English - 1 ! IMPORTANT SAFETY INSTRUCTIONS ! 1.READ these instructions. 2.KEEP these instructions. 3.HEED all warnings. 4.FOLLOW all instructions. 5.DO NOT use this apparatus near water. 6.CLEAN ONLY with dry cloth. 7.DO NOT block any ventilation openings. Install in accordance with the manu- facturer's instructions. 8.DO NOT install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9.DO NOT defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wider blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10.PROTECT the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11.ONLY USE attachments/accessories specified by the manufacturer. 12. 13.UNPLUG this apparatus during lightning storms or when unused for long periods of time. 14.REFER all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is dam- aged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 15.DO NOT expose the apparatus to dripping and splashing. DO NOT put objects filled with liquids, such as vases, on the apparatus. This symbol indicates that dangerous voltage constituting a risk of electric shock is present within this unit. This symbol indicates that there are important operating and maintenance instructions in the literature accompanying this unit. WARNING! USING THIS SYSTEM AT EXCESSIVE VOLUMES CAN CAUSE PERMANENT HEARING DAMAGE. USE AS LOW A VOLUME AS POSSIBLE. In order to use this system safely, avoid prolonged listening at excessive sound pressure levels. Please use the following guidelines established by the Occupational Safety Health Administration (OSHA) on maximum time exposure to sound pressure levels before hearing damage occurs. 90 dB SPL at 8 hours 95 dB SPL at 4 hours 100 dB SPL at 2 hours 105 dB SPL at 1 hour 110 dB SPL at ½ hour 115 dB SPL at 15 minutes 120 dB SPL — avoid or damage may occur It is difficult to measure the exact Sound Pressure Levels (SPL) present at the eardrum in live applications. In addition to the volume setting on the PSM, the SPL in the ear is affected by ambient sound from floor wedges or other devices. The isolation provided by the fit of quality earpieces is also an important factor in determining the SPL in the ear. Here are some general tips to follow in the use of this product to protect your ears from damage: • Turn up the volume control only far enough to hear properly. • Ringing in the ears may indicate that the gain levels are too high. Try lowering the gain levels. • Have your ears checked by an audiologist on a regular basis. If you experience wax buildup in your ears, stop using the system until an audiologist has examined your ears. • Wipe the ear molds with an antiseptic before and after use to avoid infections. Stop using the earphones if they are causing great discomfort or infection. USE only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 2 - English Quickstart P7T Transmitter Setup 1.Connect the transmitter to a power outlet using the supplied power cord. 2.Attach the supplied antenna to the ANTENNA OUT BNC connector. 3.Connect an audio source, such as a mixer, to the audio inputs of the transmitter. You can use both input jacks or choose either one for a mono source. NOTE: All inputs are phantom power protected up to 60 VDC. 4.Set the PAD switch to either +4 dB or –10 dB depending on the signal level from the audio source. 5.Turn on the transmitter. 6.Set the SOURCE switch to MONO if you are using only one input. Otherwise set it to STEREO/MixMode. 7.Set the GROUP switch UP to group 1. 8.Set the CHANNEL dial to an unused channel. NOTE: See Selecting Channels. 9.Power on the audio source and adjust the level control until the LEDs are in the –3 dB to +3 dB range. P7R Receiver Setup 10.Attach the antenna to the ANTENNA connector. Use the red dot to align the threads. 11.Insert a 9V alkaline battery. 12.Set the DIP switches (See Dip Switches) 13.Set the channel to the same one as the transmitter. 14.Set the balance control to the center detent position. 15.Plug in the earphones and insert the earphones into your ears. 16.Turn the receiver on by rotating the volume dial clockwise past the click. NOTE: If you do not hear anything, check the RF LED on the transmitter to make sure it is receiving the radio signal from the transmitter. ÑÑÑÑÑÑÑÑÑÑÑÑ 1. 2. 3. 5. 4. 6. 7. 9. 8. 10. 11. 12. 13. 14. 15. 16. Refer to the Troubleshooting section of this manual if you encounter any problems. LOWER THE VOLUME before troubleshooting the problem. English - 3 Components P7T Transmitter with rack-mounting hardware and detachable PA7 15 antenna P7R Body-Pack Receiver with detachable PA71 0 antenna E1 or E5 Earphones with foam and flex-tip inserts Features • UHF operation. • Stereo or MixMode™ control for custom monitor mixes. • 32 user-selectable frequencies per system. • Up to 16 compatible frequencies for 16 different mixes. • Frequency compatible with all Shure Wireless systems (country dependent). • MPX Stereo audio transmission. • Switchable high-frequency boost on P7R. • +4 dBu and –10 dBV input level select switch on P7T. • Electronically balanced, combined 1/4-in. and XLR connectors on P7T can be used with balanced or unbalanced outputs. • Volume and Balance dials on the P7R Receiver. •…
Text truncated - open the document above for the full version.
