DD4UT1BLo Power Body Pack Transmitter

1 UT S ER IES ENGLISH THE TWO MINUTE USER’S GUIDE 2:00 The instructions on this page will help you get your UT Series system up and running in minutes. For more detailed instructions, read the section of this manual that applies to your system. RECEIVER SETUP 1. Connect the supplied ac power adapter to the DC INPUT connector on the back of the receiver. Insert the adapter’s cable into the power cable retainer on the bottom of the unit. Plug the adapter into a wall socket or other electrical outlet. The green POWER light on the receiver will glow. 2. If you are using The Guitarist-UHF, connect the receiver output to a guitar am- plifier using any standard guitar cable. If you are using The Vocal Artist-UHF, The Headset-UHF, or The Presenter-UHF, connect the receiver output to an audio mixer using an XLR to XLR audio cable. 3. Raise the antennas and point away from each other at a 45° angle from vertical. TRANSMITTER SETUP 1. Open the transmitter battery compartment and install a 9 V battery. Observe proper battery polarity (“+/–”). 2. If you are using The Vocal Artist-UHF, no further transmitter setup is required. 3. If you are using a body-pack transmitter (The Presenter-UHF, The Headset-UHF or The Guitarist-UHF), plug the microphone cable or a WA302 instrument cable into the four-pin connector on the transmitter (if using The Headset-UHF, see tag on headset for assembly instructions). If using The Guitarist-UHF, plug the instru- ment cable into the guitar output and adjust the volume control of the guitar. OPERATING THE SYSTEM 1. Slide the transmitter POWER/OFF switch to the POWER position. The transmitter’s green POWER light and the receiver’s yellow DIVERSITY A/B lights will glow. 2. Slide the MUTE/ON switch on the body-pack or hand-held transmitter to the ON position. 3. Talk or sing into the microphone, or play your guitar. The receiver’s red AUDIO PEAK light should flicker when loud sounds are transmitted. If the AUDIO PEAK light does not flicker or stays on constantly, the transmitter gain may need adjustment. (Refer to the Transmitter Audio Gain Adjustment section). NOTE: This step is particularly important for The Guitarist system, since guitar outputs can vary widely. 4. Adjust the receiver VOLUME control until the receiver output level matches the level of your guitar or microphone through a cable. (The factory setting is in the full clockwise position.) If using The Guitarist-UHF system, see Receiver Volume Adjustment for The Guitarist-UHF to match the receiver volume level to the level of a wired system. benefit YOU ARE NOW READY TO PERFORM! IMPORTANT: Every wireless performance is a unique situation, and can present a vari- ety of problems. Never attempt a performance without first conducting a “walkthrough” test on the wireless system in the performing area. If you encounter a problem, refer to the Troubleshooting table. 2 ENGLISH THANK YOU FOR CHOOSING SHURE Congratulations! You have purchased the finest wireless system in its class. Your Shure wireless system is engineered to provide a low-noise, high-quality sound comparable to other systems costing much more. Built in the tradition of reliability that has made Shure a symbol of American quali- ty for more than half a century, this wireless system should provide you with excellent performance for years. To get the most out of your UT Series wireless system, please read the applicable section in this guide before you attempt to use the system. If you have any questions that are not answered in this booklet, please contact Shure Customer Service at (847) 866-2553, Monday through Friday, from 8:00 am to 4:30 pm, Central Standard Time. For technical data by fax, dial (800)488-3297 and follow the recorded directions. Visit our website at www.shure.com for further information on this and other Shure products. INTRODUCTION Your new UT Series system is designed to give you the best of both sound reinforce- ment worlds: the freedom of a wireless system, and the reliability of world-famous Shure sound quality. This manual covers each of the UT Series systems: The Vocal Artist-UHF, The Presenter-UHF, The Headset-UHF, and The Guitarist-UHF. SYSTEM FEATURES All Shure UT Series systems offer a variety of of exceptional features, including: •Diversity Receivers with Exclusive Shure MARCAD Circuitry: MARCAD (MAximum Ratio Combining Audio Diversity) circuitry continuously processes the rf signal from each antenna and combines the audio outputs to produce one signal of optimum quality. The result is improved reception and exceptional free- dom from dropouts. •Low-Traffic UHF Transmission: UT systems use a UHF (Ultra High Frequen- cy) range between approximately 596 to 862 MHz (available frequencies de- pend on regulations in the country where the system is used). In urban areas, UHF frequencies are less congested than those in the VHF range, and are less susceptible to interference. •Multiple System Use: Up to eight UT systems can be used in the same perfor- mance space. Each system must be set at a different frequency. If systems are set to the same frequency, contact an authorized Shure dealer. NOTE: In multi- ple use situations, each transmitter must have a dedicated receiver. •Simultaneous Output Use: Unbalanced 1 / 4 ” phone plug and balanced XLR output connectors may be used simultaneously to different external devices. •Stackable and Rack-Mountable Receivers: If multiple systems are in use, re- ceivers may either be stacked or rack-mounted, with two receivers fitting in the optional rack mount tray. In these situations, antennas should not touch or be crossed. (See Stacking and Rack-mounting Receivers.) •Range: UT Series transmitters will work at a distance of up to 100 meters (about 300 ft.) from the receiver. •Noise Squelch: The noise squelch circuit analyzes signal quality instead of sig- nal strength, which allows the circuit to discriminate between noise and desired signal. This reduces the likelihood of noise burst due t…

