E8HTG-1226Wireless Touchpad

User Manual Wireless Touchpad Setup: Wireless Touchpad System Requirements The following is a list of system requirements: z One USB port (for the USB Receiver) z Microsoft Windows 8. Contents of the Box Note: NOTE: The USB receiver may be pre‐installed on your computer. Note: Insert documents vary according to shipping country’s requirements. Setting Up Step 1: Setting up the Wireless Touchpad Step 2: Connect the USB Receiver to Computer If your keyboard and mouse are NOT working, please refer to Troubleshooting page Features: Wireless Touchpad Front View 1 LED Indicator Indicates the status of Power on and when battery is low. White (solid) – Fade on = 1 sec. On = 10 sec. Fade off = 1 sec. Amber (flashing) – Battery charge is < 15% power. 2 Right Click 3 Left Click 1 3 2 Back View 1. Power switch 2. Battery compartment 2 1 Gesture Functions Cursor Moving, Left/Right/Up/Down Tap, Open the App, the function as the mouse left button. Support single and double click. Left Edge swipe, Reveal all the open App, left edge to right side. Right Edge swipe, Reveal start charm Top Edge swipe, Close open App, from top edge to down side Top Edge swipe, Reveal App Menu Slide, left/right, App move as same as the finger move. Zoom in, Zoom out picture/Metro surface/Page and so on. Zoom out, Zoom out picture/Metro surface/Page and so on. Rotate, All the supported rotated App, support 90°rotate. 2-finger tap, reveal App menu Page Forward Page Backward Page Down Page Up Display Desktop Display Metro surface Lock the screen Volume Down Volume Up Mute On/Off Specifications: Wireless Touchpad Electrical Operating Voltage 2.0 V to 3.2 V Battery life 3 months and above Battery require 2*AA Alkaline Physical Characteristics Height 23(± 0.4) mm Length 130(± 0.5) mm Width 128(± 0.5).mm Weight 205 gw with batteries Environmental Operating temperature 0 °C to 40 °C Storage temperature -40 °C to 65 °C Operating humidity 90% maximum Relative Humidity, non condensing Storage humidity 95% maximum Relative Humidity, non condensing 2.4 GHz Wireless Radio transmission Bi-directional, Enhanced Shock Burst™ Range 10M without signal disturbance and no direction limit Troubleshooting: Wireless Touchpad If you have problems with your Touchpad: z Check if the batteries are inserted in the correct orientation. z Check if the Touchpad's power switch is set to on. z Remove and reinstall the batteries. The power status light fades on (solid white) for about 1 second and on 10 seconds and then fades off 1 second. z Remove and insert the USB receiver again. z Restart your computer. Insert the USB receiver into another USB port on your computer. FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to Part 15 the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. CAUTION: You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. Industry Canada Statement: This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable. IMPORTANT BATTERY INFORMATION ● Keep batteries out of reach of children. ● Insert the batteries in the proper direction as indicated by the positive (+) and negative (-) markings in the battery chamber. ● Do not mix old and new batteries or batteries of different types (for example, carbon and alkaline batteries). ● Always remove old, weak, or worn-out batteries propmptly and recycle or proper disposal of them in accordance with Local and National Disposal Regulations. ● If a battery leaks, remove all batteries and recycle or dispose of them in accordance with the battery manufacture's instructions and Local and National Disposal Regulations. Before inserting new batteries, thoroughly clean the compartment with a damp paper towel, or follow the battery manufacture's recommendations for cleanup. If fluid from the battery comes into contact with skin or clothes, flush skin with water immediately. ● Remove the batteries if your device is to be stored for an extended period of time wit…

Text truncated - open the document above for the full version.

Chicony Electronics Co., Ltd. NO. 25, Wu-Gong 6th Rd., Wugu Dist., New Taipei City 248, Taiwan, R.O.C Tel: 886-2-22988120 Fax: 886-2-22989745 Federal Communications Commission Authorization and Evaluation Division Date: 9/12/2012 Confidentiality Request FCC ID: E8HTG-1226 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Thank you! Sincerely yours, ------------------------------------------ T.S.Chen / Manager Chicony Electronics Co., Ltd. Tel: +886 2-2298-8120 Fax: +886 2-2298-9745 E-mail : [email protected]

