CYAN MAGENTAYELLOWBLACK X22-14711-02_BKT.indd 131.08.19 01:05 X22-14711-02_BKT.indd 231.08.19 01:05 RL Touch surface LED Charging case USB-C charging port Pair button X22-14711-02_BKT.indd 331.08.19 01:05 Pair your Surface Earbuds 1. Put both earbuds in the case. 2. Press and hold the Pair button on the bottom of the case for 5 seconds. The LED on the case will flash white when your earbuds are in pairing mode. 3. On your iPhone, Android, or Windows 10 PC, go to Bluetooth settings, then select Surface Earbuds. Note: When you open the case the first time, your earbuds will go into pairing mode automatically. X22-14711-02_BKT.indd 431.08.19 01:05 Find your fit To find the best fit, try the different-sized earbud tips provided. Put each earbud in your ear, and then adjust until each one is snug and fits comfortably. Large (L)Medium (M) (already attached) Small (S) X22-14711-02_BKT.indd 531.08.19 01:05 Touch gestures Use the following touch gestures on either earbud. Swipe forward Next Double tap Play/pause music Answer/end call Touch & hold Activate digital assistant Swipe up Volume up Swipe backward Previous Swipe down Volume down X22-14711-02_BKT.indd 631.08.19 01:05 Charge your earbuds Place your earbuds in the case to charge. When the case needs to be charged, the LED will appear amber. Plug the USB cable into the USB-C port on the case, and then plug the other end into any standard USB charging port. The light will fade in and out while charging, and then appear solid white when the case is fully charged. When your earbuds are fully charged, you can get up to 8 hours of music playback. The case holds up to an additional 16 hours of battery life. This gives you up to 24 hours of use. X22-14711-02_BKT.indd 731.08.19 01:05 Get the Surface Audio app Use the Surface Audio app to get the latest updates for your earbuds, change settings, watch tutorial videos, set up Cortana for digital assistance, and more. To download, visit aka.ms/AudioApp. More info To learn more about using Surface Earbuds, visit aka.ms/SurfaceEarbuds. See aka.ms/SurfaceSafety for important safety information, including information about hearing safety. X22-14711-02_BKT.indd 831.08.19 01:05 Do more with Microsoft Office 365 and Cortana Use Surface Earbuds to: • Manage your Outlook calendar, email, and to-dos with your voice. • Dictate in Word and other Microsoft Office apps. • Advance slides and get live captions or subtitles in PowerPoint. • Get digital assistance from Cortana—set reminders, get answers to questions, and more. For more info, see aka.ms/SurfaceEarbuds. To set up Cortana and connect to Office 365 (sold separately), follow the directions in the Surface Audio app. X22-14711-02_BKT.indd 931.08.19 01:05 X22-14711-02_BKT.indd 1031.08.19 01:05 Google Play and the Google Play logo are trademarks of Google LLC. Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc. X22-14711-02_BKT.indd 1131.08.19 01:05 X22-14711-02 support.microsoft.com ©2019 Microsoft. X22-14711-02_BKT.indd 1231.08.19 01:05

