CLF-TIANDY-PTZHigh speed Dome camera

IR Speed Dome Camera User’s Manual CONTENTS Chapter 1 Precautions .................................................................................. 3 Chapter 2 Structure ........................................................................................ 5 Chapter 3 Dome Settings ............................................................................. 7 Chapter 4 Installation Guide .................................................................... 10 Chapter 5 Functions Description .......................................................... 13 5．1 Features ......................................................................................... 13 5．2 Function Instruction ................................................................. 14 Chapter 6 Operation instruction ........................................................... 18 Chapter 1 Precautions ● Please read this manual carefully bef ore installation. ● Handle with care In transportation and storage process, we need to prevent stress, such as severe vibration, and immersion to avoid any damage to the product. This product must be carried disassembled and packaged, either in delivery to users or in return delivery to the factory for repairing. Damage caused by assembled transportation will not be covered by warranty. ● Install with care Handle the product carefully and gently. Prevent such incorrect operations as stress, severe vibration, or may lead to mechanical failure, affecting the overall performance of product; Under the cover are advanced optical devices, avoid direct hand touch, for the sake of image quality; The electrical installation must comply with safety standards, with use of dedicated power adapter; Control signals and video signals should maintain a sufficient distance from high-voltage equipment or cables in the transmission process, if necessary, take anti-lightning, anti-surge and other protective measures. Keep power off until the completion of all installation. ● Do not dismantle parts Do not dismantle internal parts, please turn to qualified maintenance professionals to carry out repairs. ● Do not put any object into the product Make sure that there is no metal object or flammable materials inside the product. Such objects or materials may lead to fire, short circuit or damage. If water or liquid flow into the product, turn off the power and disconnect the power cord immediately, and then negotiate with the company. Be careful to protect the camera. Avoid the rain, sea erosion. ● Keep the product away from electric or magnetic fields If the product is placed near TV, radio transmitters, electromagnetic devices, electric motors, transformers, loudspeakers in the vicinity, the electromagnetic fields generated by them would interfere the image. ● Do not point the camera at strong light Regardless of power on/off status, do not point the camera at the sun or very bright objects, do not point the camera at bright stationary objects for a long time, otherwise it will cause unrecoverable damage to the camera CCD. ● Maintenance with care It is advised to avoid collision or vibration. Do not use strong or abrasive detergents to clean the dome body. When cleaning up dirt, use dry cloth. if dirt is uneasy to remove, swab with a neutral detergent. If there is sticky dust on the lens, please use the special lens paper. ● Working Environment Power AC 100~240V/0.5A Communication port RS485 Environmental temperature －25～50°C（IR off） －25～30°C（IR on） Moisture <95％（Non-condensing） Atmospheric pressure 86～106KPa Note: make sure outdoor installation meets water-proof requirements. ● Camera Module Specification Items TC-D2636L-IRWI-T Zoom Camera FCB-CX1020 Image Sensor 1/4” EX-View HAD CCD Picture Elements NTSC:768(H)x494(V)/PAL:752(H)x582(V) Resolution 550TV Line Video Output 1Vp-p Composite Video(75Ω) SYNC System Internal/External (V-Lock) Zoom 36X Optical, 12X Digital S/N Ratio 50dB Mini. Illumination 0.01Lux ICR On White Balance ATW/Indoor/Outdoor/Manual/AWB/One Push WB Gain Auto/Manual Chapter 2 Structure Front view Side view Housing Camera Dial Switch IR Led Chapter 3 Dome Settings Protocol Setting This product supports two protocols: PELCO-P、PELCO-D, and two baud rate: 9600BPS, 4800BPS, 2400BPS. Protocol dip switch is bit 1~3 of SW2. Baud Rate Setting Baud rate setting dip switch is bit 4~5 of SW2. Dome Address Setting 8-bit dip switch （SW1）at dome side is for setting dome address. Dome setting adopts binary system, the 8 th bit is the highest, the 1 st bit is the lowest. Total 255 dome addresses could be set.。 Dome address code table under protocol PELCO-P: Dome address code table under protocol PELCO-D： *Notice: 1. “1” means “on” status and “0” means “off” status. 2. Dip switch for protocol PELCO-P are the same, while dip switch for PELCO-D is slightly different. PELCO_D protocol supports maximum 254 dome addresses. Chapter 4 Installation Guide 1、Take out the bracket and unscrew the power box from the bracket. 2、Thread cables across the bracket and connect them to the circuit board in the power box. Install the dome body to the bracket, screw up with 4 inner hexagon screws. If necessary, apply water-proof glue to the joint gap. 3、unscrew the cover with the mark “SET”, set communication protocol and addresses. Screw up again with care to avoid water.After the installation of dome body, use two outer hexagon screws to tighten bracket and power box. 4、Attach the drill positioning paste to the wall, and drill according to the paste, and install expansion bolts. 5、Install the dome body together with bracket and power box to the expansion bolts, and tighten with screws. 6、Remove two screws from the power box, and open it. Thread power cable（AC220V）through the water-proof head on the left, and RS485 and video cable through the water-proof head on the right. Connect cables to the circuit board, double check order of connection to avoid damage from wrong connection. After cable connection, tighten the two heads, if …

Text truncated - open the document above for the full version.

