E5MDS-MERCMIMO3Wireless Data Transceiver

05-6301A01, Rev. 01MDS Mercury Series Quick Start1 MDS Mercury Series Setup Guide MDS Mercury TM Series transceivers provide an easy-to-install wireless network service with long range and secure operation at adaptive data rates approaching 30 Mbps. The transceiver is designed for demanding applications in industrial environments, where reliability and range are paramount. The transceiver comes in two primary models—Base Station (BS) and Subscriber Unit (SU), each with unique hardware profiles. Both models support Ethernet and serial services. A BS is a wireless switch that usually provides connectivity into a wired Ethernet LAN/WAN. Subscriber Units associate over the air with a BS and are typically connected to an Ethernet or Serial device via a local cable. NOTE:To determine whether a unit is an BS or Subscriber Unit, check the dome label on the top of the unit. Refer to the Mercury Series Technical Manual (05-6302A01) for advanced procedures and cautionary information. 1.1Connectors & Indicators Figure 1 shows the connectors and indicators of a Standard BS. These items are referenced in the installation and operation steps that follow. Note that SU radios may have an additional connector present for WiFi service, depending on order requirements. If WiFi is not provided on an SU, the GPS connector will also be absent. Invisible place holder Figure 1. Connectors and Indicators (Standard BS shown; SU Similar) There are three main requirements for installing the transceiver— adequate and stable primary power, a good antenna system, and the correct interface between the transceiver and the data device. Figure 2 shows a typical Mercury installation. 2.1Installation Steps Listed below are the basic steps for installation. It is highly recom- mended that the BS be installed first so that you can quickly check the operation of each associated SU as it is placed on the air. Invisible place holder Figure 2. Typical Mercury Installation (SU Shown; BS Similar) 2.1.1 Step 1—Mount the Transceiver Use the supplied 6-32 x 1/4 inch (6 mm) screws to attach the mounting brackets to the bottom of the radio. Figure 3 shows the mounting dimensions of the unit. Mount the radio to a stable sur- face. (Fasteners not supplied.) Invisible place holder Figure 3. Transceiver Mounting Dimensions (Dimensions for BS and SU identical) 2.1.2 Step 2—Install the Antenna Base units typically use sector antennas, while SU’s typically use a directional panel antenna. All antennas should be mounted in the clear to a sturdy support. Connect the antenna’s feedline cable to the transceiver’s WiMAX Antenna Port. To minimize RF interfer- ence, the antenna should be at least 9 inches (> 23 cm) away from connected device(s), sensors and other external components. 1.0INTRODUCTION 2.0INSTALLATION            !"# $    %& ' %& '                   !"!#!!  $  %"  $ "%  & '((&)'( *+#   $ " " &, #-./.)0) &--,#&*+#    " "   % )*-& *#&1!#+"!/ 2-# ! 1 #&"!/ 2.75 ̋ (7 cm) 8 5/8 ̋ (21.8 cm) 2MDS Mercury Series Quick Start05-6301A01, Rev. 01 Install GPS Antenna (if required) Install the GPS antenna in accordance with the manufacturer’s instructions. Connect it to the GPS Port on the unit’s front panel. 2.1.3 Step 3—Measure & Connect DC Power The DC input to the transceiver must be within 10–60 Vdc and capable of continuously providing at least 150 watts. A power con- nector with screw-terminals is provided with each unit. Strip the wire leads to 6 mm (1/4 inch). Be sure to observe proper polarity with the positive lead (+) on the left, and the negative on the right. The unit is designed for use in negative ground systems only. The power supply should be equipped with overload protection (NEC Class 2), to protect against a short circuit between its output ter- minals and the radio’s power connector. NOTE:It takes about 30 seconds for the unit to fully power up, and a few minutes to associate with another unit, espe- cially if GPS is required for time synchronization. 2.1.4 Step 4—Review the Transceiver’s Configuration One key setting must be known before beginning configuration: •IP Address—Must be a unique address to allow for IP access through the LAN port or over-the-air. Check with your System Administrator for this information. (Default address is 192.168.1.1) Other parameters commonly needing review or adjustment are listed below, followed by Log-in and Configuration procedures. •RF Output Power Level (BS Only)—Check and adjust as necessary for compliance with regulatory limits. (Default power is +30 dBm for 1800 model, +23 dBm for 3650 model.) Note that Subscriber Units auto-adjust power output based on target receive signal level (set at the BS). •Password—Used for remote access and Menu System. •Frequency—Operating frequency in MHz. •TDD Sync Mode (BS only)—Selections are: Free Run and GPS Required. Free Run allows rapid configuration and initial testing. GPS Required synchronizes the BS’s transmissions to the GPS timing. GPS Required is only needed to synchronize multiple Base Stations. NOTE:The default password and username is admin. A unique IP address and subnet are required to access the Menu System, either through the LAN port, or remotely over-the-air. Log-in and Configuration Procedure The following is an overview of the local log-in and configuration procedure using the COM1 serial port. a.Connect a computer’s serial port to the unit’s COM1 Port. b.Launch a terminal communication program, such as HyperTerminal, on the computer. Configure it to: 115,200 bps/8N1/no handshaking/VT100. c.Press ENTER. A login prompt is displayed that requires a username and password. d.Enter the username and password. e.Review other settings and make changes as necessary, such as the unit passwo…

