EF400100SECURITY ALARM TRANSMITTER

Copyright © 2013 235240 X11 TTLDW O 01 TTLDW C 01 UNIVERSALDOOR/WINDOWTRANSMITTERSInstallation Instructions PRODUCT DESCRIPTIONThe TTLDWO01 and TTLDWC01 are battery powered supervised stationary transmitters. These transmitters can be used in a variety of wireless security and remote sensing applications. Triggering the transmitter with its built-in magnetic switch sends a digitally coded wireless signal to the alarm control.Both models have an optional external input that can be triggered by dry contact devices. The Model TTLDWC01 connects to normally closed (N/C) devices. The Model TTLDWO01 connects to normally open (N/O) devices. The transmitter is programmed using Confi guration Mode to select the internal magnetic switch only, the external contact input only, or both.The transmitter can send fi ve different signal types: fault, restore, low battery, tamper, and status. The system must be programmed to the transmitter’s code before testing and operation. Refer to the alarm control’s instructions for details on programming.In a typical installation, the magnet is mounted on a door or window and the transmitter is mounted on the frame. When the door or window is opened, the magnet moves away from the transmitter and a fault signal is sent. When the door or window is closed, the magnet returns next to the transmitter and a restore signal is sent. About every 65 minutes the transmitter sends a supervisory status signal to update the system. If the battery tests low, a low battery signal is included with any transmission. The transmitter is powered from two 3-Volt CR2032 lithium batteries (included).An internal switch detects if the transmitter’s case is opened. Opening the case will send a tamper signal. Two screws and double-stick tape are provided for mounting the transmitter. FEATURES BATTERY INSTALLATION OR REPLACEMENT INPUT CONFIGURATION MODE OPTIONAL EXTERNAL CONTACT TRANSMITTER MOUNTING PROGRAMMING & TESTING TATTLETALE PORTABLE ALARM SYSTEMS LIMITED WARRANTYThis TATTLETALE PORTABLE ALARM SYSTEMS product is warranted against defects in material and workmanship for a period of one year. This warranty does not apply in cases of improper installation, misuse, failure to follow installation and operating instructions, alteration, abuse, accident or tampering, or repair by anyone other than tattletale. This warranty does not cover the replacement of batteries that are used to power the product. There are no obligations or liabilities on the part of TATTLETALE PORTABLE ALARM SYSTEMS for consequential damages arising out of or in connection with use or performance of this product or other indirect damages with respect to loss of property, revenue, or profi t, or cost of removal, installation or reinstallation. All implied warranties, including implied warranties for merchantability and implied warranties for fi tness, are valid only until the warranty expires. This TATTLETALE PORTABLE ALARM SYSTEMS Warranty is in lieu of all other warranties express or implied.All products returned for warranty service require a Return Merchandise Authorization Number (RMA#). Contact TATTLETALE Technical Support at 1-888-835-5668 or at www.tattletale.com for an RMA # and other important details.This device complies with FCC Part 15 and Canada Rules and Regulations. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.Conformité RéglementaireCe dispositif est conforme à la réglementation de la IC et (Partie 15) de la FCC. Son fonctionnement est soumis à deux conditions : (1) ce dispositif ne doit pas causer d’interférences nuisibles, et (2) ce dispositif doit accepter toute interférence reçue, y compris les interférences pouvant entraîner des conditions de fonctionnement indésirables.Changes or modifi cations to the device may void FCC complianceLes modifi cations apportées à l’appareil peuvent annuler la conformité FCC. www.tattletale.com 6269 Frost Road. Westerville OH 43082 PRINTER’S INSTRUCTIONS: INSTR,INSTL,TTLDWO&C01 - FILE NAME: 235240 X11- INK: BLACK - MATERIAL: 20 LB. MEAD BOND - SIZE: 11.000” X 8.500” - SCALE: 1-1 TRAN S MITTER MAGNET DOUBLE- S TICK TAPE EXTERNAL CONTACT LEAD S MOUNTING S CREW S MAGNET ALIGNMENT MARK S EXTERNAL CONTACT MAGNET 3 FEET MAXIMUM EXTERNAL CONTACT CONNECTOR AN EXTERNAL CONTACT CAN BE CONNECTED TO THE TRAN S MITTER 1 PLUG THE EXTERNAL CONTACT LEAD S INTO THE TRAN S MITTER' S EXTERNAL CONTACT CONNECTOR 2 WIRE THE EXTERNAL CONTACT TO THE LEAD S FOR MODEL TTLDWC01 U S E NORMALLY CLO S ED CONTACT S FOR MODEL TTLDWO01 U S E NORMALLY OPEN CONTACT S TRAN S MITTER ON DOOR FRAME MAGNET ON DOOR OPENING ORCLO S ING THE DOOR TRIGGER S THE TRAN S MITTER INSTALLATION TIP: TO MINIMIZE PHYSICAL SHOCK TO THE UNIT, ALWAYS MOUNT THE TRANSMITTER ON THE STATIONARY PART OF THE OPENING 1/2" GAP MAXIMUM !!! MOUNT MAGNET NEXT TO ALIGNMENT MARK S ATTACH MOUNTING PLATEWITH TWO S CREW S OR U S E THE DOUBLE- S TICK TAPE NOTE: MOUNTING THE TRANSMITTER WITH DOUBLE-STICK TAPE IS NOT ALLOWED IN UL INSTALLATIONS 1 REFER TO THE S Y S TEM' S IN S TRUCTION S AND PLACE THE ALARM CONTROL IN PROGRAM MODE VERIFY THAT THE TRAN S MITTER HA S BEEN "LEARNED" BY THE ALARM CONTROL 2 OPEN OR CLO S E THE PROTECTED DOOR TO S END A S IGNAL 3 S IGNAL TO RECEIVER OPENDOOR TE S T THE S Y S TEM TO VERIFY PROPER OPERATION, CHECKTHAT THE S Y S TEM INDICATE S WHEN THE DOOR I S OPEN OR CLO S ED 4 NOTICE TO USERS IN CALIFORNIA - CR COIN CELL LITHIUM BATTERY INFORMATION: THIS PRODUCT CONT AINS A CR COIN CELL LITHIUM BATTERY WHICH CONTAINS PERCHLORATE MATERIAL - SPECIAL HANDLING MAY APPLY - SEE www.dtsc.ca.gov/hazardouswaste/perchlorate KEEP AWAY FROM SMALL CHILDREN. IF BATTERIES ARE SWALLOWED, PROMPTLY SEE A DOCTOR. DO NOT TRY TO RECHARGE THESE BATTERIES. DISPOSAL OF USED BATTERIES MUST BE MADE IN ACCORDANCE WITH THE WASTE RECOVERY AND RECYCLING REGULATIONS IN YOUR…

