E8HMSR0195Wireless Mouse

A. FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to Part 15 the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. WARNING: A shielede-type power cord is required in order to meet FCC emission limits and also to prevent interference to the nearby radio and television reception. It is essential that only the supplied power cord be used. Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. CAUTION: AVOID PROLONGED USE OF THE KEYBOARD WITHOUT BREAKS. Take regular breaks and keep a good posture. Consult your physician promptly if you notice any lost of motion or pain in your wrist when using the keyboard. B. PRODUCT SPECIFICATION 1. FREQUENCY BAND : Keyboard – 27.145 27.195 MHz Mouse – 27.045 27.095 MHz 2. CHANNEL : 2 channels for keyboard / 2 channels for mouse. 3. FREQUENCY MODULATION : FSK MODE 4. POWER RATTING : Keyboard : 3 V , 30 mA (MAX) Mouse : 3 V , 50 mA (MAX) Receiver : 5 V , 200 mA (MAX) 5. BATTERY LIFE TIME : Keyboard : 600 HOURS REFERENCE (OPERATING MODE) Mouse : 300 HOURS REFERENCE (OPERATING MODE) 6. OPERATING TEMPERATURE : 0º C~ 40º C. 7. STORAGE TEMPERATURE : -10º C ~ 60º C. USUS C. HARDWARE INSTALLATION 1. Turn off your computer 2. Plug the receiver connector in purple into keyboard port on your computer and locate the other connector in green to mouse port 3. Place the receiver horizontally and keep approx. 8 inches (or 20 centimeters) space from other electrical devices 4. Load two AA batteries into battery chamber on the back of keyboard and two AAA battery to battery chamber of mouse 5. Turn on your computer D. SOFTWARE INSTALLATION 1. Insert CD into your CD-ROM drive 2. Multimedia Keyboard Driver Installation screen appears. Click Windows OS of your computer. Follow the instructions on the screen to complete the software installation. E. USER CAN DO EITHER ONLY CHANNEL SETTING OR CHANNEL / ID SETTING WHEN INTERFERENCE OCCURS KEYBOARD & MOUSE CHANNEL SETTING: 1. Push the connect button on the back of keyboard (mouse) changing the operating channel to the other one. 2. Please push the connect button on the top of receiver. The indicator on the top of receiver starts blinking,then repeat step 1 within 30 seconds if keyboard (mouse) is not working properly KEYBORAD & MOUSE CHANNEL / ID SETTING: 1. Remove the batteries from battery chamber on the back of keyboard (mouse). 2. Push the connect button on the top of receiver. The indicator on the top of receiver starts blinking. 3. Push the connect button on the back of keyboard (mouse), and hold it down batteries into load the y chamber then release the connect button within 30 seconds. 4. Setting is complete. The indicator on receiver will turn off automatically. The channel is then changed to the other channel and ID channged to a random ID. 5. Please push the connect button on receiver , then push the connect button on the back of keyboard (mouse) within 30 seconds to recover if keyboard (mouse) is not working properly. ?Note: To have maximum performance, avoid placing receiver, keyboard and mouse on metalic surface.Operating distance between keyboard, mouse and receiver will depend on the environment around. User can try various locations for the receiver in order to find best operating performance.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

Page 1 ANNEX PHOTOGRAPHS OF EUT Label Location

REV: 0 CHICONY MSR0195 WBR0175 11/16-'01 0175-03 253-R0175- SCALE: 1 : 1 DWG NO.: NOTES NOTES NOTES MODEL NO. MODEL NO.: REMARKPART NO. MAT.: TOL: UNIT: MM Q'TYSIZE: A4 SPEC: APPROVED CHECKEDDESIGNED NAME: FINISH: REV LTRREV . DIMENSIONDATEDESIGNAPPROVE A B TAMMY SPEC. ID LABEL MSR0195 Power Rating : 3V 50mA Serial Number : MSR0195 Power Rating : 3V 50mA Serial Number : NOTES: 1.MATERIAL: SYNTHETIC PAPER t=0.15mm (WITH GLUE) (UL/CSA APPROVED) 2.BACKGROUND COLOR: WHITE 3.CHARACTER COLOR: PANTONE Process Black C 4.FINISHED: ADHESIVE. (SONY NP303) 5.LABEL VENDOR HAS TO BE APPRD. BY UL/CSA. (FOR MOUSE) FCC ID: E8HMSR0195 FCC ID: E8HMSR0195 0560 0560 40.0mm 20.0mm 4-R1.0 R R R R R R LR ****** LR ****** E164844 E164844 TUV Rheinland .. geprufte Sicherheit .. TUV Rheinland .. geprufte Sicherheit .. Made in ******** Made in ******** CET \ LR94275 CEM 1 \ LR104146 CEM 2 \ LR114370 CET \ Made in Thailand CEM \ Made in China

Page 3 Page 4 Page 5 Page 6 Page 7 Page 8

FCC ID: E8HMSR0195 ADT No.901116A02A Operational Description The transmitter of the EUT (Wireless Mouse) is powered by 3V Battery. The receiver is powered by host computer. Both transmitter and receiver use internal printed antenna. The output power of this device is very low. Under normal operating condition, the output power of the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

