EF400195DIGITAL TRANSMITTER

PRINTER’S INSTRUCTIONS: INSTR,INSTL,MC3089 ,1 CH,TX - LINEAR P/N: 10029379_Rev-X1 - INK: BLACK - MATERIAL: 20 LB. MEAD BOND - SIZE: 9.000” X 3.500” - SCALE: 1-1 - SIDE 1 OF 2 ® Multi-Code 10029379_Rev-X1 CLL lortnoC & ytiruceS ketroN 0202 © thgirypoC USA & Canada (800) 421-1587 & (800) 392-0123 (760) 438-7000 - Toll Free FAX (800) 468-1340 www.nortekcontrol.com WARNING: the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. DIGITAL TRANSMITTER MODEL 3089 INSTALLATION INSTRUCTIONS Congratulations! You have just purchased a MULTI-Code Digital Transmitter, on the market. With a little care this transmitter should provide you with many years of excellent service. Please take a moment to read the follo ACCESSING THE CODE SWITCH Insert a small coin into the slot located at the bottom end of the transmitter. Twist the coin and remove the access cover to expose the code switch and battery compartment. SELECTING A CODE You may set your transmitter to any code you desire but be sure that the code you set matches the code that has been set on your radio receiver. The digital code is determined by the positions of the 10 small switches numbered 1 through10 located in the receiver and transmitter. Any combination of ON (CLOSED) or OFF (OPEN) positions can be selected by using a small screwdriver or ball point pen. (NOTE: The switches are in the “On” position when the side next to the number is pressed in.) In setting your own personal code we strongly urge that several coding schemes be avoided: ALL ON; ALL OFF; 2, 4, 6, 8, 10 ON; 1, 3, 5, 7, 9 ON. These positions are similar to our or other manufacturer’s test positions, or are frequently used. Once the code has been set, check the operation and replace the hatches. 5 8 7 6 1 4 3 2 9 10 PRINTER’S INSTRUCTIONS: INSTR,INSTL,MC3089 ,1 CH,TX - LINEAR P/N: 10029379_Rev-X1 - INK: BLACK - MATERIAL: 20 LB. MEAD BOND - SIZE: 9.000” X 3.500” - SCALE: 1-1 - SIDE 2 OF 2 TRANSMITTER INSTALLATION The transmitter is completely self contained, including battery, and can be operated while mounted in the car. It is supplied with a clip for attaching to the sun visor, if desired. If the clip is used attach to the case by sliding it into the recess provided TRANSMITTER BATTERY REPLACEMENT Replacement battery - 9 volt NEDA 1604 (Eveready 216 or equivalent). The battery in the transmitter can be checked or changed by removing the front lower half of the transmitter. Refer to the directions under “accessing the code switch” for battery replacement. TO REPLACE OR ADD A SET A replacement or new transmitter or receiver may be purchased by specifying the Model Number and the RF frequency digital code can be matched to the companion receiver or transmitter by following the above procedure. FCC & IC Notice This device complies with Part 15 of the FCC Rules and Industry Canada license exempt standard(s). Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference received that may cause undesired operation. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L ’exploitation est autorisée aux deux conditions suivantes: 1) l’a ppareil ne doit pas produire de brouillage, et 2) l’utilisateur de l’a ppareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. OPERATIONAL CHECK To check operation, move back a reasonable distance (about 50 ft.) and press the transmitter button. Operation should be reliable at this distance but environment and location of both the transmitter and receiver will affect the range. If the transmitter is stowed well out of sight, it may be necessary to remove it from its mounting and hold near the windshield. Try different locations and positions. If operation is still unsatisfactory, the problem may be isolated by: 1. Checking the door operator. If the door will not open when the wall button is pressed, the problem is likely to be the operator. If the door will open by pressing the wall button, but not when the radio control button is pressed, the problem is probably in the radios. 2. Replacing the transmitter battery. If after performing the above operational checks, the controls still do not function, they should be returned to your dealer for repair or replacement.

Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID:EF400195 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name • Block Diagram • Schematic Diagram • Operational Description • POFIT_Block • POFIT_SCH • POFIT_OPS The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application for180 days as outlined below: Exhibit Type File Name • Test Setup Photos • Internal Photos • External Photos • User Manual • 3089_ Test Setup photo---DSC • 3089_INT PHOTO • 3089_External Photos • 3089_User Manual Sincerely, Signature: Name: Josh Hansen Date: 2020/03/31

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2020/03/31 SUBJECT: FCC Application for FCC ID: EF400195 To Whom It May Concern: We, the undersigned, hereby authorize Alex Li NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park Sanwei Community, Xixiang Street, Baoan District Shenzhen China Tel: +86-0755-61156584 Email: alex.li @ntek.org.cn on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by NTEK Testing Technology Co., Ltd. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Signatory 2020-03-31 Josh Hansen Applicant: Nortek Security & Control LLC Address: 5919 Sea Otter Place,Suite 100, Carlsbad, California, 92010 United States

Date: Mar 31, 2020 FCC ID: EF400195 Model Number: 3089 To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, Nortek Security & Control LLC, declare that this EUT (FCC ID: EF400195) will conduct FCC compliance testing, the SDOC part recognized test lab(Shenzhen NTEK Testing Technology Co., Ltd.( ShenZhen Lab.). 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen 518126 P.R. China) Please contact me if you have any question. Sincerely, (Signed) Name / Title: Josh Hansen/ Engineering Manager, Regulatory Company: Nortek Security & Control LLC Address: 5919 Sea Otter Place,Suite 100, Carlsbad, California, 92010 United States Phone: 7604387179 Fax: 760-438-7043 Email: [email protected]

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

® 3089 EF400195 1078A-00195 HVIN: 10029769-0110028515_Rev-X1 LABEL,FCC,MCS308911,TX,1CH P/N: 10028515_Rev-X1

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 TX ANT Photo 3 Photo 4 Photo 5 Photo 6

