DI407208901LTE Base Station

NEC Corporation
LTE Base Station - FCC ID DI407208901 - NEC Corporation
Click to zoom

Application Details

Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant
Aug 15, 2012
Application Purpose
Original Equipment
Date of Application
Aug 15, 2012
Equipment Note
LTE Base Station
Frequency Range
746.00000000 - 756.00000000
Company
NEC Corporation
Country
Japan

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗

Cover Letter(s)

↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 imnenb_LR3.0 LTE Installation Manual eNB MB-14310050-001(E)-01 March, 2012 2 Copyright © 2012 by NEC Corporation This document describes the current planned product and feature description and release. However, the specifications, configuration and the release plan contained in this document are subject to change without any notice due to NEC's continuing design improvement. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated in any form for by any means without the written permission of NEC Corporation. All designations used in this document can be trademarks, the use of which by third parties for their own purposes violates the rights of their owners. Printed in Japan 3 Revision History Revision History IssueDateRevision DescriptionAuthorApprovalRemarks 1.0March 30, 20121st releaseT.ArakiK. Yoshida 4 Preface Preface Purpose of This Manual This manual describes the required knowledge and procedure to install the LTE system (eNodeB, hereafter referred to as eNB). GThis manual targets the 700MHz All-in-one Type eNB. Target Reader This manual is intended for the LTE system installation personnel and operation and maintenance personnel of a network operator. Manual Structure •Section 1 Overview Describes the system structure, equipment names and the main specification of the equipment. •Section 2 Equipment Appearance Shows the appearance of eNB equipment and its dimensions. •Section 3 Equipment Installation Conditions Shows the required space to install eNB equipment. •Section 4 Interface Conditions Shows the cable connection system diagram and eNB equipment interface. •Section 5 Installation Describes the cautions when carrying the equipment and the procedure to install eNB equipment. •Section 6 Cable Work Describes the procedure to work on various types of cables. •Section 7 Voltage Check Describes the procedure to check the voltage of the eNB equipment. Symbols Used in This Manual In this manual, the following symbol is used to show notes. When reference to a note is required, it is expressed as "Refer to [i]." G CCC...CCC (CCC...CCC : note text) 5 Precautions Precautions The alert labels in this manual and attached to the eNB equipment body indicates the items you must follow to prevent potential injury and safety hazard to you and other people, and perform the operation safely. Please read this manual thoroughly before starting any operations. Also, this manual must be kept in a safe place, so that you can read it whenever required. When alert labels are directly attached to the equipment, always read the content. This manual is intended for the LTE system installation personnel and operation and maintenance personnel of a network operator. Safety Instructions The "Safety Instructions" provides safety instructions for the LTE system installation operations. For other items, read the equipment manuals. Definitions of Alert Categories The following symbols categorize the dangers and level of damage that occurs when the content is ignored or wrong procedure was performed. ! DANGER: This symbol indicates that there is explicit life-threatening danger that may cause death or serious injuries if this item is ignored and the equipment is handled wrongly. ! WARNING: This symbol indicates that it may cause death or serious injuries if this item is ignored and the equipment is handled wrongly. ! CAUTION: This symbol indicates that it may cause injuries and physical damage if this item is ignored and the equipment is handled wrongly. 6 Precautions Alert Labels The following shows the alert labels attached to the equipment. If an alert label is attached, always follow the instruction written on the label. Federal Communications Commission Changes or modifications not expressly approved by NEC Corporation could void the users authority to operate the equipment. (Section 15.21) Section 15.105 (a) Class A Warning Label NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. About the Safety Instructions When you find a safety instruction in this manual, be sure to read the instruction before starting the work. The following safety instructions, especially regarding items that may cause death or injury to you and other people in this manual are listed by their alert categories. 7 Precautions Alert Category: CAUTION ! CAUTION: About the Work in General •Before starting the work, check the area of evacuation at the time of disaster. •Do not work wearing slippers. They may cause injury by falling, etc. •Be careful not to stumble over cables, parts and tools while working. It may cause injuries and accidents. •Be careful not to get the sleeves and hems of the working clothes caught. It may cause injuries and accidents. •Do not place liquid such as water into the equipment, and do not touch the equipment with wet hands. Moisture in the equipment may cause electrocution and equipment failure. In case liquid gets into the equipment, turn off the equipment power and request repair. • Do not dismantle or alter the equipment. It may cause electrocution, fire and equipment failure. •When installing or removing the equipment, cure the floor surface of the installed location to prevent damage by dropping parts. About Handling the eNB Equipment and SFP •When handling eNB equipment itself and SFP, wear globes (thin cotton gloves)…