Microphones and Audio Electronics SHURE Incorporated 5800 Touhy Avenue Niles, IL 60714 – 4608 • USA Phone: 847-600-2000 FAX: 847-600-1212 Web Address: www.shure.com July 7, 2003 American TCB, Inc. 6731 Whittier Avenue McLean, VA 22101 Subject: Request for Non disclosure for FCC ID: DD4P7TB To Whom It May Concern: Pursuant to 47 CFR Section 0.459, Shure Incorporated hereby requests non- disclosure and confidential treatment of the following materials submitted in support of FCC certification application for FCC ID # DD4P7TB: a. Schematic Diagrams b. Operational Description c. Block Diagram Above materials contain trade secrets, proprietary and technical information which would customarily be guarded from competitors under 47 CFR section 0.457(d)(2). Disclosure or publication of any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Shure Incorporated understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Sincerely yours, Edgar C. Reihl Director, Global Compliance Shure Incorporated
American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 July 7, 2003 RE: FCC ID: DD4P7TB_ATCB000564 Attention: Mark Mastroianni / Edgar C. Reihl, I have a few comments on this Application. 1. Report section 2.1 (Summary of Test Results) states on page 4 of the report, “that the device was done in accordance with the Filing and Measurement Guidelines for Frequency Hopping Spread Spectrum Systems DA 00-705 and Appendix A “BLUETOOTH APPROVALS.” Please note that this is a not a bluetooth device. This is a Part 74 device. Also, please note that test methods for licensed parts are to be done to EIA/TIA 603. Please correct the report to reflect the proper testing and test methods. xx 2. FYI – please note that the power listed in the limit table on page 9 of the report is listed as “Radiated”. Please note that the limit IAW 74.861(e)(1)(ii) is at the input of the antenna (i.e. conducted power). xx 3. Please provide information on the modulation used for the OBW plots. What was the input modulating frequency, etc. xx 4. Please note that all devices other that Part 15 and 18 require radiated field strength measurements in accordance with 2.1053. Please note that this is an antenna substitution measurement, not a part 15 field strength type measurement. Your explanation of radiated emissions provided on page 6 of the report is inadequate and incorrect. Please provide the proper antenna substitution data for radiated emissions of a part 74 device. xx 5. Please note that because of the apparent incorrect reference to the type of device (i.e. Bluetooth and not a part 74 device - see item 1) and because of the apparent incorrect use of ANSI C63.4 as a radiated emissions measurement method (see page 6 of the report), it is not clear if any of the testing was performed correctly. Please provide a brief description of the test methods used for the conducted antenna terminal measurements, the Occupied Bandwidth measurements and antenna substitution radiated spurious emissions measurements. Please also note that licensed devices must meet 47CFR part 2 as well as the specifics of the individual part under which a device is being certified (i.e. Part 74 for this device). Please make sure that all parts (2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055 and 2.1057) and any particular variation associated with Part 74 are properly addressed in the report. Also, please use the FCC accepted test methodology for licensed devices (i.e. TIA 603 as appropriate). xx 6. FYI – no action needed. Please note that the parts list is not classified as confidential. This exhibit will be listed on the FCC website and available for view to the public. If confidentiality is desired for the parts list, please include this on the request for confidentiality. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. z Page 2 July 7, 2003 Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.
