American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 July 5, 2002 RE: Microsoft Corporation FCC ID: C3KKB10 After a review of the submitted information, I have a few comments on the above referenced Application. 1) The Users Manual Contains the following information: Regulatory Information This device complies with part 15 of the FCC Rules and Industry Canada RSS-210. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. a) Tested to comply with FCC standards. For home and office use. Model number: Wireless Optical Desktop receiver (all models), FCC IDs C3KKB9 and C3KMS9; Wireless Optical Desktop Pro receiver (all models), FCC IDs C3KKB10 and C3KMS9. This paragraph sounds like the FCC ID's are also being applied to the receiver portion of the device. Are the receivers labeled with the FCC ID Number? The receivers should be labeled only with the proper FCC DoC Labeling (Logo, etc.) and NOT with the FCC ID number. The FCC ID number is applicable only to the keyboard portion. Please adjust the information above so that it is not misleading. 2) The test reports states that 3 samples were provided. It is not clear why 3 samples were tested. Please explain. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

FCC ID Label Location

Artwork NUMBERDESCRIPTIONPROPRIETARY NOTETOLERENCES DWN./DATE SOFTWARE VERSION DRAWING NUMBERREVISION THE INFORMATION CONTAINED HEREON IS CONFIDENTIAL, IS SUBMITTED IN CONFIDENCE, AND IS PROPRIETARY INFORMATION OF MICROSOFT CORPORA- TION, AND SHALL ONLY BE USED IN THE FURTHERANCE OF, THE CONTRACT OF WHICH THIS DRAWING FORMS A PART, AND SHALL NOT, WITHOUT MICROSOFT CORPORATION'S PRIOR WRITTEN APPROVAL, BE REPRODUCED OR IN ANY WAY USED IN WHOLE OR IN PART IN CONNECTION WITH SERVICES OR EQUIPMENT OFFERED FOR SALE OF FURNISHED TO OTHERS, THE INFORMATION CONTAINED HEREON MAY NOT BE DISCLOSED TO A THIRD PARTY WITHOUT CONSENT OF MICROSOFT CORPORATION, AND THEN, ONLY PURSUANT TO A MICROSOFT APPROVED NONDISCLOSURE AGREEMENT. Artwork, Product Label, MS Wireless Optical Dsktp Pro Keybd AWX01-03811-01 Gerald Olive 4/18/2002 Paper UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN MILLIMETERS Adobe Illustrator 7.0 INDUSTRIAL DESIGN FILE NAME AWX01-03811-01.ai Scale 1:1 OUTline does not print Microsoft Corporation - Made in China (S) Microsoft Wireless Natural MultiMedia Keyboard Canada 210 560 0 LIS T E D AC C E S S O R Y ITE 78CJ F CC ID : C3KKB10 This de vic e co m plie s wit h pa r t 15 of the FCC Ru les . O p er ati o n is s ubj ect to t he f ollo wing conditio ns : (1 ) This de vice ma y n o t ca u se har m ful in ter f ere n ce , and (2) this de vic e m ust ac cept an y inte rf erence receiv ed, including int er f er enc e tha t ma y cause undes ired o pe r ation. E01 3V 100mA

Page 3 Page 4

Page 5 Page 6 Page 7

FCC ID: C3KKB10 ADT No.910612R04 Operational Description The transmitter of the EUT (Wireless Keyboard) is powered by 3V Battery. The transmitter use Wire Antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

