DV8LX5160AECG and Respiration Transmitter

2-35-8 HONGO BUNKYO-KU TOKYO 113 JAPAN - Phone 81-3-5684-1300- Fax 81-3-5684-1321 FCC Labeling Requirements and Information Date: August 3, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: FCC Labeling Requirements FCC ID: DV8LX5160A The following label information is required by the FCC Rules and Regulations for certified devices. Also attached, please find marketing information required by the FCC Rules and Regulations. Thank you for your attention to these matters. Sincerely, Yoshi Muraki General Manager Engineering Development Department 2-35-8 HONGO BUNKYO-KU TOKYO 113 JAPAN - Phone 81-3-5684-1300 - Fax 81-3-5684-1321 Request for Confidentiality Date: August 3, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: DV8LX5160A We, Fukuda Denshi Co., Ltd. request that the following information is to be held confidential pursuant to CFR 47, Section .457 and .459. Block Diagram Schematics Parts List Technical Description Tune Up Specification These contain schematic and operational details of the product for which certification is being sought. This information is classified as “Company Confidential” and disclosure of these exhibits would potentially be harmful to our business because this product incorporates innovative lowpower RF transmitter design techniques, ECG processing technology, and other such details that would be useful to a competitor in the medical telemetry business. This information is not available to the public since all service and repairs are done on a sub-assembly basis and the design details are hidden. It is expected that this information would remain sensitive for at least two years from the date of submission. Thank you for your attention to this matter. Yoshi Muraki General Manager Engineering Development Department 2-35-8 HONGO BUNKYO-KU TOKYO 113 JAPAN - Phone 81-3-5684-1300 - Fax 81-3-5684-1321 Manufacturer’s Letter Date: August 3, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: DV8LX5160A To Whom It May Concern: Please be advised that the manufacturer will ensure that the above-referenced model will be manufactured in accordance with the FCC Rules and Regulations. Thank you for your attention to this matter. Yoshi Muraki General Manager Engineering Development Department

2-35-8 HONGO BUNKYO-KU TOKYO 113 JAPAN - Phone 81-3-5684-1300 - Fax 81-3-5684-1321 Request for Confidentiality Date: August 3, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID:DV8LX5160A We, Fukuda Denshi Co., Ltd. request that the following information is to be held confidential pursuant to CFR 47, Section .457 and .459. Block Diagram Schematics Parts List Technical Description Tune Up Specification These contain schematic and operational details of the product for which certification is being sought. This information is classified as “Company Confidential” and disclosure of these exhibits would potentially be harmful to our business because this product incorporates innovative lowpower RF transmitter design techniques, ECG processing technology, and other such details that would be useful to a competitor in the medical telemetry business. This information is not available to the public since all service and repairs are done on a sub-assembly basis and the design details are hidden. It is expected that this information would remain sensitive for at least two years from the date of submission. Thank you for your attention to this matter. Yoshi Muraki General Manager Engineering Development Department

2-35-8 HONGO BUNKYO-KU TOKYO 113 JAPAN - Phone 81-3-5684-1300 - Fax 81-3-5684-1321 Letter Of Agency Date: August 3, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Please be advised that Fukuda Denshi Co., Ltd. authorizes A-Pex International Co., Ltd. to act on our behalf, until otherwise notified, for applications submitted to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Yoshi Muraki General Manager Engineering Development Department

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 September 26, 2002 RE: FCC ID: DV8LX5160A Attention: I have a few comments on this Application. 1 The internal photos are not clear. Please provide clear internal photos. 2 You RF exposure statement states the device has 0.25mW conducted power. The antenna conducted plot on pages 20 and 22 show 104.22dBuV (-2.78dBm or .5mW) and 105.09dBuV (-1.91dBw or .644mW). Please correct your rf exposure statement, 731 and report to reflect the measured value of antenna conducted at the fundamental. While limits for 95H devices are in field strength at 3 meters, the grant uses antenna-conducted power generally. 3 The following files cannot be opened by the FCC servers adobe acrobat User's Manual.pdf confidential_Schematics.pdf Please provide files without Asian or otherwise undefined fonts. 4 Please note, the report and the 731 do not agree on the emissions designator. Please provide the proper emissions designator and explain how you derived this designator. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

