E8HVGP-BMS21Bluetooth Laser Mouse

Wireless Laser Mouse VGP-BMS21 © 2011 Sony Corporation Printed in China 4-259-138-11(1) Operating Instructions English WARNING To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture. To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only. Owner’s Record The model number and the serial number are located inside the battery compartment of the mouse. Record the serial number in the space provided below. Refer to this number whenever you call your Sony dealer regarding this product. Model No. VGP-BMS21 Serial No. ____________________ Safety information  Do not look directly into the lens. The laser light may cause eye injury.  In the following circumstances, set the power to off and have it checked by qualified personnel before continuing its use. – Water or a foreign object has entered the mouse. – Smoke is coming out of the mouse. – There is an unusual noise or smell. – The mouse is dropped or the exterior of the mouse has broken.  Do not place the mouse in a location subject to: – On an unstable surface – In very humid areas or where there is no ventilation – Excessive dust – Direct sunlight or extreme heat – Mechanical vibration or shock – Greasy fumes  If the mouse is brought directly from a cold to a warm location or is placed in a very damp room, moisture may condense on the inside of the mouse. If this occurs, the mouse may not work properly. Precautions on using the batteries  If the battery liquid is leaking: – Do not touch the battery liquid directly. If your eyes, skin, or clothing comes into contact with the battery liquid, wash well with pure water. If you have skin inflammation or a wound results, consult a doctor immediately. – Wipe the battery compartment carefully, and insert new batteries.  Dispose of used batteries promptly and properly. Discard used batteries according to the manufacturer’s instructions. In some areas, the disposal of batteries in household or business waste may be prohibited. Please use the appropriate public collection system.  Batteries may explode or leak if recharged, or disposed of in fire.  Do not disassemble, heat above 60 ̊C (140 °F) or incinerate.  Replace only with the same or equivalent type recommended by the manufacturer. Do not mix old (used) and new batteries, or batteries of a different type. Be sure to use batteries specified in “Power requirements” of “Specifications.” Danger of explosion if battery is incorrectly replaced.  Keep away from children.  Insert the batteries with the correct +/– orientation.  When the batteries have run out, or when you intend to not use the mouse over a prolonged period, remove the batteries.  Do not short-circuit the metal terminals of the battery or wet them with any liquid, for example, water, coffee, or juice. Conditions of use  Do not use this device on hospital premises. Doing so may cause medical devices to malfunction.  Do not use this device on an aircraft, as doing so may cause the aircraft's equipment to malfunction.  If using this device near a pacemaker, make sure it is at least 20 cm (8 inches) away from the pacemaker.  Sony is not responsible for any interference that you may experience or that may be caused when operating this device.  Check for and respect airline restrictions on use of wireless capabilities. If use of the wireless function is prohibited on the airline, set the power switch on this device to OFF before boarding. The equipment is classified as a CLASS 1 LASER PRODUCT and complies with the Laser Products Safety Standard IEC/EN 60825-1(2007). Caution - Repair and maintenance of this equipment should be made only by Sony authorized technicians. Improper repairs and use can create safety hazards. Caution - Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. You can find the following sticker on the bottom of the equipment. For customers in the U.S.A. The following FCC statements apply only to the version of this model manufactured for sale in the USA. Other versions may not comply with FCC technical regulations. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. For questions regarding your product or for the Sony Service Center nearest you, call 1-888-476- 6972 in the United States or 1-800-961-7669 in Canada. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that …

Text truncated - open the document above for the full version.

Chicony Electronics Co., Ltd. No.25 Wu-Gong 6 Th Rd. Wu-Ku Industrial Park, Taipei, Taiwan, R.O.C. Tel: 886-2-22988120 Fax: 886-2-22989745 Federal Communications Commission Authorization and Evaluation Division Date: 10/18/2011 Confidentiality Request FCC ID: E8HVGP-BMS21 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Thank you! Sincerely yours, ------------------------------------------ T.S.Chen / Manager Chicony Electronics Co., Ltd. Tel: +886 2-2298-8120 Fax: +886 2-2298-9745

