Wireless Keyboard + Mouse Kits User’s Manual ~ English ~ A. FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to Part 15 the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. CAUTION: AVOID PROLONGED USE OF THE KEYBOARD WITHOUT BREAKS. Take regular breaks and keep a good posture. Consult your physician promptly if you notice any lost of motion or pain in your wrist when using the keyboard. IMPORTANT BATTERY INFORMATION ● Keep batteries out of reach of children. ● Insert the batteries in the proper direction as indicated by the positive (+) and negative (-) markings in the battery compartment. ● Do not mix old and new batteries or batteries of different types (for example, carbon and alkaline batteries). ● Always remove old, weak, or worn-out batteries promptly and recycle or proper disposal of them in accordance with Local and National Disposal Regulations. ● If a battery leaks, remove all batteries and recycle or dispose of them in accordance with the battery manufacture's instructions and Local and National Disposal Regulations. Before inserting new batteries, thoroughly clean the compartment with a damp paper towel, or follow the battery manufacture's recommendations for cleanup. If fluid from the battery comes into contact with skin or clothes, flush skin with water immediately. ● Remove the batteries if your device is to be stored for an extended period of time without being used. PRODUCT DISPOSAL INFORMATION Dispose of this product in accordance with Local and National Disposal Regulations. B. PRODUCT SPECIFICATION 1. Power requirement: 3V 2. Battery : Keyboard : 2 pieces of AAA Batteries Mouse : 2 pieces of AAA Batteries 3. Battery life time : Keyboard : 900 hours reference (operating mode) Mouse : 300 hours reference (operating mode) 4. Operation distance : Keyboard : 10 M without signal disturbance and no direction limit. Mouse : 10 M without signal disturbance and no direction limit. 5. Mouse resolution : 1600 DPI 6. System OS support: Windows 2000/ XP/ Vista/ Windows 7/ Windows 8 7. Operating temperature : 0°C ~ +40°C 8. Storage temperature : -40°C ~ +65°C Wireless Keyboard + Mouse Kits User’s Manual - 1 - Getting Started Thank you for choosing this 2.4G Wireless keyboard and Mouse Kits. It operates with digital radio technology to ensure no hinder communication between the keyboard, the mouse and your computer without connecting cable. The transmission and receiving of keyboard and mouse are free from angle restriction. Features ● Complies with Directive 1995/5/EC of the European Parliament and Commission. ● Complies with the mutual recognition of conformity 1999 for radio and telecommunications Equipment. ● Manufactured with environmental friendly recycled materials. ● Fully compliant with original USB version 2.0 and HID Version 1.11. Preparing Keyboard, mouse and receiver Before working with your new keyboard and mouse, look at the "Hardware Installation", and take a few one-time preparations. Hardware Installation ● Place the receiver at least 20 cm from other electrical devices (e.g. monitor) to achieve optimum performance. ● The distance between the keyboard, mouse and receiver should not exceed 10 M. ● Do not place the receiver on metal surfaces. ● Do not move optical mouse on following surface - Glass or any transparent materials Dark surface Mirror or reflecting surface Mouse pad with too many colors Rough surface. Step 1: Connect the receiver ● Plug the dongle connector into an USB port. ● SYSTEM will take around 10 sec to find your keyboard and mouse automatically. Step 2: Insert batteries Inserting batteries in mouse The mouse requires two alkaline AAA batteries. ● Remove the battery compartment cover on the bottom of the mouse ● First push the battery puller in then insert two AAA batteries into battery compartment. ● Fix the battery compartment cover (1)on the bottom of mouse again. CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to instructions. Refer to "Important Battery Information" for disposal instructions. Inserting batteries in keyboard The keyboard requires two alkaline batteries (AAA). ● Remove the battery compartment cover (1) on the bottom of the keyboard by pushing it in the direction of arrow. ● Insert two AAA batteries. The illustration in the battery compartment (2) shows how to insert the batteries prope…

Text truncated - open the document above for the full version.

