E8HMSR0238BWireless Mouse

1 User’s Guide for Wireless Input Device A. FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to Part 15 the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ! Reorient or relocate the receiving antenna ! Increase the separation between the equipment and receiver ! Connect the equipment into an outlet on a circuit different from that to which the receiver is connected ! Consult the dealer or an experienced radio/TV technician for help You are cautio ned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to opeate the equipment. CAUTION: AVOID PROLONGED USE OF THE KEYBOARD WITHOUT BREAKS. Take regular breaks and keep a good posture. Consult your physician promptly if you notice any lost of motion or pain in your wrist when using the keyboard. 2 B. PRODUCT SPECIFICATION 1. Frequency Band: Mouse 27.045 27.095 2. Channel: 2 channels for mouse 3. Frequency Modulation: FSK mode 4. Power Ratting: Mouse3V, 50mA (max) Receiver5V, 100mA (max) 5.RF Power: <10mW 6. Battery Life Time: Mouse: 50 working hours with continuous operation 7. Operating Temperature: 0°C ~ 40°C Storage Temperature: -10°C ~ 60°C C. HARDWARE INSTALLATION 1. Plug the receiver connector into USB port on your computer 2. Load two AA batteries to battery chamber of mouse D. CHANNEL SETTING WHEN INTERFERENCE OCCURS 1. The first binding by user Step 1 – Push the button on receiver Step 2 – Push the button on back of mouse 2. Change channel Push the button on the back of mouse Alternate: Step 1 – Press receiver button, LED green light is blinking Step 2 – Push mouse button on back of device and then LED light stops blinking on receiver to confirm channel is changed. 3. Change ID Step 1 – Press receiver button, LED green light is blinking. Step 2 – Push the button on the back of mouse more than two seconds and release, LED green light becomes blinking faster in 3 seconds and then light is off. Note: To have maximum performance, avoid placing receiver, keyboard and mouse on metallic surface. Operating distance between keyboard, mouse and receiver will depend on the environment around. User can try various locations for the receiver in order to find best operating performance.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 January 14, 2003 RE: Chicony Electronics, Inc. FCC ID: E8HMSR0238B I have a few comments on this Application. 1.) Form 731 as submitted calls this device a “27MHz Wireless Keyboard”. This device is quite obviously a wireless mouse, correct? It shall be labeled such unless you have some objections. 2.) The Block Diagram supplied does not meet the intent of Part 2 of the Rules. Please provide a block diagram showing the frequencies and their paths within this device. 3.) The Manual makes mention of a “shielded power cord”. Please revise. William H. Graff President and Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3

For FCC ID Label Location

REFERENCE ONLY REV: 0 CHICONY MUR0238... MUR0238... 12/23-'02 B0238-FCC 253-00238-00 SCALE: 1 : 1 DWG NO.: NOTES NOTES NOTES MODEL NO. MODEL NO.: REMARKPART NO. MAT.: TOL: UNIT: MM Q'TYSIZE: A4 SPEC: APPROVEDCHECKEDDESIGNED NAME: FINISH: REV LTRREV . DIMENSIONDATEDESIGNAPPROVE A B TAMMY SPEC. ID LABEL NOTES: 1.MATERIAL: SYNTHETIC PAPER t=0.15mm (WITH GLUE) (UL/CSA APPROVED) 2.BACKGROUND COLOR: WHITE 3.CHARACTER COLOR: PANTONE Process Black C 4.FINISHED: ADHESIVE. 5.LABEL VENDOR HAS TO BE APPRD. BY UL/CSA. VENDER UL MARK. CET \ Made in Thailand CEM \ Made in China (FOR MOUSE W/BALL) FCC ID: E8HMSR0238B 0560 Made in ******** Canada 210 Model No.: MSR0238B Power Rating: 3V 50mA Serial No.: TUV Rheinland .. geprufte Sicherheit .. R31310 XXXXXXXX CET \ CET CEM 2 \ CEM2 CEM 3 \ CEM3 E164844 ID: US C

Page 4 Page 5 Page 6 Page 7 Page 8 Page 9

FCC ID: E8HMSR0238B ADT No.911210R04 Operational Description The transmitter of the EUT (27MHz Wireless Mouse) which uses Printed Antenna is powered by 3V Battery. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