Product and Regulatory Guide, Limited Warranty & Agreement X22-17423-01_BRO.indd 127.08.19 16:45 2 LIMITED HARDWARE WARRANTY & AGREEMENT (WITH BINDING ARBITRATION AND CLASS ACTION WAIVER IN THE U.S.) By purchasing or using your Microsoft Product, you agree to the Manufacturer’s Limited Hardware Warranty & Agreement at support.microsoft.com/warranty. Please read the summary on page 9. If you do not agree to it, do not set up or use your Microsoft Product and return the Microsoft Product to Microsoft or your retailer for a refund. If you live in (or are a business with your principal place of business in) the United States, please read the binding arbitration clause and class action waiver at aka.ms/hw‑warr‑arbitration and the summary on page 12. It binds you and Microsoft and affects how disputes concerning your Microsoft Product, its price, advertising, marketing, communications, your purchase transaction, billing, or the Manufacturer’s Limited Hardware Warranty & Agreement are resolved. CLEANING & USAGE INSTRUCTIONS Always handle your device with care to maintain its appearance. To clean, wipe the outer surface with a soft, lint-free cloth. This symbol identifies safety and health messages in this guide. WARNING: Read safety and health information Microsoft products are developed to be safe and effective. Please read this guide for important safety and health information about your device and for the terms of the Limited Warranty that applies to your device. The guide is intended to help you be more comfortable and productive while using this device. Failure to follow the instructions for proper set up, use, and care for your device can increase the risk of serious personal injury, death, or property damage. You can find additional support at support.microsoft.com or on the Surface App for Surface devices. NOTICE: Read use instructions Failure to properly set up, use, and care for this product can increase the risk of damage to your device. Read this guide and keep all printed guides for future reference. For replacement guides, go to www.microsoft.com/hardware or refer to the Microsoft Help and Support section for contact information. X22-17423-01_BRO.indd 227.08.19 16:45 3 NOTICE: Heat related concerns for wearable devices Your device may become very warm during normal use. It complies with the user-accessible surface temperature limits defined by the International Standards for Safety (IEC 60950-1 and IEC 62368). To reduce heat-related concerns, follow these guidelines: • Use CAUTION when operating your device with a pillow, blanket or other soft material contacting the device, because the material can block the airflow which may result in the device overheating. • If your device gets uncomfortably warm, remove it and take a break. • If your device is used for long periods, its surface can become very warm. While the temperature may not feel hot to the touch, if you maintain physical contact with the device for a long time, your skin might suffer a low-heat injury. • Never place the power supply unit (PSU) for your device on furniture or any other surface that might be marred by exposure to heat since the surface of the PSU may increase in temperature during normal use. CAUTION: Device stability Do not place your device on uneven or unstable surfaces. Be sure to hold it securely when it is carried and not via an accessory, cable, or cord. Failure to hold your device securely could cause it to fall or hit a person or object, which could damage your device, damage other property, or cause personal injury. WARNING: Choking hazard This device may contain small parts that may be a choking hazard to children under 3 years. Keep small parts away from children. WARNING: Keep out of the reach of small children Your device and its accessories are not toys. Do not allow small children to play with them because children could hurt themselves or others or damage your device. Keep your device and all its parts and accessories out of the reach of small children. WARNING: High‑risk use Your device is not designed or intended for use in any application or situation where failure of any kind of the device could lead to death, serious bodily injury, or severe environmental damage (“high-risk use”). If you elect to use your device for a high-risk use, you do so at your own risk. X22-17423-01_BRO.indd 327.08.19 16:45 4 CAUTION: Skin irritation This device is made of materials commonly used in wearable consumer electronic devices. However, certain people may develop skin irritation due to allergies or sensitivities. To reduce the risk of skin irritation: • Clean your device regularly. • Avoid using lotions or other products under the portions of the device that contact your skin. • Do not wear over injured skin. • Where applicable, tighten the adjustment until snug, but not uncomfortably tight. • If your skin becomes irritated, stop using device. If symptoms are severe or persist, consult your physician. CAUTION: Hearing safety Frequent or extended exposure to loud noise or sounds when using a headset or headphones can cause temporary or permanent hearing loss. Individual susceptibility to noise-induced hearing loss and potential hearing problems varies. Also, the sound volume produced by a device may vary depending on the nature of the sound, device settings, and the headset or headphones used. As a result, there is no single volume setting that is appropriate for everyone or for every combination of sound, settings, and equipment. Here are a few common-sense recommendations to minimize your exposure to loud noises or sounds when using a headset or headphones with your device: • Minimize your time listening to loud sound. All of the sound you are exposed to each day adds up. At maximum volume, listening to music or other content on your device with a headset or headphones can permanently damage your hearing in 15 minutes. If you are exposed to other loud sounds also, it takes less time listening at high …

Text truncated - open the document above for the full version.

