Chicony Standard Bluetooth Keyboard Users Manual Model No.: KT-1263 Issue: May. 28, 2012 Scope Getting Start Thank you for choosing this ultrathin keyboard with Bluetooth technology to ensure no hinder communication between the keyboard and your computer without connecting cable. The transmission and receiving of keyboard are free from angle restriction. It can be used with IBM PC compatible computers pre-installed with the Windows 7, Windows Vista or Windows XP operating system. Part Names Hot Keys Status light indicator ¾ Battery Status Led Battery low : Red LED will be lighted for 0.5seconds and will be lighted again after 5 seconds. This will be repeating until no power or start recharging. ¾ Connect Status Led Power ON : Blue LED brighten 5sec Pairing ： Blue LED flash 0.5s/0.5s (3min) Searching: Blue LED brighten 5sec continued to success Charging: Red LED flash 0.5s/0.5s Charging full: Red LED turn off Before Use ¾ Recharging the battery Plug USB recharge cable from keyboard to PC USB hub or USB adaptor at least 10 minutes. Ensure battery power is above low level. ¾ Set power switch is On Configuring the Keyboard Configuring Steps Operation of the Bluetooth software may vary depending on your personal computer/device. For details, refer to the manuals provided with your personal computer. The setup instructions are based on your operating system. Case A: Click (Start), then “Control Panel.” Case B: Click the “Hardware and Sound” icon. Case C: If the “Bluetooth Devices” icon is in the “Hardware and Sound” window: Then go to following D, if the “Bluetooth Devices” icon is not visible in the “Hardware and Sound” window: Close the “Control Panel” and go to pre-install XP section. Case D: Click the “Bluetooth Devices” icon, and verify the contents of the window displayed. If you switch to Classic View, double-click the “Bluetooth Devices” icon. Case E: Review the Bluetooth Devices windows shown here. If you see window 1, go to the instructions in Step (A). If you see window 2, go to the instructions in Step (B). Window 1 Window 2 Steps (A) 1. Turn on the keyboard. 2. Press the CONNECT button on the bottom of the keyboard. The status light flashes blue. 3. On the “Bluetooth Devices” window, click the “Add Wireless Device” icon. 4. In the device list, select “Bluetooth Keyboard” and click “Next.” 5. When “This device has been successfully added to this computer” window displayed, you can start use this Bluetooth Keyboard. Steps (B) 1. Turn on the keyboard. 2. On the “Bluetooth Devices” window, select the “Devices” tab and click “Add.” The “Add Bluetooth Device Wizard” appears. 3. Press the CONNECT button on the bottom of the keyboard. The status light flashes blue. 4. Select the “My device is set up and ready to be found” check box and click “Next.” 5. In the device list, select “Bluetooth Keyboard” and click “Next.” 6. When “This device has been successfully added to this computer” window displayed, you can start use this Bluetooth Keyboard. Here is an example for Bluetooth keyboard configuration to Windows Vista and Windows 7. Step 1: Click the “Bluetooth Devices” icon Æ choose “Add a Device”. Step 2: In “Select a device to add to this computer” window Æ choose “Bluetooth Keyboard” Æ “Next” Note: If this step failed, please click “Try Again” and press any key on the Bluetooth Keyboard to reconnect again. Step 4: When “This device has been successfully added to this computer” window displayed, you can start use this Bluetooth Keyboard. Disconnecting Turn off the Keyboard. Reconnection Turn on the Keyboard, and then reconnect. Note It may take time to reconnect after turning off the Keyboard. Troubleshooting and Tips The keyboard does not operate following installation or is not recognized. • Make sure the batteries are not too weak. • To determine whether the keyboard, mouse or computer causes the problem test the keyboard and mouse on a second computer if possible; or test another keyboard and mouse on your current computer. If you are still unable to solve the problem, please contact your point of sale or your dealer. If you need to exchange the keyboard, please note that you must return it to your dealer in its original packaging and also a produce proof of purchase (receipt). Keep your receipt in a safe place after purchase. FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to Part 15 the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference wil not occur in a particular installation. If this equipment does cause harmful interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful Interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your…

Text truncated - open the document above for the full version.

Chicony Electronics Co., Ltd. No.25 Wu-Gong 6 Th Rd. Wu-Ku Industrial Park, Taipei, Taiwan, R.O.C. Tel: 886-2-22988120 Fax: 886-2-22989745 Federal Communications Commission Authorization and Evaluation Division Date: 6/4/2012 Confidentiality Request FCC ID: E8HKT-1263 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Thank you! Sincerely yours, ------------------------------------------ T.S.Chen / Manager Chicony Electronics Co., Ltd. Tel: +886 2-2298-8120 Fax: +886 2-2298-9745 E-mail : [email protected]

Chicony Electronics Co., Ltd. No.25 Wu-Gong 6 Th Rd. Wu-Ku Industrial Park, Taipei, Taiwan, R.O.C. Tel: 886-2-22988120 Fax: 886-2-22989745 Power of Attorney To whom it may concern: Date: June 4, 2012 We, the undersigned, Chicony Electronics Co., Ltd., hereby authorize Bureau Veritas Consumer Products Services(H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan on our behalf shall have the same effects as acts of our own. Product Name Model FCC ID Bluetooth Keyboard KT-1263 E8HKT-1263 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------ T.S.Chen / Manager Chicony Electronics Co., Ltd. Tel: +886 2-2298-8120 Fax: +886 2-2298-9745 E-mail : [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received , including interference that may cause undesired operation. 00000 06/04-’12 06/04-’12 06/04-’12 FCC ID: E8HKT-1263 REV: B CHICONY KT-1263 KT1263-FCC(CHICONY)-X0 253-01263L- SCALE: 1 : 1 DWG NO.: NOTES NOTES NOTES MODEL NO. MODEL NO.: REMARKPART NO. MAT.: TOL: UNIT: MM Q'TYSIZE: A4 SPEC: APPROVEDCHECKEDDESIGNED NAME: FINISH: REV LTRREV . DIMENSIONDATEDESIGNAPPROVE B C TAMMYMAGGIETOMMY SPEC. ID LABEL NOTES: 1. MATERIAL: SYNTHETIC PAPER t=0.1mm (WITH GLUE) (UL/CSA APPROVED) 2. BACKGROUND COLOR: WHITE 3. TEXT COLOR: PANTONE Process Black C 4. FINISHED: ADHESIVE. 5. LABEL VENDOR HAS TO BE APPRD. BY UL/CSA 6. THIS PRODUCT/COMPONENT MUST COMPLY WITH CHICONY SPECIFICATION "ISO 361" KT-1263 The Windows logo is a registered trademark of Microsoft Corporation. Model No.: KT-1263 Power Rating: 3.7V 30mA USB Charge power: 5V 100mA Serial No.: Made in China +0 -0.2 +0 -0.2 VENDER UL MARK.

FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

Page 3 Page 4 Page 5 Page 6

FCC ID: E8HKT-1263 Report No.: RF120523D02 Operational Description The device is a Frequency Hopping device with 79 hopping frequencies. The antenna type is Printed antenna and there is no antenna connector used. The EUT is a unit that contains a Bluetooth radio module. Bluetooth is a short-range wireless technology operating in the 2.4GHz band. It enables devices to have the ability to form networks and exchange information. The other instruction, please have a look at the user’s manual.