Text truncated - open the document above for the full version.

UT1B & UT2B Block DiagramMicrophone input Switchableattenuatio n Pre-em p hasis Compandor Limiter Crystal OSC/x4 Amp Buffer Tripler Buffer Tripler BPF Buffer

Cover Letter UT1B FCC ID:DD4UT1B Federal Communications Commission Equipment Approval Services September 30,1999 Dear Ladies and Gentleman: We at Shure Inc are submitting a body pack transmitter, having a Model Number of UT1B, and a FCC ID Number DD4UT1B for Type Acceptance . This unit has been tested at DLS Electronic Systems Inc. and found to be in compliance with Part 74, Subpart H. Any Questions regarding this report should be directed to Edgar C. Reihl P.E. at (847) 866-2289 or [email protected]. In an effort to reduce the file size I removed some of the photos that I thought to be superfluous. Should it be required, these photos are available for submission. I thank you for your assistance in this matter. Sincerely Yours Albert Wahout Development Engineer 1 (847)866-2654 [email protected]

General Product Description The Shure UT1B is a low cost wireless bodypack transmitter designed for the Music industry (MI) market. The UT1B is a single frequency, crystal controlled transmitter with a 9 volt battery for power supply. The frequency range for the UT1B is 740 to 752 MHz. ISpecial Features 1.Power on/off LED to indicate the operating status of the transmitter. 2.Low profile on/off power switch prevents accidental turn-off. 3.Input attenuation switch 4.Low battery indicator to inform the user when to change the battery. 5.Mute Switch to provide audio on /off function. 6.Tini QG microphone connector allows the users to choose a variety of headset or lavalier microphones offered by Shure. 7. Adjustable gain allows use with high or low impedance microphones. 8. May be used with dynamic or condenser type microphones. 9. Electronic circuitry prevents damage to the unit if the user installs the battery reversed.