CETECOM ICT Services GmbH Test report no.: 4_0989-01-03/03Issue Date: 23.05.2003Page 67 (77) Photographs of the equipment P7T Photograph no.: 1 CETECOM ICT Services GmbH Test report no.: 4_0989-01-03/03Issue Date: 23.05.2003Page 68 (77) Photographs of the equipment P7T Photograph no.: 2
CETECOM ICT Services GmbH Test report no.: 4_0989-01-03/03Issue Date: 23.05.2003Page 69 (77) Photographs of the equipment P7T Photograph no.: 3 CETECOM ICT Services GmbH Test report no.: 4_0989-01-03/03Issue Date: 23.05.2003Page 70 (77) Photographs of the equipment P7T Photograph no.: 4
Part TypeQtyDesignatorsDescriptionMfr #MfrSubtitutions 140A0051Y1CRYSTAL,QUARTZ,SMD,4MHzYuwa Corp (Japan) #SB-941007See Shure AVL for alternate vendors 140A111Y4CRYSTAL,QUARTZ,SMD,38kHzEpson America #MC-306-38.0000KA-K2SUBSTITUTIONS MUST BE APPROVED 140A261Y800CRYSTAL,QUARTZ,SMD,16MHzToyocom #TN4-25843SUBSTITUTIONS MUST BE APPROVED 145AF49901R205RESISTOR,SMD1206,499,1/4W,1%Dale #CRCW12064990FSee Shure AVL for alternate vendors 145BF10007R70 R71 R75 R76 R101 R140 R201RESISTOR,SMD 805,100,1/8W,1%NIC #NRC10F1000See Shure AVL for alternate vendors 145BF22R11R209RESISTOR,SMD 805,22.1,1/8W,1%NIC #NRC10F22R1See Shure AVL for alternate vendors 145BF49R95R61 R74 R93 R98 R99RESISTOR,SMD 805,49.9,1/8W,1%NIC #NRC10F49R9See Shure AVL for alternate vendors 145BJ0006R9 R100 R104 R213 R841 R842RESISTOR,SMD 805,0,1/8W,5%NIC #NRC10Z0See Shure AVL for alternate vendors 145BJ1R06R43 R182 R185 R186 R214 R215RESISTOR,SMD 805,1,1/8W,5%NIC #NRC10J1R0See Shure AVL for alternate vendors 145FF0005R33 R37 R39 R470 R570RESISTOR,SMD 603,000,1/10W,1%Dale #CRCW0603000ZSee Shure AVL for alternate vendors 145FF10001R28RESISTOR,SMD 603,100,1/10W,1%Dale #CRCW06031000FSee Shure AVL for alternate vendors 145FF100128R24 R25 R29 R56 R57 R58 R62 R65 R72 R73 R79 R86 R106 R107 R117 R122 R165 R176 R178 R400 R401 R410 R468 R500 R505 R510 R568 R806 RESISTOR,SMD 603,1K,1/10W,1%Dale #CRCW06031001FSee Shure AVL for alternate vendors 145FF100244R3 R4 R5 R7 R19 R21 R30 R31 R36 R42 R44 R45 R59 R64 R66 R119 R121 R134 R197 R220 R459 R462 R464 R466 R471 R475 R480 R481 R490 R491 R492 R493 R494 R503 R509 R557 R560 R562 R564 R571 R574 R580 R581 R845 RESISTOR,SMD 603,10K,1/10W,1%Dale #CRCW06031002FSee Shure AVL for alternate vendors 145FF100317R90 R91 R95 R163 R170 R172 R175 R194 R421 R465 R521 R563 R851 R853 R855 R856 R880 RESISTOR,SMD 603,100K,1/10W,1%Dale #CRCW06031003FSee Shure AVL for alternate vendors 145FF10046R88 R92 R94 R103 R423 R523RESISTOR,SMD 603,1M,1/10W,1%Dale #CRCW06031004FSee Shure AVL for alternate vendors 145FF10R03R196 R828 R890RESISTOR,SMD 603,10,1/10W,1%Dale #CRCW060310R0FSee Shure AVL for alternate vendors 145FF12122R54 R108RESISTOR,SMD 603,12.1K,1/10W,1%Dale #CRCW06031212FSee Shure AVL for alternate vendors 145FF13323R123 R477 R577RESISTOR,SMD 603,13.3K,1/10W,1%NIC #NRC06F1332See Shure AVL for alternate vendors 145FF15002R831 R832RESISTOR,SMD 603,150,1/10W,1%NIC #NRC06F1500See Shure AVL for alternate vendors 145FF15014R67 R82 R120 R144RESISTOR,SMD 603,1.5K,1/10W,1%Dale #CRCW06031501FSee Shure AVL for alternate vendors 145FF15024R80 R83 R450 R550RESISTOR,SMD 603,15K,1/10W,1%NIC #NRC06F1502See Shure AVL for alternate vendors 145FF16R55R820 R821 R824 R826 R827RESISTOR,SMD 603,16.5,1/10W,1%NIC #NRC06F16R5See Shure AVL for alternate