E2X-ST-GM6000NESL Graphic TAG

S-TAG Datasheet(ST-GM6000N) Preliminary REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 1/14 CUSTOMER APPROVAL SHEET Company Name MODEL ST-GM6000N CUSTOMER APPROVAL □ A PPROVAL FOR SPECIFICATIONS ONLY (Spec. Ver. 0.1) □ CUSTOMER REMARK : Issued By Checked By Approved By ES Kim DS Yoon JG Ryu Samsung Electro-Mechanics 314, Maetan3-Dong, YoungTong-Gu, Suwon, Gyunggi-Do, Korea Tel : 82-31-210-5114 S-TAG Datasheet(ST-GM6000N) Preliminary REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 2/14 S-TAG Datasheet S -Label (Electronic Label System) REV 0.1 Sa msung Electro-Mechanics 2015-07-01 Summary This datasheet presents the general performance and specifications of S-Tag for S-Label ESL (Electronic She lf Label) system, which is based on IEEE 802.15.4. © 2015 Samsung Electro-Mechanics. All rights reserved The names of actual companies and products mentioned herein may be the trademarks of their respective owners. No part of this document may be reproduced, stored in a retrieval system, or transmitted in any form or by any means without the express written consent of Samsung Electro- Mechanics. This document is subject to change without notice. S-TAG Datasheet(ST-GM6000N) Preliminary REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 3/14 Table of Contents 1 G ENERAL DESCRIPTION ..................................................................................................... 5 1.1 F EATURES ......................................................................................................................... 6 1.2 T YPICAL APPLICATIONS ......................................................................................................... 6 1.3 A PPEARANCE ...................................................................................................................... 6 2 SPECIFICATION .................................................................................................................. 7 2.1 PRODUCT SPECIFICATION ....................................................................................................... 7 2.2 R ADIO (RF) SPECIFICATION ................................................................................................... 7 2.3 NFC SPECIFICATION............................................................................................................. 8 2.4 MECHANICAL DRAWING ......................................................................................................... 8 2.5 L ABELS ............................................................................................................................. 9 3 PACKAGE ........................................................................................................................... 11 4 CAUTIONS FOR TREATMENT............................................................................................. 12 4.1 U SAGE ENVIRONMENT .......................................................................................................... 12 4.2 S TORAGE AND USE .............................................................................................................. 12 4.3 BATTERY REPLACEMENT ........................................................................................................ 13 4.4 FCC ............................................................................................................................... 14 S-TAG Datasheet(ST-GM6000N) Preliminary REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 4/14 Document History Rev. Date R evision history Page 0.1 01 JUL 2015 Draft - S-TAG Datasheet(ST-GM6000N) Preliminary REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 5/14 1 General Description This S-Tag product is a part of Samsung S-Label (Electronic Shelf Label) system as well as S-Label Gateway (S-Gate), Remote controller (S-RC). S-Label system make up a system that electronically displays price and other product information on S-Tags, which has been traditionally printed or written on paper in places like retail markets. S-Tag receives product price/information updates from S-Gate and updates or changes its display of price a nd other information. S-Tag is the product based on IEEE standard 802.15.4 for low power wireless communication applications. S-Tag consists of RF transceiver, RF circuitry and 8051-compatible MCU offering IEEE 802.15.4 based network protocol and MAC protocol and other peripheral devices. S-TAG Datasheet(ST-GM6000N) Preliminary REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 6/14 1.1 Features - Display : E-Paper active type Display (6.0 Inch, 128 Dpi, 600 * 448 Pixel) - Communication : Wireless communication based on IEEE 802.15.4 (2405~2480MHz) - Operating on 2.4GHz Unlicensed ISM band for ZigBee - Low Power Consumption - External Wakeup : RF Wakeup (Using ISM Band(2.4GHz)) - Outline Dimension : 134.4 mm x 109.5 mm x 14.2 mm - Working condition: Indoor where wireless communication is available. - NFC(13.56MHz) Available 1.2 Typical Applications - Retail industry with electronic displays, platforms, solutions and services. - Intelligently communicating, managing, and optimizing price and product information. 1.3 Appearance Figure 1 Appearance S-TAG Datasheet(ST-GM6000N) Preliminary REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 7/14 2 Specification 2.1 Product Specification Item Description Size 134.4 mm x 109.5 mm x 14.2 mm Battery CR2450 Lithium Battery (3V, 4PCS) 2.5 ~ 3.3Vdc(condition : In active status) Display E-Paper active type Display (118.80 * 88.26 mm, 128 Dpi, 600 * 448 Pixel) Housing Color White Information display Price, Unit, Symbol etc. Communication Wireless communication based on IEEE 802.15.4 (2405~2480MHz) Communication Distance Radius 20m (Line of Sight) Operation Temp. 0 ~ 40 °C (@20~60% RH) Etc. No additional anti-theft locking structure : Rail Mounted only 2.2 Radio (RF) 1 Specification Item Parameter SPEC Unit Co…

