E8HRG-0618UReceiver

A. FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to Part 15 the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. CAUTION: AVOID PROLONGED USE OF THE KEYBOARD WITHOUT BREAKS. Take regular breaks and keep a good posture. Consult your physician promptly if you notice any lost of motion or pain in your wrist when using the keyboard. INFORMATION FOR OPTICAL POINTING DEVICES ONLY: This product has been tested to comply with International Standard IEC 60825-1: (1993), incld. Amd. 2(2001).  This product users LEDs that are inherently Class 1. IMPORTANT BATTERY INFORMATION • Keep batteries out of reach of children. • Insert the batteries in the proper direction as indicated by the positive (+) and negative (-) markings in the battery chamber. • Do not mix old and new batteries or batteries of different types (for example, carbon and alkaline batteries). • Always remove old, weak, or worn-out batteries propmptly and recycle or proper disposal of them in accordance with Local and National Disposal Regulations. • If a battery leaks, remove all batteries and recycle or dispose of them in accordance with the battery manufacture's instructions and Local and National Disposal Regulations. Before inserting new batteries, thoroughly clean the compartment with a damp paper towel, or follow the battery manufacture's recommendations for cleanup. If fluid from the battery comes into contact with skin or clothes, flush skin with water immediately. • Remove the batteries if your device is to be stored for an extended period of time without being used. PRODUCT DISPOSAL INFORMATION Dispose of this product in accordance with Local and National Disposal Regulations. B. PRODUCT SPECIFICATION 1. Frequency Deviation: ± 320 KHz 2. ModulationTypp: GFSK Mode 3. Transmitter Power: 0dBm Max 4. Power requirement: 2V~3.2V 5. Battery: Keyboard : 2 pieces of AA Batteries  Mouse : 2 pieces of AAA Batteries 6. Battery life time : Keyboard : 1200 hours reference (operating mode) Mouse : 110 hours reference (operating mode) 7. Operation distance : Keyboard : 10 M without signal disturbance and nodirection limit. Mouse: 10 M without signal disturbance and no direction limit. 8. Mouse resolution : 800 DPI 9. Operating temperature : -10º C ~ +40º C 10. Storage temperature : -40º C ~ +85º C. English Class 1 LED Product Contents Getting Started .................................................................................................................. 1 Features ............................................................................................................................. 1 Preparing Keyboard, Mouse and Receiver .......................................................................... 1 Hardware Installation ......................................................................................................... 1 Connect the receiver ...................................................................................................... 1 Inserting batteries ........................................................................................................... 1 Inserting batteries into mouse .................................................................................. 1 Inserting batteries into keyboard ............................................................................... 1 Connection ...................................................................................................................... 2 Software Installation ............................................................................................................ 2 Installing software for mouse ............................................................................................ 2 Installing software for keyboard ........................................................................................ 2 Displaying Keyboard Modes ................................................................................................ 2 Working with Keyboard and Mouse ..................................................................................... 2 Using mouse wheel ......................................................................................................... 2 Keyboard ............................................................................................................................ 2 Multimedia-keys ..............…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT

FCC ID: E8HRG-0618U FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

Page 2 Page 3

FCC ID: E8HRG-0618U Report No.: RF960710A06 Operational Description The transmitter of the EUT (Receiver) is powered by 5.0Vdc from host equipment. The type of antenna is Printed antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: RF960710A06 1 Report Format Version 2.0.6 FCC TEST REPORT REPORT NO.: RF960710A06 MODEL NO.: RG-0618U RECEIVED: July 13, 2007 TESTED: July 27 ~ 30, 2007 ISSUED: Aug. 8, 2007 APPLICANT: Chicony Electronics Co., Ltd. ADDRESS: No. 25, Wu-Gong 6th Rd., Wu Ku Industrial Park, Taipei Hsien, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. This test report consists of 31 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF, A2LA or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF960710A06 2 Report Format Version 2.0.6 Table of Contents 1. CERTIFICATION..........................................................................................3 2. SUMMARY OF TEST RESULTS..................................................................4 2.1 MEASUREMENT UNCERTAINTY...............................................................4 3. GENERAL INFORMATION..........................................................................5 3.1 GENERAL DESCRIPTION OF EUT............................................................5 3.2 DESCRIPTION OF TEST MODES..............................................................6 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.........................................6 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.............7 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................8 3.4 DESCRIPTION OF SUPPORT UNITS........................................................8 4. TEST TYPES AND RESULTS......................................................................9 4.1 CONDUCTED EMISSION MEASUREMENT..............................................9 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT............................9 4.1.2 TEST INSTRUMENTS................................................................................9 4.1.3 TEST PROCEDURES...............................................................................10 4.1.4 DEVIATION FROM TEST STANDARD.....................................................10 4.1.5 TEST SETUP ...........................................................................................10 4.1.6 EUT OPERATING CONDITIONS..............................................................11 4.1.7 TEST RESULTS........................................................................................12 4.2 RADIATED EMISSION MEASUREMENT.................................................18 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...............................18 4.2.2 TEST INSTRUMENTS..............................................................................19 4.2.3 TEST PROCEDURES...............................................................................20 4.2.4 DEVIATION FROM TEST STANDARD.....................................................20 4.2.5 TEST SETUP ...........................................................................................21 4.2.6 EUT OPERATING CONDITIONS..............................................................21 4.2.7 TEST RESULTS........................................................................................22 4.3 BAND EDGES MEASUREMENT..............................................................26 4.3.1 LIMITS OF BAND EDGES MEASUREMENT............................................26 4.3.2 TEST INSTRUMENTS..............................................................................26 4.3.3 TEST PROCEDURE.................................................................................26 4.3.4 DEVIATION FROM TEST STANDARD.....................................................26 4.3.5 EUT OPERATING CONDITION................................................................26 4.3.6 TEST RESULTS........................................................................................26 5. PHOTOGRAPHS OF THE TEST CONFIGURATION.................................29 6. INFORMATION ON THE TESTING LABORATORIES...............................30 7. APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB......................................................31 Report No.: RF960710A06 3 Report Format Version 2.0.6 1. CERTIFICATION PRODUCT: Receiver BRAND NAME: Chicony MODEL NO.: RG-0618U APPLICANT: Chicony Electronics Co., Ltd. TESTED: July 27 ~ 30, 2007 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.4-2003 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Aug. 8, 2007 ( Annie Chang / Senior Specialist ) TECHNICAL ACCEPTANCE : , DATE: Aug. 8, 2007 Responsible for RF ( Jun Wu / Senior Engineer ) APPROVED BY : , DATE: Aug. 8, 2007 ( Ken Liu / Deputy Manager ) Report No.: RF960710A06 4 Report Format Version 2.0.6 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD PARAGRAPH TEST TYPE RESULT REMARK 15.207 Conducted Emission Test PASS Minimum passing margin is –13.16dB at 0.209MHz 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 12.209 PASS Minimum passing margin is –4.03dB at 4804.000MHz 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST
