FCC ID: E8HRG-1091 Report No.: RF110315D19-2 Operational Description The transmitter of the EUT (Dongle) is powered by 5Vdc from host equipment. The type of antenna is Strip Antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: SA110315D19-2 Report Format Version 4.0.0 1 RF EXPOSURE REPORT REPORT NO.: SA110315D19-2 MODEL NO.: RG-1091 FCC ID: E8HRG-1091 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Chicony Electronics Co., Ltd. ADDRESS: No. 25, Wu-Gong 6th Rd., Wu Ku Industrial Park, Taipei Hsien, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION : No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan Report No.: SA110315D19-2 Report Format Version 4.0.0 2 1. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2. MPE CALCULATION FORMULA Pd = (Pout) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW Pi = 3.1416 R = distance between observation point and center of the radiator in cm 3. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA110315D19-2 Report Format Version 4.0.0 3 4. CALCULATION RESULT OF MAXIMUM POWER CALCULATION FOR MAXIMUM PEAK VALUE FREQUENCY BAND (MHz) MAX RADIATED POWER (dBm) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2403-2480 2.0 20 0.0003 1.00 ---END---

Report No.: RF110315D19-2 1 Report Format Version 4.0.0 FCC TEST REPORT REPORT NO.: RF110315D19-2 MODEL NO.: RG-1091 FCC ID: E8HRG-1091 RECEIVED: Mar. 15, 2011 TESTED: Mar. 17 ~ 18, 2011 ISSUED: Mar. 22, 2011 APPLICANT: Chicony Electronics Co., Ltd. ADDRESS: No. 25, Wu-Gong 6th Rd., Wu Ku Industrial Park, Taipei Hsien, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan This test report consists of 30 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110315D19-2 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD..............................................................................3 1. CERTIFICATION..........................................................................................4 2. SUMMARY OF TEST RESULTS..................................................................5 2.1 MEASUREMENT UNCERTAINTY...............................................................5 3. GENERAL INFORMATION..........................................................................6 3.1 GENERAL DESCRIPTION OF EUT............................................................6 3.2 DESCRIPTION OF TEST MODES..............................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.........................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.............8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS...........................10 3.4 DESCRIPTION OF SUPPORT UNITS......................................................10 4. TEST TYPES AND RESULTS....................................................................11 4.1 CONDUCTED EMISSION MEASUREMENT............................................11 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT..........................11 4.1.2 TEST INSTRUMENTS..............................................................................11 4.1.3 TEST PROCEDURES...............................................................................12 4.1.4 DEVIATION FROM TEST STANDARD.....................................................12 4.1.5 TEST SETUP............................................................................................12 4.1.6 EUT OPERATING CONDITIONS..............................................................13 4.1.7 TEST RESULTS........................................................................................14 4.2 RADIATED EMISSION MEASUREMENT.................................................16 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...............................16 4.2.2 TEST INSTRUMENTS..............................................................................17 4.2.3 TEST PROCEDURES...............................................................................18 4.2.4 DEVIATION FROM TEST STANDARD.....................................................18 4.2.5 TEST SETUP............................................................................................19 4.2.6 EUT OPERATING CONDITIONS..............................................................19 4.2.7 TEST RESULTS........................................................................................20 4.3 BAND EDGES MEASUREMENT..............................................................25 4.3.1 LIMITS OF BAND EDGES MEASUREMENT............................................25 4.3.2 TEST INSTRUMENTS..............................................................................25 4.3.3 TEST PROCEDURE.................................................................................25 4.3.4 DEVIATION FROM TEST STANDARD.....................................................25 4.3.5 EUT OPERATING CONDITION................................................................25 4.3.6 TEST RESULTS........................................................................................25 5. PHOTOGRAPHS OF THE TEST CONFIGURATION.................................28 6. INFORMATION ON THE TESTING LABORATORIES...............................29 7. APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB......................................................30 Report No.: RF110315D19-2 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release N/A Mar. 22, 2011 Report No.: RF110315D19-2 4 Report Format Version 4.0.0 1. CERTIFICATION PRODUCT: Dongle BRAND NAME: DELL MODEL NO.: RG-1091 APPLICANT: Chicony Electronics Co., Ltd. TESTED: Mar. 17 ~ 18, 2011 TEST ITEM: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.4-2003 ANSI C63.10-2009 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Celia Chen / Senior Specialist ) APPROVED BY : , DATE: ( Ken Liu / Manager ) Report No.: RF110315D19-2 5 Report Format Version 4.0.0 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD SECTION TEST TYPE AND LIMIT RESULT REMARK 15.207 Conducted Emission Test PASS Minimum passing margin is –12.61dB at 0.564MHz 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental fr…