Text truncated - open the document above for the full version.

LINEAR LLC 1950 CAMINO VIDA ROBLE, SUITE 150, CARLSBAD, CA 92008-6517 PHONE (760) 438-7000 ● (800) 421-1587 ● ENG. FAX (760) 438-7043 MAIL: P.O. BOX 9003 ● CARLSBAD, CA 92018-9003 Letter of Agency I appoint Intertek Testing Services NA Inc. to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of EF4TTLDWO01 equipment under the FCC rules until further notice. I further certify that no party (as defined in 1.2002 of CFR 47, 1995) to this application, including myself, is subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.,853A. Dated this May 10, 2013. _____________________________________ Signature __John W. Kuivinen, P.E. _ Name __Senior Regulatory Compliance Engineer _____ Title __Linear LLC ____________________________ Company ____760-438-7138 ________________________ Telephone

LINEAR LLC 1950 CAMINO VIDA ROBLE, SUITE 150, CARLSBAD, CA 92008-6517 PHONE (760) 438-7000 ● (800) 421-1587 ● ENG. FAX (760) 438-7043 MAIL: P.O. BOX 9003 ● CARLSBAD, CA 92018-9003 Attention: Application Examiner Re: Request for confidentiality Applicant: Linear LLC FCC ID: EF400100 To whom it may concern, Request is hereby submitted by {Your company name] to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: • Parts list • Schematic Short-term Confidentiality [Complete this section if short-term confidentiality is requested] [Your company name] has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development.] Sincerely, John W. Kuivinen, P.E. Senior Regulatory Compliance Engineer [email protected] Linear LLC