FCC ID: E8HMSR0195 Report No.: RF901116A02A 1 Issued: Nov. 27, 2001 FCC TEST REPORT REPORT NO.: RF901116A02A MODEL NO.: MSR0195 RECEIVED: Nov. 16, 2001 TESTED: Nov. 20, 2001 APPLICANT: Chicony Electronics Co., Ltd. ADDRESS: No. 25, Wu-Gong 6 th Rd., Wu Ku Industrial Park, Taipei Hsien, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chia Pau Tsuen, Linkou Hsiang, Taipei, Taiwan, R.O.C. This test report consists of 14 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Lab Code: 200102-0 0528 ILAC MRA FCC ID: E8HMSR0195 Report No.: RF901116A02A 2 Issued: Nov. 27, 2001 Table of Contents 1CERTIFICATION...................................................................................................... 3 2SUMMARY OF TEST RESULTS ............................................................................. 4 3GENERAL INFORMATION..................................................................................... 5 3.1GENERAL DESCRIPTION OF EUT........................................................................ 5 3.2DESCRIPTION OF TEST MODES .......................................................................... 6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS........................................ 6 3.4DESCRIPTION OF SUPPORT UNITS ..................................................................... 6 4TEST PROCEDURE AND RESULT ........................................................................ 7 4.1CONDUCTED EMISSION MEASUREMENT......................................................... 7 4.2RADIATED EMISSION MEASUREMENT ............................................................. 7 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT..................................... 7 4.2.2 TEST INSTRUMENT....................................................................................... 8 4.2.3 TEST PROCEDURE ....................................................................................... 9 4.2.4 TEST SETUP ................................................................................................ 10 4.2.5 EUT OPERATING CONDITION .................................................................... 10 4.2.6 TEST RESULT ...............................................................................................11 5PHOTOGRAPHS OF THE TEST CONFIGURATION ........................................... 13 6INFORMATION ON THE TESTING LABORATORIES........................................ 14 FCC ID: E8HMSR0195 Report No.: RF901116A02A 3 Issued: Nov. 27, 2001 1 CERTIFICATION PRODUCT : Wireless Mouse BRAND NAME : CHICONY MODEL NO : MSR0195 APPLICANT : Chicony Electronics Co., Ltd. STANDARDS : 47 CFR Part 15, Subpart C(15.227) ANSI C63.4-1992 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility on Nov. 20, 2001. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: E8HMSR0195 Report No.: RF901116A02A 4 Issued: Nov. 27, 2001 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C STANDARD PAR AGR APH TEST TYPERESULTREMARK 15.107Conducted Emission TestN/A Power supply is 3VDC from batteries 15.227Radiated Emission TestPASS Minimum passing margin is –15.30dBuV at 132.20 & 162.40 MHz NOTE: The receiver part to communicate with the EUT has been verified to comply with FCC Part 15, Subpart B, Class B (DoC). The test report can be provided upon request. FCC ID: E8HMSR0195 Report No.: RF901116A02A 5 Issued: Nov. 27, 2001 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT Wireless Mouse MODEL NO. MSR0195 POWER SUPPLY 3VDC from battery MODULATION TYPE FSK CARRIER FREQUENCY OF EACH CHANNEL 27.045, 27.095 MHz BANDWIDTH OF EACH CHANNEL 10KHz NUMBER OF CHANNEL 2 ANTENNA TYPE Loop antenna DATA CABLE NA I/O PORTS NA ASSOCIATED DEVICES NA NOTE: 1. The EUT is the transmitter part of a Wireless Mouse. 2. For more detailed features description of the EUT, please refer to the manufacturer's specifications or the User's Manual. FCC ID: E8HMSR0195 Report No.: RF901116A02A 6 Issued: Nov. 27, 2001 3.2 DESCRIPTION OF TEST MODES Two channels are provided in this EUT. ChannelFrequencyChannelFrequency 127.045 MHz227.095 MHz NOTE: Channel 1 and 2 were pre-tested in chamber. Channel 2, the worst case, was chosen for the final test. 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS The EUT is the transmitter part of a Wireless Mouse. According to the specifications of the manufacturer, it must comply with the requirements of the following standards: FCC CFR 47 Part 15, Subpart C (15.227) ANSI C63.4-1992 All tests have been performed and recorded as per the above standards. 3.4 DESCRIPTION OF SUPPORT UNITS NA FCC ID: E8HMSR0195 Report No.: RF901116A02A 7 Issued: Nov. 27, 2001 4 TEST PROCEDURE AND RESULT 4.1 CONDUCTED EMISSION MEASUREMENT NA 4.2 RADIATED EMISSION MEASUREMENT 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT According to 15.227 the field strength of emissions from intentional radiators operated under these frequencies bands shall not exceed the following: Fundamental Frequency (MHz) Field Strength of Fundamental (dBuV/m) PeakAverage 26.96-27.28 10080 Field strength limits are at the distance of 3 meters, emissions radiated outside of the specified bands, shall be according to the general radiated limits in 15.209 as following: Field Strength of Fundamental Other Frequencies (MHz) uV/meterdBuV/meter 30-8810040.0 88-21615043.5 216-96020046.0 Above 96050054.…
