FCC ID: E8HMP-0550 Report No.: RF940712A08 Operational Description The device is a Frequency Hopping device with 79 hopping frequencies. The antenna type is Strip antenna and there is no antenna connector used. The EUT is a unit that contains a Bluetooth radio module. Bluetooth is a short-range wireless technology operating in the 2.4GHz band. It enables devices to have the ability to form networks and exchange information. The other instruction, please have a look at the user’s manual.

FCC ID: E8HMP-0550 Report No: SA940712A081 RF EXPOSURE REPORT REPORT NO.: SA940712A08 MODEL NO.: MP-0550 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT : Chicony Electronics Co., Ltd. ADDRESS : No. 25, Wu-Gong 6th Rd., Wu Ku Industrial Park, Taipei Hsien, Taiwan, R.O.C. ISSUED BY : Advance Data Technology Corporation LAB ADDRESS : No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. FCC ID: E8HMP-0550 Report No: SA940712A082 RF Exposure Measurement 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: E8HMP-0550 Report No: SA940712A083 3. Friis Formula Friis transmission formula: Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by manufacturer enabled the EUT to transmit data at lowest, middle and highest channel individually. FCC ID: E8HMP-0550 Report No: SA940712A084 5. Conclusion No Evaluation Required if power is below this threshold: F(GHz)mW Low2.402 High2.480 24.58 Maximum measured transmitter power: Pout (dBm)Pout (mW) Conducted Power2.751.884 EIRP Power0.851.216 *Note: The antenna is Strip antenna with –1.9dBi gain Threshold for no SAR evaluation is 24.58mW Transmitter power is 1.884mW Conclusion: No SAR evaluation required since Transmitter Pout is below FCC threshold

FCC ID: E8HMP-0550 Report No.: RF940712A081Report Format Version 2.0.3 FCC TEST REPORT REPORT NO.: RF940712A08 MODEL NO.: MP-0550 RECEIVED: July 12, 2005 TESTED: Aug. 8 ~ 30, 2005 ISSUED: Sep. 5, 2005 APPLICANT: Chicony Electronics Co., Ltd. ADDRESS: No. 25, Wu-Gong 6th Rd., Wu Ku Industrial Park, Taipei Hsien, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. This test report consists of 50 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA NO. 2177-01 FCC ID: E8HMP-0550 Report No.: RF940712A082Report Format Version 2.0.3 TABLE OF CONTENTS 1.CERTIFICATION........................................................................................4 2.SUMMARY OF TEST RESULTS................................................................5 2.1MEASUREMENT UNCERTAINTY.............................................................6 3.GENERAL INFORMATION........................................................................7 3.1GENERAL DESCRIPTION OF EUT..........................................................7 3.2DESCRIPTION OF TEST MODES............................................................8 3.2.1CONFIGURATION OF SYSTEM UNDER TEST........................................9 3.2.2TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL...........10 3.3.3GENERAL DESCRIPTION OF APPLIED STANDARDS..........................11 3.3.4DESCRIPTION OF SUPPORT UNITS.....................................................12 4.TEST TYPES AND RESULTS..................................................................13 4.1CONDUCTED EMISSION MEASUREMENT...........................................13 4.2RADIATED EMISSION MEASUREMENT................................................13 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT.............................13 4.2.2TEST INSTRUMENTS.............................................................................14 4.2.3TEST PROCEDURES..............................................................................15 4.2.4DEVIATION FROM TEST STANDARD....................................................15 4.2.5TEST SETUP..........................................................................................16 4.2.6EUT OPERATING CONDITIONS.............................................................16 4.2.7TEST RESULTS.......................................................................................17 4.3NUMBER OF HOPPING FREQUENCY USED........................................25 4.3.1LIMIT OF HOPPING FREQUENCY USED..............................................25 4.3.2TEST INSTRUMENTS.............................................................................25 4.3.3TEST PROCEDURES..............................................................................25 4.3.4DEVIATION FROM TEST STANDARD....................................................26 4.3.5TEST SETUP..........................................................................................26 4.3.6TEST RESULTS.......................................................................................26 4.4DWELL TIME ON EACH CHANNEL........................................................28 4.4.1LIMIT OF DWELL TIME USED................................................................28 4.4.2TEST INSTRUMENTS.............................................................................28 4.4.3TEST PROCEDURES..............................................................................28 4.4.4DEVIATION FROM TEST STANDARD....................................................28 4.4.5TEST SETUP..........................................................................................29 4.4.6TEST RESULTS.......................................................................................29 4.5CHANNEL BANDWIDTH.........................................................................32 4.5.1LIMITS OF CHANNEL BANDWIDTH.......................................................32 4.5.2TEST INSTRUMENTS.............................................................................32 4.5.3TEST PROCEDURE................................................................................32 4.5.4DEVIATION FROM TEST STANDARD....................................................33 4.5.5TEST SETUP..........................................................................................33 4.5.6EUT OPERATING CONDITION...............................................................33 4.5.7TEST RESULTS.......................................................................................33 4.6HOPPING CHANNEL SEPARATION.......................................................36 4.6.1LIMIT OF HOPPING CHANNEL SEPARATION.......................................36 FCC ID: E8HMP-0550 Report No.: RF940712A083Report Format Version 2.0.3 4.6.2TEST INSTRUMENTS.............................................................................36 4.6.3TEST PROCEDURES..............................................................................36 4.6.4DEVIATION FROM TEST STANDARD....................................................37 4.6.5TEST SETUP..........................................................................................37 4.6.6TEST RESULTS.......................................................................................37 4.7MAXIMUM PEAK OUTPUT POWER.......................................................40 4.7.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT........40 4.7.2TEST INSTRUMENTS.............................................................................40 4.7.3TEST PROCEDURES...................................................................…

Text truncated - open the document above for the full version.

FCC ID: E8HMP-0550 Report No.: RF940712A0849Report Format Version 2.0.3 5.PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