Microsoft Corporation is an equal opportunity employer. Subject: Authorized signatories February 26, 2019 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 AGENCY AUTHORIZATION LETTER FOR MICROSOFT EMPLOYEES To whom it may concern, I, the undersigned hereby authorize the following, to act on my behalf, as the agent(s), in all matters relating to all processes for FCC equipment authorization for Microsoft® Corporation (Grantee Code: C3K). Hasnain Syed Anindita Mitra David Johnson Michael Boucher Kyle Chen Chaitrali Limaye Wei Sun Zachary Gray Daniel Salinas Vishwas Varadanahalli Narayan Albert Huang Mengni Yin Choon Sian Ooi Nisha Nandakumar If you have any questions regarding the authorization, please don’t hesitate to contact me. Sincerely, Hasnain Syed Sr. Director, EMC/SI & RF Compliance Microsoft Corporation Email: [email protected]

Microsoft Corporation is an equal opportunity employer. August 28 th , 2019 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. All acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our representative, we still recognize that we ar e responsible to: a)Comply with the relevant provisions of the certification program; b)Make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c)Make claims regarding certification only in respect of the scope for which certification has been granted; d)Not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e)Upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f)Use certification only to indicate that products are certified as being in conformity with specified standards; g)Endeavor to ensure that no certificate nor report nor any part thereof is used in a misleading manner; h)Ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i)Keep a record of all complaints made known to us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j)Take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k)Document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely, Mengni Yin Compliance Engineer, Microsoft Corporation. Microsoft Corporation is an equal opportunity employer.

Sep 4 th , 2019 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality for FCC ID: C3K1852 To Whom It May Concern: Pursuant to the provisions of the Commission’s rules 47 CFR sections 0.457(d) and 0.459, we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. •Block Diagram •Schematics •Operational Description The above-mentioned documents contain detailed system and equipment descriptions that are considered as proprietary information in the operation of the equipment. Public disclosure of the above documents might be harmful to our company and would give competitors an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we are requesting the commission to grant short-term confidentiality on the following attachments until March 30, 2020. Microsoft Corporation is an equal opportunity employer. Microsoft Corporation is an equal opportunity employer. •External Photos •Test Setup Photos •User’s Manual •Internal Photos It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and the information will be available for public review once the grant of equipment authorization is issued. Sincerely, Mengni Yin Compliance Engineer, Microsoft Corporation.

Refe rence No.: 190626D06-ExtPho Page 1 / 3 CONSTRUCTION PHOTOS OF EUT--C3K1852 Refe rence No.: 190626D06-ExtPho Page 2 / 3 Refe rence No.: 190626D06-ExtPho Page 3 / 3

Microsoft Corporation is an equal opportunity employer. Cover Letter FCC ID Location for Model 1852 The FCC ID for 1852 will be not be placed on the product due to the product size (25 mm x 25 mm x 19.9mm) and shape will not support legible marking. Marking would be too small to read and distorted due to the product’s shape. in accordance with page 4 of the FCC’s General Guidelines for Labeling and Other Information Required to be Provided to Users states: When the device is so small, or for such use that it is impracticable to label with a font size that is four points or larger (and the device does not utilize electronic labeling), then the FCC ID shall be placed in the user manual, and the FCC ID shall also be placed either on the device packaging or on a removable label attached to the device. Below contents will be placed in user manual instead. Mengni Yin Compliance Engineer Microsoft Corporation

Refe rence No.: 190626D06-IntPho Page 1 / 5 CONSTRUCTION PHOTOS OF EUT-C3K1852 Refe rence No.: 190626D06-IntPho Page 2 / 5 Refe rence No.: 190626D06-IntPho Page 3 / 5 Refe rence No.: 190626D06-IntPho Page 4 / 5 Refe rence No.: 190626D06-IntPho Page 5 / 5

