CPODASHTablet PC

D D A A S S H H U U s s e e r r G G u u i i d d e e V V e e r r s s i i o o n n : : 1 1 . . 0 0 DASH User Guide 2 Introduction 1. Please read these safety instructions carefully. 2. Please keep this User’s Manual for later reference. 3. Please disconnect this equipment from connecter before cleaning. Don’t use liquid or prayed detergent for cleaning. User moisture sheet or cloth for cleaning. 4. Make sure the equipments are connected to the power source with the correct voltage, frequency, and ampere. 5. All cautions and warnings on the equipment should be noted. 6. Never pour any liquid into opening: this could cause fire or electrical shock. 7. Never open the equipment. For safety reason, the equipment should only be opened by qualified service personnel. 8. If one of the following situations arises, get the equipment checked by a service personnel: a. Liquid has penetrated into the equipment. b. The equipment has been exposed to moisture. c. The equipment has not worked well or you cannot get it work according to user manual. d. The equipment has dropped and damaged. If the equipment has obvious sign of breakage. DASH User Guide 3 9. Caution on use of battery: User the battery recommended by the manufacturer or the same type of battery installed by the manufacturer. If incorrect battery is used, it may cause explosion or fire hazard. Recycle or discard used batteries according the manufacturer’s instruction or your local authority. 10. The computers use nonvolatile memory that requires a battery to retain system information when power is removed. The 3V lithium battery is on the system board. The battery life depends on the amount of time the computer is powered on. If the computer does not display the correct time and date, replace the battery. IMPORTANT：Loss of BIOS settings occurs when the battery is removed. BIOS settings must be reconfigured whenever the battery is replaced. WARNING：A risk of fire and chemical burn exists if the battery is not handled properly. Do not disassemble, crush, puncture, or short external contacts, or expose the battery to temperatures higher than 60 °C (140 °F). Do not dispose of a used battery in water or fire. CAUTION：Danger of explosion if battery is incorrectly replaced. Replace only with same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. DASH User Guide 4 FCC Compliance Statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. DASH User Guide 5 FCC RF Radiation Exposure Statement: 1. This Transmitter has been demonstrated co-location compliance requirements with Wi-Fi, Bluetooth and RF ID. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device was tested for typical hand held operations with the device contacted directly to the human body to the back side of the tablet pc. To maintain compliance with FCC RF exposure compliance requirements, avoid direct contact to the transmitting antenna during transmitting. E E u u r r o o p p e e – – E E U U D D e e c c l l a a r r a a t t i i o o n n o o f f C C o o n n f f o o r r m m i i t t y y This device complies with the essential requirements of the R&TTE Directive 1999/5/EC and EMC directive 2004/108/EC. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the R&TTE Directive 1999/5/EC and EMC directive 2004/108/EC:  EN 55022: 2006 +A1: 2007  EN 61000-3-2 : 2006  EN 61000-3-3 : 1995 + A1 : 2001 + A2 : 2005  EN 55024: 1998 + A1: 2001 + A2: 2003 DASH User Guide 6 (IEC 61000-4-2: 2008; IEC 61000-4-3: 2006 + A1:2007; IEC 61000-4-4: 2004; IEC 61000-4-5: 2005; IEC 61000-4-6: 2003 + A1: 2004 +A2: 2006; IEC 61000-4-8: 1993 +A1: 2000; IEC 61000-4-11: 2004)  EN 60950-1: 2001 Safety of information technology equipment  EN 300 328 V1.7.1: 2006  EN 301 489-17 V2.1.1: 2009 and EN 301 489-1 V1.8.1: 2008  EN 62311: 2008 This device is a 2.4GHz wideband transmission system (transceiver), intended for use in all EU member states and EFTA countries under the following conditions and/or with the following restrictions:  In Italy the end-user should apply for a license at the national spectrum authorities in order to obtain authorization to use the device for setting up outdoor radio links and/or for supplying public access to telecommunications and/or network services.  This device may not be used for setting up outdoor radio links in France and in some areas the RF output power may be limited to 10 mW EIRP in the frequency range of 2454 – 2483.5 MHz. For detailed information the end-user should contact the national spectrum authori…

Text truncated - open the document above for the full version.