FCC ID: E8HMSR0238B Report No.: RF911210R041Issued: Jan. 09, 2003 FCC TEST REPORT REPORT NO.: RF911210R04 MODEL NO.: TX: MSR0238B; RX: Wireless Desktop Receiver 1.0A RECEIVED: Dec. 10, 2002 TESTED: Dec. 27 ~ Dec. 31, 2002 APPLICANT: Chicony Electronics Co., Ltd. ADDRESS: No. 25, Wu- Gong 6 th Rd. Wu Ku Industrial Park, Taipei Hsien, Taiwan, R.O.C ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chia Pau Tsuen, Linkou Hsiang, Taipei, Taiwan, R.O.C. This test report consists of 15 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Lab Code: 200102-0 0528 FCC ID: E8HMSR0238B Report No.: RF911210R042Issued: Jan. 09, 2003 Table of Contents 1CERTIFICATION.......................................................................................3 2SUMMARY OF TEST RESULTS................................................................4 3GENERAL INFORMATION........................................................................5 3.1GENERAL DESCRIPTION OF EUT...........................................................5 3.2DESCRIPTION OF TEST MODES.............................................................6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS...............................6 3.4DESCRIPTION OF SUPPORT UNITS........................................................7 4TEST PROCEDURE AND RESULT............................................................8 4.1CONDUCTED EMISSION MEASUREMENT...............................................8 4.2RADIATED EMISSION MEASUREMENT...................................................8 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT..................................8 4.2.2TEST INSTRUMENT.................................................................................9 4.2.3TEST PROCEDURE................................................................................10 4.2.4DEVIATION FROM TEST STANDARD......................................................10 4.2.5TEST SETUP...........................................................................................11 4.2.6EUT OPERATING CONDITION................................................................11 4.2.7TEST RESULT.........................................................................................12 4.3ANTENNA REQUIREMENT......................................................................13 4.3.1STANDARD APPLICABLE........................................................................13 4.3.2ANTENNA CONNECTED CONSTRUCTION.............................................13 5PHOTOGRAPHS OF THE TEST CONFIGURATION.................................14 6INFORMATION ON THE TESTING LABORATORIES................................15 FCC ID: E8HMSR0238B Report No.: RF911210R043Issued: Jan. 09, 2003 1 CERTIFICATION PRODUCT : 27MHz Wireless Mouse BRAND NAME : Chicony MODEL NO : TX: MSR0238B; RX: Wireless Desktop Receiver 1.0A APPLICANT : Chicony Electronics Co., Ltd. STANDARDS : 47 CFR Part 15, Subpart C(15.227) ANSI C63.4-1992 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility from Dec. 27 ~ Dec. 31, 2002. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: E8HMSR0238B Report No.: RF911210R044Issued: Jan. 09, 2003 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.207Conducted Emission TestNA 15.227Radiated Emission TestPASS Minimum passing margin is –11.50dBuV at 120.00MHz NOTE: The receiver part to communicate with the EUT has been verified to comply with FCC Part 15, Subpart B, Class B (DoC). The test report can be provided upon request. FCC ID: E8HMSR0238B Report No.: RF911210R045Issued: Jan. 09, 2003 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT 27MHz Wireless Mouse MODEL NO. TX: MSR0238B; RX: Wireless Desktop Receiver 1.0A POWER SUPPLY 3VDC from battery for transmitter 5VDC from host equipment for receiver MODULATION TYPE FSK CARRIER FREQUENCY OF EACH CHANNEL 27.045 / 27.095 MHz BANDWIDTH OF EACH CHANNEL 10kHz NUMBER OF CHANNEL 2 ANTENNA TYPE Printed Antenna DATA CABLE NA I/O PORTS USB ASSOCIATED DEVICES NA NOTE: 1. The EUT is the transmitter part of a 27MHz Wireless Mouse. 2. For more detailed features description of the EUT, please refer to the manufacturer's specifications or the User's Manual. FCC ID: E8HMSR0238B Report No.: RF911210R046Issued: Jan. 09, 2003 3.2 DESCRIPTION OF TEST MODES Two channels are provided in this EUT. ChannelFrequencyChannelFrequency 127.045 MHz227.095 MHz NOTE: Two channels were pre-tested in chamber. Channel 1, the worst case, was chosen for final test. 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS The EUT is the transmitter part of a 27MHz Wireless Mouse. According to the specifications of the manufacturer, it must comply with the requirements of the following standards: FCC 47 CFR Part 15, Subpart C(15.227) ANSI C63.4-1992 All tests have been performed and recorded as per the above standards. FCC ID: E8HMSR0238B Report No.: RF911210R047Issued: Jan. 09, 2003 3.4 DESCRIPTION OF SUPPORT UNITS The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. NO.PRODUCTBRANDMODEL NO.SERIAL NO.FCC ID 1 PERSONAL COMPUTER HPBrio BA410SG12902751 FCC DOC APPROVED 2 COLOR MONITOR ADICM100 026058T102006 11 A FCC DOC APPROVED 3PRINTEREPS…

Text truncated - open the document above for the full version.

FCC ID: E8HMSR0238B Report No.: RF911210R0414Issued: Jan. 09, 2003 5 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