Text truncated - open the document above for the full version.

Elliott TCB 684 W. Maude Ave Sunnyvale, CA, 94085 To whom it may concern: The enclosed documents constitute a formal submittal and application for Equipment Authorization for a wireless broadband service transmitter GE MDS LLC MERCURY3650 MIMO pursuant to the following rules: Subpart Z of Part 90 of FCC Rules (CFR 47) The Mercury2 MIMO radio operates as a 2x2 spacial-multiplexing radio in the 3650-3700 MHz frequency band. It employs a restricted contention based protocol. The use of a restricted contention based protocol limits the frequency range to 3650-3675 MHz per Subpart Z of Part 90 of the FCC rules. Elliott Laboratories, as duly authorized agent prepared this submittal. A copy of the letter of our appointment as agent is included with the application. If there are any questions or if further information is needed, please contact Elliott Laboratories for assistance. Sincerely, David W. Bare Chief Engineer Page 1 of 1

175 Science Parkway, Rochester, New York 14620 USA (585) 242-9600 Phone (585) 242-9620 Fax Oct 27th, 2010 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Subject: Authority to Act as an Agent to FCC & IC (industry Canada) Applicant: GE MDS LLC. Product: MDS MERCURY3650MIMO FCC ID: E5MDS-MERCMIMO Dear Sir/Madam, Elliott Laboratories 684 W. Maude Avenue Sunnyvale, CA 94085 This is your letter of authorization to accept our appointment of Elliott Labs, as our Agent for GE MDS LLC, to sign applications before the FCC and to make representations to you on our behalf. Elliott Lab’s is to receive and exchange data between our company and the FCC. If you have any queries, please do not hesitate to contact me at 585 242-8440: Yours truly, Dennis W McCarthy Agency Compliance Engineer GE Digital Energy – MDS T +1 (585) 242‐8440 D * 22 608‐8440 E [email protected] www.GEDigitalEnergy.com

175 Science Parkway, Rochester, New York 14620 USA (585) 242-9600 Phone (585) 242-9620 Fax Oct 27th, 2010 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Subject: Request for withholding from public disclosure the schematic diagrams and system block diagrams pursuant to an application for certification . Applicant: GE MDS LLC Product: Data Transceiver MDS MERCURY3650MIMO Model: MDS MERCURY3650MIMO FCC ID: E5MDS- MERCMIMO Dear Sir/Madam, We, Microwave Data Systems, would like to request that the schematic diagrams, system block diagram, Theory of Operation and Bill of Materials submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457(d) of the Commission's Rules, and Section 552(b)(4) of the Freedom of Information Act. These sections authorize as a withholding from public inspection materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any queries, please do not hesitate to contact me at 585 242-8440: Yours truly, Dennis McCarthy Agency Compliance Engineer GE MDS 175 Science Parkway Rochester NY 14620 Phone (585) 242-8440 Email [email protected]