Description:UT1 Bodypack TransmitterDRWG. UT1-7 Refer To Drawing NOS. 90-8786-11 Page 1 of 11 SSRecord of Changes Made 1.Production Release 2ECO 81417: Modified audio limits on page 2 & 4 5ECO 81646: added C218 for groupA 3ECO 81525: Added new adjustment for export models 4ECO 81646: remove C251, added C218 for groupB Exp Dwg. No: Used in: SHURE BROTHERS INC. 222 HARTREY AVENUE EVANSTON, IL 60202 PHONE 847-866-2200 Microphones-Electronic Components Typed: Anny Liao Checked: Approved: Kevin Mikes Approved: Shure Model UT1 T-series UHF Bodypack Transmitter Project #16996 Outline General Product Description I Special Features II Circuit Description III Test Equipment IV Alignment Procedure V Test for Product Acceptance VI Agency Approvals VII Mechanical Specification VIII Environmental Specification IX Service Evaluation General Product Description The Shure UT1 is a low cost wireless bodypack transmitter designed for the Music industry (MI) market. The UT1 is a single frequency, crystal controlled transmitter with a 9 volt battery for power supply. The frequency range for the UT1 is 596 to 608, 614 to 626, 740 to 752 and 800 to 862 MHz. I Special Features 1. Power on/off LED to indicate the operating status of the transmitter. 2. Low profile on/off power switch prevents accidental turn-off. 3. Input attenuation switch 4. Low battery indicator to inform the user when to change the battery. 5. Mute Switch to provide audio on /off function. 6. Tini QG microphone connector allows the users to choose a variety of headset or lavalier microphones offered by Shure. 7. Adjustable gain allows use with high or low impedance microphones. 8. May be used with dynamic or condenser type microphones. 9. Electronic circuitry prevents damage to the unit if the user installs the battery reversed. II Circuit Description Audio Section Signals Audio signals enter the UT1 through a 4 pin Tini QG jack. Pin 1 is a ground, pin 2 supplies regulated 5 Vdc bias for electret condenser Description:UT1 Bodypack TransmitterDRWG. UT1-7 Refer To Drawing NOS. 90-8786-11 Page 2 of 11 SSRecord of Changes Made 1.Production Release 2ECO 81417: Modified audio limits on page 2 & 4 5ECO 81646: added C218 for groupA 3ECO 81525: Added new adjustment for export models 4ECO 81646: remove C251, added C218 for groupB Exp Dwg. No: Used in: SHURE BROTHERS INC. 222 HARTREY AVENUE EVANSTON, IL 60202 PHONE 847-866-2200 Microphones-Electronic Components Typed: Anny Liao Checked: Approved: Kevin Mikes Approved: microphone, pin 3 is the audio input, and pin 4 is a 20 kΩload resistor connected to pin 3 for electret microphones. The audio signals then pass through a switch (SW103) which engages and disengages a 20 dB pad. The pad is engaged when very large signals are expected at the input. An example would be those produced by an instrument with very sensitive or active pickups. Next, the audio signal enters a preamplifier stage consisting of one section of op amp (U102D). The voltage gain of this stage may be adjusted over a 32 dB range by means of an externally-accessible potentiometer (R105). This enables the user to compensate for level difference at the source. The output signal is then attenuated via a voltage divider (R150 and R151) to match the input range of the compandor. Pre-emphasis Stage The preamplified audio signal is then passed through a passive pre- emphasis network consisting of R100, C105, C106, R110, and R111. Audio Signal Compression The signal next enters the NE571D integrated circuit compandor (U101B), providing a 2:1 logarithmic compression of the audio signal. A lower noise floor is achieved with the assistance of U102A. An internal potentiometer (R139) is provided for nulling system audio distortion. Op amp U102B operates as a 2-pole active low pass filter to restrict the bandwidth of the system to audio frequencies. The NE571D also contains an identical second channel (U101A) that is used to supply regulated, low-noise 5 Vdc bias to various audio and RF circuit points. RF section Processed Audio enters R207, an internal potentiometer adjusted for 45 kHz deviation (100 % modulation) with a +0.3 dBV (2.5 dBu), 1 kHz tone at the output of the audio section. The audio is then fed to varactor diode D201, which is part of the modulated oscillator-tripler stage (Q201)(see note). The base-emitter circuit of Q201 operates as a crystal-controlled Colpitts oscillator in the 20 MHz region. Fundamental-mode crystal Y201 is tuned to 10 kHz below series resonance by the series combination of frequency-netting coil L211, diode D201, capacitor C225, and feedback capacitors C220 and C229. Frequency Stability Description:UT1 Bodypack TransmitterDRWG. UT1-7 Refer To Drawing NOS. 90-8786-11 Page 3 of 11 SSRecord of Changes Made 1.Production Release 2ECO 81417: Modified audio limits on page 2 & 4 5ECO 81646: added C218 for groupA 3ECO 81525: Added new adjustment for export models 4ECO 81646: remove C251, added C218 for groupB Exp Dwg. No: Used in: SHURE BROTHERS INC. 222 HARTREY AVENUE EVANSTON, IL 60202 PHONE 847-866-2200 Microphones-Electronic Components Typed: Anny Liao Checked: Approved: Kevin Mikes Approved: To ensure frequency stability with changes in battery voltage, regulated 5 Vdc bias is applied to the varactor diode and to the base of Q201. C220 and C229 provide temperature compensation. The collector circuit of Q201 is tuned to the third harmonic of the oscillator frequency (approximately 67 MHz) by means of L205, C214, and C239. C217 couples RF energy to a second tuned circuit consisting of L212, C235, C240 and C227, which also forms a capacitively-tapped voltage divider for matching into the base of Q202, operating as a buffer amplifier. Note: For UT1’s operating in the 800 MHz range, the tank circuitry of Q201 is tuned to the fourth harmonic of the oscillator (Approximately 90 MHz). Frequency Tripler and Buffer The third stage (Q203) is operated as a frequency tripler with the collector circuit tuned to the intermediate frequ…

Text truncated - open the document above for the full version.

