DXS-600SUPERVISEDLONG RANGECONVERTIBLETRANSMITTEROperation Instructions PRODUCT DESCRIPTION The Model DXS-600 is a battery powered, miniature, water-resistant*, supervised transmitter designed for use with Linear’s PERS Consoles and DX or DXS Format receivers.The transmitter is supplied in the pendant confi guration with an adjustable lanyard with a breakaway release. An optional wristband mount is also included. WARNING! After snapping the transmitter into the wristband mount, do not attempt to remove the unit from the wristband mount or damage may result . Pressing the button on the transmitter sends a digitally coded wireless signal to its companion Console. To insure sending a complete signal, press the transmitter button for a minimum of two seconds.The DXS-600 transmitter is factory set to a unique code, so no fi eld coding is required. When its button is pressed, the transmitter can send a signal for up to 30 seconds per activation. The signal indicator on the transmitter lights green when the unit is activated. Consoles must be programmed to the transmitter’s code before system testing and operation. Refer to the Console’s instructions for details on programming.After the fi rst activation, the transmitter will send a status signal every two hours. Every two hours the transmitter also tests for a low battery. If the battery tests low, a low battery signal is sent. If the transmitter is activated with a low battery, the signal indicator will light red.The transmitter is sealed to provide water-resistance. The unit’s battery is not replaceable. The transmitter should be discarded at the end of its battery life.* NOTE: Water resistance not tested by UL OPTIONS & FEATURES ENABLING STATUS & PROGRAMMING SYSTEM TESTING LIMITED WARRANTY This Nortek Security & Control product is warranted against defects in material and workmanship for twenty four (24) months. This warranty extends only to wholesale customers who buy direct from Nortek Security & Control or through Nortek Security & Control’s normal distribution channels. Nortek Security & Control does not warrant this product to consumers. Consumers should inquire from their selling dealer as to the nature of the dealer’s warranty, if any. There are no obligations or liabilities on the part of Nortek Security & Control LLC for consequential damages arising out of or in connection with use or performance of this product or other indirect damages with respect to loss of property, revenue, or pro fi t, or cost of removal, installation, or reinstallation. All implied warranties, including implied warranties for merchantability and implied warranties for fi tness, are valid only until the warranty expires. This Nortek Security & Control LLC Warranty is in lieu of all other warranties express or implied.All products returned for warranty service require a Return Product Authorization Number (RPA#). Contact Returns at 1-855-546-3351 for an RPA# and other important details.IMPORTANT !!! Radio controls provide a reliable communications link and fi ll an important need in portable wireless signaling. However, there are some limitations which must be observed. • For U.S. installations only: The radios are required to comply with FCC Rules and Regulations as Part 15 devices. As such, they have limited transmitter power and therefore limited range. • A receiver cannot respond to more than one transmitted signal at a time and may be blocked by radio signals that occur on or near their operating frequencies, regardless of code settings. • Infrequently used radio links should be tested regularly to protect against undetected interference or fault.• A general knowledge of radio and its vagaries should be gained prior to acting as a wholesale distributor or dealer, and these facts should be communicated to the ultimate users. This device complies with part 15 of the FCC Rules and Industry Canada license exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.Les changements ou modi fi cations non approuvés expressément par la partie responsable de la conformité pourrait annuler l’autorité de l’utilisateur à faire fonctionner l’équipement. ACTIVATE THE T R AN S MITTE R TO PE R MANENTLY ENABLE S TATU S R EPO R TING THE INDICATION THAT S TATU S R EPO R T S A R E BEING S ENT I S THE S IGNAL INDICATO R BLINKING 3 TIME S AFTE R EACH T R AN S MITTE R ACTIVATION INSTRUCTIONS FORTHE INSTALLER P R OG R AM THE T R AN S MITTE R INTO THE CON S OLE BY PLACING THE CON S OLE INTO P R OG R AM MODE, THEN S END A S IGNAL TO THE CON S OLE F R OM THE T R AN S MITTE R . R EFE R TO THE UL LI S TED PE RS -2400B, PE RS - 3 600B, O R PE RS -4200 CON S OLE' S P R OG R AMMING IN S T R UCTION S FO R DETAIL S . IMPORTANT ! TEST SYSTEM WEEKLY ! THE MANUFACTURER STRONGLY RECOMMENDS THAT YOU TEST THIS EQUIPMENT FREQUENTLY. OVER A PERIOD OF TIME, NO ELECTRONIC PRODUCT IS BETTER THAN THE INSPECTION AND MAINTENANCE IT RECEIVES. THEREFORE, FROM THE TIME OF INSTALLATION, IT IS ABSOLUTELY NECESSARY TO TEST THE SYSTEM AT LEAST ONCE A WEEK. PLACE THE CON S OLE IN "TE S T" MODE AND ACTIVATE THE T R AN S MITTE R . VE R IFY THAT THE S IGNAL WA S R ECEIVED AND THAT THE S Y S TEM R EPO R T S A S R EQUI R ED. IF THE SIGNAL INDICATOR LIGHTS RED, THE BATTERY IS LOW AND THE TRANSMITTER NEEDS TO BE REPLACED WRISTBAND …
Text truncated - open the document above for the full version.