Date：November 28, 2012 Subject:DoC declaration To Whom it may concern, We, as the grantee of this project FCC ID: CPODASH, would like to declare that the composite Portion categorized as computer peripheral has been authorized under the Declaration of Conformity procedures. Brand Name & Model Name of the specified radio equipment: ASTERIX/ DASH FCC ID: CPODASH Product Name: TABLET PC Regards,

Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 1 Total Page: 22 Rev.00 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 2 Total Page: 22 Rev.00 Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 3 Total Page: 22 Rev.00 Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 4 Total Page: 22 Rev.00 Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 5 Total Page: 22 Rev.00

Portable Computing Group First International Computer, Inc. PART NO. MODEL NO. DRAWING NO. UNIT : 3RD.ANGLE'S 100.1-150.0 150.1- 50.1-100.0 20.1-50.0 0-20.0 ±2.5 ±3.0 ±1.5 ±1.0 ±2.0 31°-60° 61°-90° 0-30° SIZE DRAWN CHECKED DESIGNED APPROVED ±2° ±3° ±1° NAME DRAWING OF SHEET SCALE REV. mm PAPER 800.1- 500.1-800.0 ±4.0 ±5.0 200.1-500.0 50.1-200.0 ±3.0 ±2.0 0-50.0 ±1.0 PALLET & BAG 600.1-1000.0 1000.1- 150.1-600.0 50.1-150.0 0-50.0 ±4.0 ±5.0 ±2.0 ±1.5 ±3.0 CUSHION ANGLE Tony 2012/11/15 Sherven 2012/11/15 Sherven 2012/11/15 Sherven 2012/11/15 CARPO-KE00 25-4XXXX-XX LABEL RATING FOR CARPO KE00R00 DASH(PioneerPOS) 25-4XXXX-XX A X X 1 1 A B C D F E A B C DE F 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 DC SYM. DATE DESCRIPTION OF REVISIONS DRAWN APPD A 2012/11/15 RELEASE DRAWING Sherven Tony EB 1:1 1:1 5 . C3 79.5mm+-0.2 31.5mm+-0.2 19V 2.1A (RATING):  !"#$%&' *First International Computer, Inc. 300 NOTE :1. COLOR : SILVER( BACKGROUND : BLACK ( MATERIAL PC 0.125+GLUE 0.05mm) THICKNESS : 0 0. 5mm GLUE M UL UL THE MATERIAL MUST BE FIT FOR ROHS. ) ) 2. :  ( 3. .175 0 4. :3 4675. ： 6.  ,   !"#.7. PC ( Include adhesive $%&, ) ± FCC ID:CPODASH ! Pioneer POS Solution, Inc. Made in China 19V 3.42A 19V 3.42A INPUT : PRODUCT NAME TABLET PC : MODEL NO DASH .: 19V 3.42A FCC ID:CPODASH ! Pioneer POS Solution, Inc. Made in China 19V 3.42A 19V 3.42A INPUT : PRODUCT NAME TABLET PC : MODEL NO DASH .: FCC ID:CPODASH ! Pioneer POS Solution, Inc. Made in China 19V 3.42A 19V 3.42A INPUT : PRODUCT NAME TABLET PC : MODEL NO DASH .:

Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 6 Total Page: 22 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 7 Total Page: 22 Rev.00 Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 8 Total Page: 22 Rev.00 Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 9 Total Page: 22 Rev.00 Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 10 Total Page: 22 Rev.00 Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 11 Total Page: 22 Rev.00 Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 12 Total Page: 22 Rev.00 BT Module Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 13 Total Page: 22 Rev.00 BT Antenna Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 14 Total Page: 22 Rev.00 WLAN Module Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 15 Total Page: 22 Rev.00 Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 16 Total Page: 22 Rev.00 RFID Module Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 17 Total Page: 22 Rev.00 WLAN Antenna Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 18 Total Page: 22 Rev.00 Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 19 Total Page: 22 Rev.00 Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 20 Total Page: 22 Rev.00 RFID Antenna Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 21 Total Page: 22 Rev.00 Battery Compliance Certification Services Inc. Reference No.: T120807D01 Report No.: T121115D02-1 Date of Issue: November 15, 2012 A1 - 22 Total Page: 22 Rev.00