R201 4.99 k Ω +9 V @ 30 mA UT 1 RF Board (from 90_8786K-11) Notes:1. All resistors are in ohms, 1 / 16 W, 1%, 0603 unless otherwise specified. 2. All non-polarized capacitors are shown in μ Fd and have a 10% tolerance and a w 50 V rating unless otherwise specified. Electrolytic capacitors are shown in μ F  volts. 3. The symbol indicates a PC board ground. 4. The values for frequency-dependent components, indicated by asterisks ( * ), are in the table. 5. “ NS ” means “not stuffed” (not used, intended for future use). 6. The bolded designations “Carrier Freq.,” “Deviation,” and “Rf Pwr.” mark adjustment points.7. For the initial domestic units, which can be identified by the “F” level pcb, see the variable- parts table preceding the fold-out schematics. E 1999, Shure Brothers Inc. 25A1046 (SB) TP204 P20156A8042 12 TP212 P20256A8042 +5 V @ 1 mA 12 TP201 C205.01 μ F R207 10 k Ω 31 2 2.2 μ F C212 R206 49.9 k Ω 31 2 D201 TP202 C2231000 pF 7 L211 8 13 R209150 k Ω 1 3 2 Y201 C225 22 μ F + C2031000 pF 162A12 LF201 C2011000 pF R202 20 k Ω L205 180 nH C214 1 2 3 9V MMBTH10L 1.3 V 0.6 V C220 47 pF C217 C239 1000 pF C206 C235 C240 C22968 pF TP213 L212 180 nH R2087.5 k Ω R210 750 Ω C227 220 pF R21220 k Ω 1.55 V C204 1000 pF R20430.1 k Ω L207 180 nH LF204 162A12 C221 C222 C237 TP217 C241 C210 C274 C242 MMBTH10L 9V 0.8 V 3 1 2 I216 R216 C236 1000 pF C273220 pF L213 180 nH C230 220 pF R21310 k Ω R20330.1 k Ω LF202 162A12 L208 + C218 C243 C211 C260220 pF 1.13 V 9V 0.42 V MMBTH10L 1 3 2 I218 C233 C238 C279 NS L214 C231 R214 301 Ω C275220 pF 1000 pF C226 R211 20 k Ω R215 301 Ω MMBTH10L 0.92 V 1 2 I223 1.66 V 9V 3 R205 30.1 k Ω L206 LF203 162A12 C2021000 pF C207 1000 pF + C208 NS C245 C209 NS C261220 pF R217 30.1 k Ω C216 1pF C234 + C280 1.15 V 1 9V 3 0.44 V TP230 AT41533 2 I225 L210 C232 220 pF C276 1000 pF C224 R218 10 k Ω R219 200 Ω C250 .01 μ F C277 NS L2175nH C249 + C282 1 1.55 V 2 3 + L216 5nH C246 C281 C248NS C262220 pF LF215 162A12 C2361000 pF LF220 162A12 9V C266 0.1 μ F C267 NS L223 C283NS R220 4.99 k Ω 0.85 V L222 C285 AT41533 C25268 pF R221 2.49 kΩ R222 68.1Ω C268 TP234 I227 L224 C271 C270 0.1μF C278 NS C269 Ant 1 TPTRFTP235 1 23 21 3 Gnd Gnd Gnd Out In BPF 4 8 F201 765 Gnd Gnd Gnd TP5 0 Ω R5 TP7 R8 0 Ω TP8 0 Ω R6 0 Ω R7 TP6TP1 0 Ω R223 TP3 R226 0 Ω TP4 0 Ω 0 Ω R224 TP2 R225 162B27 15 800–820 MHz E 162A27 15 614–620 MHz B 162A27 15 596–608 MHz A Group Frequency Range C214C221 pF F201 Part No. 162A27 15 620–626 MHz C 854–862 MHz H 151215 C224 pF 12 C226 pF 27686868 C235C237 pF 12202020 6.8 1512 C238 pF 15 4.7 1012 C240 pF 10 L206, L208L210, L214 nH 33565656 L222 nH 22 not usednot usednot used L223 nH 180220220220 1.5 1212 C241 pF 12 4.78.2 12 C242 pF 10 not used 8.28.2 C243 pF 8.2 C246 p.no. 152C04152C04152C04152C04 C268 pF 27 not usednot usednot used C270 pF not used 1.51.51.5 C271 pF not used 5.65.65.6 not used 4747 C285 pF 47 162B27 C210 C211 pF 1000 not usednot usednot usednot used 12 111 C217C222 pF 1 0.5 15 27 15 1111 0.5 8.2 not used 1212 C239 pF 12 1.5 not used 1.5 not used not used 6.8 6.88.2 C245 pF 6.8 6.8 152A04 C234 p.no. not usednot usednot usednot used 152A04 27 not used 1 C281 pF not used 5.65.65.6 not used C282 pF 3.3 not usednot usednot used 3.3 not used 33 22 180 Frequency-Dependent Parts Deviation Carrier Freq. Crystal * * * * * ** * * * ** * * * * * * Rf Pwr. * Rf Pwr. Rf Pwr. * * * * * * * ** * * * * * * 0.5 0.50.5 C249 pF 0.5 1 0.50.50.5 C272 pF 0.5 1 Q206 Q205 C272 C251 Q204 Q203 Q202 Q201 * ** L224 nH not used 222222 not used 121515 C280 pF 1510 C233 pF * * * * C251 p.no. not used 152C04152C04152C04 not used 220 not usednot usednot usednot used C274 pF C218 p.no. 152C04 not usednot usednot used 152C04 * EGDB FA HC