vendors 145FF20015R49 R51 R153 R156 R200RESISTOR,SMD 603,2K,1/10W,1%Dale #CRCW06032001FSee Shure AVL for alternate vendors 145FF20025R55 R114 R118 R456 R554RESISTOR,SMD 603,20K,1/10W,1%Dale #CRCW06032002FSee Shure AVL for alternate vendors 145FF22101R221RESISTOR,SMD 603,221,1/10W,1%NIC #NRC06F2210See Shure AVL for alternate vendors 145FF22R12R807 R808RESISTOR,SMD 603,22.1,1/10W,1%NIC #NRC06F22R1See Shure AVL for alternate vendors 145FF24902R187 R190RESISTOR,SMD 603,249,1/10W,1%NIC #NRC06F2490See Shure AVL for alternate vendors 145FF24918R47 R48 R113 R115 R402 R403 R501 R506 RESISTOR,SMD 603,2.49K,1/10W,1%Dale #CRCW06032491FSee Shure AVL for alternate vendors 145FF24925R12 R18 R23 R34 R195RESISTOR,SMD 603,24.9K,1/10W,1%Dale #CRCW06032492FSee Shure AVL for alternate vendors 145FF24934R457 R458 R555 R556RESISTOR,SMD 603,249K,1/10W,1%Dale #CRCW06032493FSee Shure AVL for alternate vendors 145FF27422R112 R116RESISTOR,SMD 603,27.4K,1/10W,1%NIC #NRC06F2742See Shure AVL for alternate vendors 145FF30112R188 R192RESISTOR,SMD 603,3.01K,1/10W,1%Dale #CRCW06033011FSee Shure AVL for alternate vendors 145FF30122R422 R522RESISTOR,SMD 603,30.1K,1/10W,1%Dale #CRCW06033012FSee Shure AVL for alternate vendors 145FF30131R171RESISTOR,SMD 603,301K,1/10W,1%Dale #CRCW06033013FSee Shure AVL for alternate vendors 145FF33215R1 R2 R164 R504 R508RESISTOR,SMD 603,3.32K,1/10W,1%NIC #NRC06F3321See Shure AVL for alternate vendors 145FF33R21R830RESISTOR,SMD 603,33.2,1/10W,1%NIC #NRC06F33R2See Shure AVL for alternate vendors 145FF36511R68RESISTOR,SMD 603,3.65K,1/10W,1%NIC #NRC06F3651See Shure AVL for alternate vendors 145FF39211R223RESISTOR,SMD 603,3.92K,1/10W,1%NIC #NRC06F3921See Shure AVL for alternate vendors (90A8963C) P7T-H3 Rackmount Transmitter Shure Incorporated Confidential 07/03/2003Page 1 of 5 Part TypeQtyDesignatorsDescriptionMfr #MfrSubtitutions (90A8963C) P7T-H3 Rackmount Transmitter 145FF402112R26 R27 R35 R78 R85 R146 R173 R177 R181 R183 R455 R553 RESISTOR,SMD 603,4.02K,1/10W,1%NIC #NRC06F4021See Shure AVL for alternate vendors 145FF402215R50 R60 R63 R125 R198 R420 R461 R463 R469 R472 R520 R559 R561 R572 R573 RESISTOR,SMD 603,40.2K,1/10W,1%NIC #NRC06F4022See Shure AVL for alternate vendors 145FF43211R222RESISTOR,SMD 603,4.32K,1/10W,1%NIC #NRC06F4321See Shure AVL for alternate vendors 145FF49901R89RESISTOR,SMD 603,499,1/10W,1%Dale #CRCW06034990FSee Shure AVL for alternate vendors 145FF499113R6 R8 R20 R22 R53 R87 R203 R474 R478 R567 R575 R800 R881 RESISTOR,SMD 603,4.99K,1/10W,1%Dale #CRCW06034991FSee Shure AVL for alternate vendors 145FF499210R32 R38 R46 R404 R405 R502 R507 R817 R818 R819 RESISTOR,SMD 603,49.9K,1/10W,1%Dale #CRCW06034992FSee Shure AVL for alternate vendors 145FF49932R147 R801RESISTOR,SMD 603,499K,1/10W,1%Dale #CRCW06034993FSee Shure AVL for alternate vendors 145FF49R93R467 R565 R823RESISTOR,SMD 603,49.9,1/10W,1%NIC #NRC06F49R9See Shure AVL for alternate vendors 145FF60424R453 R460 R552 R558RESISTOR,SMD 603,60.4K,1/10W,1%NIC #NRC06F6042See Shure AVL for alternate vendors 145FF75001R69RESISTOR,SMD 603,750,1/10W,1%NIC #NRC06F7500See Shure AVL for alternate vendors 145FF75016R10 R17 R81 R84 R189 R191RESISTOR,SMD 603,7.5K,1/10W,1%NIC #NRC06F7501See Shure AVL for alternate vendors 145FF82511R802RESISTOR,SMD 603…
Text truncated - open the document above for the full version.