Compliance Certification Services Inc. Reference No.: T120807D01-RP2 FCC ID: CPODASH Report No.: T121115D02-RP2-1 Page 97 APPENDIX I RADIO FREQUENCY EXPOSURE LIMIT According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this chapter. EUT Specification EUT TABLET PC Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5.825GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others Exposure classification Occupational/Controlled exposure (S = 5mW/cm 2 ) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power IEEE 802.11b mode: 17.41 dBm (55.08 mW) IEEE 802.11g mode: 16.22dBm (41.87 mW) IEEE 802.11n HT 20 MHz mode: 16.12 dBm (40.92 mW) IEEE 802.11n HT 40 MHz mode: 16.18 dBm (41.49 mW) Antenna gain (Max) 1.4 dBi (Numeric gain: 1.38) Evaluation applied MPE Evaluation* SAR Evaluation N/A Remark: The maximum output power is 17.41dBm (55.08 mW) at 2462MHz (with 1.38 numeric antenna gain.) TEST RESULTS No non-compliance noted. MPE EVALUATION No non-compliance noted. Compliance Certification Services Inc. Reference No.: T120807D01-RP2 FCC ID: CPODASH Report No.: T121115D02-RP2-1 Page 98 Calculation Given d GP E ×× = 30 & 3770 2 E S = Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 3770 30 d GP S ×× = Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields () () 2 2 0796.0 100/3770 1000/30 d GP d GP S × ×= × ×× = Equation 1 Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Maximum Permissible Exposure Substituting the MPE safe distance using d = 20 cm into Equation 1: Yields GPS××=000199.0 Where P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Compliance Certification Services Inc. Reference No.: T120807D01-RP2 FCC ID: CPODASH Report No.: T121115D02-RP2-1 Page 99 IEEE 802.11b mode: EUT output power = 55.08mW Numeric Antenna gain = 1.38 Æ Power density = 0.015126 mW / cm2 IEEE 802.11g mode: EUT output power = 41.87 mW Numeric Antenna gain = 1.38 Æ Power density = 0.011498 mW / cm2 IEEE 802.11n HT 20 MHz mode: EUT output power =40.92 mW Numeric Antenna gain = 1.38 Æ Power density = 0.011237mW / cm2 IEEE 802.11n HT 40 MHz mode: EUT output power = 41.49mW Numeric Antenna gain = 1.38 Æ Power density = 0.011394 mW / cm2 (For mobile or fixed location transmitters, the maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger.)