Chicony Electronics Co., Ltd. No.25 Wu-Gong 6 Th Rd. Wu-Ku Industrial Park, Taipei, Taiwan, R.O.C. Tel: 886-2-22988120 Fax: 886-2-22989745 Federal Communications Commission Authorization and Evaluation Division Date: October 18, 2011 Confidentiality Request FCC ID: E8HVGP-BMS21 Pursuant to DA 04-1705 of the Commission’s Rules, we request short-term confidential treatment for the following information until Jan. 31, 2012 of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External Photos Test Setup Photos User’s Manual Internal Photo Thank you! Sincerely yours, ------------------------------------------ T.S.Chen / Manager Chicony Electronics Co., Ltd. Tel: +886 2-2298-8120 Fax: +886 2-2298-9745

Chicony Electronics Co., Ltd. No.25 Wu-Gong 6 Th Rd. Wu-Ku Industrial Park, Taipei, Taiwan, R.O.C. Tel: 886-2-22988120 Fax: 886-2-22989745 Power of Attorney To whom it may concern: Date: October 18, 2011 We, the undersigned, Chicony Electronics Co., Ltd., hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan on our behalf shall have the same effects as acts of our own. Product Name Model FCC ID Bluetooth Laser Mouse VGP-BMS21 E8HVGP-BMS21 If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------ T.S. Chen / Manager Chicony Electronics Co., Ltd. Tel: +886 2-2298-8120 Fax: +886 2-2298-9745

Page 1 CONSTRUCTION PHOTOS OF EUT

8HVGP-BMS21 IC:5524A-VGPBMS21 KCC-CRM-E8H-VGP-BMS21

FCC ID: E8HVGP-BMS21 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Cover has hinge which attached to the mouse body and can't be removed when it is at open position Label

Page 2 Page 3 Page 4 Page 5 Page 6

FCC ID: E8HVGP-BMS21 Report No.: RF110927D09 Operational Description The device is a Frequency Hopping device with 79 hopping frequencies. The antenna type is Printed antenna and there is no antenna connector used. The EUT is a unit that contains a Bluetooth radio module. Bluetooth is a short-range wireless technology operating in the 2.4GHz band. It enables devices to have the ability to form networks and exchange information. The other instruction, please have a look at the user’s manual.

Report No: SA110927D09 1 Report Format Version 4.0.0 RF EXPOSURE REPORT REPORT NO.: SA110927D09 MODEL NO.: VGP-BMS21 FCC ID: E8HVGP-BMS21 RECEIVED: Sep. 27, 2011 TESTED: Sep. 30 ~ Oct. 3, 2011 ISSUED: Oct. 11, 2011 APPLICANT: Chicony Electronics Co., Ltd. ADDRESS: No. 25, Wu-Gong 6th Rd., Wu Ku Industrial Park, Taipei Hsien, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist.,New Taipei City, Taiwan ( R.O.C ) This test report consists of 5 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced, except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval or endorsement by any government agency. The test results in the report only apply to the tested sample. Report No: SA110927D09 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD....................................................................................3 1. CERTIFICATION..............................................................................................4 2. CONCLUSION.................................................................................................5 Report No: SA110927D09 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA110927D09 Original release Oct. 11, 2011 Report No: SA110927D09 4 Report Format Version 4.0.0 1. CERTIFICATION PRODUCT: Bluetooth Laser Mouse BRAND NAME: SONY MODEL NO.: VGP-BMS21 APPLICANT: Chicony Electronics Co., Ltd. TESTED: Sep. 30 ~ Oct. 3, 2011 TEST ITEM: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Celia Chen / Senior Specialist ) APPROVED BY : , DATE: ( Ken Liu / Manager ) Report No: SA110927D09 5 Report Format Version 4.0.0 2. CONCLUSION No Evaluation Required if power is below this threshold: F(GHz) mW Low 2.402 High 2.480 24.58 Maximum measured transmitter power: Pout (dBm) Pout (mW) Conducted Power -0.8 0.8 EIRP Power -3.7 0.4 *Note: The antenna is Printed antenna with -2.89dBi gain Threshold for no SAR evaluation is 24.58mW Transmitter power is 0.8mW Conclusion: No SAR evaluation required since Transmitter Pout is below FCC threshold ---END---

