FCC ID: C3KMS8 Report No.: RF900629R01 1 Issued: July 18, 2001 ANNEX PHOTOGRAPHS OF EUT FCC ID: C3KMS8 Report No.: RF900629R01 2 Issued: July 18, 2001

FCC ID : Label Location

FCC ID: C3KMS8 Report No.: RF900629R01 3 Issued: July 18, 2001 FCC ID: C3KMS8 Report No.: RF900629R01 4 Issued: July 18, 2001

FCC ID: C3KMS8 ADT No.900629R01 Operational Description The transmitter of the EUT (Wireless Mouse) is powered by 3V Battery. The receiver is powered by host computer. Both transmitter and receiver use printed antenna. Because the room inside the housing is very limited, so the size of the antenna is far smaller than one wavelength (27MHz), which means the radiation efficiency is very low. But under normal use condition, the transmitter and the receiver is quite close, so high EIRP power is not needed and neither not allowed because of interference.

FCC ID: C3KMS8 Report No.: RF900629R011Issued: July 18, 2001 FCC TEST REPORT REPORT NO.: RF900629R01 MODEL NO.: Wireless Wheel Mouse Wireless Desktop Wheel Mouse RECEIVED: June 29, 2001 TESTED: July 6, 2001 APPLICANT:MICROSOFT CORPORATION ADDRESS: ONE MICROSOFT WAY REDMON, WA98052-6339, U.S.A ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 14 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Lab Code: 200102-0 0528 FCC ID: C3KMS8 Report No.: RF900629R012Issued: July 18, 2001 Table of Contents 1CERTIFICATION ......................................................................................................... 3 2SUMMARY OF TEST RESULTS ................................................................................ 4 3GENERAL INFORMATION ........................................................................................ 5 3.1GENERAL DESCRIPTION OF EUT........................................................................... 5 3.2DESCRIPTION OF TEST MODES ............................................................................. 6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ......................................... 6 3.4DESCRIPTION OF SUPPORT UNITS ........................................................................ 6 4TEST PROCEDURE AND RESULT............................................................................ 7 4.1CONDUCTED EMISSION MEASUREMENT ........................................................... 7 4.2RADIATED EMISSION MEASUREMENT................................................................ 7 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT .................................... 7 4.2.2 TEST INSTRUMENT ...................................................................................... 8 4.2.3 TEST PROCEDURE ....................................................................................... 9 4.2.4 TEST SETUP ................................................................................................ 10 4.2.5 EUT OPERATING CONDITION .................................................................... 10 4.2.6 TEST RESULT ...............................................................................................11 5PHOTOGRAPHS OF THE TEST CONFIGURATION ............................................. 13 6INFORMATION ON THE TESTING LABORATORIES ......................................... 14 FCC ID: C3KMS8 Report No.: RF900629R013Issued: July 18, 2001 1 CERTIFICATION PRODUCT : Wireless Mouse (Transmitter part) BRAND NAME : Microsoft MODEL NO : Wireless Wheel Mouse Wireless Desktop Wheel Mouse APPLICANT : MICROSOFT CORPORATION STANDARDS : 47 CFR Part 15, Subpart C, ANSI C63.4-1992 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility on July 9, 2001. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: C3KMS8 Report No.: RF900629R014Issued: July 18, 2001 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.107Conducted Emission TestN/A Power supply is 3Vdc from batteries. 15.227Radiated Emission TestPASS Minimum passing margin is –10.9dBuV at 35.1MHz NOTE: The receiver part to communicate with the EUT has been verified to comply with FCC Part 15, Subpart B, Class B (DoC). The test report can be provided upon request. FCC ID: C3KMS8 Report No.: RF900629R015Issued: July 18, 2001 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCTWireless Mouse (Transmitter part) MODEL NO. Wireless Wheel Mouse Wireless Desktop Wheel Mouse POWER SUPPLY3VDC from battery (1.5V x 2) MODULATION TYPEFSK FREQUENCY RANGENA CARRIER FREQUENCY OF EACH CHANNEL 27.045MHZ, 27.145MHz BANDWIDTH OF EACH CHANNEL NA NUMBER OF CHANNEL2 ANTENNA TYPEPrinted Antenna DATA CABLENA I/O PORTSNA ASSOCIATED DEVICESNA NOTE: 1. The EUT is the transmitter part of a Wireless Mouse. 2. Wireless Wheel Mouse and Wireless Desktop Wheel Mouse are identical except for their model name and marketing area. Wireless Wheel Mouse was chosen as a representative mode for the test. 3. For a more detailed features description, please refer to the manufacturer's specifications or the User's Manual. FCC ID: C3KMS8 Report No.: RF900629R016Issued: July 18, 2001 3.2 DESCRIPTION OF TEST MODES Two channels are provided in this EUT. ChannelFrequencyChannelFrequency 127.045 MHz 227.145 MHz NOTE: Channel 1, the worst case, was chosen for final test. 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS The EUT is the transmitter part of a Wireless Mouse. According to the specifications of the manufacturer, it must comply with the requirements of the following standards: FCC CFR 47 Part 15, Subpart C ANSI C63.4-1992 All tests have been performed and recorded as per the above standards. 3.4 DESCRIPTION OF SUPPORT UNITS NO.PRODUCTBRANDMODEL NO.SERIAL NO.FCC ID 1Personal Computer IBM2187-12W1S218714ABNA000V FCC DoC APPROVED 221" COLOR MONITOR HPD2846JP92233133FCC DoC APPROVED 3PRINTERHP2225C+3123S97230DSI6XU2225 4MODEMACEEX1414980020510IFAXDM1414 5PS/2 KEYBOARD FORWARDFDA-104GA FDKB8110111F4ZDA-104G NO.SIGNAL CABLE DESCRIPTION OF THE ABOVE SUPPORT UNITS 1NA 21.8 m braid shielded wire, terminated with VGA connector via metallic frame, w/o core. 31.2m braid shielded wire, terminated with DB25 and Centronics connector via metallic frame, w/o core. 41.2 m braid shielded wire, …