Chicony Electronics Co., Ltd. NO. 25, Wu-Gong 6th Rd., Wugu Dist., New Taipei City 248, Taiwan, R.O.C. Tel: 886-2-22988120 Fax: 886-2-22989745 Power of Attorney To whom it may concern: Date: August 13, 2012 We, the undersigned, Chicony Electronics Co., Ltd., hereby authorize Bureau Veritas Consumer Products Services(H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan on our behalf shall have the same effects as acts of our own. Product Name Model FCC ID Wireless Keyboard KG-1213 E8HKG-1213 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------ T.S.Chen / Manager Chicony Electronics Co., Ltd. Tel: +886 2-2298-8120 Fax: +886 2-2298-9745 E-mail : [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT

REV: A NO BRAND KG-1213 08/09-’12 08/09-’12 08/09-’12 KG1213-FCC(253)-X0 253-01213L- SCALE: 1 : 1 DWG NO.: NOTES NOTES NOTES MODEL NO. MODEL NO.: REMARKPART NO. MAT.: TOL: UNIT: MM Q'TYSIZE: A4 SPEC: APPROVEDCHECKEDDESIGNED NAME: FINISH: REV LTRREV . DIMENSIONDATEDESIGNAPPROVE B C TAMMYT. S.JAKE SPEC. ID LABEL NOTES: 1. MATERIAL: SYNTHETIC PAPER t=0.15mm (WITH GLUE) (UL/CSA APPROVED) 2. BACKGROUND COLOR: WHITE 3. TEXT COLOR: PANTONE Process Black C 4. FINISHED: ADHESIVE. 5. LABEL VENDOR HAS TO BE APPRD. BY UL/CSA 6. THIS PRODUCT/COMPONENT MUST COMPLY WITH CHICONY SPECIFICATION "ISO 361" KG-1213 Model Number : KG-1213 Power Rating : 3V 30mA Serial Number : Made in China This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received , including interference that may cause undesired operation.000000000 VENDER UL MARK FCC ID: E8HKG-1213

FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

Page 2 Page 3 Page 4 Page 5 Page 6 Page 7

FCC ID: E8HKG-1213 Report No.: RF120725D10 Operational Description The transmitter of the EUT (Wireless Keyboard) is powered by 3Vdc from batteries. The type of antenna is Strip antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: RF120725D10 1 of 23 Report Format Version 5.0.0 FCC TEST REPORT REPORT NO.: RF120725D10 MODEL NO.: KG-1213 FCC ID: E8HKG-1213 RECEIVED: Jul. 25, 2012 TESTED: Jul. 27, 2012 ISSUED: Aug. 1, 2012 APPLICANT: Chicony Electronics Co., Ltd. ADDRESS: NO. 25, Wu-Gong 6th Rd., Wugu Dist., New Taipei City 248, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF120725D10 2 of 23 Report Format Version 5.0.0 Table of Contents RELEASE CONTROL RECORD..................................................................................3 1. CERTIFICATION...............................................................................................4 2. SUMMARY OF TEST RESULTS.......................................................................5 2.1 MEASUREMENT UNCERTAINTY....................................................................5 3. GENERAL INFORMATION...............................................................................6 3.1 GENERAL DESCRIPTION OF EUT..................................................................6 3.2 DESCRIPTION OF TEST MODES....................................................................7 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL....................8 3.3 DESCRIPTION OF SUPPORT UNITS............................................................10 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST.............................................10 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS.................................11 4. TEST TYPES AND RESULTS.........................................................................12 4.1 CONDUCTED EMISSION MEASUREMENT..................................................12 4.2 RADIATED EMISSION AND BAND EDGE MEASUREMENT.........................12 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.....................................12 4.2.2 TEST INSTRUMENTS....................................................................................13 4.2.3 TEST PROCEDURES.....................................................................................14 4.2.4 DEVIATION FROM TEST STANDARD...........................................................14 4.2.5 TEST SETUP..................................................................................................15 4.2.6 EUT OPERATING CONDITIONS....................................................................15 4.2.7 TEST RESULTS..............................................................................................16 5. PHOTOGRAPHS OF THE TEST CONFIGURATION......................................21 6. INFORMATION ON THE TESTING LABORATORIES....................................22 7. APPENDIX A – MODIFICATION RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB.........................................................23 Report No.: RF120725D10 3 of 23 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF120725D10 Original release Aug. 1, 2012 Report No.: RF120725D10 4 of 23 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: Wireless Keyboard BRAND: Chicony MODEL NO.: KG-1213 APPLICANT: Chicony Electronics Co., Ltd. TESTED: Jul. 27, 2012 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.10-2009 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Annie Chang / Supervisor ) APPROVED BY : , DATE: ( Ken Liu / Manager ) Report No.: RF120725D10 5 of 23 Report Format Version 5.0.0 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD PARAGRAPH TEST TYPE RESULT REMARK 15.207 Conducted Emission Test N/A Power supply is 3.0Vdc from batteries 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 15.209 PASS Meet the requirement of limit. Minimum passing margin is -9.0dB at 2390.00MHz. 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have bee…

Text truncated - open the document above for the full version.

Report No.: RF120725D10 1 of 1 Report Format Version 5.0.0 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