FCC SAR Exclusion Test Report Report Format Version 5.0.0 Page No. : 1 of 8 Report No. : SA190626D06A Issued Date : Dec. 17, 2019 Reference No. : 191204D03 Variant FCC SAR Exclusion Report Report No. : SA190626D06A Applicant : MICROSOFT CORPORATION Address : ONE MICROSOFT WAY REDMOND, WA 98052-6399, U.S.A. Product : Bluetooth Accessory FCC ID : C3K1852 Brand : Microsoft Model No. : 1852 Standards : FCC 47 CFR Part 2 (2.1093), IEEE C95.1:1992, IEEE Std 1528:2013 KDB 865664 D01 v01r04, KDB 865664 D02 v01r02, KDB 447498 D01 v06 Sample Received Date : Jun. 26, 2019 Date of Evaluation : Aug. 15, 2019 Lab Address : No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist.,New Taipei City, Taiwan Test Location : No. 19, Hwa Ya 2nd Rd, Wen Hwa Vil, Kwei Shan Dist., Taoyuan City 33383, Taiwan CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch–Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. This report is issued as a supplementary report to BV CPS report no.: SA190626D06-1. The difference compared with original report is increasing the output power of BT LE via software. Prepared By : Rona Chen / Specialist Approved By : Gordon Lin / Assistant Manager FCC Accredited No.: TW0003 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. FCC SAR Exclusion Test Report Report Format Version 5.0.0 Page No. : 2 of 8 Report No. : SA190626D06A Issued Date : Dec. 17, 2019 Reference No. : 191204D03 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Summary of Maximum SAR Value ....................................................................................................................................... 4 2. Description of Equipment Under Test ................................................................................................................................. 5 3. SAR Measurement Evaluation .............................................................................................................................................. 6 3.1 Maximum Output Power ............................................................................................................................................... 6 3.1.1 Maximum Target Conducted Power ................................................................................................................. 6 3.1.2 Measured Conducted Power Result ................................................................................................................ 6 4.1 SAR Testing Exclusions ............................................................................................................................................... 7 4. Information of the Testing Laboratories .............................................................................................................................. 8 Appendix A. Photographs of EUT and Setup FCC SAR Exclusion Test Report Report Format Version 5.0.0 Page No. : 3 of 8 Report No. : SA190626D06A Issued Date : Dec. 17, 2019 Reference No. : 191204D03 Release Control Record Report No. Reason for Change Date Issued SA190626D06A Initial release Dec. 17, 2019 FCC SAR Exclusion Test Report Report Format Version 5.0.0 Page No. : 4 of 8 Report No. : SA190626D06A Issued Date : Dec. 17, 2019 Reference No. : 191204D03 1. Summary of Maximum SAR Value Equipment Class Mode Highest SAR-1g Head (W/kg) DSS Bluetooth EDR Not Required Note: 1. The SAR criteria (Head & Body: SAR-1g1.6 W/kg, and Extremity: SAR-10g 4.0 W/kg)for general population/uncontrolled exposure is specified in FCC 47 CFR part 2 (2.1093) and ANSI/IEEE C95.1-1992. FCC SAR Exclusion Test Report Report Format Version 5.0.0 Page No. : 5 of 8 Report No. : SA190626D06A Issued Date : Dec. 17, 2019 Reference No. : 191204D03 2. Description of Equipment Under Test EUT Type Bluetooth Accessory FCC ID C3K1852 Brand Name Microsoft Model Name 1852 Tx Frequency Bands (Unit: MHz) Bluetooth : 2402 ~ 2480 Uplink Modulations Bluetooth : GFSK, π/4-DQPSK, 8-DPSK Maximum Tune-up Conducted Power (Unit: dBm) Please refer to section 4.6.1 of this report Antenna Type PCB Antenna EUT Stage Engineering Sampl…

Text truncated - open the document above for the full version.