Chicony Electronics Co., Ltd. NO. 25, Wu-Gong 6th Rd., Wugu Dist., New Taipei City 248, Taiwan, R.O.C. Tel: 886-2-22988120 Fax: 886-2-22989745 Power of Attorney To whom it may concern: Date: September 14, 2012 We, the undersigned, Chicony Electronics Co., Ltd., hereby authorize Bureau Veritas Consumer Products Services(H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan on our behalf shall have the same effects as acts of our own. Product Name Model FCC ID Wireless Touchpad TG-1226 E8HTG-1226 Dongle RG-1217 E8HRG-1217 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------ T.S.Chen / Manager Chicony Electronics Co., Ltd. Tel: +886 2-2298-8120 Fax: +886 2-2298-9745 E-mail : [email protected]

Page: 1

DESIGNEDAPPROVED REV LTR DATE REV . DIMENSION DESIGNED DWG NO : REV . APPROVED KEY MODEL : DESCRIPTION: Scale: 1226L TG-1226 CHECK Great B A Sharon SEP/13-`2012FEB/20-`2012 Jonathan NOTE: 1. PRINT COLOR : PANTONE 423C (GRAY) 2. DRAWING FOR PRINTING REFERENCE ONLY 3. DIMENSIONAL TOLERANCE +/- 0.15 mm 4. This product / component must comply with Chicony specification "ISO 361" BOTTOM CAB, W/PRINT ICON SEP/13-`2012 1/1 FCC ID: E8HTG-1226 TG-1226 型號 額定電壓電流 MADE IN CHINA (中國製造)

Page: 2 Page: 3 Page: 4 Page: 5 Page: 6 Page: 7

FCC ID: E8HTG-1226 Report No.: RF120904D09 Operational Description The transmitter of the EUT (Wireless Touchpad) is powered by 3.0Vdc from batteries. The type of antenna is Strip antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: RF120904D09 1 of 23 Report Format Version 5.0.0 FCC TEST REPORT REPORT NO.: RF120904D09 MODEL NO.: TG-1226 FCC ID: E8HTG-1226 RECEIVED: Sep. 4, 2012 TESTED: Sep. 7~ 10, 2012 ISSUED: Sep. 13, 2012 APPLICANT: Chicony Electronics Co., Ltd. ADDRESS: NO. 25, Wu-Gong 6th Rd., Wugu Dist., New Taipei City 248, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF120904D09 2 of 23 Report Format Version 5.0.0 Table of Contents RELEASE CONTROL RECORD.................................................................................. 3 1. CERTIFICATION ............................................................................................... 4 2. SUMMARY OF TEST RESULTS ....................................................................... 5 2.1 MEASUREMENT UNCERTAINTY .................................................................... 5 3. GENERAL INFORMATION ............................................................................... 6 3.1 GENERAL DESCRIPTION OF EUT .................................................................. 6 3.2 DESCRIPTION OF TEST MODES .................................................................... 7 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .................... 8 3.3 DESCRIPTION OF SUPPORT UNITS ............................................................ 10 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST ............................................. 10 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................. 11 4. TEST TYPES AND RESULTS ......................................................................... 12 4.1 CONDUCTED EMISSION MEASUREMENT .................................................. 12 4.2 RADIATED EMISSION AND BAND EDGE MEASUREMENT ......................... 12 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT ..................................... 12 4.2.2 TEST INSTRUMENTS .................................................................................... 13 4.2.3 TEST PROCEDURES ..................................................................................... 14 4.2.4 DEVIATION FROM TEST STANDARD ........................................................... 14 4.2.5 TEST SETUP .................................................................................................. 15 4.2.6 EUT OPERATING CONDITIONS .................................................................... 15 4.2.7 TEST RESULTS .............................................................................................. 16 5. PHOTOGRAPHS OF THE TEST CONFIGURATION ...................................... 21 6. INFORMATION ON THE TESTING LABORATORIES .................................... 22 7. APPENDIX A – MODIFICATION RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB ......................................................... 23 Report No.: RF120904D09 3 of 23 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF120904D09 Original release Sep. 13, 2012 Report No.: RF120904D09 4 of 23 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: Wireless Touchpad BRAND NAME: Chicony MODEL NO.: TG-1226 APPLICANT: Chicony Electronics Co., Ltd. TESTED: Sep. 7~ 10, 2012 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.10-2009 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Sep. 13, 2012 ( Jessica Cheng / Specialist ) APPROVED BY : , DATE: Sep. 13, 2012 ( Ken Liu / Manager ) Report No.: RF120904D09 5 of 23 Report Format Version 5.0.0 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD PARAGRAPH TEST TYPE RESULT REMARK 15.207 Conducted Emission Test N/A Power supply is 3.0Vdc from batteries 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 15.209 PASS Meet the requirement of limit. Minimum passing margin is -8.6dB at 2390.00MHz. 2.1 MEAS…

Text truncated - open the document above for the full version.

Report No.: RF120904D09 1 of 1 Report Format Version 5.0.0 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
