E8HDCD210C200WIRELESS CAMCORDER
Chicony Electronics Co Ltd
Click to zoom
Application Details
- Equipment Class
- DTS - Digital Transmission System
- Date of Grant
- Apr 24, 2013
- Application Purpose
- Original Equipment
- Date of Application
- Apr 23, 2013
- Equipment Note
- WIRELESS CAMCORDER
- Frequency Range
- 2412.00000000 - 2462.00000000
- Company
- Chicony Electronics Co Ltd
- Country
- Taiwan
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
Wireless Camcorder User Manual English | Names of Parts | 1 Getting Started Mini USB Port Photo button Wide/Tele lever Light External lens filter mount Lens Indicator Microphone Speaker LCD touch panel Record button Power button HDMI port Digital light button Pause button Tripod socket Battery / SD card cover | || 1 Getting Started Charging the Unit β’ Before initial use, fully charge the camera via power adapter or USB to computer system. β’ During charging, the indicator flashes. When the camera is fully charged, the indicator turns off. Shoot Video β’ Press Record button to shoot videos and press it again to stop. Take Photo β’ Press Photo button halfway down to focus, and then press it all the way down to take photos. Before using wireless modes, install below applications: β’ Mobile app: Download [Unieye] from Google Play or Apple Store. β’ PC software: Install [Unieye] from camera (Windows). (page 6) Modes Navigation β’ Tap the LCD touch panel to display the main menu. [Direct Mode] Connecting camera to mobile or PC for remote controlling, live viewing, album managing, and camera setup. [Cloud Mode] Connecting camera to cloud server via access point (AP) or mobile hotspot for internet videos and live monitoring. [Playback] To view or delete the videos or photos. [Setup] To setup camera (refer to page 7). English | 2 English | Direct Mode (Local) Mobile / PC Direct Mode (Mobile) For initial use, install [Unieye] app on mobile. Each camera has a unique Camera ID. ( C2-xxxxxxxx) Password is not required for the initial use, however, it is advised to go to [Setup] in [Unieye] to setup password after connection is completed. Connect to Camera For iOS user: β’ Set camera to Direct Mode . β’ On mobile, go to [Settings] [Wi-Fi]Select camera. 3G connection will switch to WiFi within 1 min. β’ Run [Unieye]. β’ Press camera bar to start. Zoom In Zoom Out Take Photo Shoot Video Invert Image Android: iOS: For Android user: β’ Set camera to Direct Mode and wait until the is lit. β’ Activate WiFi on mobile. β’ Run [Unieye]. β’ Press camera bar to start. | 3 Cloud Mode (Mobile) Note: Move the camera further away from mobile when echo occurs. Keeping the LCD display on preview in order to use live streaming on mobile. Two Way Voice β’ Press to turn on mobile mic. and speak to camera. β’ Camera mic. is muted while speaking. || 3 Cloud Mode (Mobile) Cloud Mode (Internet) AP Cloud Server Cloud AP AP Mobile Hotspot Mobile / PC USTREAM 3G/4G Before using Cloud Mode, setting up cloud AP and cloud server on camera are required. Step 1: Setup Cloud AP in Direct Mode On mobile, got to app [Setup][Cloud Settings][Cloud AP]. Select a WiFi network from [AP list] and enter password. If no preferred AP is found, press [Other] from [AP list]Enter network SSID and password. Note: Mobile hotspot can be set as Cloud AP. Step 2: Setup Cloud Server in Direct Mode β’ New user, press then enter email/username/password for auto- registration. Returning user, enter email/username/password only. β’ Select cloud server for camera to access. β’ Press [Save to Camera]. A live broadcasting social media. USTREAM Recommended Cloud Server for Access: English | 4 English | Step 3: Connect Camera to Cloud Server Options to connect to cloud server: 1. On mobile, press [Camera to Cloud] in [Setup] page. 2. On camera, set to [Cloud Mode] If connection fails, one of the following situations will be shown. Step 4: View Live Video on Cloud Server Options to view live videos: 1. Use mobile app: USTREAM is available in Google Play or Apple Store. 2. Visit website: http://www.ustream.tv Then search for username and select "username's show" to watch live video through camera. Note: 1. Cloud service may change depending on their policy. 2. In some areas, mobile may not activate hotspot where there is no 3G/4G. 3. Experiencing delays while viewing live video may be due to high internet traffic. SituationCause/Solution Cannot connect to cloud AP or invalid SSID password. Camera not inside WiFi area or weak signal. Check AP settings or move camera closer to cloud AP. No internet or the cloud server is not accessible. Cannot log in cloud server via internet. Cloud service may be blocked by firewall. Cloud server username or password incorrect. Refer toin [Setup] for instructions. Username already taken. Create new account in [Unieye]. | 5 Cloud Mode (Mobile) | PC Application To use [Unieye] on PC, install [Unieye] PC software first. The [Unieye] PC version has similar features and interface to the [Unieye] mobile version for easy user experience. Install [Unieye] PC Software from Camera β’ Connect the camera to PC via a USB cable. β’ [Unieye] AutoRun/AutoPlay activates. β’ If AutoRun/AutoPlay is not starting: Go to [My computer] search [Unieye] for installation. β’ Once installed, unplug the camera from PC then run the [Unieye] PC software. [Unieye] PC Software Features β’ Press [View HD] or double-click the viewing window to maximize it into full screen. Double-click again to return to [Unieye] interface. β’ To save videos or photos to PC: Go to [Album]Select videos or photos Press [Save to PC]. Cloud Mode (Mobile) English | 6 English | Setup List in Camera Resolution FHD 1920x1080p (30fps) HD60 1280x720p (60fps) HD30 1280x720p (30fps) StabilizationStabilize the motion video. LightTurn on/off the LED light. Night ModeSet for night scenes. Slow MotionRecord video in slow motion; resolution 720p. Time Lapse Record one frame per second; 30 frames per second in playback. Self-TimerActivate 10-second self-timer. SoundOperation sound on/off. TV Format NTSC (60Hz) For NTSC TV standard. PAL (50Hz) For PAL TV standard. Format SD CardFormat memory card. Default SettingsRestore camera to factory default. Language English, Spanish, French, German, Portuguese, Italian, Simplified Chinese, Traditional Chinese, Japanese, Korean. | 7 | Setup List in Camera | 7 Troubleshooting SituationCause/Solution Camera cannot turn onBattery power is low. Recharge the battery. Camera cannot turn on aβ¦