Microphones and Audio Electronics SHURE Incorporated 222 Hartrey Avenue Evanston, IL 60202 – 3696 • USA Phone: 847-866-2200 FAX: 847-866-2433 Web Address: www.shure.com RF SAFETY STATEMENT Date: 07/07/2003 Time: 9:30 AM To: American TCB, Inc. 6731 Whittier Avenue McLean, VA 22101 From: Edgar C. Reihl Phone: 847-866-2289 Director, Global Compliance Fax: 847-866-2456 Applicant: Shure Incorporated E-Mail: [email protected] ______________________________________________________________________ Dear Ladies and/or Gentlemen: The Shure Model P7TB PSM Transmitter is intended for rack mounted or table top operation only. It is not designed to be hand held or worn on the body. Dated this 7 th day of July, 2003. By: Edgar C. Reihl, P.E. Title: Director, Global Compliance Phone: 847-866-2289
CETECOM ICT Services GmbH Radio Satellite Communication Untertürkheimer Straße 6-10 . D-66117 SaarbrückenTelephon: +49 (0)681 598-0Telefax: -9075 RSC14issue test report consist of 78 PagesPage 1 (78) Recognized by the Federal Communications Commission FCC–Identification Number: 90462 TCB ID: DE 0001 Accredited by the German Accreditation Council DAR–Registration Number TTI–P–G 166/98 Independent ETSI compliance test house ETSI Accredited Bluetooth™ Test Facility (BQTF) Test Report No.: 4_0989-01-03/03 FCC Part 74.861 / CANADA RSS-123 P7T / P7R (PSM 700 Series) FCC ID : DD4P7TB CETECOM – ICT Services GmbH Untertürkheimerstr. 6-10 66117 Saarbrücken, Germany Telephone: + 49 (0) 681 / 598-0 Fax: + 49 (0) 681 / 589-9075 BLUETOOTH is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM CETECOM ICT Services GmbH Test report no.: 4_0989-01-03/03Issue Date: 23.05.2003Page 2 (78) Table of Contents 1 General Information 1.1 Notes 1.2 Testing Laboratory 1.3 Details of Applicant 1.4 Application Details 1.5 Test Item 1.6 Test Specifications 2 Technical Test 2.1 Summary of Test Results 2.2 Test Report CETECOM ICT Services GmbH Test report no.: 4_0989-01-03/03Issue Date: 23.05.2003Page 3 (78) 1 General Information 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. Test Laboratory Manager: 2003-07-11RSC8411Berg M. DateSectionNameSignature Technical Responsibility for Area of Testing: 2003-07-11RSC8412Hausknecht D. DateSectionNameSignature CETECOM ICT Services GmbH Test report no.: 4_0989-01-03/03Issue Date: 23.05.2003Page 4 (78) 1.2 Testing Laboratory CETECOM ICT Services GmbH Untertürkheimer Straße 6 - 10 66117 Saarbrücken Germany Telephone: + 49 681 598 - 0 Telefax : + 49 681 598 - 9075 E-mail: [email protected] Internet: www.cetecom-ict.de Accredited testing laboratory The Test laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025. DAR-registration number : TTI-P-G 166/98-30 Accredited Bluetooth™ Test Facility (BQTF) BLUETOOTH is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM 1.3Details of Applicant Name : SHURE Europe GmbH Street : Wannenäckerstrasse 28 City : D-74048 Heilbronn Country : Germany Telephone : +49 (0) 7131 72 14 0 Telefax : +49 (0) 7131 72 14 14 Contact : Mr. Wolfgang Bilz Telephone : +49 (0) 7131 72 14 34 1.4 Application Details Date of receipt of application : 2003-05-14 Date of receipt of test item : 2003-05-16 Date of test : 2003-05-16/19/20 CETECOM ICT Services GmbH Test report no.: 4_0989-01-03/03Issue Date: 23.05.2003Page 5 (78) 1.5 Test Item Type of equipment : In Ear Monitoring System Type designation: Tx: P7T and Rx: P7R (PSM 700 Series) Manufacturer: SHURE Inc. Street: 5800 West Toughy Avenue City: Niles, IL 60714-4608 Country: USA Serial number: -.