175 Science Parkway, Rochester, New York 14620 USA (585) 242-9600 Phone (585) 242-9620 Fax May 17th, 2010 Applicant: GE MDS LLC. Product: MERCURY3650-MIMO Dear Sir/Madam, Elliott TCB 684 W. Maude Avenue Sunnyvale, CA 94085 Mercury 3650 Contention protocol: Referencing document FCC-07-99A1, Paragraph 34 describes unrestricted and restricted contention-based protocols, respectively: “Those contention protocols that we refer to as unrestricted protocols are broadly compatible and function to prevent interference even with other, dissimilar contention technologies on the market.” and “On the other hand, restricted contention protocols can prevent interference only with other devices incorporating the same protocol.” The Mercury 3650 employs WiMAX scheduling that is categorized as a restricted contention protocol. The WiMAX contention protocol used in the Mercury 3650 allows for coordination to avoid interference with other WiMAX operators, but does not provide the ability to prevent interference to other spectrum users employing alternate interference technology. The MDS Mercury 3650 employs an IEEE 802.16D WiMAX chipset for the media access control and modem. The WiMAX protocol standard provides a point-to- multipoint channel access scheme that is controlled by the base station. The MDS Mercury 3650 uses Time Division Duplex causing the downlink to operate for part of the time and the uplink to operate for part of the time. The base station to subscriber station communications, also known as the downlink, is controlled entirely by the base station. In the uplink, the subscriber station uses contention opportunities scheduled by the base station to request an allocation of bandwidth for sending payload data. The base station answers these requests by providing bandwidth grants. If a subscriber station does not receive a bandwidth grant within an interval of time it will resubmit its request on its next contention opportunity. If the subscriber station continues to not get a bandwidth grant it will discard the payload frame. Contentions are resolved using a truncated binary exponential backoff. The base station controls both the initial and maximum backoff windows. When contending, the subscriber station randomly chooses a number of deferred contention opportunities before transmitting. The Mercury 3650 allows the installer to configure an Approved Access Point list that contains the MAC addresses of desired AP radios in the network. When an Access Point sends scheduling data to the Mercury 3650 remote, the remote compares the MAC Address of the AP to this approved MAC address list, and discards the scheduling information if it has originated from a foreign network. This allows coexistence with co- channel WiMAX networks with minimal interference. If you have any queries, please do not hesitate to contact me at 585 242-8440: Yours truly, Dennis McCarthy Agency Compliance Engineer GE MDS 175 Science Parkway Rochester NY 14620 Phone (585) 242-8440 Email [email protected]

Radio Test Data Client: Contact: Standard: Test Specific Details General Test Configuration 24.9(Note - manual states 25cm required) 24.6 Calculation uses the free space transmission formula: S = (PG)/(4 πd 2 ) Where: S is power density (W/m 2 ), P is output power (W), G is antenna gain relative to isotropic, d is separation distance from the transmitting antenna (m). Summary of Results Minimum separation distance for 18dBi ant. (in cm): Minimum separation distance for 13dBi ant. (in cm): Test Engineer Mehran Birgani Date of Evaluation 10/14/2010 FCC Part 90, RSS-119Class: - Maximum Permissible Exposure Objective: The objective of this test session is to perform final qualification testing of the EUT with respect to the specification listed above. Model: MERCURY2 T-Log Number: T80830 Account Manager: Susan Pelzl GE MDS LLCJob Number: J80799 Dennis McCarthy 24.6 Minimum separation distance for 13dBi ant. (in cm): Modifications Made During Testing No modifications were made to the EUT during testing Deviations From The Standard No deviations were made from the requirements of the standard. T80830.xlsMPE CalculationPage 1 of 2 Radio Test Data Client: Contact: Standard: FCC Part 90, RSS-119Class: - Model: MERCURY2 T-Log Number: T80830 Account Manager: Susan Pelzl GE MDS LLCJob Number: J80799 Dennis McCarthy Use: General Antenna: Panel 18dBi less 6dB cable loss Cable LossAntPower Freq.LossGainat AntEIRP MHzdBmmWdBdBidBmmW 3652 - 3673 26.9489.861820.97762.47 For the cases where S > the MPE Limit Freq. MHz 3652 - 3673 Use: General Antenna: Omni 13dBi less 6dB cable loss Cable LossAntPower Freq.LossGainat AntEIRP MHzdBmmWdBdBidBmmW 3652 - 3673 31.81513.661325.87585.78 mW/cm^2mW/cm^2 1.0001.509 EUTPower Density (S)MPE Limit 1.00024.9 Total Power*at 20 cmat 20 cm at 20 cm mW/cm^2 1.000 1.544 1.544 Power Density (S)MPE LimitDistance where mW/cm^2mW/cm^2cm Power Density (S) at 20 cmat 20 cmS <= MPE Limit mW/cm^2 MPE LimitEUT Total Power*at 20 cm 3673 For the cases where S > the MPE Limit Freq. MHz 3652 - 3673 * Maximum measured total output power from the radio for this antenna. The total power is integrated over the 99% bandwidth of the output. Power Density (S)MPE LimitDistance where at 20 cmat 20 cmS <= MPE Limit 1.5091.00024.6 mW/cm^2mW/cm^2cm T80830.xlsMPE CalculationPage 2 of 2

