5.3 Test Results .................................................................................................................... 7 6 SAR Test Exclusion ............................................................................................................... 8 6.1 FCC ................................................................................................................................ 8 SAR Test Exclusion Criteria .................................................................................... 8 FCC SAR Test Exclusion Evaluation ...................................................................... 8 6.2 IC .................................................................................................................................... 8 SAR Test Exclusion Criteria .................................................................................... 8 IC SAR Test Exclusion Evaluation .......................................................................... 8 Report#: R-TR217-FCCIC-MPE-2 Issued: 01/14/2016 Page 4 of 9 Microsoft EMC Laboratory Test Report Attestation Microsoft Corporation Model: 1754 FCC ID: C3K 1754 IC ID: 3048A-1754 Applicable Standards Specification Test Result RF Exposure requirements from: FCC CFR47 Part 2.1093 Industry Canada RSS-102 Issue 5 Complies Microsoft EMC Laboratory attests that the product model identified in this report has been tested to and meets the requirements identified in the above standards. The test results in this report solely pertains to the specific sample tested, under the conditions and operating modes as provided by the customer. This report shall not be used to claim product certification, approval, or endorsement by A2LA or any agency of any Government. Reproduction, duplication or publication of extracts from this test report requires prior written approval of Microsoft EMC Laboratory. This document replaces the previously issued test report #R-TR217-FCCIC-MPE-1 issued by Microsoft EMC Labs on 12/28/2015. Written By: Andy Shen Reviewed/ Issued By: Sajay Jose Radio Test Engineer EMC/RF Compliance Lab Manager Report#: R-TR217-FCCIC-MPE-2 Issued: 01/14/2016 Page 5 of 9 Microsoft EMC Laboratory 2 Deviations from Standards None. 3 Facilities and Accreditations 3.1 Test Facility All test facilities used to collect the test data are located at Microsoft EMC Laboratory, 17760 NE 67 th Ct, Redmond WA, 98052, USA 3.2 Accreditations The lab is established and follows procedures as outlined in IEC/ISO 17025 and A2LA accreditation requirements. A2LA Accredited Testing Certificate Number: 3472.01 Report#: R-TR217-FCCIC-MPE-2 Issued: 01/14/2016 Page 6 of 9 Microsoft EMC Laboratory 4 Product Description Company Name: Microsoft Corporation Address: One Microsoft Way City, State, Zip: Redmond, WA 98052-6399 Customer Contact: Jennifer Liu Functional Description of the EUT: Wireless Input Device Model: 1754 FCC ID: C3K1754 IC ID: 3048A-1754 Radio Description: BT LE (2402- 2480 MHz) Declared Output Power: -1dBm ±1dB Modulation: GFSK Antenna Type and Gain: Internal 3.68 dBi Gain EUT Classification: DTS Equipment Design State: EV2-Production equivalent Prototype FW0.99.14 Equipment Condition: Good Test Sample Details: SN: 0001274547523 – Conducted SN: 0000725547523 – Radiated RF Exposure Conditions: Extremity Exposure, Body Exposure 4.1 Test Configurations The EUT was preprogrammed to transmit continuously with a constant duty cycle on low, middle, and high channels. LEDs on the unit indicated the proper mode of operation. White LED blink once: Low Channel 2402 MHz White LED blink twice: Mid Channel 2440 MHz White LED blink three times: High channel 2480 MHz Yellow LED: Transmitter turn off Report#: R-TR217-FCCIC-MPE-2 Issued: 01/14/2016 Page 7 of 9 Microsoft EMC Laboratory 5 Peak Conducted Output Power Measurements 5.1 Test Method Antenna port conducted meas…

Text truncated - open the document above for the full version.