Ac cess Control | Security & Home Automation | Health & Wellness | Home Technology 1950 Camino Vida Roble Suite 150 Carlsbad CA 92008 800.421.1587 www.nortekcontrol.com CETCB 114 Olinda Drive Brea, CA 92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc., specifically including the employees of Compatible Electronics, as an Agent for Nortek Security & Control LLC, 1950 Camino Vida Roble Suite 150, Carlsbad CA 92008, for a period of one year, to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the following Nortek Security & Control LLC product: Model: FCC ID: Under FCC Docket Number 20780 and General Docket Number 80‐284 pursuant to Part 15 of FCC Rules and Regulations. Please also accept this letter as an attestation that neither Nortek Security & Control LLC nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non‐voting, have been denied federal benefits under section 5301 of the Anti‐Drug‐Abuse act of 1988.21 U.S.C. 853(a). In addition, Nortek Security & Control LLC will notify the Federal Communications Commission if, at any time, the situation changes causing Nortek Security & Control LLC to be denied federal benefits. If you have any questions or need additional information, please feel free to give me a call at (760) 438‐7179 Sincerely, Josh Hansen Regulatory Engineer
Ac cess Control | Security & Home Automation | Health & Wellness | Home Technology 1950 Camino Vida Roble Suite 150 Carlsbad CA 92008 800.421.1587 www.nortekcontrol.com CETCB 114 Olinda Drive Brea, California 92823 Gentlemen: We, Nortek Security & Control LLC, would like to declare that the application being submitted for the device with FCC ID: , has not been submitted to another TCB or FCC for certification. Sincerely, Josh Hansen Regulatory Engineer
Ac cess Control | Security & Home Automation | Health & Wellness | Home Technology 1950 Camino Vida Roble Suite 150 Carlsbad CA 92008 800.421.1587 www.nortekcontrol.com CETCB 114 Olinda Drive Brea, California 92823 Gentlemen: We, Nortek Security & Control LLC, would like to request that all schematics, block diagrams, and operational descriptions submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457 (d) of the Commission’s Rules, and Section 552 (b)(4) of the Freedom of Information Act. These sections authorize the withholding from public inspection, those materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any questions, please feel free to give me a call at (760) 438‐7179 Sincerely, Josh Hansen Regulatory Engineer
Correspondence by Project Project Number: Correspondence NumberMemo EF400129-1 1) The block diagram submitted is not sufficient. As per section 2.1033(b)(5) of the FCC rules, the block diagram must show “the frequency of all oscillators used in the device. The signal path and frequency shall be indicated at each block. The tuning range(s) and intermediate frequency(ies) shall be indicated at each block.” A new Block Diagram has been submitted. 2) In the documentation provided, it states that the EUT will have a minimum transmission time of two seconds. However, the data provided in the test report shows a transmission of less than one second. Please explain this difference and correct as necessary. A new Operational Description has been submitted. 3) The user manual is missing the required 15.105 statement. Please send a corrected user manual. The product does not contain an independent digital device unrelated to the transmitter operation. Untitled Documenthttp://www.celectronics.com/CorrespondenceByProject.asp?ProjectNum... 1 of 15/7/2015 10:59 AM