+9 V Audio R107 60.4 k Ω I121 C102 1 μ F 16 V + R10849.9 k Ω I175 R146 1M Ω C129 680 pF R101 1M Ω 1 SW103 55A168 2 C104 0.33 μ F 3 I177 C131 .0068 μ F R143 100 k Ω TP 103 I161 R301 20 k Ω 3 4 1 I162 MGnd J30195A8188 R302 499 Ω I119 I160 I165 2 R303 499 Ω C302 33 pF MGnd C301 33 pF I163 95A8622 J2 123 95A8622 J1 123 AGnd I168 TP 102 +5 V 0.1 μ F C111 R1021k Ω I122 3 C135 680 pF C103 33 pF 10 D101 184A08 MMBD7000L 12 I124 U102D +– 9 MC33179D 188A49 Gain TP 120 8 R105 100 k Ω 46F8008 CW C130 47 pF I126 R1032.49 k Ω + C10110 μ F NA I178 R150 604 Ω R151750 Ω R100 2k Ω I128 C105 0.33 μ F I129 0.0033 μ F C106 I130 R110 100 k Ω R111 2k Ω +5 V I131 1213 U102C + MC33179D 188A49 – 14 I139 R116 10 k Ω C11247 μ F + C11347 μ F + I133 R117 4.99 k Ω 7 C134 33 pF 6 U102B MC33179D 188A49 +– I132 5 + C108 1 μ F 16 V R113 24.9 k Ω R11224.9 k Ω 5 G U101A 188A01 –+ 673 + C1154.7 μ F 16 V + C1251 μ F 16 V I135 I176 2 I136 R144 40.2 k Ω C132 .0068 μ F R11575 k Ω I127 2 8 1 N137 R114 60.4 k Ω C109 1 μ F 16 V + I137 C11033 pF +5 V +5 V C1 1 μ F 16 V I166 + R140 10 k Ω Distortion I167 3 1 R141 10 k Ω R13920 k Ω 146F02 I145 C116 4.7 μ F 16 V + 2 3 1 I153 Q101 MMBT5087L R119 1k Ω I152 2.49 k Ω R120 +5 V R121 I151 I150 1 2 1k Ω R122 3 Q102 MMBT5087L The circuitry inside these dashed lines is onlyon European units. C1174.7 μ F 16 V + 1 I149 R123 10 k Ω I143 C1182200 pF I148 C119 330 pF 23 I144 + C114 1 μ F 16 V R126 402 k Ω R124 12.1 k Ω +– U102A MC33179D 188A49 I141 R125 10 k Ω I134 + C120 4.7 μ F 16 V +5 V R118100 k Ω I146 R127 249 Ω C121 + 4.7 μ F 16 V I171 Audio to RF Audio to RF 1 12 45 3 6 7 8 SW102 55A8096 +5 V I105 11 R129 13.3 k Ω 1014 U101B 188A01 15 G +– 12 I154 16 9 R128 49.9 k Ω R130 100 Ω I156 C12733 pF LF102 +5 V to RF TP 142 +9 V Audio 13 4 U101C 188A01 +9 V Audio C10733 pF 4 11 V+V– U102E 188A49 MC33179D 2 R133 3.32 k Ω TP 101 I109 J104 56A8066 AGnd 2 LF103 1 I110 1 I111 3 1 Q104 MMBT5089L 2 I164 3 Q105 MMBT5088L 1 I114 R138 6.81 k Ω C12833 pF 2 3 Q106 MMBT5088L I115 24 Bottom To p D102 86B8437 Red Green 13 I116 R135 4.02 k Ω I112 R1346.81 k Ω I172 R13720 k Ω R14520 k Ω R131 30.1 k Ω I157 R13220 k Ω 1 I159 1 2 Q103 MMBT404AL LF101 TP 107 +9 V Audio C12433 pF + 21 TP 104 J101 56A8041 3 +9 V to RF Audio to RF 2 C1234.7 μ F 16 V SW101 55A168 2 3 I108 J103 56A8066 Notes:1. All resistors are 1 / 16 W, 1%, 0603 unless otherwise specified. 2. Electrolytic capacitors are shown in μ F and volts. Unless otherwise specified, all non-polarized capacitors have a w 50 V rating and a 10% tolerance. 3. The symbol indicates a PC board ground. 4. DZ 1 was not placed on the pre-1999 domestic boards (34A8589F). E 1999, Shure Brothers Inc. 25A1046 (SB) UT 1 Audio Board (from 90_8786 K -11) J102 56A8041 C12233 pF I106 Atten. Power Battery +9 V Battery Gnd. +5 V Mute 2.49 k Ω DZ1 13 __2 MMBZ5252BL The circuitry inside these dashedlines is on the mic-jack pcb.