- FCC-ID: DD4P7TB IC : - Hardware: H3, L2 Software : - Additional information : Frequency: L3= 632-663 MHz ; H2= 524-554 Type of modulation: 98K0F8E (2x max.Audio Frequency + 2x max. FM Deviation) Number of channels : 32 Antenna: BNC Power supply: Tx: 115C AC / 60 Hz; Rx: 9V DC Battery Output power: 110.2 mW Field strength: 87.0 dBμV/m at 3m Occupied bandwidth: max. 100 kHz Transmitter spurious : 46.4 dBμV/m at 3m (706.32 MHz) Receiver spurious. 43.1 dBμV/m at 3m (7522.2 MHz) Temperature range: -30°C - +50°C DECLARATION OF COMPLIANCE: I declare that the testing was performed or supervised by me; that the test measurements were made in accordance with the above-mentioned Industry Canada standard(s); and that the equipment identified in this application has been subjected to all the applicable test conditions specified in the Industry Canada standards and all of the requirements of the standard have been met. Signature: _______________________________________________ Date: ___2003-05-09 Michael Berg ; Test management NAME AND TITLE (Please print or type): 1.6 Test Specifications: FCC Part 74 Subpart H CANADA RSS-123 CETECOM ICT Services GmbH Test report no.: 4_0989-01-03/03Issue Date: 23.05.2003Page 6 (78) 2 Technical Test 2.1Summary of Test Results TEST PROCEDURE All tests were done in accordance with the EIA/TIA 603. FOR PART 74 H WE USE THE SUBSTITUTION METHOD ( TIA/EIA 603). The product fullfills also the requirements for CANADA RSS-123 No deviations from the technical specification(s) were ascertained in the course of the tests performed. Final verdict : PASS CETECOM ICT Services GmbH Test report no.: 4_0989-01-03/03Issue Date: 23.05.2003Page 7 (78) 2.2Testreport TEST REPORT Testreport no.: 4_0989-01-03/03 CETECOM ICT Services GmbH Test report no.: 4_0989-01-03/03Issue Date: 23.05.2003Page 8 (78) TEST REPORT REFERENCE LIST OF MEASUREMENTS PARAMETER TO BE MEASUREDPAGE OUTPUT POWER (conducted) FCC Rule Part 74.8619 AFC FREQ ERROR vs. VOLTAGE FCC Rule Part 74.86110 AFC FREQ ERROR vs. TEMPERATURE11 CHARACTERISTICS OF THE AUDIO MODULATION CIRCUITRY12 OCCUPIED BANDWIDTH FCC Rule Part 74.861(e)(3), (5)/ Sec. 2.98918 CONDUCTED EMISSIONS FCC 74 861(e)(6)31 Emission mask FCC 74 861(e)(6)38 RADIATED EMISSIONS FCC Rule Part 74 subpart H44 Conducted emissions § 15.107/20753 FCC Part 15 Subpart B (Receiver P7R)54 SPURIOUS RADIATION § 15.10955 TEST EQUIPMENT AND ANCILLARIES USED FOR TESTS63 Test setup65 Photographs of the equipment68 CETECOM ICT Services GmbH Test report no.: 4_0989-01-03/03Issue Date: 23.05.2003Page 9 (78) Equipment under test : P7T Ambient temperature : 23° °° °C Relative humidity : 50% REFERENCE NUMBER(S) OF TEST EQUIPMENT USED (for reference numbers see test equipment listing) 12 OUTPUT POWER (conducted)FCC Rul…
