E8HKT-1409Bluetooth Wireless Keyboard

E9288 / First Edition / April 2014 ASUS Mobile Dock Keyboard Touchpad gestures 1. Finger slide2. Tap/Double tap Slide your finger across the touchpad to move the pointer. Single tap to select an item. Double tap to launch an item. 3. Drag and drop4. Two-finger scroll (up/down) Select an item then press and hold the left-click button. Using your other finger, slide down the touchpad to drag and drop the item to a new location. Slide two fingers to scroll up or down. 5. Two-finger scroll (left/right)6. Two-finger tap and hold Slide two fingers to scroll left or right.Use two fingers to hold a selected item. 2. Micro USB port Use this port charge the charge the battery pack. 1. Charging/Bluetooth LED indicator This LED indicator flashes different colors when charging your ASUS mobile dock keyboard or establishing a Bluetooth connection. 5. Touchpad Allows you to use multi-gestures to navigate onscreen, and simulates the functions of a regular mouse. 3. Bluetooth/power switch Turns your ASUS mobile dock keyboard off. Turns your ASUS mobile dock keyboard on. Turns the Bluetooth function on. 4. Function keys These keys allow you to perform different tasks on your Tablet PC. Hardware setup • ASUS Mobile Dock Keyboard • Quick Start Guide WARNING! Keep your TransBoard away from electromagnetic devices, especially navigational aids and transmission devices such as antennas and routers. NOTE: If any of the items is damaged or missing, contact your retailer. Using your ASUS mobile dock keyboard Docking your ASUS PadFone To dock your ASUS PadFone: Put the ASUS mobile dock keyboard on a flat and stable surface. Align the ASUS PadFone with the ASUS mobile dock keyboard. Firmly insert the ASUS PadFone into the hinge. IMPORTANT! Always pick up the entire assembly from the bottom when your ASUS PadFone is attached to the ASUS mobile dock keyboard. Charging your ASUS mobile dock keyboard To charge your ASUS mobile dock keyboard: Connect the USB cable to the power adapter. Insert the Micro USB end of the USB cable to the mobile dock keyboard. Plug the power adapter into a grounded power outlet. Charge your ASUS mobile dock keyboard for eight (8) hours before using it in battery mode for the first time. IMPORTANT! • Use only the ASUS PadFone’s bundled power adapter and USB cable to charge your ASUS PadFone mobile dock keyboard. Using a different power adapter may damage these devices. • Ensure that you plug the power adapter to the correct power outlet with the correct input rating. The output voltage of this adapter is DC 5V, 250mA. • When using your ASUS PadFone assembly while plugged-in to a power outlet, the grounded power outlet must be near the unit and easily accessible. Home PgDp PgUp End Fn Returns to the previous page. Home PgDp PgUp End Fn Toggles the internal wireless LAN ON or OFF. Home PgDp PgUp End Fn Toggles the internal Bluetooth ON or OFF. Home PgDp PgUp End Fn Toggles the touchpad ON or OFF. Home PgDp PgUp End Fn Decreases the display brightness. Home PgDp PgUp End Fn Increases the display brightness. Home PgDp PgUp End Fn Toggles the ambient light sensor ON or OFF. Home PgDp PgUp End Fn Captures the screen image. Home PgDp PgUp End Fn Launches the web browser. Home PgDp PgUp End Fn Launches the Settings screen. The special keys on your ASUS mobile dock keyboard have standalone functions and some must be used with the function key <Fn>. NOTE: The placement of the special keys on the mobile dock keyboard may vary with country or region, but their functions remain the same. Home PgDp PgUp End Fn Returns to the previous track when playing music. Home PgDp PgUp End Fn Starts playing music from your playlist. Resumes or pauses the current playback. Home PgDp PgUp End Fn Fast forwards or skips to the next track during playback. Home PgDp PgUp End Fn Mutes the speaker. Home PgDp PgUp End Fn Decreases the speaker volume. Home PgDp PgUp End Fn Increases the speaker volume. Home PgDp PgUp End Fn Locks the ASUS PadFone and put it into sleep mode. Returns to Home Screen. Browses the contents in the ASUS PadFone and the web. Activates the properties menu and is equivalent to or on the screen. Home PgDp PgUp End Fn Home PgDp PgUp End Fn Press <Fn> and the arrow keys to scroll up and down or scroll to the start and end of a document or web page. Undocking your ASUS PadFone To undock your ASUS PadFone: Put the entire assembly on a flat and stable surface. Remove the ASUS PadFone from the ASUS mobile dock keyboard. ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components, as well as the packaging materials. Please go to http://csr.asus.com/english/Takeback.htm for the detailed recycling information in different regions. REACH Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of Chemicals) regulatory framework, we published the chemical substances in our products at ASUS REACH website at http://green.asus.com/english/REACH.htm VCCI: Japan Compliance Statement (VCCI Class B Statement) Taiwan Wireless Statement 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大 功率或變更原設計之特性及功能。低功率射頻電機之使用不得影響飛航安全及干擾合法通信； 經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前項合法通信，指依電信 法規定作業之無線電通信。低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性 電機設備之干擾。 Industry Canada Statement This device complies with RSS-210 of Industry Canada rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme à la norme CNR-210 d’Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brou…