EMC Test ServicesReport No. 7582 1250 Peterson Drive, Wheeling, Illinois 60090, USA09/22/99 Page 1 TEST SPECIFICATION: FCC "Rules and Regulations", Part 74, Experimental Radio, Auxiliary, Special Broadcast and Other Program Distribution Services for Operation in the 614 to 806 MHz Band Subpart H, Low Power Auxiliary Stations Sections 74.801 to 74.882 THE FOLLOWING MEETS THE ABOVE TEST SPECIFICATION Formal Name:UT1 Body Pack UHF Transmitter Kind of Equipment:Body Pack Transmitter Test Configuration:Single frequency crystal controlled. Emission Designator:120KF3B Transmitter FCC ID:DD4UT1 Model Number: UT1 Serial Number: NA Dates of Test:August 20, 1999 Test Conducted For:Shure, Inc. 222 Hartrey Avenue Evanston, Illinois 60202-3696 NOTICE:Please see change information listed inside of this report. This report must not be used by the customer to claim product endorsement by NVLAP or any agency of the United States Government, and it cannot be reproduced (except in full), without the approval of D.L.S. Electronic Systems Inc. EMC Test ServicesReport No. 7582 1250 Peterson Drive, Wheeling, Illinois 60090, USA09/22/99 Page 2 SIGNATURE PAGE Report Written By: Arnom C. Rowe Test Engineer EMC-001375-NE Report Reviewed by: Jack Prawica Lab Manager Report Approved by: Brian J. Mattson General Manager Company Official: Shure, Inc. Page 3 Page 4 EMC Test ServicesReport No. 7582 1250 Peterson Drive, Wheeling, Illinois 60090, USA09/22/99 Page 5 1.Cover Pagei 2.Signature Pageii 3.NBS Certificate of Accreditationiii 5.Table of Contentsiv 7.Summary of Test Report1.0 7.Introduction2.0 7.Object3.0 7.Test Set-up4.0 8.Test Equipment (Bandwidths and Detector Function)5.0 8.RF Power Output6.0 9.Graphs taken of the RF Power Output Measurements6.0 14.Modulation Characteristics7.0 15.Graphs taken of the Modulation Characteristics7.0 18.Occupied Bandwidth8.0 19.Graphs taken of the Occupied Bandwidth8.0 20.Frequency Deviation9.0 21.Graphs taken of the Frequency Deviation9.0 22.Spurious Emission Measurements at Antenna Terminals10.0 23.Conducted Emission Data taken10.0 24.Conducted Emission Graphs Taken10.0 EMC Test ServicesReport No. 7582 1250 Peterson Drive, Wheeling, Illinois 60090, USA09/22/99 Page 6 25.Field Strength of Spurious Emission Measurements11.0 27.Radiated Data taken for Field Strength Measurements11.0 32.Radiated Graphs taken for Field Strength Measurements11.0 50.Frequency Stability (Temperature)12.0 51.Graphs taken of Frequency Stability (Temperature)12.0 62.Frequency Stability (Voltage Variation)13.0 63.Photo Information and Test Set-Up14.0 64.Photos Taken During Testing15.0 68.Change Information16.0 70.Results of Tests17.0 70.Conclusion18.0 71.Equipment ListTABLE 1 EMC Test ServicesReport No. 7582 1250 Peterson Drive, Wheeling, Illinois 60090, USA09/22/99 Page 7 1.0SUMMARY OF TEST REPORT It was found that the UT1 Body Pack UHF Transmitter S/N NA meets the radio interference emission requirements of the FCC "Rules and Regulations", Part 74, Subpart H, Sections 