A- PEX INTERNATIONAL CO., LTD. □HEAD OFFICE 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan TEL:0596-24-6717/FAX:0596-24-8020 Date: September 30, 2002 RE: Fukuda Denshi Co., Ltd. FCC ID: DV8LX5160A Dear Mr. Dennis Ward, Regarding the above referenced application, please find our reply to the comments dated September 26, 2002: 1) We upload the revised internal photos for the equipment. 2) We modified the conducted power to 0.644mW on RF Exposure Statement and Form 731. Please refer to revised RF Exposure statement and Form 731. 3) Please find uploaded Schematics.pdf and User’s Manual.pdf 4) As described on FCC Part 2.202.(c).(1) and (2), we used the formula of item (g) to derive the emission designator listed on Form 731. The bandwidth described on test report (No. 22KE0010-YK) is the value derived from actual measurement. In addition, we included the explanation on page 5 of the test report, in order to clarify that all other out of band emissions than the band ages were tested using the QP function of the analyzer. Please refer to uploaded revised page 9 of test report (No. 22KE0010-YK). We hope the above replies are satisfactory. Best regards, Yukari Ito (Ms.) A-Pex International Co., Ltd.

Fukuda Denshi Co., Ltd. FCC ID: DV8LX5160A External Photo Front View Fukuda Denshi Co., Ltd. FCC ID: DV8LX5160A Rear View Fukuda Denshi Co., Ltd. FCC ID: DV8LX5160A Top View Bottom View Fukuda Denshi Co., Ltd. FCC ID: DV8LX5160A Left Side View Right Side View

Fukuda Denshi Co., Ltd. FCC ID: DV8LX5160A Label Information Fukuda Denshi Co., Ltd. FCC ID: DV8LX5160A

Fukuda Denshi Co., Ltd. FCC ID: DV8LX5160A Internal Photo Front View Fukuda Denshi Co., Ltd. FCC ID: DV8LX5160A Rear View Fukuda Denshi Co., Ltd. FCC ID: DV8LX5160A PCB Component Side Fukuda Denshi Co., Ltd. FCC ID: DV8LX5160A PCB Solder Side

17725 NE 65 th Street • Redmond, WA 98052 • Phone 1-800-365-6668 • Fax (425) 869-2018 June 28, 2002 To whom it may concern, Re: Temperature - Frequency stability Certification This letter is to certify that the Temperature – Frequency stability of the LX- 5160 telemetry transmitter which is satisfied it’s specification over the operating temperature range. Yoshi Muraki General Manager, Engineering Development Department Fukuda Denshi Co., Ltd. Test report of Frequency Stability EUT : LX-5160, Serial No. =2002062010 Freq. Range : 608 to 614 MHz Freq. Stability : +/-2.5 ppm Operating temp. : +10 to +40 degrees C Date : June. 24. 2002 Manufacture : Fukuda Denshi Co., Ltd. Test engineer : Tamotsu Toya Test site : Fukuda Denshi, Hongo office, Engineering Development Department Temp. Chamber : LHU-112, TABAI ESPEC CORP. Serial No.1571794 Registration No. 224-046-001 Freq. Counter : TR5823H, ADVANTEST Serial No.00570534 Registration No.202-027-001 Measurement result: Temp. degrees C Freq. MHz Difference, HzDifference, ppm 0 610.999744 -256 - 0.42 +10 611.000290 +290 +0.47 +20 611.000195 +195 +0.32 +25 611.000053 + 53 +0.09 +30 610.999935 - 65 -0.11 +40 610.999857 -143 - 0.23 +50 610.999788 -212 - 0.35

FCC:ID : DV8LX5160A Test report No. : 22KE0010-YK Page : 12 of 39 Issued date : July 23, 2002 A-pex International Co., Ltd. YAMAKITA LAB. 907 Kawanishi, Yamakita-machi, Ashigarakami-gun, Kanagawa-ken, 258-0124 JAPAN Telephone: int +81 465 77 1011 Facsimile: int +81 465 77 2112 MF060b(23.04.02) Radiated emission FCC:ID : DV8LX5160A Test report No. : 22KE0010-YK Page : 13 of 39 Issued date : July 23, 2002 A-pex International Co., Ltd. YAMAKITA LAB. 907 Kawanishi, Yamakita-machi, Ashigarakami-gun, Kanagawa-ken, 258-0124 JAPAN Telephone: int +81 465 77 1011 Facsimile: int +81 465 77 2112 MF060b(23.04.02) Pre check of worse-case position X axis Y axis FCC:ID : DV8LX5160A Test report No. : 22KE0010-YK Page : 14 of 39 Issued date : July 23, 2002 A-pex International Co., Ltd. YAMAKITA LAB. 907 Kawanishi, Yamakita-machi, Ashigarakami-gun, Kanagawa-ken, 258-0124 JAPAN Telephone: int +81 465 77 1011 Facsimile: int +81 465 77 2112 MF060b(23.04.02) Z axis