File: R80994 Rev 1 Page 1 of 18 Radio Test Report FCC Part 90 (3650 MHz to 3700 MHz) Model: MERCURY2-MIMO COMPANY: GE MDS LLC 175 Science Parkway Rochester, NY 14620 TEST SITE(S): Elliott Laboratories 41039 Boyce Road. Fremont, CA. 94538-2435 REPORT DATE: December 13, 2010 FINAL TEST DATES: October 11, 13, 14 and 20, 2010 AUTHORIZED SIGNATORY: ______________________________ David W. Bare Chief Engineer Elliott Laboratories Elliott Laboratories is accredited by the A2LA, certificate number 2016-01, to perform the test(s) listed in this report, except where noted otherwise. This report shall not be reproduced, except in its entirety, without the written approval of Elliott Laboratories Elliott Laboratories -- EMC Department Test Report Report Date: December 13, 2010 File: R80994 Rev 1 Page 2 of 18 REVISION HISTORY Rev# Date Comments Modified By - 12/3/2010 First release 1 12/13/2010 Correct typographical error in summary power values on page 6 and removed references to RSS-GEN and RSS-197 dwb Elliott Laboratories -- EMC Department Test Report Report Date: December 13, 2010 File: R80994 Rev 1 Page 3 of 18 TABLE OF CONTENTS REVISION HISTORY .............................................................................................................................................. 2 TABLE OF CONTENTS .......................................................................................................................................... 3 SCOPE........................................................................................................................................................................ 4 OBJECTIVE .............................................................................................................................................................. 5 STATEMENT OF COMPLIANCE......................................................................................................................... 5 DEVIATIONS FROM THE STANDARDS ............................................................................................................ 5 TEST RESULTS........................................................................................................................................................ 6 FCC PART 90Z – BASE AND FIXED STATIONS, 3650 – 3700 MHZ.................................................................... 6 EXTREME CONDITIONS .................................................................................................................................... 7 MEASUREMENT UNCERTAINTIES..................................................................................................................7 EQUIPMENT UNDER TEST (EUT) DETAILS .................................................................................................... 8 GENERAL.............................................................................................................................................................. 8 OTHER EUT DETAILS......................................................................................................................................... 8 ENCLOSURE......................................................................................................................................................... 8 MODIFICATIONS................................................................................................................................................. 8 SUPPORT EQUIPMENT....................................................................................................................................... 8 EUT OPERATION ................................................................................................................................................. 8 TESTING ................................................................................................................................................................... 9 GENERAL INFORMATION ................................................................................................................................. 9 RF PORT MEASUREMENT PROCEDURES .................................................................................................... 10 OUTPUT POWER................................................................................................................................................ 10 BANDWIDTH MEASUREMENTS ....................................................................................................................11 CONDUCTED SPURIOUS EMISSIONS............................................................................................................ 11 TRANSMITTER MASK MEASUREMENTS..................................................................................................... 11 FREQUENCY STABILITY ................................................................................................................................. 11 RADIATED EMISSIONS MEASUREMENTS.................................................................................................... 12 INSTRUMENTATION ........................................................................................................................................ 13 FILTERS/ATTENUATORS ................................................................................................................................ 13 ANTENNAS......................................................................................................................................................... 13 ANTENNA MAST AND EQUIPMENT TURNTABLE ..................................................................................... 13 SAMPLE CALCULATIONS ................................................................................................................................. 14 SAMPLE CALCULATIONS - CONDUCTED SPURIOUS EMISSIONS ......................................................... 14 SAMPLE CALCULATIONS –RA…