Report No.: RF190626D06-3 R1 Page No. 1 / 55 Report Format Version: 6.1.1 Reference No.: 190820D09 Cancels and replaces the report no.: RF190626D06-3 dated Sep. 3, 2019 FCC Test Report Report No.: RF190626D06-3 R1 FCC ID: C3K1852 Test Model: 1852 Received Date: Jun. 26, 2019 Test Date: Aug. 7 to 19, 2019 Issued Date: Sep. 24, 2019 Applicant: MICROSOFT CORPORATION Address: ONE MICROSOFT WAY REDMOND, WA 98052-6399, U.S.A. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan FCC Registration / Designation Number: 198487 / TW2021 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF190626D06-3 R1 Page No. 2 / 55 Report Format Version: 6.1.1 Reference No.: 190820D09 Cancels and replaces the report no.: RF190626D06-3 dated Sep. 3, 2019 Table of Contents Release Control Record .............................................................................................................................. 4 1 Certificate of Conformity .................................................................................................................. 5 2 Summary of Test Results ................................................................................................................. 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .......................................................................................................................... 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes .................................................................................................................. 8 3.2.1 Test Mode Applicability and Tested Channel Detail ......................................................................... 9 3.3 Description of Support Units ............................................................................................................. 11 3.3.1 Configuration of System under Test .............................................................................................. 11 3.4 General Description of Applied Standards ........................................................................................ 13 4 Test Types and Results .................................................................................................................. 14 4.1 Radiated Emission and Bandedge Measurement ............................................................................ 14 4.1.1 Limits of Radiated Emission and Bandedge Measurement .......................................................... 14 4.1.2 Test Instruments ............................................................................................................................ 15 4.1.3 Test Procedures ............................................................................................................................. 16 4.1.4 Deviation from Test Standard ........................................................................................................ 16 4.1.5 Test Setup ...................................................................................................................................... 17 4.1.6 EUT Operating Conditions ............................................................................................................. 18 4.1.7 Test Results ................................................................................................................................... 19 4.2 Conducted Emission Measurement .................................................................................................. 34 4.2.1 Limits of Conducted Emission Measurement ................................................................................ 34 4.2.2 Test Instruments ............................................................................................................................ 34 4.2.3 Test Procedures ............................................................................................................................. 35 4.2.4 Deviation From Test Standard ....................................................................................................... 35 4.2.5 Test S…

Text truncated - open the document above for the full version.

Ref erence No.: RF190626D06A Page No. 1 / 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (Mode B) Ref erence No.: RF190626D06A Page No. 2 / 5 CONDUCTED EMISSION TEST (Mode C) Ref erence No.: RF190626D06A Page No. 3 / 5 RADIATED EMISSION TEST (Mode A) <Frequency Range below 1GHz> Ref erence No.: RF190626D06A Page No. 4 / 5 RADIATED EMISSION TEST (Mode A) <Frequency Range above 1GHz> Ref erence No.: RF190626D06A Page No. 5 / 5 CONDUCTED TEST (Mode A)

FCC SAR Test Report Report Format Version 5.0.0 Report No. : SA190626D06A Reference No. : 191204D03 <Photographs of EUT> EUT EUT with Earphone Cap FCC SAR Test Report Report Format Version 5.0.0 Report No. : SA190626D06A Reference No. : 191204D03 <Antenna Location> The separation distance for antenna to edge: Antenna To Top Side (mm) To Bottom Side (mm) To Left Side (mm) To Right Side (mm) To Rear Face (mm) To Front Face (mm) BT 2.45 22.55 12.5 12.5 17.76 0.75 Top Side Left Side Right Side BT Antenna Bottom Side <EUT Rear View> Top Side <EUT Rear View> Bottom Side Right Side Left Side <EUT Right Side View> <EUT Right Side View> Top Side Bottom Side Rear Face Front Face Rear Face Front Face Bottom Side Top Side