Text truncated - open the document above for the full version.

S-TAG Datasheet(ST-GM60001) Preliminary REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 1/14 CUSTOMER APPROVAL SHEET Company Name MODEL ST-GM60001 ST-GM60KC1 CUSTOMER APPROVAL □APPROVAL FOR SPECIFICATIONS ONLY (Spec. Ver. 0.1) □CUSTOMER REMARK : Issued By Checked By Approved By ES Kim DS Yoon JG Ryu Samsung Electro-Mechanics 314, Maetan3-Dong, YoungTong-Gu, Suwon, Gyunggi-Do, Korea Tel : 82-31-210-5114 S-TAG Datasheet(ST-GM60001) Preliminary REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 2/14 S-TAG Datasheet S-Label (Electronic Label System) REV 0.1 Sam sung Electro-Mechanics 2015-07-01 Summary This datasheet presents the general performance and specifications of S-Tag for S-Label ESL (Electronic Shelf Label) system, which is based on IEEE 802.15.4. © 2015 Samsung Electro-Mechanics. All rights reserved The names of actual companies and products mentioned herein may be the trademarks of their respective owners. No part of this document may be reproduced, stored in a retrieval system, or transmitted in any form or by any means without the express written consent of Samsung Electro- Mechanics. This document is subject to change without notice. S-TAG Datasheet(ST-GM60001) Preliminary REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 3/14 Table of Contents 1 GENERAL DESCRIPTION ..................................................................................................... 5 1.1 F EATURES ......................................................................................................................... 6 1.2 T YPICAL APPLICATIONS ......................................................................................................... 6 1.3 A PPEARANCE ...................................................................................................................... 6 2 SPECIFICATION .................................................................................................................. 7 2.1 PRODUCT SPECIFICATION ....................................................................................................... 7 2.2 R ADIO (RF) SPECIFICATION ................................................................................................... 7 2.3 MECHANICAL DRAWING ......................................................................................................... 8 2.4 LABELS ............................................................................................................................. 9 3 PACKAGE ........................................................................................................................... 11 4 CAUTIONS FOR TREATMENT............................................................................................. 12 4.1 U SAGE ENVIRONMENT .......................................................................................................... 12 4.2 STORAGE AND USE .............................................................................................................. 12 4.3 B ATTERY REPLACEMENT ........................................................................................................ 13 4.4 FCC ............................................................................................................................... 14 S-TAG Datasheet(ST-GM60001) Preliminary REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 4/14 Document History Rev. Date Revision history Page 0.1 01 JUL 2015 Draft - S-TAG Datasheet(ST-GM60001) Preliminary REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 5/14 1 General Description This S-Tag product is a part of Samsung S-Label (Electronic Shelf Label) system as well as S-Label Gateway (S-Gate), Remote controller (S-RC). S-Label system make up a system that electronically displays price and other product information on S-Tags, which has been traditionally printed or written on paper in places like retail markets. S-Tag receives product price/information updates from S-Gate and updates or changes its display of price and other information. S-Tag is the product based on IEEE standard 802.15.4 for low power wireless communication applications. S-Tag consists of RF transceiver, RF circuitry and 8051-compatible MCU offering IEEE 802.15.4 based network protocol and MAC protocol and other peripheral devices. S-TAG Datasheet(ST-GM60001) Preliminary REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 6/14 1.1 Features - Display : E-Paper active type Display (6.0 Inch, 128 Dpi, 600 * 448 Pixel) - Communication : Wireless communication based on IEEE 802.15.4 (2405~2480MHz) - Operating on 2.4GHz Unlicensed ISM band for ZigBee - Low Power Consumption - External Wakeup : RF Wakeup (Using ISM Band(2.4GHz)) - Outline Dimension : 134.4 mm x 109.5 mm x 14.2 mm - Working condition: Indoor where wireless communication is available. 1.2 Typical Applications - Retail industry with electronic displays, platforms, solutions and services. - Intelligently communicating, managing, and optimizing price and product information. 1.3 Appearance Figure 1 Appearance S-TAG Datasheet(ST-GM60001) Preliminary REV 0.1 Samsung Electro-Mechanics Proprietary and Confidential 7/14 2 Specification 2.1 Product Specification Item Description Size 134.4 mm x 109.5 mm x 14.2 mm Battery CR2450 Lithium Battery (3V, 4PCS) 2.5 ~ 3.3Vdc(condition : In active status) Display E-Paper active type Display (118.80 * 88.26 mm, 128 Dpi, 600 * 448 Pixel) Housing Color White Information display Price, Unit, Symbol etc. Communication Wireless communication based on IEEE 802.15.4 (2405~2480MHz) Communication Distance Radius 20m (Line of Sight) Operation Temp. 0 ~ 40 °C (@20~60% RH) Etc. No additional anti-theft locking structure : Rail Mounted only 2.2 Radio (RF) 1 Specification Item Parameter SPEC Unit Condition Min Typ Max TX Transmit Power 6 8 10 dBm Error Vector Magnitude 10 30 % When measured for 100 chips Tx Current 40 mA Total current at max Tx Power RX…