Compliance Certification Services Inc. FCC ID: CPODASH Report No.: T121115D02-SF Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 29 Rev. 00 ANSI/IEEE Std. C95.1-1992 in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C FCC TEST REPORT For TABLET PC Trade Name: ASTERIX Model: DASH Issued to PIONEER POS SOLUTION INC 238 Benton Ct, City of Industry, CA 91789, USA. Issued by Compliance Certification Services Inc. No. 11, Wugong 6th Rd., Wugu Industrial Park, Taipei Hsien 248, Taiwan. http://www.ccsrf.com [email protected]. Issued Date: September 07, 2012 Compliance Certification Services Inc. Report No.: T121115D02-SF Page 2 Rev. 00 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 September 21, 2012 Initial Issue ALL Anson Lu Compliance Certification Services Inc. Report No.: T121115D02-SF Page 3 Rev. 00 TABLE OF CONTENTS 1. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) ................................... 4 2. EUT DESCRIPTION ..................................................................................................... 5 3. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED ............................. 6 3.1 REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC.................... 6 4. DOSIMETRIC ASSESSMENT SYSTEM ................................................................... 6 4.1 MEASUREMENT SYSTEM DIAGRAM .........................................................................7 4.2 SYSTEM COMPONENTS.................................................................................................8 5. EVALUATION PROCEDURES................................................................................. 11 6. MEASUREMENT UNCERTAINTY ......................................................................... 15 7. EXPOSURE LIMIT ..................................................................................................... 17 8. TYPICAL COMPOSITION OF INGREDIENTS FOR LIQUID TISSUE PHANTOMS.................................................................................................................. 18 9. MEASUREMENT RESULTS ..................................................................................... 19 9.1 TEST LIQUID CONFIRMATION ..................................................................................19 9.2 SYSTEM PERFORMANCE CHECK..............................................................................21 9.3 EUT TUNE-UP PROCEDURES AND TEST MODE.....................................................22 9.4 EUT TEST POSITION .....................................................................................................24 9.5 SAR MEASUREMENTS RESULTS...............................................................................26 10. EQUIPMENT LIST & CALIBRATION STATUS ................................................... 27 11. FACILITIES ................................................................................................................. 28 12. REFERENCES ............................................................................................................. 28 13. ATTACHMENTS ......................................................................................................... 29 Compliance Certification Services Inc. Report No.: T121115D02-SF Page 4 Rev. 00 1. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Applicant PIONEER POS SOLUTION INC 238 Benton Ct, City of Industry, CA 91789, USA. Equipment Under Test: TABLET PC Trade Name: ASTERIX Model Number: DASH Date of Test: September 05, 2012 Device Category: PORTABLE DEVICES Exposure Category: GENERAL POPULATION/UNCONTROLLED EXPOSURE APPLICABLE STANDARDS STANDARD FCC FCC OET 65 Supplement C IEEE 1528 2003 KDB 447498 D01 KDB 248227 D01 Deviation from Applicable Standard None TEST RESULT No non-compliance noted The device was tested by Compliance Certification Services Inc. in accordance with the measurement methods and procedures specified in OET Bulletin 65 Supplement C (Edition 01-01). The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved by: Tested by: Alex Wu Anson Lu Section Manager Test Engineer Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. Report No.: T121115D02-SF Page 5 Rev. 00 2. EUT DESCRIPTION Product TABLET PC Trade Name ASTERIX Model Number DASH Model Discrepancy N/A Frequency Range 802.11b: 2412 ~ 2462 MHz 802.11g: 2412 ~ 2462 MHz 802.11n HT20: 2412 ~ 2462 MHz 802.11n HT40: 2422 ~ 2452 MHz Bluetooth: 2402 ~ 2480 MHz Maximum Output Power (Average): 802.11b: 14.45 dBm 802.11g: 6.03 dBm 802.11n HT20: 6.82 dBm 802.11n HT40: 6.41 dBm Bluetooth: 3.10 dBm Max. SAR (1g): 802.11b: 0.320 W/kg 802.11g: SAR test is not required, please refer to page 22. 802.11n HT20: SAR test is not required, please refer to page 22 802.11n HT40: SAR test is not required, please refer to page 22 Bluetooth: SAR test is not required, please refer to page 22 Modulation Technique 802.11b: Direct Sequence Spread Spectrum (DSSS) 802.11g: Orthogonal Frequency Division Multiplexing (OFDM) 802.11n: Orthogonal Frequency Division Multiplexing (OFDM) GFSK for 1Mbps; π/4-DQPSK for 2Mbps; 8DPSK for 3Mbps Antenna Specification Antenna type: WLAN antenna: PIFA antenna Bluetooth: CHIP antenna Battery Model: 21CP7/47/103 Rating: 7.4V 3800mAh, 28.12Wh Remark: The sample selected for test was prototype that approximated to production product and was provided by manufacturer. Bluetooth maximum output power 1.24dBm(1.330mW ) is less than 24.979…

Text truncated - open the document above for the full version.