Text truncated - open the document above for the full version.

Chicony Electronics Co., Ltd. NO. 25, Wu-Gong 6th Rd., Wugu Dist., New Taipei City 248, Taiwan, R.O.C Tel: 886-2-22988120 Fax: 886-2-22989745 Federal Communications Commission Authorization and Evaluation Division Date: 4/24/2014 Confidentiality Request FCC ID: E8HKT-1409 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Thank you! Sincerely yours, ------------------------------------------ T.S.Chen / Manager Chicony Electronics Co., Ltd. Tel: +886 2-2298-8120 Fax: +886 2-2298-9745 E-mail : [email protected]

Chicony Electronics Co., Ltd. NO. 25, Wu-Gong 6th Rd., Wugu Dist., New Taipei City 248, Taiwan, R.O.C Tel: 886-2-22988120 Fax: 886-2-22989745 Date: 2014-04-24 FCC ID: E8HKT-1409 AUTHORIZATION LETTER To whom it may concern: We, the undersigned Chicony Electronics Co., Ltd. hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in FCC Part 15C and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan on our behalf shall have the same effects as acts of our own. 1. FCC ID:E8HKT-1409 for model: PF-06 Mobile Dock If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------ T.S.Chen / Manager Chicony Electronics Co., Ltd. Tel: +886 2-2298-8120 Fax: +886 2-2298-9745 E-mail : [email protected]

Chicony Electronics Co., Ltd. NO. 25, Wu-Gong 6th Rd., Wugu Dist., New Taipei City 248, Taiwan, R.O.C Tel: 886-2-22988120 Fax: 886-2-22989745 Federal Communications Commission Authorization and Evaluation Division Date: May 6, 2014 Confidentiality Request FCC ID: E8HKT-1409 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we request short-term confidential treatment for the following information until Aug. 4, 2014 of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External Photos Test Setup Photos User’s Manual Internal Photo Thank you! Sincerely yours, ------------------------------------------ T.S.Chen / Manager Chicony Electronics Co., Ltd. Tel: +886 2-2298-8120 Fax: +886 2-2298-9745 E-mail : [email protected]

Page 1 of 7 Report No.: 140403D07 CONSTRUCTION PHOTOS OF EUT Brand Name: ASUS / Model Name: PF-06 Mobile Dock

ABCDEFGH CHECKAPPROVE DESIGN ASUS KT-1409 PART NAME: PART NO.: DWG No.: 04/17-’14 04/17-’14 04/17-’14 REV. A TAMMY MAGGIE JERRY 14090311L SPEC. ID LABEL ADHESIVE LOCATION * 僅供參考LABEL黏貼位置，其他料件 請參照承認圖面。 000-01409L-A05 SPEC. ID LABEL SPEC. ID LABEL