Text truncated - open the document above for the full version.

DT&C Co., Ltd. 42, Yurim-ro, 154beon-gil, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea 449-935 Date: Aug. 21, 2015 UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards;

Samsung Electro Mechanics 314, Maethan-3 Dong, Paldal-Ku, Kyungki-Do, Suwon-City, Korea, 442-743 Date: Aug. 21, 2015 UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA RE: Request of Confidentiality for FCCID: E2X-ST-GM6000N To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Samsung Electro Mechanics hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Samsung Electro Mechanics temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description SHORT-TERM 5 Internal Photos 6 External Photos 7 Test-Setup Photos 8 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Jin Hwan, Lim Manager

Samsung Electro Mechanics 314 Maetan-3 Dong Pal Dal-Ku Kyungki-Do, Suwon-City, Korea, 442-743 Date: Aug. 21, 2015 Letter of Authorization We, the undersigned, hereby authorize Harvey Sung of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCCID: E2X-ST-GM6000N including signing of all documents relating to these matters. Any and all acts carried out by Harvey Sung of DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Samsung E lectro Mechanics “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Jin Hwan, Lim Assistant Manager

SAMSUNG ELECTRO-MECHANICS CO.,LTD 314,Metan 3-dong,Yeongtong-gu,Suwon-si,Gyeonggi-do 443-743,Korea Aug 18, 2015 DECLARATION OF IDENTITY Applicant : SAMSUNG ELECTRO-MECHANICS CO.,LTD. Type of Product : ESL Graphic TAG Model Name : ST-GM6000N Add Model Name : ST-GM60001, ST-GM60KC1 FCC ID : E2X-ST-GM6000N We would like to add the variant mode that it’s ST-GM60001, ST-GM60KC1. It doesn’t differ with electric and circuit, because this model is not mounted only NFC IC on the PCB to basic model. The NFC IC doesn’t affect the RF characteristics. MODEL 1 MODEL 2 Characteristics Difference ST-GM60001 ST-GM60KC1 Not mounted NFC IC Label Model Name (because of Customer) Sincerely, Dongsik Yoon / Principal Engineer

FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. External Photo ST-GM6000N FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. View 1 FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. View 2 FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. View 3 FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. External Photo ST-GM60KC1, ST-GM60001 FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. View 1 FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. View 2 FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. View 3

FCC ID : E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. ST-GM6000N ST-GM60KC1 ST-GM60001 - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included in the user manual.

FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. Page 1 / 10 Internal Photo. ST-GM6000N FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. Page 2 / 10 View 1 FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. Page 3 / 10 View 2 FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. Page 4 / 10 View 3 FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. Page 5 / 10 View 4 FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. Page 6 / 10 Internal Photo. ST-GM60KC1, ST-GM60001 FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. Page 7 / 10 View 1 FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. Page 8 / 10 View 2 FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. Page 9 / 10 View 3 FCCID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. Page 10 / 10 View 4

Portable device Mobile device Simultaneous Transmitting MHzmm dBi =( ) = [ 0.08 + ( 200mm - 50 mm X 10 ) ] = 1500.1 Note. The calculation result was rounded to one decimal place f or comparison. Maximum power density Numeric power gain of the antenna Maximum power with turn-up toler ance Distance from transmitting antenna 2 G = R = = ) 2 S = 2 P , ㎽/㎝ π Copyright ⓒ 2015, DT&C Co., Ltd. 1.000000 ㎽/㎝ G → SAR evaluation for general population exposure conditions by measurement or numerical simulation is not required. The limit for maximum permissible exposure = 0.000909 2 ㎽/㎝ /( 4R Conclusion: The exposure condition of this device is compliant with FCC rul es. S = P = Maximum Permissible Exposure(MPE) evaluation for mobile device [ Threshold at 50 mm + ( test sep aration distance - 50 mm ) X 1 0 ] mW 10.00 dBm Note. dBm August 19, 2015 FCC ID : E2X-ST-GM6000N KDB 447498 D01 clasue 4.3.1 Step 2- 2) SAR test exclusion thres holds for 1500MHz to 6GHz at test separationn distances > 50 mm - Device category = Standalone SAR test exclusion considerations 200 - Max. power with turn-up tolerance = 10.0 2480 - Min. test separ ation distance = mW 10.00 - Max. transmitting frequency = Single Transmitting Max. Typical Power = - Transmitting mode = - Max. Antenna Gain = -3.4