Report No.: RF110927D09 1 Report Format Version 4.0.0 FCC TEST REPORT REPORT NO.: RF110927D09 MODEL NO.: VGP-BMS21 FCC ID: E8HVGP-BMS21 RECEIVED: Sep. 27, 2011 TESTED: Sep. 30 ~ Oct. 3, 2011 ISSUED: Oct. 11, 2011 APPLICANT: Chicony Electronics Co., Ltd. ADDRESS: No. 25, Wu-Gong 6th Rd., Wu Ku Industrial Park, Taipei Hsien, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist.,New Taipei City, Taiwan ( R.O.C ) This test report consists of 44 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110927D09 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD................................................................................4 1. CERTIFICATION........................................................................................5 2. SUMMARY OF TEST RESULTS...............................................................6 2.1 MEASUREMENT UNCERTAINTY.............................................................7 3. GENERAL INFORMATION........................................................................8 3.1 GENERAL DESCRIPTION OF EUT..........................................................8 3.2 DESCRIPTION OF TEST MODES............................................................9 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST........................................9 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL...........10 3.3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS..........................12 3.3.4 DESCRIPTION OF SUPPORT UNITS.....................................................12 4. TEST TYPES AND RESULTS..................................................................13 4.1 CONDUCTED EMISSION MEASUREMENT...........................................13 4.2 RADIATED EMISSION MEASUREMENT................................................13 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.............................13 4.2.2 TEST INSTRUMENTS.............................................................................14 4.2.3 TEST PROCEDURES.............................................................................15 4.2.4 DEVIATION FROM TEST STANDARD....................................................15 4.2.5 TEST SETUP...........................................................................................16 4.2.6 EUT OPERATING CONDITIONS.............................................................16 4.2.7 TEST RESULTS......................................................................................17 4.3 NUMBER OF HOPPING FREQUENCY USED........................................21 4.3.1 LIMIT OF HOPPING FREQUENCY USED..............................................21 4.3.2 TEST INSTRUMENTS.............................................................................21 4.3.3 TEST PROCEDURES.............................................................................21 4.3.4 DEVIATION FROM TEST STANDARD....................................................22 4.3.5 TEST SETUP...........................................................................................22 4.3.6 TEST RESULTS......................................................................................22 4.4 DWELL TIME ON EACH CHANNEL........................................................24 4.4.1 LIMIT OF DWELL TIME USED................................................................24 4.4.2 TEST INSTRUMENTS.............................................................................24 4.4.3 TEST PROCEDURES.............................................................................24 4.4.4 DEVIATION FROM TEST STANDARD....................................................24 4.4.5 TEST SETUP...........................................................................................25 4.4.6 TEST RESULTS......................................................................................25 4.5 CHANNEL BANDWIDTH.........................................................................29 4.5.1 LIMITS OF CHANNEL BANDWIDTH.......................................................29 4.5.2 TEST INSTRUMENTS.............................................................................29 4.5.3 TEST PROCEDURE................................................................................29 4.5.4 DEVIATION FROM TEST STANDARD....................................................30 4.5.5 TEST SETUP...........................................................................................30 4.5.6 EUT OPERATING CONDITION...............................................................30 4.5.7 TEST RESULTS......................................................................................31 4.6 HOPPING CHANNEL SEPARATION.......................................................32 4.6.1 LIMIT OF HOPPING CHANNEL SEPARATION.......................................32 4.6.2 TEST INSTRUMENTS.............................................................................32 Report No.: RF110927D09 3 Report Format Version 4.0.0 4.6.3 TEST PROCEDURES.............................................................................32 4.6.4 DEVIATION FROM TEST STANDARD....................................................32 4.6.5 TEST SETUP...........................................................................................32 4.6.6 TEST RESULTS......................................................................................33 4.7 MAXIMUM PEAK OUTPUT POWER.......................................................34 4.7.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT........34 4.7.2 TEST INSTRUMENTS........................................…

Text truncated - open the document above for the full version.

Report No.: RF110927D09 1 Report Format Version 4.0.0 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