ABCDEFGH CHECKEDAPPROVED DESIGNED ASUS/BLACK KT-1409 PART NAME: DWG No.: SPEC. ID LABEL 1 US 783-14093L-A 90XB01YP-BKB000 (B) 1 Item Language Chicony P/N (A) NOTES: 1. MATERIAL: SYNTHETIC PAPER t=0.1mm (WITH GLUE) (UL/CSA APPROVED) 2. BACKGROUND COLOR: PANTONE Process Black C 3. TEXT & SYMBOLS COLOR: WHITE 4. ADDED PRINTING TEXT COLOR: WHITE 5. FINISHED: ADHESIVE. 6. LABEL VENDOR HAS TO BE APPRD. BY UL/CSA 7. THIS PRODUCT/COMPONENT MUST COMPLY WITH CHICONY SPECIFICATION "ISO 361" REV. D KT1409-FCC(783)-X4-TS 04/09-’14 04/09-’14 04/09-’14 JERRYT. S.TAMMY VENDER UL MARK. 4-R0.5 109.5 0.1 + - 15.5 0.1 + - Model No.(型號/型號): PF-06 Mobile Dock S/N: P/N: FCC ID: E8HKT-1409 Input Rating(額定電壓電流/額定: 3.7V 30mA USB Charge Rating(充電電壓電流/充電電壓電流): 5V 250mA 電壓電流) Bluetooth Wireless Keyboard 製造商 / 製造商 : 華碩電腦股份有限公司 ( 中國製造 / 中國製造 ) Made in China ( /藍牙無線鍵盤) 藍牙無線鍵盤 BC S/N **** ** BEHAD BEHAD Month code (1碼). Jan. 1, Feb. 2... Oct. A, Nov. B, Dec. C \ \ \ \ \ Year code (1碼). EXP.: 2009 \ 9, 2010 \ A, 2011 \ B, 2012 \ C, 2013 \ D, 2014 \ E, 2015 \ F, 2016 \ G, 2017 \ H, 2018 \ J, 2019 \ K, 2020 \ L, 2021 \ M, 2022 \ N, 2023 \ R, 2024 \ S, 2025 \ T, 2026 \ W, 2027 \ X, 2028 \ Y, 2029 \ Z, 2030 \ 0, 2031 \ 1... ***** ******************** Serial No (4碼). .( 0001 ~ 9999, A001~A999, B001~B999, ... Z001-Z999) Star from 0001~Z999 廠別碼(1碼). 茂瑞廠 \ 1, CEM2/清溪廠 \ 2, CEM3/吳江廠 \ 3 ASUS P/N .See Note-(B) 1

Page 2 of 7 Report No.: 140403D07 Page 3 of 7 Report No.: 140403D07 Page 4 of 7 Report No.: 140403D07 Page 5 of 7 Report No.: 140403D07 Page 6 of 7 Report No.: 140403D07 Page 7 of 7 Report No.: 140403D07

FCC ID: E8HKT-1409 Report No.: RF140403D07 Operational Description The device is a Frequency Hopping device with 79 hopping frequencies. The antenna type is PCB antenna and there is no antenna connector used. The EUT is a unit that contains a Bluetooth radio module. Bluetooth is a short-range wireless technology operating in the 2.4GHz band. It enables devices to have the ability to form networks and exchange information. The other instruction, please have a look at the user’s manual.

FCC SAR Test Report Report Format Version 5.0.0 Page No. : 1 of 4 Report No. : SA140403D07 Issued Date : Apr. 30, 2014 FCC SAR Evaluation Report Report No. : SA140403D07 Applicant : Chicony Electronics Co., Ltd. Address : NO. 25, Wu-Gong 6th Rd., Wugu Dist., New Taipei City 248, Taiwan, R.O.C Product : Bluetooth Wireless Keyboard FCC ID : E8HKT-1409 Brand : ASUS Model No. : PF-06 Mobile Dock Standards : FCC 47 CFR Part 2 (2.1093) / IEEE C95.1:1992 / IEEE 1528:2003 IEEE 1528a-2005 / KDB 865664 D01 v01r03 / KDB 447498 D01 v05r02 / KDB 616217 D04 v01r01 Sample Received Date : Apr. 03, 2014 Date of Evaluation : Apr. 30, 2014 CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch – Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Rona Chen / Specialist Approved By : Gordon Lin / Assistant Manager This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. FCC SAR Test Report Report Format Version 5.0.0 Page No. : 2 of 4 Report No. : SA140403D07 Issued Date : Apr. 30, 2014 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Summary of Maximum SAR Value ....................................................................................................................................... 4 2. Description of Equipment Under Test ................................................................................................................................. 5 3. SAR Measurement Evaluation .............................................................................................................................................. 6 4.1 EUT Configuration and Setting ..................................................................................................................................... 6 4.2 EUT Testing Position .................................................................................................................................................... 6 4.3 Maximum Output Power ............................................................................................................................................... 6 4.6.1 Maximum Conducted Power .............................................................................................................................. 6 4.6.2 Measured Conducted Power Result ................................................................................................................... 6 4.4 SAR Testing Results .................................................................................................................................................... 6 4. Information on the Testing Laboratories ............................................................................................................................. 7 Appendix A. Photographs of EUT FCC SAR Test Report Report Format Version 5.0.0 Page No. : 3 of 4 Report No. : SA140403D07 Issued Date : Apr. 30, 2014 Release Control Record Report No. Reason for Change Date Issued SA140403D07 Initial release Apr. 30, 2014 FCC SAR Test Report Report Format Version 5.0.0 Page No. : 4 of 4 Report No. : SA140403D07 Issued Date : Apr. 30, 2014 1. Summary of Maximum SAR Value Equipment Class Mode Highest Reported Body SAR1g (1.0 cm Gap) (W/kg) DSS Bluetooth N/A Note: 1. SAR testing for Bluetooth is not required because its maximum output power is less than 20mW. FCC SAR Test Report Report Format Version 5.0.0 Page No. : 5 of 4 Report No. : SA140403D07 Issued Date : Apr. 30, 2014 2. Description of Equipment Under Test EUT Type Bluetooth Wireless Keyboard FCC ID E8HKT-1409 Brand Name ASUS Model Name PF-06 Mobile Dock Tx Frequency Bands (Unit: MHz) Bluetooth : 2402 ~ 2480 Uplink Modulations Bluetooth : GFSK Maximum Tune-up Conducted Power (Unit: dBm) Bluetooth : -0.71 Antenna Type PCB Antenna EUT Stage Engineering Sample Note: 1. The above EUT information is declared by manufacturer and for more detailed features description please refers to the manufacturer's specifications or User's Manual. List of Accessory: Battery Brand Name Powertronics Co., Ltd Model Name 253370 Power Rating 3.7Vdc, 450mAh Type …