FCCID : E2X-ST-GM6000N DTNC1507-03622 Report No. : DRTFCC1508-0181 TRF-RF226(00)140710 Page 2 / 32 Copyright ○ C 2015, DT&C Co., Ltd. Test Report Version Test Report No. Date Description DRTFCC1508-0181 Aug. 24, 2015 Initial issue DRTFCC1508-0181(1) Aug. 27, 2015 Update Radiated Spurious Emissions and Appendix II FCCID : E2X-ST-GM6000N DTNC1507-03622 Report No. : DRTFCC1508-0181 TRF-RF226(00)140710 Page 3 / 32 Copyright ○ C 2015, DT&C Co., Ltd. Table of Contents 1. EUT Description .......................................................................................... 4 2. Summary of Tests ........................................................................................ 5 3 Test Methodology ......................................................................................... 6 3.1 EUT Configuration ............................................................................................................ 6 3.2 EUT Exercise ..................................................................................................................... 6 3.3 General Test Procedures ................................................................................................. 6 3.4 Description of Test Modes ............................................................................................... 6 4. Instrument Calibration ................................................................................ 7 5. Facilities and Accreditations ...................................................................... 7 5.1 Facilities ............................................................................................................................ 7 5.2 Equipment ......................................................................................................................... 7 6. Antenna Requirements ............................................................................... 7 7. Test Result ................................................................................................... 8 7.1 6 dB Bandwidth Measurement ........................................................................................ 8 7.2 Maximum Peak Conducted Output Power ................................................................... 11 7.3 Maximum Power Spectral Density. ............................................................................... 14 7.4 Out of Band Emissions at the Band Edge / Conducted Spurious Emissions .......... 17 7.5 Radiated Measurement. ................................................................................................. 26 7.5.1 Radiated Spurious Emissions. ................................................................................. 26 7.6 POWERLINE CONDUCTED EMISSIONS ....................................................................... 29 8. LIST OF TEST EQUIPMENT ...................................................................... 30 APPENDIX I .................................................................................................... 31 APPENDIX II ................................................................................................... 32 FCCID : E2X-ST-GM6000N DTNC1507-03622 Report No. : DRTFCC1508-0181 TRF-RF226(00)140710 Page 4 / 32 Copyright ○ C 2015, DT&C Co., Ltd. 1. EUT Description Product ESL Graphic TAG Model Name ST-GM6000N Add Model Name ST-GM60001, ST-GM60KC1 Power Supply DC 3.0V (Not rechargeable battery) Frequency Range 2405 ~ 2480MHz (16 channels) Modulation Type OQPSK (ZIGBEE) Antenna Specification Antenna Type: Internal Antenna Antenna Gain: -3.40 dBi(PK) The difference between model names is declared from applicant. - ST-GM6000N = ZIGBEE with RFID TAG function - ST-GM60001, ST-GM60KC1 = ZIGBEE without RFID TAG function FCCID : E2X-ST-GM6000N DTNC1507-03622 Report No. : DRTFCC1508-0181 TRF-RF226(00)140710 Page 5 / 32 Copyright ○ C 2015, DT&C Co., Ltd. 2. Summary of Tests FCC Part Section(s) Parameter Limit Test Condition Status Note 1 I. Transmitter Mode (TX) 15.247(a) 6 dB Bandwidth > 500 kHz Conducted C 15.247(b) Transmitter Output Power < 1 Watt C 15.247(d) Out of Band Emissions / Band Edge 20 dBc in any 100 kHz BW C 15.247(e) Transmitter Power Spectral Density < 8 dBm/3kHz C 15.205 15.209 General Field Strength Limits (Restricted Bands and Radiated Emission Limits) FCC 15.209 limits Radiated C Note2 15.207 AC Conducted Emissions FCC 15.207 limits AC Line Conducted NA Note3 15.203 Antenna Requirements FCC 15.203 - C Note 1 : C=Comply NC=Not Comply NT=Not Tested NA=Not Applicable Note 2: This test item was performed in each axis and the worst case data was reported. Note 3: The power of this device is only DC(Not rechargeable Battery). FCCID : E2X-ST-GM6000N DTNC1507-03622 Report No. : DRTFCC1508-0181 TRF-RF226(00)140710 Page 6 / 32 Copyright ○ C 2015, DT&C Co., Ltd. 3 Test Methodology Generally the tests were performed according to the KDB558074 v03r03. And ANSI C63.10-2013 was used to reference appropriate EUT setup and maximizing procedures of radiated spurious emission and AC line conducted emission testing. 3.1 EUT Configuration The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT Exercise The EUT was operated in the test mode to fix the TX frequency that was for the purpose of the measurements. According to its specifications, the EUT must comply with the requirements of the Section 15.207, 15.209 and 15.247 under the FCC Rules Part 15 Subpart C. 3.3 General Test Procedures Conducted Emissions According to the requirements in Section 6.2 of ANSI C63.10, the EUT is placed on the wooden table, which is 0.8 m above ground plane and the conducted emissions from the EUT are measured in the frequency range between 0.15 MHz and 30 MHz using CISPR Quasi-peak and Average detector. Radiated Emissions The EUT is pla…

Text truncated - open the document above for the full version.

FCC ID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. Test Setup photographs EUT Position: X-axis EUT Position: Y-axis EUT Position: Z-axis FCC ID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (0.009 ~ 30MHz) FCC ID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (below 1000MHz) FCC ID: E2X-ST-GM6000N Copyright Ⓒ 2015, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (Above 1GHz)