气1JT皿NDY 天11'天地伟业数码科技有限公司 地雄天摊市华苑产业区〈环，千〉海必华科=赂8号 电话022.5859ω" 传必022.58~96040 Occlanttio n 011 l1lodc l diffc r c llcc 产品整异声明 \\'.' the "'，，'配 rsil:"eclhcreby CII" fi rm 111M ~ n) " r 011 r 1,,'od Uft;"" 1111 its bu rin!( ，h ~ foLlowông model ""l11t,.. rs a re jtle nt inl in cireui!η~"，l d.'Clriω1. ","<:11:0";<31 3m!川Iysic楠Icon~'rUflion: tht onl) d irrc rc nC<3 ~ rf tht ~p"e"l""..nCf、tr.odfn~mc " "， 1m叫"阳fort rlltling Ilurllose 1I1们在下剧组在名并翻腾此确认以F产品型号之间的笙辩仅为外观ω离你及型日4、 H 只它设计完全州同. • T hf wbo、e叩pUra"CfIs r"rω，，， 泪ndsilk-sn~" (1111) 上边Hi说外观仅循产品的霸色2是鲍印 1'.",10<110" Tn归 "刷忡。"。 四... .,. ",. a刷号 产品起在 ... 高速唱m幢幢头 帮TIANDV ，，~"'由阻 1<-且"川 πω 队t哩句.震平同.xm提 属.偏e.从，，ω" • 1 '1四S~Ilru,' idc '1' 1."剑1,a mplt wi!h d ifferfl1n ðε叫"叩ecifi.d附~I"'Hfo旷 furt" ., e\'剑，川11"" 如有以，所峰'晚界篇键供，~伴也展做退步、，伪 。"田JuNkIDn>mt Tr:od~ n>mr 目1阳1.1no IkMr;p'itjll 严品r.栋 自怀 响号 擅"'面协 "^_n甲"">> .. ..

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Tiandy Digital Technology Co., Ltd ________________________________________________________________ 2012-05-08 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Tiandy Digital Technology Co., Ltd hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description: High Speed Dome camera model name:TC-D2622H-IRWI FCC ID: CLF-TIANDY-PTZ We affirm that between SIEMIC and b mobile HK Limited, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature: Client’s signature: Tiandy Digital Technology Co., Ltd Client’s name / title: Manfred.Liu/ DIRECTOR Contact information / address: No.8, Haitai Huake Rd2 (outside Ring Rd), Huayuan New Technology Industrial Park

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 1.0 2.0 August – 11 - 2008 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 2.0 Tiandy Digital Technology Co., Ltd. _________________________________________________________________________ 2012-05-08 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID: CLF-TIANDY- PTZ We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature Client’s signature: Tiandy Digital Technology Co., Ltd. Client’s name / title: Manfre.Liu/ Director Contact information / address: No.8, Haitai Huake Rd2 (outside Ring Rd),Huayuan New Technology Industrial Park

Annex B. EUT External Photo Whole Package - Top View EUT - Front View EUT - Rear View

FCC ID：CLF-TIANDY-PTZ FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Label Location

Annex B. EUT Internal Photo Photo #1 EUT-Uncovered View Photo #2 Front of view- Power box Photo #3 Front of view- Power adapter plate Photo #4 Rear of view- Power adapter plate Photo #5 Front of view- Power board Photo #6 Rear of view- Power board Photo #7 Front of view- LED Lens Photo #8 Front of view- Motherboard internal Photo #9 Front of view- Motor Photo #10 Front of view- motherboard Photo #11 Rear of view- motherboard Photo #12 Front of view- Dome Address board Photo #13 Front of view- Internal lens Photo #14 Front of view- LED board Photo #15 Rear of view- LED board