Report No.: S20030301002001 ` Page 1 of 27 RADIO TEST REPORT FCC ID: EF400195 Product: DIGITAL TRANSMITTER Trade Mark: N/A Model No.: 3089 Family Model: N/A Report No.: S20030301002001 Issue Date: 25 Mar. 2020 Prepared for Nortek Security & Control LLC 5919 Sea Otter Place Carlsbad, CA 92010 United States Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Tel.: +86-755-6115 6588 Fax.: +86-755-6115 6599 Website:http://www.ntek.org.cn Report No.: S20030301002001 ` Page 2 of 27 Table of Contents Page 1.TEST RESULT CERTIFICATION 3 2. SUMMARY OF TEST RESULTS 4 3.FACILITIES AND ACCREDITATIONS 5 3.1 FACILITIES 5 3.2 LABORATORY ACCREDITATIONS AND LISTINGS 5 3.3 MEASUREMENT UNCERTAINTY 5 4. GENERAL DESCRIPTION OF EUT 6 5. DESCRIPTION OF TEST MODES 8 6. SETUP OF EQUIPMENT UNDER TEST 9 6.1 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM 9 6.2 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 10 6.3 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 7. ANTENNA REQUIREMENT 12 7.1 STANDARD REQUIREMENT 12 7.2 EUT ANTENNA 12 8. CONDUCTED EMISSION MEASUREMENT 13 8.1 APPLICABLE STANDARD 13 8.2 CONFORMANCE LIMIT 13 8.3 MEASURING INSTRUMENTS 13 8.4 TEST CONFIGURATION 13 8.5 TEST PROCEDURE 13 8.6 TEST RESULTS 14 9. RADIATED EMISSION MEASUREMENT 15 9.1 APPLICABLE STANDARD 15 9.2 RADIATED EMISSION LIMITS 15 9.3 TEST PROCEDURE 17 9.4 TEST SETUP 19 9.5 TEST RESULTS 20 10. BANDWIDTH TEST 25 10.1 TEST PROCEDURE 25 10.2 DEVIATION FROM STANDARD 25 10.3 TEST SETUP 25 10.4 TEST RESULTS 26 11. TRANSMITTER TIMEOUT 27 11.1 REQUIREMENTS 27 Report No.: S20030301002001 ` Page 3 of 27 1.TEST RESULT CERTIFICATION Applicant’s name ......................... : Nortek Security & Control LLC Address ....................................... : 5919 Sea Otter Place Carlsbad, CA 92010 United States Manufacturer's Name .................. : Flextronics Electronics Technology (Shenzhan) Co., Ltd Address ....................................... : 89 Yong Fu Road, Tong Fu Yu Industrial Park, Fu Yong Town, Bao An District, Shenzhen 518103, China Product description Product name .............................. : DIGITAL TRANSMITTER Model and/or type reference ..... : 3089 Family Model ............................... : N/A Measurement Procedure Used: APPLICABLE STANDARDS APPLICABLE STANDARD/ TEST PROCEDURE TEST RESULT FCC 47 CFR Part 15, Subpart C KDB 174176 D01 Line Conducted FAQ v01r01 ANSI C63.10-2013 Complied This device described above has been tested by Shenzhen NTEK Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of Shenzhen NTEK Testing Technology Co., Ltd., this document may be altered or revised by Shenzhen NTEK Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. The test results of this report relate only to the tested sample identified in this report. Date of Test : 03 Mar. 2020 ~ 25 Mar. 2020 Testing Engineer : (Allen Liu) Technical Manager : (Jason Chen) Authorized Signatory : (Sam Chen) Report No.: S20030301002001 ` Page 4 of 27 2. SUMMARY OF TEST RESULTS FCC Part15 (15.231), Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A Note(1) 15.203 Antenna Requirement Pass 15.231(b) 15.209 15.205 Radiated Spurious Emission Pass 15.231(c) Occupied Bandwidth Pass 15.231(a)(2) Transmitter Timeout Pass NOTE: (1) ” N/A” denotes test is not applicable in this Test Report. (2) The EUT is using a new battery Report No.: S20030301002001 ` Page 5 of 27 3.FACILITIES AND ACCREDITATIONS 3.1 FACILITIES All measurement facilities used to collect the measurement data are located at 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.10 and CISPR Publication 22. 3.2 LABORATORY ACCREDITATIONS AND LISTINGS Site Description CNAS-Lab. : The Laboratory has been assessed and proved to be in compliance with CNAS-CL01:2006 (identical to ISO/IEC 17025:2005) The Certificate Registration Number is L5516. IC-Registration The Certificate Registration Number is 9270A. CAB identifier:CN0074 FCC- Accredited Test Firm Registration Number: 463705. Designation Number: CN1184 A2LA-Lab. The Certificate Registration Number is 4298.01 This laboratory is accredited in accordance with the recognized International Standard ISO/IEC 17025:2005 General requirements for the competence of testing and calibration laboratories. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer to joint ISO-ILAC-IAF Communiqué dated 8 January 2009). Name of Firm : Shenzhen NTEK Testing Technology Co., Ltd. Site Location : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. 3.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Conducted Emission Test ±2.80dB 2 RF power, conducted ±0.16dB 3 Spurious emissions, conducted ±0.21dB 4 All emissions, radiated(30MHz~1GHz) ±2.64dB 5 All emissions, radiated(1GHz~6GHz) ±2.40dB 6 All emissions, radiated(＞6GHz) ±2.52dB 7 Temperature ±0.5°C 8 Humidity ±2% Report No.: S20030301002001 ` Page 6 of 27 4. GENERAL DESCRIPTION OF EUT Equipment DIGITAL TRANSMITTER Trade Name N/A Model Name 3089 Family Model N/A Model Difference N/A Product Description The EUT is a DIGITAL TRANSMITTER Operation Frequency: 300MHz Modulation Type: OOK Number Of Channel 1CH Antenna Designation: P…

Text truncated - open the document above for the full version.

Model: 3089 Radiated Measurement Photos END OF REPORT