74.801 to 74.882 for Low Power Auxiliary Stations operating in the 740 to 752 MHz Frequency Band. 2.0INTRODUCTION On August 20, 1999, a series of radio frequency interference measurements were performed on Body Pack Transmitter, S/N NA. The tests were performed according to the procedures of FCC as stated in Part 2 Subpart J, Equipment Authorization Procedures of the Code of Federal Regulations 47, by personnel of D.L.S. Electronic Systems, Inc. who are responsible to Donald L. Sweeney, Senior EMC Engineer. 3.0OBJECT The purpose of this series of tests was to determine if the test sample could meet the radio frequency emission requirements of the FCC "Rules and Regulations", Part 74, Subpart H, Sections 74.801 to 74.882 for Low Power Auxiliary Stations operating in the 740 to 752 MHz Frequency Band. 4.0TEST SET-UP All radiated emission tests were performed at D.L.S. Electronic Systems, Inc. The radiated tests were made with the test item placed on a wooden turntable located in the Test Room with the receive antenna placed one meter from the device under test. EMC Test ServicesReport No. 7582 1250 Peterson Drive, Wheeling, Illinois 60090, USA09/22/99 Page 8 5.0TEST EQUIPMENT (Bandwidths and Detector Function) All data was automatically plotted using peak detector function. This information was then used to determine the frequencies of maximum emissions. Manual measurements were performed on these frequencies using a peak detector function of the Analyzer with the bandwidths specified by the FCC. From 200 MHz to 1000 MHz a bandwidth of 100 kHz was used (except for Occupied Bandwidth), and above 1000 MHz, wide enough bandwidths were used, depending upon the test being made, to ensure proper measurement of the narrowband signal. A list of the equipment used can be found in Table 1. All equipment was calibrated per the instruction manuals supplied by the manufacturer. 6.0RF POWER OUTPUT - PART 2.1046 As stated in PART 74.861 (e-1), the output power should not exceed 250 milliwatts (24 dBm). The UT1 Body Pack UHF Transmitter was tuned according to the tune-up procedures specified in Part 2.1033 (c-9), and adjusted for its maximum output power. The RF output power was measured in the open field, using the following test method: Substitution Method: The radiated signal from the EUT was measured. The EUT was then substituted with a signal generator and a tuned dipole antenna. The output of the signal generator was increased until the level received by the tuned dipole equaled that of the previous measurement from the EUT. Measurement made: 117.6 dBuV which equals 0.0115 watts MARGIN: 0.01 watts - 0.0115 watts = -0.0015 watts LIMIT: Manufacturer's rated output power = 0.01 watts Tolerance = .005% NOTE: See the following pages for the graphs of the actual measurements made: EMC Test ServicesReport No. 7582 1250 Peterson Drive, Wheeling, Illinois 60090, USA09/22/99 Page 9 GRAPHS TAKEN OF THE RF POWER OUTPUT MEASUREMENTS PART 2.1046 EMC Test ServicesRepor…

