DRWTFY3830R2-Channel AC/DC Baby Monitor(Receiver)
Eagletron Telecommunications Ltd
Click to zoom
Application Details
- Equipment Class
- CYY - Communications Receiver used w/Pt 15 Transmitter
- Date of Grant
- Oct 14, 2001
- Application Purpose
- Original Equipment
- Date of Application
- Oct 14, 2001
- Equipment Note
- 2-Channel AC/DC Baby Monitor(Receiver)
- Frequency Range
- 49.83000000 - 49.89000000
- Country
- Hong Kong
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
External Photos
Test SetupFCCID : DRWTFY3830R External Photo -front External Photo - rear
Internal Photos
Test SetupFCCID : DRWTFY3830R Internal Photo - 1 Internal Photo - 2 Test SetupFCCID : DRWTFY3830R Internal Photo – 3
Test Report
Inte rte k Te sting Se rvice s Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2745 8306 Eagletron Telecommunications Ltd. Application For Certification (FCC ID: DRWTFY3830R) Superheterodyne Receiver WO# 0013781 WL/Sandy September 12, 2001 INTERTEK TESTING SERVICES FCC ID: DRWTFY3830R i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1 :General Description EXHIBIT 2 :System Test Configuration EXHIBIT 3 :Emission Results EXHIBIT 4 :Equipment Photographs EXHIBIT 5 :Product Labelling EXHIBIT 6 :Technical Specifications EXHIBIT 7 :Instruction Manual EXHIBIT 8 :Miscellaneous Information INTERTEK TESTING SERVICES FCC ID: DRWTFY3830R ii MEASUREMENT/TECHNICAL REPORT Eagletron Telecommunications Ltd. - MODEL: WTP 3-in-1 Monitor 3830 FCC ID: DRWTFY3830R This report concerns (check one:)Original Grant X Class II Change _____ Equipment Type: Superheterodyne Receiver (example: computer, printer, modem, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)?Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37?Yes No X If no, assumed Part 15, Subpart B for unintentional radiator - the new 47 CFR [10-1-96 Edition] provision. Report prepared by:Wilson Loke Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576, Castle Peak Road, Kowloon, Hong Kong Phone:852-2173-8575 Fax:852-2745-8306 INTERTEK TESTING SERVICES FCC ID: DRWTFY3830R iii Table of Contents 1.0 General Description ...........................................................................................................2 1.1 Product Description ..........................................................................................................2 1.2 Related Submittal(s) Grants ..............................................................................................2 1.3 Test Methodology .............................................................................................................3 1.4 Test Facility.......................................................................................................................3 2.0 System Test Configuration .................................................................................................5 2.1 Justification .......................................................................................................................5 2.2 EUT Exercising Software ..................................................................................................5 2.3 Special Accessories ...........................................................................................................5 2.4 Equipment Modification ...................................................................................................6 2.5 Support Equipment List and Description ..........................................................................6 3.0 Emission Results .................................................................................................................8 3.1 Field Strength Calculation .................................................................................................9 3.2 Radiated Emission Configuration Photograph ................................................................10 3.3 Radiated Emission Configuration Data ...........................................................................12 3.4 Line Conducted Emission Configuration Photograph.....................................................14 3.5 Line Conducted Emission Configuration Data ...............................................................15 4.0 Equipment Photographs ..................................................................................................17 5.0 Product Labelling .............................................................................................................19 6.0 Technical Specifications ...................................................................................................21 7.0 Instruction Manual ...........................................................................................................23 8.0 Miscellaneous Information ..............................................................................................25 8.1 Discussion of Pulse Desensitization ................................................................................26 8.2 Calculation of Average Factor ........................................................................................27 8.3 Emissions Test Procedures..............................................................................................28 INTERTEK TESTING SERVICES FCC ID: DRWTFY3830R iv List of attached file Exhibit typeFile Descriptionfilename Test ReportTest Reportreport.doc Operation DescriptionTechnical Descriptiondescri.pdf Test Setup PhotoRadiated EmissionRconfig photos.doc External PhotoExternal Photoexternal photos.doc Internal PhotoInternal Photointernal photos.doc Block DiagramBlock Diagramblock.pdf SchematicsCircuit Diagramcircuit.pdf ID Label/LocationLabel Artwork and Locationlabel.pdf User ManualUser Manualmanual.pdf Test ReportConducted Emissionconduct.pdf Test Setup PhotoConducted Emissionconfig photos.doc INTERTEK TESTING SERVICES FCC ID: DRWTFY3830R 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: DRWTFY3830R 2 1.0 General Description 1.1Product Description The Equipment Under Test (EUT) is a 2-Channel AC/DC Baby Monitor (Receiver) operating at 49.83 and 49.89MHz. The EUT is powered by 6.0V d.c. (4 x 1.5V “AAA” batteries (LR03)) or AC adaptor. This unit ‘receives’ sounds from the baby’s unit, so it can hear baby’s sounds. There are three receiving options to choose ‘sound and light’, ‘lights only’ and ‘sound only’. Also, it has on/status indicator and low battery warning function. For electronic filing,…
Text truncated - open the document above for the full version.
Test Setup Photos
Test SetupFCCID : DRWTFY3830R Conduct Photo - 1 Conduct Photo - 2 Test SetupFCCID : DRWTFY3830R Conduct Photo – 3
Test Setup Photos
Test SetupFCCID : DRWTFY3830R Radiated -front Radiated - rear
Contact Information
Applicant
Damien Liu(General Manager)
Test Firm
Intertek Testing Services Hong KongBilly Chow
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15B | 49.83 MHz - 49.89 MHz | - |