Rev 2.0 RADIO TEST REPORT For MODEL NO. 1754 FCC ID: C3K1754 IC ID: 3048A-1754 Test Report No. R-TR217-FCCIC-BTLE-2 Issue Date: 01/14/2016 FCC CFR47 Part 15 Subpart C Industry Canada RSS-247 Issue 1 Prepared by Microsoft EMC Laboratory 17760 NE 67th Ct, Redmond WA, 98052, U.S.A. 425-421-9799 [email protected] TESTING CERT #3472.01 Test Report#: R‐TR217‐FCCIC‐BTLE‐2 Issued: January 14, 2016 Page 2 of 49 Microsoft EMC Laboratory 1 Record of Revisions Revision Date Section Page(s)Summaryof Changes Author/Revised By: 1.0 12/28/2015 All All Version 1.0 Andy Shen 2.0 01/14/2016 8.3 9.1.5 9.7.5 14 17 39, 41-42. Added test setup for <30MHz. Updated Fig 9-2. Added test data for <30MHz and updated >1GHz data. Andy Shen Test Report#: R‐TR217‐FCCIC‐BTLE‐2 Issued: January 14, 2016 Page 3 of 49 Microsoft EMC Laboratory Table of Contents 1 Record of Revisions ........................................................................................................................... 2 2 Deviations from Standards ............................................................................................................... 7 3 Facilities and Accreditations ............................................................................................................. 7 3.1 Test Facility ................................................................................................................................. 7 3.2 Accreditations ............................................................................................................................. 7 3.3 Test Equipment ........................................................................................................................... 7 4 Measurement Uncertainty ................................................................................................................. 7 5 Product Description ............................................................................................................................ 8 5.1 Test Configurations .................................................................................................................... 8 5.2 Environmental Conditions ......................................................................................................... 8 5.3 Antenna Requirements .............................................................................................................. 8 5.4 Equipment Modifications ........................................................................................................... 9 5.5 Dates of Testing ......................................................................................................................... 9 6 Test Results Summary .................................................................................................................... 10 7 Test Equipment List ......................................................................................................................... 11 8 Test Site Description ........................................................................................................................ 13 8.1 Radiated Emissions Test Site ................................................................................................ 13 8.2 Antenna port conducted measurements ............................................................................... 13 8.3 Test Setup Diagrams ............................................................................................................... 13 9 Test Results- Conducted ................................................................................................................. 16 9.1 Duty Cycle ................................................................................................................................. 16 Test Requirement: ............................................................................................................ 16 Test Method: ..................................................................................................................... 16 Limits: ................................................................................................................................. 16 Test Results: ..................................................................................................................... 16 Test Data: .......................................................................................................................... 17 9.2 6-dB Bandwidth ........................................................................................................................ 19 Test Requirement: ............................................................................................................ 19 Test Method: ..................................................................................................................... 19 Limits: ................................................................................................................................. 19 Test Results: ..................................................................................................................... 19 Test Report#: R‐TR217‐FCCIC‐BTLE‐2 Issued: January 14, 2016 Page 4 of 49 Microsoft EMC Laboratory Test Data: .......................................................................................................................... 20 9.3 Output Power ............................................................................................................................ 22 Test Requirement: ............................................................................................................ 22 Test Method: ..................................................................................................................... 22 Limits: ................................................................................................................................. 22 Test Results: ...........…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOS For MODEL NO. 1754 FCC ID: C3K1754 IC ID: 3048A-1754 Test Report No. R-TR217-FCCIC-TS-2 Issue Date: 14 January 2016 FCC CFR47 Part 15 Subpart C IC RSS-247 Issue 1 Prepared by Microsoft EMC Laboratory 17760 NE 67th Ct, Redmond WA, 98052, U.S.A. 425-421-9799 [email protected] TESTING CERT #3472.01 Test Report#: R‐TR217‐FCCIC‐TS‐2 Issued: 1/14/2016 Page 2 of 7 Microsoft EMC Laboratory 1 Record of Revisions Revision Date Section Page(s)Summaryof Changes Author/Revised By: 1.0 12/28/2015 All All Version 1.0 Daniel Salinas 2.0 01/14/2016 2 3-5 Added test setup photos for <30MHz testing. Updated >1GHz test setup pics. Andy Shen Test Report#: R‐TR217‐FCCIC‐TS‐2 Issued: 1/14/2016 Page 3 of 7 Microsoft EMC Laboratory 2 Test Setup photographs Fig.1 Radiated Spurious Emissions Test Setup (9kHz – 30MHz) Fig.2 Radiated Spurious Emissions Test Setup (30MHz – 1GHz) Test Report#: R‐TR217‐FCCIC‐TS‐2 Issued: 1/14/2016 Page 4 of 7 Microsoft EMC Laboratory Fig.3 Radiated Spurious Emissions Test Setup (1‐18 GHz) Fig 4. Radiated Spurious Emissions Test Setup (1‐18 GHz) EUT Setup Test Report#: R‐TR217‐FCCIC‐TS‐2 Issued: 1/14/2016 Page 5 of 7 Microsoft EMC Laboratory Fig.5 Radiated Spurious Emissions (18‐26.5GHz) Fig.6 Antenna port Conducted Measurements Test Setup Test Report#: R‐TR217‐FCCIC‐TS‐2 Issued: 1/14/2016 Page 6 of 7 Microsoft EMC Laboratory Fig.7 AC Line Conducted Emissions Measurements Test Setup (Front of EUT Setup with Monitoring Equipment) Fig. 8 AC Line Conducted Emissions Test Setup 2 (Side of EUT with 80cm LISN spacing) Test Report#: R‐TR217‐FCCIC‐TS‐2 Issued: 1/14/2016 Page 7 of 7 Microsoft EMC Laboratory Fig. 9 AC Line Conducted Emissions Measurements Test Setup 3 (EUT Setup)