FCC ID: C3KKB10 Report No.: RF910612R04 1 Issued: June 24, 2002 FCC TEST REPORT REPORT NO.: RF910612R04 MODEL NO.: Microsoft ® Wireless Natural ® MultiMedia Keyboard RECEIVED: June 12, 2002 TESTED: June 14 ~ June 20, 2002 APPLICANT:MICROSOFT CORPORATION ADDRESS: ONE MICROSOFT WAY, REDMOND, WA 98052-6399, U.S.A. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chia Pau Tsuen, Linkou Hsiang, Taipei, Taiwan, R.O.C. This test report consists of 18 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Lab Code: 200102-0 0528 ILAC MRA FCC ID: C3KKB10 Report No.: RF910612R04 2 Issued: June 24, 2002 Table of Contents 1CERTIFICATION .......................................................................................................3 2SUMMARY OF TEST RESULTS ...............................................................................4 3GENERAL INFORMATION........................................................................................5 3.1GENERAL DESCRIPTION OF EUT ................................................................5 3.2DESCRIPTION OF TEST MODES ..................................................................6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS .................................6 3.4DESCRIPTION OF SUPPORT UNITS ............................................................6 4TEST procedure and result........................................................................................7 4.1CONDUCTED EMISSION MEASUREMENT...................................................7 4.2RADIATED EMISSION MEASUREMENT........................................................7 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT .....................................7 4.2.2 TEST INSTRUMENT .......................................................................................8 4.2.3 TEST PROCEDURE........................................................................................9 4.2.4 TEST SETUP.................................................................................................10 4.2.5 EUT OPERATING CONDITION.....................................................................10 4.2.6 TEST RESULT (A) ......................................................................................... 11 4.2.7 TEST RESULT (B) .........................................................................................13 4.2.8 TEST RESULT (C).........................................................................................15 5PHOTOGRAPHS OF THE TEST CONFIGURATION ..............................................17 6INFORMATION ON THE TESTING LABORATORIES .............................................18 FCC ID: C3KKB10 Report No.: RF910612R04 3 Issued: June 24, 2002 1 CERTIFICATION PRODUCT : Wireless Keyboard BRAND NAME : Microsoft ® MODEL NO : Microsoft ® Wireless Natural ® MultiMedia Keyboard APPLICANT : MICROSOFT CORPORATION STANDARDS : 47 CFR Part 15, Subpart C (15.227) ANSI C63.4-1992, Canada RSS 210 We, Advance Data Technology Corporation, hereby certify that three samples of the designation have been tested in our facility from June 14 to June 20, 2002. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: C3KKB10 Report No.: RF910612R04 4 Issued: June 24, 2002 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.207 Conducted Emission TestN/A Power supply is 3VDC from batteries 15.227 Radiated Emission TestPASS Minimum passing margin is –19.4dBuV at 54.20MHz NOTE: The receiver part to communicate with the EUT has been verified to comply with FCC Part 15, Subpart B, Class B (DoC). The test report can be provided upon request. FCC ID: C3KKB10 Report No.: RF910612R04 5 Issued: June 24, 2002 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCTWireless Keyboard MODEL NO.Microsoft ® Wireless Natural ® MultiMedia Keyboard POWER SUPPLY3VDC from battery MODULATION TYPE FSK CARRIER FREQUENCY OF EACH CHANNEL 27.095MHz, 27.195MHz BANDWIDTH OF EACH CHANNEL NA NUMBER OF CHANNEL2 ANTENNA TYPEwire antenna DATA CABLENA I/O PORTSNA ASSOCIATED DEVICESNA NOTE: 1. The EUT is the transmitter part of a Wireless Keyboard. 2. Three identical samples were tested at Microsoft’s request, the serial numbers are DVT2#146(R), DVT2#214(R) and DVT2#223(R). 3. For more detailed features description of the EUT, please refer to the manufacturer's specifications or the User's Manual. FCC ID: C3KKB10 Report No.: RF910612R04 6 Issued: June 24, 2002 3.2 DESCRIPTION OF TEST MODES Two channels were provided in this EUT. ChannelFrequencyChannelFrequency 127.095MHz227.195MHz NOTE: Test result (A) is for sample serial number DVT2#214(R), test result (B) is for sample DVT2#223(R) and test result (C) is for sample DVT2#146(R). 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS The EUT is the transmitter part of a Wireless Keyboard. According to the specifications of the manufacturer, it must comply with the requirements of the following standards: FCC CFR 47 Part 15, Subpart C (15.227) ANSI C63.4-1992, Canada RSS 210 All tests have been performed and recorded as per the above standards. 3.4 DESCRIPTION OF SUPPORT UNITS NA FCC ID: C3KKB10 Report No.: RF910612R04 7 Issued: June 24, 2002 4 TEST PROCEDURE AND RESULT 4.1 CONDUCTED EMISSION MEASUREMENT NA 4.2 RADIATED EMISSION MEASUREMENT 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT According to 15.227 the field strength of emissions from intentional radiators…