.50 12.7 .30 7.6 REVISIONS REV DESCRIPTION DATEAPPROVED X1 INITIAL RELEASE TOLERANCES: UNLESS OTHERWISE NOTED ALL DIMENSIONS ARE INCHES [MM]: DECIMALS ANGLES: ± 0.5° .XX±.01 [.3] CONCENTRICITY:±.005 [.13] DO NOT SCALE DRAWING A 4 B 3 FINISH: MATERIAL: (UNLESS OTHERWISE SPECIFIED) DC NOTES: 4 3 DRAWING NO.: APPROVED:APPROVED: 2 CAD OPERATOR:CHECKED:APPROVED:APPROVED: SCALE: DATE DATE C SIZE: DATE DATEDATE DATE TITLE: PROJECT: SHEET: 1 REV.: A B 2 C D .XXX±.005 [.13] 1 1 OF 1 FLATNESS: ±.005 [.13] ROUNDNESS:±.005 [.13] S. TRIMBLE 3/4/2015 10006049 X1 TOLERANCES: UNLESS OTHERWISE NOTED ALL DIMENSIONS ARE INCHES [MM]: DECIMALS ANGLES: ± 0.5° .XX±.01 [.3] CONCENTRICITY:±.005 [.13] DO NOT SCALE DRAWING A 4 B 3 FINISH: MATERIAL: (UNLESS OTHERWISE SPECIFIED) DC NOTES: 4 3 DRAWING NO.: APPROVED:APPROVED: 2 CAD OPERATOR:CHECKED:APPROVED:APPROVED: SCALE: DATE DATE C SIZE: DATE DATEDATE DATE TITLE: PROJECT: SHEET: 1 REV.: A B 2 C D .XXX±.005 [.13] 1 1 OF 1 FLATNESS: ±.005 [.13] ROUNDNESS:±.005 [.13] S. TRIMBLE 3/4/2015 10006049 X1 1 : 1 A RTWORK,FCC/TRACKING,DXS-600/700 PROCESS: UV LASER ETCHING 1. FOR PLACEMENT SEE MECHANICAL ASSEMBLY DRAWING. 2. FONT AND SIZE: ARIAL NARROW, 5 POINT. 3.TO BE PRINTED BY UV LASER ON PRODUCTION LINE. ROW 1, UNIT FINISHED GOOD NUMBER FOR EXAMPLE: SST00138 ROW 2, FCC ID NUMBER: EF400129ROW 3, IC ID NUMBER: 1078A-00129ROW 4, YYWWXXXXXXX IS THE MANUFACTURING DATE CODE FOLLOWED BY THE 7 DIGIT DECIMAL NUMBER OF THE UUT TX ID. FOR EXAMPLE: 15010123456 (WEEK 1 OF 2015, TRANSMITTER ID 0123456) (ROW 1) (ROW 2)(ROW 3)(ROW 4) SST00XXX FCC ID: EF400129 IC: 1078A-00129 YYWWNNNNNNN REVISIONS REV DESCRIPTION DATE APPROVED X1 INITIAL RELEASE ULTRA-SONICALLY WELD LITE PIPE (ITEM 5) TO TOP CASE (ITEM 3) AS SHOWN AND PROVIDE A WATER TIGHT SEAL. PLACE PCB, FOAM, AND LABEL (I TEM 1,8 AND 6) BETWEEN CASES (ITEMS 2 AND 3). ULTRA-SONICALLY WELD AS SHOWN AND PROVIDE A WATER TIGHT SEAL. USE LINEAR PROVIDED ARTWORK FOR MARKING APPROXIMATELY WHERE SHOWN. BEFORE ULTRA SONICALLY WELDING CASES (ITEMS 2 AND 3) , SCAN BARCODE LABEL ON PCB (ITEM 1) TO RECORD SYSTEM. THEN PRESS BUTTON ON PCB (ITEM 1) TO TRANSMIT. DECODED TRANSMIT ID IS SAVED TO RECORD SYSTEM IN SAME RECORD AND PRINTED ON LABEL (ITEM 17 ON FINISHED GOOD LEVEL). 1234 SEE SEPARATE PARTS LISTSEE SEPARATE PARTS LIST TOLERANCES: UNLESS OTHERWISE NOTED ALL DIMENSIONS ARE INCHES [MM]: DECIMALS ANGLES: ± 0.5° .XX±.01 [.3].XXX±.005 [.13] CONCENTRICITY:±.005 [.13] DO NOT SCALE DRAWING A 4 B 3 FINISH: MATERIAL: (UNLESS OTHERWISE SPECIFIED) DC NOTES: 43 DRAWING NO.: APPROVED:APPROVED: 2 CAD OPERATOR:CHECKED:APPROVED:APPROVED: SCALE: DATE DATE C SIZE: DATE DATEDATE DATE TITLE: PROJECT: SHEET: 1 REV.: A B 2 C D 1 1 OF 1 FLATNESS: ±.005 [.13] ROUNDNESS:±.005 [.13] S. TRIMBLE 3/11/2015 10004587 X1 NONE ASSY, MECH TRANSMITTER, DXS-600 TOLERANCES: UNLESS OTHERWISE NOTED ALL DIMENSIONS ARE INCHES [MM]: DECIMALS ANGLES: ± 0.5° .XX±.01 [.3].XXX±.005 [.13] CONCENTRICITY:±.005 [.13] DO NOT SCALE DRAWING A 4 B 3 FINISH: MATERIAL: (UNLESS OTHERWISE SPECIFIED) DC NOTES: 43 DRAWING NO.: APPROVED:APPROVED: 2 CAD OPERATOR:CHECKED:APPROVED:APPROVED: SCALE: DATE DATE C SIZE: DATE DATEDATE DATE TITLE: PROJECT: SHEET: 1 REV.: A B 2 C D 1 1 OF 1 FLATNESS: ±.005 [.13] ROUNDNESS:±.005 [.13] S. TRIMBLE 3/11/2015 10004587 X1 NONE ASSY, MECH TRANSMITTER, DXS-600 2 1 4 5 2 1 4 2 8 2 3 6 4 3 LASER ETCHING DETAIL FCC & IC LABEL PRELIMINARY