Text truncated - open the document above for the full version.

UT1B (740-752MHz) Input Level Vs Deviation 05 101520253035404550556065707580 -40 -30 -20 -10 0 Input Level dBV +/-kHz Deviation 80Hz500Hz2.5kHz10kHz15kHz

UT1B (740-752MHz) Modulation vs Frequency for 100mV RMS Input 05 1015202530354045505560657075 20Hz 200Hz 2kHz 4kHz 6kHz 8kHz 10kHz 12kHz 14kHz 16kHz 18kHz 20kHz Frequency Deviation kHz

Instrument calibration: Tektronix 492AP Spectrum Analyzer. Serial #B010123 Calibrated August 11,1999 Due August 11,2000 Boonton 8200 Modulation Analyzer. Serial #20802BG Calibrated June 25,1999 Due June 25,2000 H/P 7475A Plotter. Calibration not required. Krohn-Hite 4300A Audio Oscillator Calibration not required. Beckman 320B Voltmeter Serial #70512899 Calibrated Nov. 1998 Due Nov. 1999 H/P 6218A Power Supply Calibration not required.

FCC ID: DD4UT1B LIST OF CRYSTAL FREQUENCIES The following is a list of crystal frequencies used in the Transmitter Model No: UT1B The UT1B has a single crystal that is 1/36 th of the carrier frequency –10kHz. Thus for 740MHz the crystal will be 740 divided by 36= 20.55555556MHz –10kHz = 20.54555556MHz.

EMC Test ServicesReport No. 7582 1250 Peterson Drive, Wheeling, Illinois 60090, USA09/22/99 Page 25 11.0FIELD STRENGTH OF SPURIOUS EMISSION MEASUREMENTS PART 2.1053 Radiated measurements were performed at a 1 or 3 meter test distance automatically scanning the frequency range from 200 MHz to 10000 MHz, depending upon the fundamental frequency. For the UT1 Body Pack UHF Transmitter, the highest fundamental frequency is 752 MHz so the scans were made up to 10000 MHz, to cover the tenth harmonic. All signals in the frequency range of 30 MHz to 200 MHz were measured with a Biconical Antenna and from 200 MHz to 1000 MHz a Log Periodic Antenna was used as the pickup devices. From 1000 MHz to 10000 MHz, a Double Ridge Horn Antenna was used. The cables and equipment were placed and moved within the range of positions likely to find their maximum emissions. Tests were made in both the horizontal and vertical planes of polarization. The allowed emissions for transmitters operating in the 740 to 752 MHz bands for UT1 Body Pack UHF Transmitter equipment are found under Part 74, Section 74.861, Paragraph e-6 for Low Power Auxiliary Stations. This paragraph states the mean power of the emissions shall be attenuated below the mean output power of the transmitter in accordance with the following schedule: (1)On any frequency removed from the operating frequency by more than 50 percent up to and including 100 percent of the authorized bandwidth: at least 25 dB. (2)On any frequency removed from the operating frequency by more than 100 percent up to and including 250 percent of the authorized bandwidth: at least 35 dB. (3)On any frequency removed from the operating frequency by more than 250 percent of the authorized bandwidth: at least 43+10Log10 (mean output power in watts) dB. EMC Test ServicesReport No. 7582 1250 Peterson Drive, Wheeling, Illinois 60090, USA09/22/99 Page 26 11.0FIELD STRENGTH OF SPURIOUS EMISSION MEASUREMENTS (CON'T) PART 2.1053 To determine the limit for all spurious & harmonic emissions, the following method was used: LIMIT for Spurious Emissions: As stated in Part 74, Section 74.861 (e-1 ii) the limit is 250 mW in the frequency range 614 to 806 MHz. 43 + 10*LOG10(0.01 watts) = 23.00 dB 10.00dBm extrapolated level for 0.01 watts -23.00 dB required reduction below the unmodulated fundamental -13.00 dBm or 94.00 dBuV/m at 1 meter maximum spurious emissions allowed Extrapolating the level to 3 meters: 94.00 dB…

Text truncated - open the document above for the full version.
