CELMW-2400028Remote Control

STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with Industry Canada license-exempt RSS standard(s). Operation is Subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

11 22 33 44 D D C C B B A A ** TX129 方框图 ** 2012/2/9 11:20:39 C:\Users\JASON\Desktop\TX129 方框图 .SchDoc TitleSize: Number: Date:File: Revision:Sheet of Time: A4 利积电子 *** Drawn By:Engineer:Organization: L J ApprovedBy: * MCU PIC16F676 Antenna RF 发射电路 VBAT +12V SAW433.92MHZ HT7550 5V 12V BUTTON LED

External Photo

FCC Certification Label FCC ID: CELMW-2400028 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Label Location on EUT EUT View/ FCC ID Label Location

Internal Photo Antenna

11 22 33 44 55 66 D D C C B B A A Title Number Revision Size B Date: 2012/2/9 Sheet of File: C:\Users\JASON\Desktop\TX129x2.Sch Drawn By: C2104 C5104 R91M R2310k 5V R4470K R21M R5470K Q1 A733 C3104 C4104 R83.9M R34700KR11M R12470K Q2C945 R22 470K VBAT RA4 U1Comment: 7550 RA0 AD VDD 1 RA5 2 RA4 3 RA3 4 RC5 5 RC4 6 RC3 7 RC2 8 RC1 9 RC0 10 RA2 11 RA1 12 RA0 13 VSS 14 U2 16F676 S1 S2 S3 R7390K R11390K R13390K RA1 RA2 RA3 R141K R151K R101K R171K R18 1K D1D2 D3D4D5 R20 33K Q3 2SC3356 C73P R21200 433.92M C812P 5 6 7 4 3 2 1 8 W1 433.92MHZ C6102 RC5 RC5 RA1RA2 RA3 1 2 3 4 5 烧录点 R6100 RA3 5V 5V RA1RA0 AD TX129X2 S1 S2 S3 D1 D2 D3 D4 D5 TX129 R1947K C102.7P RA4 ANT

FCC PART 15.231 EMI MEASUREMENT AND TEST REPORT For LIBERTY TECHNOLOGY (Shanghai) CO., LTD. No.3 Alley 1511 Xinge Rd., Xin Qiao Town, Song Jiang District, Shanghai City, China FCC ID: CELMW-2400028 June 7, 2012 This Report Concerns: Original Report Equipment Type: Remote Control Test Engineer: Eric Li Report No.: SHBST2011102904Y-1ER-3 Receive EUT Date/Test Date: May 25, 2012/ May 26-30, 2012 Reviewed By: Christina Deng Prepared By: Shenzhen BST Technology Co.,Ltd. 3F,Weames Technology Building, No. 10 Kefa Road,Science Park, Nanshan District,Shenzhen,Guangdong,China Tel: 0755-26747751～3 Fax: 0755-26747751～3 ext.826 Note: The test report is specially limited to the above company and this particular sample only. It may not be duplicated without prior written consent of Shenzhen BST Technology Co.,Ltd. This report must not be used by the client to claim product certification,approval,or endorsement by NVLAP, NIST or any agency of the US Government. LIBERTY TECHNOLOGY (Shanghai) CO., LTD. FCC ID: CELMW-2400028 BST FCC ID REPORT: SHBST2011102904Y-1ER-3 Page 2/21 TABLE OF CONTENTS 1. GENERAL INFORMATION ....................................................................................................3 1.1. Report information ............................................................................................................3 1.2. Measurement Uncertainty .................................................................................................3 2. PRODUCT DESCRIPTION ......................................................................................................4 2.1. EUT Description ...............................................................................................................4 2.2. Block Diagram of EUT Configuration..............................................................................4 2.3. Support Equipment List ....................................................................................................4 2.4. Test Conditions .................................................................................................................4 3. FCC ID LABEL...........................................................................................................................5 4. TEST RESULTS SUMMARY ...................................................................................................6 Modifications ................................................................................................................................6 5. TEST EQUIPMENT USED .......................................................................................................7 6. CONDUCTED POWER LINE TEST .......................................................................................8 6.1. Test Equipment .................................................................................................................8 6.2. Test Procedure ..................................................................................................................8 6.3. Test Setup..........................................................................................................................8 6.4. EUT Operating Condition.................................................................................................9 6.5. Conducted Power line Emission Limits............................................................................9 6.6. Conducted Power Line Test Result...................................................................................9 7. RADIATION EMISSIONS ......................................................................................................10 7.1. Test Equipment ...............................................................................................................10 7.2. Test Procedure ................................................................................................................10 7.3. Radiated Test Setup ........................................................................................................11 7.4. Radiated Emission Limit.................................................................................................11 7.5. Radiated Emission Test Result .......................................................................................12 8. 20DB OCCUPIED BANDWIDTH ..........................................................................................13 8.1. Test Equipment ...............................................................................................................13 8.2. Test Procedure ................................................................................................................13 8.3. FCC 15.231(c) 20dB Bandwidth Limit...........................................................................13 8.4. Test Result ......................................................................................................................14 9. RELEASE TIME MEASUREMENT......................................................................................15 9.1. Test Equipment ...............................................................................................................15 9.2. Test Procedure ................................................................................................................15 9.3. Release time Requirement ..............................................................................................15 9.4. Test Result ......................................................................................................................16 10. AVERAGE FACTOR MEASUREMENT ..............................................................................17 10.1. Average factor Measurement according to ANSI 63.4: 2003.........................................17 10.2. Test Procedure ................................................................................................................17 10.3. Measur…

Text truncated - open the document above for the full version.

深圳市冠测技术服务有限公司 Shenzhen Certification Technology Service Co., Ltd TEL: 86-755-86375552 FAX: 86-755-26736857 Test Lab Attestation Letter This attestation is to confirm that the below listed device was tested at our Test Facilities located at: Test Lab Name: Shenzhen Certification Technology Service Co., Ltd Test Lab Address: 2F, Building B, East Area of Nanchang Second Industrial Zone, Gushu 2nd Road, Bao'an District, shenzhen 518126, China Test Lab Registration Number: 197647 Date of Test: 2012-5-30 Test Report Number: SHBST2011102904Y-1ER-3 Applicant Name: LIBERTY TECHNOLOGY (Shanghai) CO., LTD. FCC ID: CELMW-2400028 Name of Engineer(s) Performing Test: Eric Li Company Name of Engineer(s) Performing Test: Shenzhen Certification Technology Service Co., Ltd TEST LABORATORY: Signature of Authorized Representative of the Test Laboratory: Full Contact Name: Mark Zhu Position/Title: General Manager

Radiated emissions test