This device FCC ID: is excluded from SAR testing by the following justification The maximum power that the transmitter is capable o f is 0.53 mW Applied duty cycle? no Using the following formula from section 4.3.1 of K DB 447498 at test separation distances ≤ 50 mm [(max. power of channel, including tune-up toleranc e, mW) / (min. test separation distance, mm)] * [ √ f(GHz)] Duty Cycle 11.00% Value 1-g (mW) 10-g (mW) 0.06 173 574 "Value" shall be ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR 1-g power limit 10-g power limit 267 668 “source-based” time-averaging based on an inherent property or duty-cycle of a device is allowed. An e xample of this is the determination of exposure from a device that uses digital technology such as a time-division mu ltiple-access (TDMA) scheme for transmission of a EF400129 Max Peak Power (dBm) Min Separation distance (mm) Fre quency (Ghz) < 50mm power limits for above frequency and distanc e When the minimum test separation distance is < 5 mm , a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 0.315 5 -2.77
Report Number: D50319R1 FCC Part 15 Subpart C Section 15.231 Test Report Supervised Long Range Convertible Transmitter - FCC ID: EF400129 Model: DXS-600 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15, SUBPART C 15.231 TEST REPORT for SUPERVISED LONG RANGE CONVERTIBLE TRANSMITTER MODEL: DXS-600 Prepared for NORTEK SECURITY & CONTROL 1950 CAMINO VIDA ROBLE, SUITE 150 CARLSBAD, CA 92008 Prepared by:_____________________ MATT HARRISON Approved by:____________________ JEFF KLINGER COMPATIBLE ELECTRONICS INC. 20621 Pascal Way LAKE FOREST, CA 92630 (949) 587-0400 DATE: MARCH 19, 2015 REPORT APPENDICES TOTAL BODY A B C D PAGES 16 2 2 13 14 47 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: D50319R1 FCC Part 15 Subpart C Section 15.231 Test Report Supervised Long Range Convertible Transmitter - FCC ID: EF400129 Model: DXS-600 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description Of Test Configuration - EMI 8 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 7. TEST PROCEDURES 13 7.1 RF Emissions 13 7.1.1 Conducted Emissions Test 13 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 14 7.1.3 Radiated Emissions (Spurious and Harmonics) Test (Continued) 15 7.1.4 Peak radiated EMI 15 7.1.5 Bandwidth of the Fundamental 16 8. CONCLUSIONS 16 Report Number: D50319R1 FCC Part 15 Subpart C Section 15.231 Test Report Supervised Long Range Convertible Transmitter - FCC ID: EF400129 Model: DXS-600 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos Test Setup Diagrams Radiated Emissions Photos Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Radiated Emissions 3-Meter Semi-Anechoic Test Chamber Below 1GHz 2 Radiated Emissions 3-Meter Semi-Anechoic Test Chamber Above 1GHz Report Number: D50319R1 FCC Part 15 Subpart C Section 15.231 Test Report Supervised Long Range Convertible Transmitter - FCC ID: EF400129 Model: DXS-600 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product certification, approval or endorsement by NVLAP, NIST, or any agency of the federal government. Device Tested: Supervised Long Range Transmitter Model: DXS-600 SN: 11 Product Description: See Expository Statement Modifications: The EUT was not modified. Manufacturer: Nortek Security & Control, LLC. 1950 Camino Vida Roble, Suite 150 Carlsbad, CA 92008 Test Date: March 19, April 7, and May 7, 2015 Test Specifications: CFR Title 47, Part 15 Subpart C, Sections 15.205, 15.209 and 15.231 Test Procedure: ANSI C63.10 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Radiated RF Emissions, 0.01 - 4000 MHz Complies with the limits of CFR Title 47, Part 15, Subpart C, section 15.205 & 15.209 2 -20 dB Occupied Bandwidth of the Emission Complies with the limits of CFR Title 47, Part 15, Subpart C, section 15.231. 3 Peak Radiated EMI Complies with the limits of CFR Title 47, Part 15, Subpart C, section 15.231. 4 Transmit Timeout Complies with the limits of CFR Title 47, Part 15, Subpart C, section 15.231. Report Number: D50319R1 FCC Part 15 Subpart C Section 15.231 Test Report Supervised Long Range Convertible Transmitter - FCC ID: EF400129 Model: DXS-600 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interferen…