Text truncated - open the document above for the full version.

Report No.: RF140403D07 1 of 41 Report Format Version 5.2.0 FCC TEST REPORT (BLUETOOTH) REPORT NO.: RF140403D07 MODEL NO.: PF-06 Mobile Dock FCC ID: E8HKT-1409 RECEIVED: Apr. 03, 2014 TESTED: Apr. 17, 2014 ~ Apr. 22, 2014 ISSUED: Apr. 28, 2014 APPLICANT: Chicony Electronics Co., Ltd. ADDRESS: NO. 25, Wu-Gong 6th Rd., Wugu Dist., New Taipei City 248, Taiwan, R.O.C ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C ) TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF140403D07 2 of 41 Report Format Version 5.2.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ..............................................................................................................4 1. CERTIFICATION ..................................................................................................................................5 2. SUMMARY OF TEST RESULTS .........................................................................................................6 2.1 MEASUREMENT UNCERTAINTY...............................................................................................6 3. GENERAL INFORMATION ..................................................................................................................7 3.1 GENERAL DESCRIPTION OF EUT ............................................................................................7 3.2 DESCRIPTION OF TEST MODES ..............................................................................................8 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .................................9 3.3 DESCRIPTION OF SUPPORT UNITS ...................................................................................... 11 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST .......................................................... 11 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................................... 12 4. TEST TYPES AND RESULTS (FOR BLUETOOTH EDR) ............................................................... 13 4.1 RADIATED EMISSION AND BANDEDGE MEASUREMENT .................................................. 13 4.1.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ................... 13 4.1.2 TEST INSTRUMENTS ................................................................................................. 14 4.1.3 TEST PROCEDURES ................................................................................................. 15 4.1.4 DEVIATION FROM TEST STANDARD ....................................................................... 15 4.1.5 TEST SETUP ............................................................................................................... 16 4.1.6 EUT OPERATING CONDITIONS ................................................................................ 17 4.1.7 TEST RESULTS........................................................................................................... 18 4.2 CONDUCTED EMISSION MEASUREMENT ........................................................................... 22 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ........................................... 22 4.2.2 TEST INSTRUMENTS ................................................................................................. 22 4.2.3 TEST PROCEDURES ................................................................................................. 23 4.2.4 DEVIATION FROM TEST STANDARD ....................................................................... 23 4.2.5 TEST SETUP ............................................................................................................... 24 4.2.6 EUT OPERATING CONDITIONS ................................................................................ 24 4.2.7 TEST RESULTS........................................................................................................... 25 4.3 NUMBER OF HOPPING FREQUENCY USED ........................................................................ 27 4.3.1 LIMIT OF HOPPING FREQUENCY USED ................................................................. 27 4.3.2 TEST SETUP ............................................................................................................... 27 4.3.3 TEST INSTRUMENTS ................................................................................................. 27 4.3.4 TEST PROCEDURE ...............................................…

Text truncated - open the document above for the full version.

Report No.: RF140403D07 1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: RF140403D07 2 RADIATED EMISSION TEST
