E8HKBR0305Wireless Keyboard

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

LABEL LOCATION FOR FCC ID

REV: X1 CHICONY WUR0305 WUR0305 04/01-'03 0305-CHI 253-00305-00 SCALE: 1.5 : 1 DWG NO.: NOTES NOTES NOTES MODEL NO. MODEL NO.: REMARKPART NO. MAT.: TOL: UNIT: MM Q'TYSIZE: A4 SPEC: APPROVEDCHECKEDDESIGNED NAME: FINISH: REV LTRREV . DIMENSIONDATEDESIGNAPPROVE A B TAMMY SPEC. ID LABEL Made in ******** 79.8 4 9 . 8 +0 + 0 -0.2 - 0 . 2 NOTES: 1.MATERIAL: SYNTHETIC PAPER t=0.15mm (WITH GLUE) (UL/CSA APPROVED) 2.BACKGROUND COLOR: WHITE 3.CHARACTER COLOR: PANTONE Process Black C 4.FINISHED: ADHESIVE. 5.LABEL VENDOR HAS TO BE APPRD. BY UL/CSA. VENDER UL MARK. CET Made in Thailand CEM Made in China CUL/TUV-GS/CE/DGT/BSMI FCC ID: E8HKBR0305 0678 Canada 210 Model Number: KBR0305 Power Rating: 3V 30mA Serial Number: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interfer- ence received, including interference that may cause undesired operation. TUV Rheinland .. geprufte Sicherheit .. R31310 CET \ CET CEM 2 \ CEM2 CEM 3 \ CEM3 E164844 ID: US C R

Page 3 Page 4

FCC ID: E8HKBR0305 ADT No.920321R05 Operational Description The transmitter of the EUT (Wireless Keyboard) which uses Wired Antenna is powered by 3V Battery. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

FCC ID: E8HKBR0305 Report No.: RF920319R03A 1 Issued: April 8, 2003 FCC TEST REPORT REPORT NO.: RF920319R03A MODEL NO.: KBR0305 RECEIVED: Mar. 19, 2003 TESTED: Mar. 24, 2003 APPLICANT:Chicony Electronics Co., Ltd. ADDRESS: No. 25, Wu-Gong 6th Rd., Wu Ku Industrial Park, Taipei Hsien, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chia Pau Tsuen, Linkou Hsiang, Taipei, Taiwan, R.O.C. This test report consists of 13 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Lab Code: 200102-0 0528 ILAC MRA FCC ID: E8HKBR0305 Report No.: RF920319R03A 2 Issued: April 8, 2003 Table of Contents 1CERTIFICATION..............................................................................................3 2SUMMARY OF TEST RESULTS .....................................................................4 3GENERAL INFORMATION..............................................................................5 3.1GENERAL DESCRIPTION OF EUT ................................................................5 3.2DESCRIPTION OF TEST MODES ..................................................................6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS .................................6 3.4DESCRIPTION OF SUPPORT UNITS ............................................................6 4TEST PROCEDURE AND RESULT ................................................................7 4.1CONDUCTED EMISSION MEASUREMENT...................................................7 4.2RADIATED EMISSION MEASUREMENT........................................................7 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT .....................................7 4.2.2 TEST INSTRUMENT .......................................................................................8 4.2.3 TEST PROCEDURE........................................................................................9 4.2.4 TEST SETUP.................................................................................................10 4.2.5 EUT OPERATING CONDITION.....................................................................10 4.2.6 TEST RESULT............................................................................................... 11 5PHOTOGRAPHS OF THE TEST CONFIGURATION ....................................12 6INFORMATION ON THE TESTING LABORATORIES ..................................13 FCC ID: E8HKBR0305 Report No.: RF920319R03A 3 Issued: April 8, 2003 1 CERTIFICATION PRODUCT : Wireless Keyboard BRAND NAME : Chicony MODEL NO : KBR0305 APPLICANT :Chicony Electronics Co., Ltd. STANDARDS : 47 CFR Part 15, Subpart C(15.227) ANSI C63.4-1992 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility on Mar. 24, 2003. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: E8HKBR0305 Report No.: RF920319R03A 4 Issued: April 8, 2003 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.207Conducted Emission TestN/A Power supply is 3VDC from batteries 15.227Radiated Emission TestPASS Meet the requirement of limit Minimum passing margin is –17.5dBuV/m at 217.54MHz NOTE: The receiver part to communicate with the EUT has been verified to comply with FCC Part 15, Subpart B, Class B (DoC). The test report can be provided upon request. FCC ID: E8HKBR0305 Report No.: RF920319R03A 5 Issued: April 8, 2003 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCTWireless Keyboard MODEL NO.KBR0305 POWER SUPPLY3VDC from Battery MODULATION TYPEFSK CARRIER FREQUENCY OF EACH CHANNEL 27.195MHz BANDWIDTH OF EACH CHANNEL NA NUMBER OF CHANNEL1 ANTENNA TYPEWired antenna DATA CABLENA I/O PORTSNA ASSOCIATED DEVICESNA NOTE: 1. The EUT is the transmitter part of Wireless Keyboard. 2. For more detailed features description of the EUT, please refer to the manufacturer's specifications or the User's Manual. FCC ID: E8HKBR0305 Report No.: RF920319R03A 6 Issued: April 8, 2003 3.2 DESCRIPTION OF TEST MODES One channel was provided to this EUT. ChannelFrequency 127.195 MHz 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS The EUT is the transmitter part of a Wireless Keyboard. According to the specifications of the manufacturer, it must comply with the requirements of the following standards: FCC 47 CFR Part 15, Subpart C (15.227) ANSI C63.4-1992 All tests have been performed and recorded as per the above standards. 3.4 DESCRIPTION OF SUPPORT UNITS NA FCC ID: E8HKBR0305 Report No.: RF920319R03A 7 Issued: April 8, 2003 4 TEST PROCEDURE AND RESULT 4.1 CONDUCTED EMISSION MEASUREMENT NA 4.2 RADIATED EMISSION MEASUREMENT 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT According to 15.227 the field strength of emissions from intentional radiators operated under these frequencies bands shall not exceed the following: Fundamental Frequency (MHz) Field Strength of Fundamental (dBuV/m) PeakAverage 26.96-27.28 10080 Emissions radiated outside of the specified bands, shall be according to the general radiated limits in 15.209 as following: Frequencies (MHz) Field strength (microvolts/meter) Measurement distance (meters) 30-881003 88-2161503 216-9602003 Above 9605003 As shown in 15.35(b), for frequencies above 1000MHz, the field strength limits are based on average detector, however, the peak field strength of any emission shall not exceed the maximum permitted average limits, specified above by more than 20dB under any condition of modulation. FCC I…

Text truncated - open the document above for the full version.

FCC ID: E8HKBR0305 Report No.: RF920319R03A 12 Issued: April 8, 2003 5 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
