EF400124Wireless Siren & Strobe

1 WA105DBZ-1 Radio Frequency Controlled Wireless Siren & Strobe NOTE: This unit must be “included in the Network” only where it will be permanently installed. The proper operation of this node in the mesh network is dependent on it knowing its location with respect to other nodes. You cannot “test bench” confi gure this module, then install. WA105DBZ-1 WIRELESS SIREN & STROBE Linear’s family of Z-Wave™ certifi ed wireless lighting controls (switches, dimmers, outlets and plug-in modules) and Security devices (alert sounder, passive infrared sensor and door/window transmitter) brings a new level of intelligent wireless capability to commercial and residential environments. The Z-Wave wireless protocol is an international wireless standard for remote home automation, security and other applications. Embedded in each device, the Z-Wave smart chip enables two-way RF communication among hundreds of Z-Wave enabled devices, allowing products and services from multiple manufacturers to work seamlessly. Linear Z-Wave products are easy to install, and allow dealers to create an integrated wireless network with nearly limitless expansion and interoperability with security and health monitoring systems, energy management, home entertainment, appliances, and more. As part of a Z-Wave network, the WA105DBZ-1 will also act as a wireless repeater to insure that commands intended for another device in the network are received. This is useful when the device would otherwise be out of the radio range of the wireless controller. For indoor use only. Retain instructions for future use. INSTALLATION 1. Remove the bracket from the siren by press the locking tab, and then gently slide up the siren. 2. Knock out the thin wall on the bracket. 3. Feed the power line from the AC adapter through the hole on bracket and connect to the screw terminal on WA105DBZ-1. For “Inclusion” to (adding to) a network: Refer to your Controller operating instructions to add this module under the command of the Wireless Controller. 4. Prepare the Controller to include a unit to the network by adding it to a group (method of adding a node to the network). Refer to controller instructions. 5. If your Controller supports Network Wide Inclusion (NWI) locate the WA105DBZ-1 near the proposed installation location. If not skip to Step 8. 6. With your Controller in Inclusion mode, plug the unit’s AC adapter into an electrical socket. Note that it will take 6 to 8 hours to fully charge the internal battery backup. 7. You should see an indication on your Controller that the “device was included” in the network. It should display binary switch / Linear. The LED will stop blinking. Skip to Step 11. If the LED does not stop blinking, relocate the WA105DBZ-1 to within 100 feet (line of sight) of a Z-Wave device or your hub and repeat Step 6. If the LED continues to blink, your Controller does not support NWI and continue with Step 8. 8. Place the WA105DBZ-1 within 3 feet of the Controller. 9. Plug included AC adapter into a standard wall outlet. Note that it will take 6 to 8 hours to fully charge the internal battery backup. 10. With your controller in Inclusion mode, depress the Tamper switch for 1 second then release. The LED light will begin blinking. 11. You should see an indication on your Controller that the “device was included” in the network. It should display binary switch / Linear. The LED will stop blinking. 12. The device will appear in the list of Switches. 13. Using the screws or adhesive tape affi x the bracket at the chosen location. 14. Place the WA105DBZ-1 back onto the bracket. 15. After 5 seconds, the WA105DBZ-1 will activate Tamper mode. ✓NOTE: If you have trouble adding the WA105DBZ-1 to a group it may be that the Home ID and Node ID were not cleared from it after testing. You must fi rst “RESET UNIT” with your controller to remove it from the network. Although adding it to a group includes it in the network, removing it from a group does not remove it from the network. If removed from a group, it functions as a repeater (only). “RESET UNIT” removes it completely from the network. For “Exclusion” from (removing from) a network: 1. Set up the Z-Wave™ Interface Controller into “exclusion” mode, and following its instruction to delete the WA105DBZ-1 from the controller. 2. Press the tamper switch of WA105DBZ-1 for 1 second and release to be excluded. The LED light will fl ash continuously when the sensor is in the Exclusion condition. BASIC OPERATION When triggered, the WA105DBZ-1 will trigger for 30 seconds (default setting). During that time the siren will emit a very loud pulsating audible alarm at 105 db. The integrated strobe light will also fl ash during the 30 seconds. ✘CAUTION: This is an extremely loud siren, do not place it near your ear. LED Indication The LED on the WA105DBZ-1 will not be on during normal operation. Remote Control The WA105DBZ-1 will respond to BASIC and BINARY commands that are part of the Z-Wave system. Refer to your controller’s instructions as to whether your controller can transmit those commands. PRINTER’S INSTRUCTIONS: INSTR,INSTL,WA105DBZ-1; LINEAR P/N: P2065 X4; INK: BLACK; MATERIAL: 20# MEAD BOND; SIZE: 8.500” x 11.000”; SCALE: 1-1; PAGE 1 OF 2 2 Copyright © 2014 Linear LLC P2065 X4 CONFIGURATION The WA105DBZ-1 supports the Confi guration command. The WA105DBZ-1 can be confi gured to operate slightly differently than how it works when you fi rst install it. Using the Confi guration command you can confi gure the following: Parameter 0: Siren / Strobe Mode By default, the siren and strobe on the WA105DBZ-1 will activate when turned on. To activate the Siren only, set parameter 0 to 1. For strobe only set to 2. • Parameter No: 0 • Length: 1 Byte • Valid Values = 0 (default) or 1 or 2. Default is 0. Parameter 1: Auto Stop Time By default the auto stop time is 30 seconds. Setting parameter 1 to 1 will increase the time to 60 seconds. Changing it to 2 will increase the stop time to 120 seconds…