Date/Time: 2012/9/5 12:34:50 Test Laboratory: Compliance Certification Services Inc. 802.11b CH11 Rate 1M_Edge 1_Main Antenna DUT: CARPO-KE00R00; Type: Tablet PC; Serial: N/A Communication System: IEEE 802.11b WLAN; Frequency: 2462 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2462 MHz; σ = 1.97 mho/m; ε r = 51.8; ρ = 1000 kg/m 3 Phantom section: Flat Section Air Temperature:24.2 deg C;Liquid Temperature:23.2 deg C Area Scan Find Secondary Maximum Within 2dB and with a peak SAR value greater than 0.0012W/kg DASY4 Configuration: lProbe: EX3DV4 - SN3554; ConvF(6.18, 6.18, 6.18); lSensor-Surface: 2.5mm (Mechanical Surface Detection) lElectronics: DAE4 Sn558; Calibrated: 2012/7/19 lPhantom: Flat Phantom ELI4.0; Type: QDOVA001BA; Serial: SN: 1052 lMeasurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Edge 1 CH11/Area Scan (6x8x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.372 mW/g Edge 1 CH11/Zoom Scan (7x7x9)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=2.5mm Reference Value = 3.27 V/m; Power Drift = 0.039 dB Peak SAR (extrapolated) = 0.727 W/kg SAR(1 g) = 0.337 mW/g; SAR(10 g) = 0.157 mW/g Maximum value of SAR (measured) = 0.482 mW/g Edge 1 CH11/Z Scan (1x1x21): Measurement grid: dx=20mm, dy=20mm, dz=5mm Maximum value of SAR (measured) = 0.353 mW/g 'DWH7LPH30 7HVW/DERUDWRU\&RPSOLDQFH&HUWLILFDWLRQ6HUYLFHV,QF  E&+115DWH0B(GJHB0DLQ$QWHQQD &RPPXQLFDWLRQ6\VWHP,(((E:/$1)UHTXHQF\0+]'XW\&\FOH 0HGLXPSDUDPHWHUVXVHGI 0+]ı PKRPİ U  ȡ NJP    3KDQWRPVHFWLRQ)ODW6HFWLRQ $LU7HPSHUDWXUHGHJ&/LTXLG7HPSHUDWXUHGHJ& $UHD6FDQ)LQG6HFRQGDU\0D[LPXP:LWKLQG%DQGZLWKDSHDN6$5YDOXHJUHDWHUWKDQ:NJ '$6<&RQILJXUDWLRQ z3UREH(;'961&RQY)   z6HQVRU6XUIDFHPP 0HFKDQLFDO6XUIDFH'HWHFWLRQ  z(OHFWURQLFV'$(6Q&DOLEUDWHG z3KDQWRP)ODW3KDQWRP(/,7\SH4'29$%$6HULDO61 z0HDVXUHPHQW6:'$6<9%XLOG3RVWSURFHVVLQJ6:6(0&$'9%XLOG  (GJH&+$UHD6FDQ [[ 0HDVXUHPHQWJULGG[ PPG\ PP 0D[LPXPYDOXHRI6$5 PHDVXUHG  P:J  (GJH&+=RRP6FDQ [[ &XEH0HDVXUHPHQWJULGG[ PPG\ PPG] PP 5HIHUHQFH9DOXH 9P3RZHU'ULIW G% 3HDN6$5 H[WUDSRODWHG  :NJ 6$5 J  P:J6$5 J  P:J 0D[LPXPYDOXHRI6$5 PHDVXUHG  P:J 'DWH7LPH30 7HVW/DERUDWRU\&RPSOLDQFH&HUWLILFDWLRQ6HUYLFHV,QF  E&+5DWH0B5HDU6LGHB0DLQ$QWHQQD &RPPXQLFDWLRQ6\VWHP,(((E:/$1)UHTXHQF\0+]'XW\&\FOH 0HGLXPSDUDPHWHUVXVHGI 0+]ı PKRPİ U  ȡ NJP    3KDQWRPVHFWLRQ)ODW6HFWLRQ $LU7HPSHUDWXUHGHJ&/LTXLG7HPSHUDWXUHGHJ& $UHD6FDQ)LQG6HFRQGDU\0D[LPXP:LWKLQG%DQGZLWKDSHDN6$5YDOXHJUHDWHUWKDQ:NJ '$6<&RQILJXUDWLRQ z3UREH(;'961&RQY)   z6HQVRU6XUIDFHPP 0HFKDQLFDO6XUIDFH'HWHFWLRQ  z(OHFWURQLFV'$(6Q&DOLEUDWHG z3KDQWRP)ODW3KDQWRP(/,7\SH4'29$%$6HULDO61 z0HDVXUHPHQW6:'$6<9%XLOG3RVWSURFHVVLQJ6:6(0&$'9%XLOG  5HDU6LGH&+$UHD6FDQ [[ 0HDVXUHPHQWJULGG[ PPG\ PP 0D[LPXPYDOXHRI6$5 PHDVXUHG  P:J  5HDU6LGH&+=RRP6FDQ [[ &XEH0HDVXUHPHQWJULGG[ PPG\ PPG] PP 5HIHUHQFH9DOXH 9P3RZHU'ULIW G% 3HDN6$5 H[WUDSRODWHG  :NJ 6$5 J   P:J6$5 J  P:J 0D[LPXPYDOXHRI6$5 PHDVXUHG  P:J 'DWH7LPH430 7HVW/DERUDWRU\&RPSOLDQFH&HUWLILFDWLRQ6HUYLFHV,QF  E&+65DWH0B(GJHB$X[$QWHQQD &RPPXQLFDWLRQ6\VWHP,(((E:/$1)UHTXHQF\0+]'XW\&\FOH 0HGLXPSDUDPHWHUVXVHGI 0+]ı PKRPİ U  ȡ NJP    3KDQWRPVHFWLRQ)ODW6HFWLRQ $LU7HPSHUDWXUHGHJ&/LTXLG7HPSHUDWXUHGHJ& $UHD6FDQ)LQG6HFRQGDU\0D[LPXP:LWKLQG%DQGZLWKDSHDN6$5YDOXHJUHDWHUWKDQ:NJ '$6<&RQILJXUDWLRQ z3UREH(;'961&RQY)   z6HQVRU6XUIDFHPP 0HFKDQLFDO6XUIDFH'HWHFWLRQ  z(OHFWURQLFV'$(6Q&DOLEUDWHG z3KDQWRP)ODW3KDQWRP(/,7\SH4'29$%$6HULDO61 z0HDVXUHPHQW6:'$6<9%XLOG3RVWSURFHVVLQJ6:6(0&$'9%XLOG  (GJH&+$UHD6FDQ [[ 0HDVXUHPHQWJULGG[ PPG\ PP 0D[LPXPYDOXHRI6$5 PHDVXUHG  P:J  (GJH&+=RRP6FDQ [[ &XEH0HDVXUHPHQWJULGG[ PPG\ PPG] PP 5HIHUHQFH9DOXH 9P3RZHU'ULIW G% 3HDN6$5 H[WUDSRODWHG  :NJ 6$5 J   P:J6$5 J  P:J 0D[LPXPYDOXHRI6$5 PHDVXUHG  P:J 'DWH7LPH553M 7HVW/DERUDWRU\&RPSOLDQFH&HUWLILFDWLRQ6HUYLFHV,QF  E&+65DWH0B(GJHB$X[$QWHQQD &RPPXQLFDWLRQ6\VWHP,(((E:/$1)UHTXHQF\0+]'XW\&\FOH 0HGLXPSDUDPHWHUVXVHGI 0+]ı PKRPİ U  ȡ NJP    3KDQWRPVHFWLRQ)ODW6HFWLRQ $LU7HPSHUDWXUHGHJ&/LTXLG7HPSHUDWXUHGHJ& $UHD6FDQ)LQG6HFRQGDU\0D[LPXP:LWKLQG%DQGZLWKDSHDN6$5YDOXHJUHDWHUWKDQ:NJ '$6<&RQILJXUDWLRQ z3UREH(;'961&RQY)   z6HQVRU6XUIDFHPP 0HFKDQLFDO6XUIDFH'HWHFWLRQ  z(OHFWURQLFV'$(6Q&DOLEUDWHG z3KDQWRP)ODW3KDQWRP(/,7\SH4'29$%$6HULDO61 z0HDVXUHPHQW6:'$6<9%XLOG3RVWSURFHVVLQJ6:6(0&$'9%XLOG  (GJH&+$UHD6FDQ [[ 0HDVXUHPHQWJULGG[ PPG\ PP 0D[LPXPYDOXHRI6$5 PHDVXUHG  P:J  (GJH&+=RRP6FDQ [[ &XEH0HDVXUHPHQWJULGG[ PPG\ PPG] PP 5HIHUHQFH9DOXH 9P3RZHU'ULIW G% 3HDN6$5 H[WU…

