C3KKB8Desktop Wireless Keyboard

American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: C3KKB8 Please be advised pursuant to 47CFR 0.459 the following information is to be held confidential and behalf of Microsoft Corporation: • Schematics • Detailed Block Diagram This application contains technical information which Microsoft Corporation deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter.

FCC ID: C3KKB8 Report No.: RF900703R01 1 Issued: July 19, 2001 ANNEX PHOTOGRAPHS OF EUT FCC ID: C3KKB8 Report No.: RF900703R01 2 Issued: July 19, 2001

FCC ID: Label Location

FCC ID: C3KKB8 Report No.: RF900703R01 3 Issued: July 19, 2001 FCC ID: C3KKB8 Report No.: RF900703R01 4 Issued: July 19, 2001 FCC ID: C3KKB8 Report No.: RF900703R01 5 Issued: July 19, 2001

FCC ID: C3KKB8 ADT No.90703R01 Operational Description The transmitter of the EUT (Wireless Keyboard) is powered by 3V Battery. The receiver is powered by host computer. Both transmitter and receiver use printed antenna. Because the room inside the housing is very limited, so the size of the antenna is far smaller than one wavelength (27MHz), which means the radiation efficiency is very low. But under normal use condition, the transmitter and the receiver is quite close, so high EIRP power is not needed and neither not allowed because of interference.

FCC ID: C3KKB8 Report No.: RF900703R01 1 Issued: July 19, 2001 FCC TEST REPORT REPORT NO.: RF900703R01 MODEL NO.: Wireless Desktop Keyboard RECEIVED: July 3, 2001 TESTED: July 11, 2001 APPLICANT:MICROSOFT CORPORATION ADDRESS: ONE MICROSOFT WAY REDMON, WA 98052-6399, USA ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chia Pau Tsuen, Linkou Hsiang, Taipei, Taiwan, R.O.C. This test report consists of 14 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Lab Code: 200102-0 0528 FCC ID: C3KKB8 Report No.: RF900703R01 2 Issued: July 19, 2001 Table of Contents 1CERTIFICATION ......................................................................................................... 3 2SUMMARY OF TEST RESULTS................................................................................ 4 3GENERAL INFORMATION ....................................................................................... 5 3.1GENERAL DESCRIPTION OF EUT .......................................................................... 5 3.2DESCRIPTION OF TEST MODES ............................................................................. 6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS......................................... 6 3.4DESCRIPTION OF SUPPORT UNITS ....................................................................... 6 4TEST PROCEDURE AND RESULT ........................................................................... 7 4.1CONDUCTED EMISSION MEASUREMENT........................................................... 7 4.2RADIATED EMISSION MEASUREMENT ............................................................... 7 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ........................................... 7 4.2.2TEST INSTRUMENT .................................................................................................. 8 4.2.3TEST PROCEDURE .................................................................................................... 9 4.2.4TEST SETUP .............................................................................................................. 10 4.2.5EUT OPERATING CONDITION .............................................................................. 10 4.2.6TEST RESULT ............................................................................................................11 5PHOTOGRAPHS OF THE TEST CONFIGURATION............................................. 13 6INFORMATION ON THE TESTING LABORATORIES ......................................... 14 FCC ID: C3KKB8 Report No.: RF900703R01 3 Issued: July 19, 2001 1 CERTIFICATION PRODUCT : Wireless Keyboard (Transmitter Part) BRAND NAME : Microsoft MODEL NO : Wireless Desktop Keyboard APPLICANT : MICROSOFT CORPORATION STANDARDS : 47 CFR Part 15, Subpart C(15.227) ANSI C63.4-1992 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility on July 11, 2001. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: C3KKB8 Report No.: RF900703R01 4 Issued: July 19, 2001 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.107Conducted Emission TestN/A Power supply is 3VDC from batteries 15.227Radiated Emission TestPASS Minimum passing margin is –7.6dBuV at 54.14MHz NOTE: The receiver part to communicate with the EUT has been verified to comply with FCC Part 15, Subpart B, Class B (DoC). The test report can be provided upon request. FCC ID: C3KKB8 Report No.: RF900703R01 5 Issued: July 19, 2001 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCTWireless Keyboard (Transmitter Part) MODEL NO.Wireless Desktop Keyboard POWER SUPPLY3VDC from battery MODULATION TYPEFSK FREQUENCY RANGENA CARRIER FREQUENCY OF EACH CHANNEL 27.095MHz, 27.195MHz BANDWIDTH OF EACH CHANNEL +/- 7 kHz NUMBER OF CHANNEL2 ANTENNA TYPEWired antenna DATA CABLENA I/O PORTSNA ASSOCIATED DEVICESNA NOTE: 1. The EUT is the transmitter part of a Wireless Keyboard (Transmitter Part). 2. For more detailed features description of the EUT, please refer to the manufacturer's specifications or the User's Manual. FCC ID: C3KKB8 Report No.: RF900703R01 6 Issued: July 19, 2001 3.2 DESCRIPTION OF TEST MODES Two channels are provided in this EUT. ChannelFrequencyChannelFrequency 127.095 MHz 227.195 MHz NOTE: Channel 2, the worst case, was chosen for final test. 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS The EUT is the transmitter part of a Wireless Keyboard. According to the specifications of the manufacturer, it must comply with the requirements of the following standards: FCC CFR 47 Part 15, Subpart C(15.227) ANSI C63.4-1992 All tests have been performed and recorded as per the above standards. 3.4 DESCRIPTION OF SUPPORT UNITS NO.PRODUCTBRANDMODEL NO.SERIAL NO.FCC ID 1PERSONAL COMPUTER IBM2187-12W1S218714ABNA 000V FCC DoC Approved 2MONITORADISM-5514A521S030301ABR8SM-5514AC 3PRINTERHP2225C+3123S97230DSI6XU2225 4MODEMACEEX1414980020510IFAXDM1414 NO.SIGNAL CABLE DESCRIPTION OF THE ABOVE SUPPORT UNITS 1NA 21.8 m braid shielded wire, terminated with VGA connector via metallic frame, w/o core. 31.2m braid shielded wire, terminated with DB25 and Centronics connector via metallic frame, w/o core. 41.2 m braid shielded wire, terminated with DB25 and DB9 connector via metallic frame, w/o core. NOTE: All power cords of the above support units are non shielded (1.8m). FCC ID: C3KKB8 Report No.: RF900703R01 7 Issued: July 19…

Text truncated - open the document above for the full version.

FCC ID: C3KKB8 Report No.: RF900703R01 13 Issued: July 19, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