Internal photos

This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. EMC Report for Linear, LLC, on Tattletale, model: TTLDWC01 / TTLDWO01 Page 1 of 21 TEST REPORT Report Number: 101166168LAX-001 Project Number: G101166168 Report Issue Date: May 10, 2013 Product Designation: Tattletale Model: TTLDWC01 / TTLDWO01 Standards: FCC ID: IC ID: FCC Part 15.231, 2013 Industry Canada RSS 210 Issue 8, December 2010 EF400100 1078A-00100 Tested by: Client: Intertek Testing Services NA, Inc. 25791 Commercentre Drive Lake Forest, CA 92630 USA Linear, LLC 1950 Camino Vida Roble, Suite 150 Carlsbad, CA 92008 USA Report prepared by Report reviewed by Meak Nget EMC Test Engineer & David O’Reilly EMC Team Leader Nicholas Abbondante Transmitter Staff Engineer Intertek REPORT NUMBER: 101166168LAX-001 Issued: May 10, 2013 EMC Report for Linear, LLC, on Tattletale, model: TTLDWC01 / TTLDWO01 Page 2 of 21 TABLE OF CONTENTS 1 Introduction and Conclusion .............................................................................................................. 3 2 Test Summary ...................................................................................................................................... 3 3 Client Information ................................................................................................................................ 4 4 Description of Equipment Under Test ................................................................................................ 5 5 System setup including cable interconnection details, support equipment and simplified block diagram ........................................................................................................................................................ 6 6 Radiated Emissions (FCC Part 15.231) .............................................................................................. 7 7 AC Mains Conducted Emissions (FCC Part 15.207) ....................................................................... 20 8 Measurement Uncertainty & Test Equipment Used ........................................................................ 20 9 Revision History ................................................................................................................................. 21 Intertek REPORT NUMBER: 101166168LAX-001 Issued: May 10, 2013 EMC Report for Linear, LLC, on Tattletale, model: TTLDWC01 / TTLDWO01 Page 3 of 21 1 Introduction and Conclusion The tests indicated in section 2.0 were performed on the product constructed as described in section 3.0. The remaining test sections are the verbatim text from the actual data sheets used during the investigation. These test sections include the test name, the specified test Method, a list of the actual Test Equipment Used, documentation Photos, Results and raw Data. No additions, deviations, or exclusions have been made from the standard(s) unless specifically noted. Based on the results of our investigation, we have concluded the product tested found to comply with the requirements of the standard(s) indicated. The results obtained in this test report pertain only to the item(s) tested. 2 Test Summary TEST FCC REFERENCE IC REFERENCE RESULTS Radiated Emission 15.231(b) RSS-210 A1.1.2 Complies Out of Band Radiated Emission 15.231(b) RSS-210 A1.1.2 Complies AC Conducted Emission 15.207 ICES-003 Not Applicable* 20 dB Bandwidth 15.231(c) RSS-210 A1.1.3 Complies Transmitter Deactivation Time 15.231(a) RSS-210 A1.1.1(a) Complies Antenna Requirement 15.203 - Complies (*) Test not applicable due to EUT being battery operated. Intertek REPORT NUMBER: 101166168LAX-001 Issued: May 10, 2013 EMC Report for Linear, LLC, on Tattletale, model: TTLDWC01 / TTLDWO01 Page 4 of 21 3 Client Information This EUT was tested at the request of: Company: Linear, LLC. 1950 Camino Vida Roble, Suite 150 Carlsbad, CA 92008 USA Contact Person: John Kuivinen Telephone: (760) 438-7138 Fax: (760) 438-7043 Email: [email protected] 3.1 Overview of the EUT Applicant: Linear, LLC Product Description: Model Number: Tattletale TTLDWC01 / TTLDWO01 FCC Identifier: IC Identifier: EF400100 1078A-00100 Transmitter activation: Manually operated. Deactivates within 5 seconds of being released. Fundamental Frequency (MHz): 433.9 MHz Antenna Requirement: The EUT uses a permanently connected internal antenna. Manufacturer name & address: Linear, LLC 1950 Camino Vida Roble, Suite 150 Carlsbad, CA 92008 USA 3.2 Environmental Conditions During the measurement the environmental conditions were within the listed ranges: Temperature: 10-40 ° C Humidity: 10-90 % Atmospheric pressure: 86-106 kPa Intertek REPORT NUMBER: 101166168LAX-001 Issued: May 10, 2013 EMC Report for Linear, LLC, on Tattletale, model: TTLDWC01 / TTLDWO01 Page 5 of 21 4 Description of Equipment Under Test Equipment Under Test Description Manufacturer Model Number Serial Number Tattletale Linear, LLC TTLDWC01 / TTLDWO01 NA Received Date: 05/06/2013 Received Condition: Good Type: Production Sample Equipment Under Test Power Configuration Rated Voltage Rated Current Frequency Number of Phases Battery Operated NA NA NA Operating mode…