Text truncated - open the document above for the full version.

Date/Time: 2012/9/5 09:39:38 AM Test Laboratory: Compliance Certification Services Inc. System check 20120905_BSL2450 Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2450 MHz; σ = 1.96 mho/m; ε r = 51.8; ρ = 1000 kg/m 3 Phantom section: Flat Section Air Temperature:24.2 deg C;Liquid Temperature:23.2 deg C Area Scan Find Secondary Maximum Within 2dB and with a peak SAR value greater than 0.0012W/kg DASY4 Configuration: lProbe: EX3DV4 - SN3554; ConvF(6.18, 6.18, 6.18); lSensor-Surface: 2.5mm (Mechanical Surface Detection)Sensor-Surface: 0mm (Fix Surface) lElectronics: DAE4 Sn558; Calibrated: 2012/7/19 lPhantom: Flat Phantom ELI4.0; Type: QDOVA001BA; Serial: SN: 1052 lMeasurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Pin=250mW, d=10mm/Area Scan (7x9x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 16.5 mW/g Pin=250mW, d=10mm/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 93.4 V/m; Power Drift = -0.039 dB Peak SAR (extrapolated) = 27.1 W/kg SAR(1 g) = 13.6 mW/g; SAR(10 g) = 6.43 mW/g Maximum value of SAR (measured) = 19.0 mW/g Pin=250mW, d=10mm/Z Scan (1x1x11): Measurement grid: dx=20mm, dy=20mm, dz=10mm Maximum value of SAR (measured) = 15.5 mW/g

Compliance Certification Services Inc. Reference No.: T120807D01-RP2 FCC ID: CPODASH Report No.: T121115D02-RP2-1 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 102 FCC 47 CFR PART 15 SUBPART C TEST REPORT For TABLET PC Model: DASH Trade Name: ASTERIX Issued to PIONEER POS SOLUTION INC 238 Benton Ct, City of Industry, CA 91789, USA. Issued by Compliance Certification Services Inc. No.11, Wu-Gong 6th Rd., Wugu Industrial Park, New Taipei City 248, Taiwan (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: November 15, 2012 Compliance Certification Services Inc. Reference No.: T120807D01-RP2 FCC ID: CPODASH Report No.: T121115D02-RP2-1 Page 2 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 November 15, 2012 Initial Issue ALL Rachel Wu Compliance Certification Services Inc. Reference No.: T120807D01-RP2 FCC ID: CPODASH Report No.: T121115D02-RP2-1 Page 3 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION....................................................................................................4 2. EUT DESCRIPTION ...........................................................................................................................5 3. TEST METHODOLOGY ....................................................................................................................6 3.1 EUT CONFIGURATION........................................................................................................................6 3.2 EUT EXERCISE....................................................................................................................................6 3.3 GENERAL TEST PROCEDURES.............................................................................................................6 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS.........................................................7 3.5 DESCRIPTION OF TEST MODES...........................................................…
