FCC ID: E8HMG-1208 Report No.: RF120615D11-1 Operational Description The transmitter of the EUT (Wireless Mouse) is powered by 3.0Vdc from batteries. The type of antenna is Strip antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: RF120615D11-1 1 of 21 Report Format Version 5.0.0 FCC TEST REPORT REPORT NO.: RF120615D11-1 MODEL NO.: MG-1208 FCC ID: E8HMG-1208 RECEIVED: Jun. 15, 2012 TESTED: Jun. 22, 2012 ISSUED: Jun. 29, 2012 APPLICANT: Chicony Electronics Co., Ltd. ADDRESS: NO. 25, Wu-Gong 6th Rd., Wugu Dist., New Taipei City 248, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non- compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF120615D11-1 2 of 21 Report Format Version 5.0.0 Table of Contents RELEASE CONTROL RECORD..................................................................................3 1. CERTIFICATION...............................................................................................4 2. SUMMARY OF TEST RESULTS.......................................................................5 2.1 MEASUREMENT UNCERTAINTY....................................................................5 3. GENERAL INFORMATION...............................................................................6 3.1 GENERAL DESCRIPTION OF EUT..................................................................6 3.2 DESCRIPTION OF TEST MODES....................................................................7 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL....................8 3.3 DESCRIPTION OF SUPPORT UNITS..............................................................9 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST...............................................9 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS...................................9 4. TEST TYPES AND RESULTS.........................................................................10 4.1 CONDUCTED EMISSION MEASUREMENT..................................................10 4.2 RADIATED EMISSION and band edge MEASUREMENT..............................10 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.....................................10 4.2.2 TEST INSTRUMENTS....................................................................................11 4.2.3 TEST PROCEDURES.....................................................................................12 4.2.4 DEVIATION FROM TEST STANDARD...........................................................12 4.2.5 TEST SETUP..................................................................................................13 4.2.6 EUT OPERATING CONDITIONS....................................................................13 4.2.7 TEST RESULTS..............................................................................................14 5. PHOTOGRAPHS OF THE TEST CONFIGURATION......................................19 6. INFORMATION ON THE TESTING LABORATORIES....................................20 7. APPENDIX A – MODIFICATION RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB.........................................................21 Report No.: RF120615D11-1 3 of 21 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF120615D11-1 Original release Jun. 29, 2012 Report No.: RF120615D11-1 4 of 21 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: Wireless Mouse BRAND: hp MODEL NO.: MG-1208 APPLICANT: Chicony Electronics Co., Ltd. TESTED: Jun. 22, 2012 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.10-2009 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Annie Chang / Supervisor ) APPROVED BY : , DATE: ( Ken Liu / Manager ) Report No.: RF120615D11-1 5 of 21 Report Format Version 5.0.0 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD PARAGRAPH TEST TYPE RESULT REMARK 15.207 Conducted Emission Test N/A Power supply is 3.0Vdc from batteries 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 15.209 PASS Meet the requirement of limit. Minimum passing margin is -8.6dB at 2390.00MHz. 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertaint…

Text truncated - open the document above for the full version.

Report No.: RF120615D11-1 1 of 1 Report Format Version 5.0.0 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