Text truncated - open the document above for the full version.

Specification of Antenna Model No.： WA105DBZ-1 Antenna Type： PCB Antenna Length Closed： 72mm Length Open： N/A Diameter： 2.3mm No. of element： N/A Antenna Gain： -10 dbm Total Resistance： 1.5Ω Temperature： -20°C ~ 70°C

RF_160, Issue 03 Declaration of Authorization We Name: Linear LLC Address: 1950 Camino Vida Roble, Suite 150 City: Carlsbad, CA 92008 Country: USA Declare that: Name Representative of agent: Daphne Liang............. (1) Agent Company name: Compliance Certification Services Inc. Address: No. 8, Jiu Cheng Ling, Jiaokeng Village, Sinhua Dist., 712, City: Tainan City Country Taiwan is authorized to apply for Certification of the following product(s): Product description: Wireless Siren & Strobe Type designation: W A105DBZ-1 Trademark: Linear LLC on our behalf. Date: 25 April 2014. City: Carlsbad, CA. USA Name: John W. Kuivinen, P.E. (2) Function: Regulatory Compliance Engineer Signature: ............................... Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure RF_501, Issue 6 Date: 16-Jul-10 Page 1 of 1 Company Name: Linear LLC Address : 1950 Camino Vida Roble, Suite 150 City: Carlsbad, CA 92008 Country: USA To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: EF400124 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the follo wing materials submitted in support of FCC certification application: Bill( s) of Material Block Diagrams Operational Description Schemati c Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical informati on, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competito rs. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importat ion rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the follo wing materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (n otes 2, 3, 4, 5) Date: 25 April 2014 Name and signature of applicant: John W. Kuivinen, P.E. Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! FCC, Request for non-disclosure RF_501, Issue 6 Date: 16-Jul-10 Page 1 of 1 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Compliance Certification Services Inc. Report No.T140325N06 Page A1 / 10 External Photo ( WA105DBZ-1 ) Compliance Certification Services Inc. Report No.T140325N06 Page A2 / 10

WA105DBZ-1 Diagram Label location Label location FCC ID FCC IDFCC ID FCC ID： ：： ：EF400124

Compliance Certification Services Inc. Report No.T140325N06 Page A3 / 10 Internal Photo ( WA105DBZ-1 ) Compliance Certification Services Inc. Report No.T140325N06 Page A4 / 10 Compliance Certification Services Inc. Report No.T140325N06 Page A5 / 10 Compliance Certification Services Inc. Report No.T140325N06 Page A6 / 10 Compliance Certification Services Inc. Report No.T140325N06 Page A7 / 10 Compliance Certification Services Inc. Report No.T140325N06 Page A8 / 10 Compliance Certification Services Inc. Report No.T140325N06 Page A9 / 10 Compliance Certification Services Inc. Report No.T140325N06 Page A10 / 10