TIANJIN TIANDY DIGITAL TECHNOLOGY CO.,LTD High speed dome camera Main Model: TC-D2618-IRWI Serial Model: TC-D36XX, TC-D6XXX March 06, 2012 Report No.: 11050106-FCC-E (This report supersedes NONE) Modifications made to the product : None This Test Report is Issued Under the Authority of: William Long Compliance Engineer Alex Liu Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: EMC Test Report for High speed dome camera Main Model: TC-D2618-IRWI Serial Model: TC-D36XX, TC-D6XXX To: FCC Part 15 Subpart B Class B: 2011 Report No: 11050106-FCC-E Issue Date: March 06, 2012 Page: 2 of 26 www.siemic.com.cn Laboratory Introduction ATION SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets . Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety Japan VCCI, JATE, TELEC, RFTEMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety Accreditations for Product Certifications Country/Region Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Japan MIC, (RCB 208) RF , Telecom Hong Kong OFTA (US002) RF , Telecom Title: EMC Test Report for High speed dome camera Main Model: TC-D2618-IRWI Serial Model: TC-D36XX, TC-D6XXX To: FCC Part 15 Subpart B Class B: 2011 Report No: 11050106-FCC-E Issue Date: March 06, 2012 Page: 3 of 26 www.siemic.com.cn This page has been left blank intentionally. Title: EMC Test Report for High speed dome camera Main Model: TC-D2618-IRWI Serial Model: TC-D36XX, TC-D6XXX To: FCC Part 15 Subpart B Class B: 2011 Report No: 11050106-FCC-E Issue Date: March 06, 2012 Page: 4 of 26 www.siemic.com.cn CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION ..........................................................................................5 2 TECHNICAL DETAILS .........................................................................................................................................6 3 MODIFICATION.....................................................................................................................................................7 4 TEST SUMMARY....................................................................................................................................................8 5 MEASUREMENTS, EXAMINATION AND DERIVED RESULTS ..................................................................9 ANNEX A. TEST INSTRUMENT & METHOD ........................................................................................................15 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ...........................................................................................20 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT................................................................................21 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PART LIST ............................................25 ANNEX E. DECLARATION OF SIMILARITY ........................................................................................................26 Title: EMC Test Report for High speed dome camera Main Model: TC-D2618-IRWI Serial Model: TC-D36XX, TC-D6XXX To: FCC Part 15 Subpart B Class B: 2011 Report No: 11050106-FCC-E Issue Date: March 06, 2012 Page: 5 of 26 www.siemic.com.cn 1 EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programme was to demonstrate compliance of the TIANJIN TIANDY DIGITAL TECHNOLOGY CO.,LTD, High speed dome camera and model: TC-D2618-IRWI against the current Stipulated Standards. The High speed dome camera has demonstrated compliance with the FCC Part 15 Subpart B Class B: 2011. EUT Information EUT Description : High speed dome camera Main Model : TC-D2618-IRWI Serial Model : TC-D36XX, TC-D6XXX (Note) Input Power : 100-240 VAC 50/60 Hz Classification Per Stipulated Test Standard : FCC Part 15 Subpart B Class B: 2011 Note: TC-D2618-IRWI, TC-D36XX, TC-D6XXX Above model different appearance, XX represents a multiple lens, from 1-100 times. Title: EMC Test Report for High speed dome camera Main Model: TC-D2618-IRWI Serial Model: TC-D36XX, TC-D6XXX To: FCC Part 15 Subpart B Class B: 2011 Report No: 11050106-FCC-E Issue Date: March 06, 2012 Page: 6 of 26 www.siemic.com.cn 2 TECHNICAL DETAILS Purpose Compliance testing of High speed dome camera with stipulated standard Applicant / Client TIANJIN TIANDY DIGITAL TECHNOLOGY CO.,LTD NO.8, HAITAI HUAKE RD2 (OUTSIDE RING ROAD),HUAYUAN NEW TECHNOLOGY INDUSTRIAL PARK, TIANJIN 300384 CHINA Manufacturer TIANJIN TIANDY DIGITAL TECHNOLOGY CO.,LTD NO.8, HAITAI HUAKE RD2 (OUTSIDE RING ROAD),HUAYUAN NEW TECHNOLOGY INDUSTRIAL PARK, TIANJIN 300384 CHINA Laboratory performing the tests SIEMIC Nanjing (China) Laboratories NO.2-1,Longcang Dadao, Yuhua Economic Development Zone, Nanjing, China Tel:+86(25)86730128/86730129 Fax:+86(25)86730127 Email:[email protected] Test report reference number 11050106-FCC-E Date EUT received December 05, 2011 Standard appl…

Text truncated - open the document above for the full version.

Annex B. Test Setup Photo Conducted Emissions Test Setup - Front View Conducted Emissions Test Setup - Side View Radiated Emissions Test Setup Below 1GHz - Front View Radiated Emissions Test Setup Above 1GHz - Rear View
