Page 1 CONSTRUCTION PHOTOS OF EUT

FCC ID: E8HMG-1090 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

REV: A MG-1090/WUG1089 MG-1090/WUG1089 253-01090L-A SCALE: 1 : 1 DWG NO.: NOTES NOTES NOTES MODEL NO. MODEL NO.: REMARKPART NO. MAT.: TOL: UNIT: MM Q'TYSIZE: A4 SPEC: APPROVEDCHECKEDDESIGNED NAME: FINISH: REV LTRREV . DIMENSIONDATEDESIGNAPPROVE SPEC. ID LABEL NOTES: MG-1090-FCC()-X0 DELL B C 03/23-'1103/23-'11 03/23-'11 TAMMY T. S. MAGGIE SAM 1. MATERIAL: SYNTHETIC PAPER t=0.15mm (WITH GLUE) (UL/CSA APPROVED) 4. FINISHED: ADHESIVE. 5. LABEL VENDOR HAS TO BE APPRD. BY UL/CSA 6. THIS PRODUCT/COMPONENT MUST COMPLY WITH CHICONY SPECIFICATION "ISO 361" 2. BACKGROUND COLOR: PANTONE Process Black C 3. TEXT & SYMBOLS COLOR: WHITE XXXXXXXXXXXXXX XXXXX/SDPPI/XXXX XXXX Complies with IDA Standards XXXXXXXX TA-XXXX/XXXX APPROVED CFT: XXXXXXXXXXXXXX SUBTEL:XXXXXXXX TRC ID: XXXXXXXXXXXXXXX MRXXXX ANRT XXXX ETA NO: XXX/XXXX/WRLO CNC: XXXXXXXX NTC Type acceptance No.: ESD-XXXXXXXX TRA REGISTERED NO.: XXXXXXXXXXXX DEALER NO.: DA0038484/10 R31310 OMAN-TRA X/NNNN/YY Dyynnnn MR 164844 / D PPID: ** (/) (/) M/N : MG-1090 Rating: 3V 50mA () MADE IN CHINA KM632 Dell Inc. XXXX IC: 5524A-MG1090 XXXXXXXXXXXXXX VENDOR UL MARK 123458789012375678912345678 CANADA ICES-003, Class B CANADA NMB-003, Classe B XXXXXXXXXXXXXXXX FCC ID: E8HMG-1090 CMIIT ID: XXXXXXXXXX

Page 2 Page 3 Page 4 Page 5

FCC ID: E8HMG-1090 Report No.: RF110315D19-1 Operational Description The transmitter of the EUT (Wireless Mouse) is powered by 3Vdc from batteries. The type of antenna is Strip Antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: SA110315D19-1 Report Format Version 4.0.0 1 RF EXPOSURE REPORT REPORT NO.: SA110315D19-1 MODEL NO.: MG-1090 FCC ID: E8HMG-1090 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Chicony Electronics Co., Ltd. ADDRESS: No. 25, Wu-Gong 6th Rd., Wu Ku Industrial Park, Taipei Hsien, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION : No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan Report No.: SA110315D19-1 Report Format Version 4.0.0 2 1. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2. MPE CALCULATION FORMULA Pd = (Pout) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW Pi = 3.1416 R = distance between observation point and center of the radiator in cm 3. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA110315D19-1 Report Format Version 4.0.0 3 4. CALCULATION RESULT OF MAXIMUM POWER CALCULATION FOR MAXIMUM PEAK VALUE FREQUENCY BAND (MHz) MAX RADIATED POWER (dBm) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2403-2480 1.4 20 0.0003 1.00 ---END---

Report No.: RF110315D19-1 1 Report Format Version 4.0.0 FCC TEST REPORT REPORT NO.: RF110315D19-1 MODEL NO.: MG-1090 FCC ID: E8HMG-1090 RECEIVED: Mar. 15, 2011 TESTED: Mar. 17, 2011 ISSUED: Mar. 22, 2011 APPLICANT: Chicony Electronics Co., Ltd. ADDRESS: No. 25, Wu-Gong 6th Rd., Wu Ku Industrial Park, Taipei Hsien, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan This test report consists of 24 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110315D19-1 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD..............................................................................3 1. CERTIFICATION...........................................................................................4 2. SUMMARY OF TEST RESULTS...................................................................5 2.1 MEASUREMENT UNCERTAINTY...............................................................5 3. GENERAL INFORMATION...........................................................................6 3.1 GENERAL DESCRIPTION OF EUT............................................................6 3.2 DESCRIPTION OF TEST MODES..............................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.........................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.............8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................9 3.4 DESCRIPTION OF SUPPORT UNITS........................................................9 4. TEST TYPES AND RESULTS.....................................................................10 4.1 CONDUCTED EMISSION MEASUREMENT............................................10 4.2 RADIATED EMISSION MEASUREMENT.................................................10 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...............................10 4.2.2 TEST INSTRUMENTS..............................................................................11 4.2.3 TEST PROCEDURES...............................................................................12 4.2.4 DEVIATION FROM TEST STANDARD.....................................................12 4.2.5 TEST SETUP............................................................................................13 4.2.6 EUT OPERATING CONDITIONS..............................................................13 4.2.7 TEST RESULTS........................................................................................14 4.3 BAND EDGES MEASUREMENT..............................................................19 4.3.1 LIMITS OF BAND EDGES MEASUREMENT............................................19 4.3.2 TEST INSTRUMENTS..............................................................................19 4.3.3 TEST PROCEDURE.................................................................................19 4.3.4 DEVIATION FROM TEST STANDARD.....................................................19 4.3.5 EUT OPERATING CONDITION................................................................19 4.3.6 TEST RESULTS........................................................................................19 5. PHOTOGRAPHS OF THE TEST CONFIGURATION..................................22 6. INFORMATION ON THE TESTING LABORATORIES................................23 7. APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB.......................................................24 Report No.: RF110315D19-1 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release N/A Mar. 22, 2011 Report No.: RF110315D19-1 4 Report Format Version 4.0.0 1. CERTIFICATION PRODUCT: Wireless Mouse BRAND NAME: DELL MODEL NO.: MG-1090 APPLICANT: Chicony Electronics Co., Ltd. TESTED: Mar. 17, 2011 TEST ITEM: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.4-2003 ANSI C63.10-2009 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Celia Chen / Senior Specialist ) APPROVED BY : , DATE: ( Ken Liu / Manager ) Report No.: RF110315D19-1 5 Report Format Version 4.0.0 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD SECTION TEST TYPE AND LIMIT RESULT REMARK 15.207 Conducted Emission Test N/A Power supply is 3Vdc from batteries 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 12.209 PASS Minimum passing margin is –6.8dB at 2390.00MHz 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Measurement Frequency Uncertainty 30MHz ~ 1GHz 3.87 dB Radiated emissions Above 1GHz 2.89 dB Report No.: RF110315D19-1 6 Report Format Version 4.0.0 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT EUT Wireless Mouse MODEL NO. MG-1090 FCC ID E8HMG-1090 POWER SUPPLY 3Vdc…