Compliance Certification Services Inc. FCC ID:EF400124 Report No.:T140325N06-RP1 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 38 FCC 47 CFR PART 15 SUBPART C: 2012 ANSI C63.4: 2009 TEST REPORT For Wireless Siren & Strobe Model: WA105DBZ-1 Brand: Linear LLC Issued to Linear LLC 1950 Camino Vida Roble, Suite 150, Carlsbad, California 92008, USA Issued by Compliance Certification Services Inc. Tainan Lab. No.8,Jiucengling, Xinhua Dist., Tainan City 712, Taiwan (R.O.C.) TEL: (06) 580-2201 FAX: (06) 580-2202 Issued Date: May 16, 2014 Compliance Certification Services Inc. FCC ID:EF400124 Report No.:T140325N06-RP1 Page 2 / 38 REVISION HISTORY Rev. Issue Date Revisions Effect Page Revised By 00 May 16, 2014 Initial Issue ALL Sunny Chang Compliance Certification Services Inc. FCC ID:EF400124 Report No.:T140325N06-RP1 Page 3 / 38 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION .........................................................................4 2. EUT DESCRIPTION..............................................................................................5 3. TEST METHODOLOGY........................................................................................6 3.1 EUT CONFIGURATION ...................................................................................6 3.2 EUT EXERCISE ...............................................................................................6 3.3 GENERAL TEST PROCEDURES ....................................................................6 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ........................7 3.5 DESCRIPTION OF TEST MODES...................................................................7 4. INSTRUMENT CALIBRATION .............................................................................8 4.1 MEASURING INSTRUMENT CALIBRATION ..................................................8 4.2 MEASUREMENT EQUIPMENT USED ............................................................8 4.3 MEASUREMENT UNCERTAINTY ...................................................................9 5. FACILITIES AND ACCREDITATIONS ...............................................................10 5.1 FACILITIES ....................................................................................................10 5.2 EQUIPMENT ..................................................................................................10 5.3 LABORATORY ACCREDITATIONS LISTING ...............................................10 5.4 TABLE OF ACCREDITATIONS AND LISTINGS............................................11 6. SETUP OF EQUIPMENT UNDER TEST ............................................................12 6.1 SETUP CONFIGURATION OF EUT ..............................................................12 6.2 SUPPORT EQUIPMENT................................................................................12 7. FCC PART 15.249 REQUIREMENTS ................................................................13 7.1 20 DB BANDWIDTH.......................................................................................13 7.2 BAND EDGES MEASUREMENT ...................................................................16 7.3 DUTY CYCLE.................................................................................................17 7.4 SPURIOUS EMISSION..................................................................................20 7.5 POWERLINE CONDUCTED EMISSIONS .....................................................32 APPENDIX I - PHOTOGRAPHS OF TEST SETUP .................................................35 APPENDIX II - PHOTOGRAPHS OF EUT .............................................................. A1 Compliance Certification Services Inc. FCC ID:EF400124 Report No.:T140325N06-RP1 Page 4 / 38 1. TEST RESULT CERTIFICATION Product: Wireless Siren & Strobe Model: WA105DBZ-1 Applicant: Linear LLC 1950 Camino Vida Roble, Suite 150, Carlsbad, California 92008, USA Manufacturer: Vision Automobile Electronics Industrial Co., Ltd No. 78, Gongye 3rd Rd., Technology Industrial Park, Tainan City 70955, Taiwan (R.O.C.) Tested: March 26, 2014 ~ March 31, 2014 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C: 2012 ANSI C63.4 : 2009 No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements emission limits of FCC Rules Part 15.107, 15.109,15.207, 15.209 and 15.249. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: Jeter Wu Assistant Manager Eric Huang Assistant Section Manager Compliance Certification Services Inc. FCC ID:EF400124 Report No.:T140325N06-RP1 Page 5 / 38 2. EUT DESCRIPTION Product Wireless Siren & Strobe Model Number WA105DBZ-1 Received Date March 25, 2014 Frequency Range 908.42MHz 20KHz Transmit Peak Power 88.38 dBμV/m Data Rate 9.6 kbps , 40kbps Number of Channels 1 Channel Type of Modulation FSK Power Supply DC 12V (Power by Adapter) Antenna Type PCB antenna Gain: -10 dBi Temperature Range -15°C ~ +60°C Power Adapter : No. Manufacturer Model No. Power Input Power Output 1 AC ADAPTOR SP41-120500 120Vac, 60Hz, 7W 12Vdc, 500mA Remark: 1. Client consigns only one model sample to test (Model Number: WA105DBZ-1). Therefore, the testing Lab. just guarantees the unit, which has been tested. 2. This submittal(s) (test report) is intended for FCC ID: EF400124-US filing to comply with Section 15.107 & 15.109 (FCC Part 15, Subpar…
