EF400206MegaCode Series Digital Transmitter

MDT-MOD MDR-MOD PERSONAL BODY ALARM SYSTEM Installation Instructions 1. PRODUCT DESCRIPTION The Model MDT-MOD tr ansmitters and Model MDR-MOD receivers are designed as wireless components in a portable Personal Body Alarm System. The system will help to locate an individual in distress. Each device is digitally coded to prevent undesired activation from adjacent systems operating on the same frequency. All MDT-MOD transmitters and MDR-MOD receivers are pre-coded at the factory to the same digital code. Model MDT-MOD tr ansmitters feature a stainless steel belt clip on the rear of the unit for fastening to a utility belt or pocket. Transmitters are activated by pulling the lanyard attached to the top of the unit, or by pressing the button on the face of the unit. The red activation indicator on the top corner of the tr ansmitter lights when the device is triggered. When the lanyard is separated from the transmitter, a digitally coded radio signal is sent for ten seconds. Any MDR-MOD receivers that are within radio range of the transmitter will activate. The radio range of each receiver is adjustable, allowing customized signal coverage at each receiver’s location. When a receiver detects a properly coded signal from one of the transmitters, its isolated Form “C” relay (normally open & closed contacts) will activate. The relay contacts are intended to be hardwired to associated annunciati on equipment that will pinpoint the location of the receiver. Transmitters are powered by two Type 2032 lithium “coin cell” batteries. When the batteries get low, the red indicator on the transmitter will light dimly when the unit is activated. If the red indicator no longer lights when the transmitter is activated, the batteries should be replaced. NOTE: Even though the transmitter stops sending a signal ten seconds after the lanyard is pulled, the red indicator will stay lit until the lanyard is replaced. To avoid constant batt ery drai n, replace the lanyard. Receivers are powered from a 24 V DC or AC power source. They each require 25 mA standby, and 60 mA operati ng current. The red indicator in the receiver shows RF signal activity and is used during reprogramming. 2. TRANSMITTER FEATURES 3. RECEIVER COMPONENT LOCATIONS4. RECEIVER INSTALLATION5. TEST AND ADJUST SYSTEM 6. REPLACING TRANSMITTER BATTERIESNORTEK SECURITY & CONTROL LLC WARRANTY This Nortek Security & Control LLC product is warranted against defects in material and wor kmanship for tw elve (12) months. The Warranty Expiration Date is labeled on the product. This warranty extends only to wholesale customers who buy direct from Nortek or through Nortek’s normal distrib ution channels. Nortek does not warrant this product to consumers. Consumers should inquire from their selling dealer as to the nature of the dealer’s warranty, if any. There are no obligations or liabilities on the part of Nortek consequential damages arising out of or in connection with use or performance of this pr oduct or other indirect damages with respect to loss of pr operty , re venue, or pr ofit, or cost of removal, installation, or reinstallation. All implied warranties, including implied warranties for merchantability and implied warranties for fi tness, are valid only until Warranty Expiration Date as labeled on the product. This Nortek Warranty is in lieu of all other warranties express or implied. All products returned for warranty service require a Return Product Authorization Number (RPA#). Contact Nortek Technical Services at 1-800-421-1587 for an RPA# and other important details. PRINTER’S INSTR UCTIONS: INSTR,INSTL,MDT -MOD - LINEAR P/N: 217947_Rev- AX1 - INK: BLA CK - MA TERIAL: 20 LB . MEAD BOND - SIZE: 11.000 ” X 8.500 ” - SCALE: 1-1 NOTE: TO AVOID CONSTANT BATTERY DRAIN, STORE TRANSMITTER WITH THE LANYARD INSERTED ACTIVATION LANYARD TO TRIGGER THE UNIT, FIRMLY PULL LANYARD TO SEPARATE IT FROM THE TRANSMITTER BELT/POCKET CLIP ACTIVATION INDICATOR ACTIVATION PUSHBUTTON BATTERY ACCESS DOOR ANTENNA WIRE RECEIVER SENSITIVITY ADJUSTMENT SENSITIVITY MORELESS RF ACTIVITY AND PROGRAMMING INDICATOR PROGRAMMING BUTTON POWER TERMINALS RELAY TERMINALS CASE SCREWS MOUNTING SCREWS SENSITIVITY ADJUSTMENT HOLE PLUG SCREW ANCHORS RECEIVER CASE REAR COVER WIRING ACCESS HOLE NOTE: RECEIVER IS PRE-PROGRAMMED DO NOT PRESS PROGRAMMING BUTTON POWER TERMINALS RELAY TERMINALS FROM 24 VOLT AC OR DC SOURCE (OBSERVE POLARITY IF USING DC POWER) CONNECT COMMON, AND EITHER NORMALLY OPEN OR NORMALLY CLOSED TERMINALS TO THE MONITORING DEVICE MOUNT CASE BACK WITH MOUNTING SCREWS CONNECT WIRES TO TERMINALS SNAP CASE TOGETHER RELAY RATING: 1 AMP @ 24 VOLTS AC/DC 1 2 3 SECURE CASE WITH CASE SCREWS 1 4 ACTIVATE THE TRANSMITTER FROM VARIOUS LOCATIONS IN THE INTENDED RECEPTION AREA WHEN FINISHED, SNAP PLUG INTO RECEIVER CASE HOLE (DON'T IF ANTENNA WIRE IS USING HOLE) 2 ADJUST THE RECEIVER SENSITIVITY TO LIMIT ITS MAXIMUM RANGE SENSITIVITY MORE RANGE LESS RANGE 3 FOR FURTHEST RANGE, EXTEND ANTENNA WIRE UP THROUGH ADJUSTMENT HOLE APPROXIMATE RANGE REDUCTION 1 TURN 2 TURNS 3 TURNS 4 TURNS 25% LESS RANGE 75% LESS RANGE 85% LESS RANGE 90% LESS RANGE 2032 REMOVE BATTERY ACCESS SCREW SWING BATTERY COMPARTMENT OPEN FLIP TRANSMITTER OVER REPLACE WITH TWO TYPE 2032 BATTERIES SIDE UP TEST T RANSMITT ER AFTER REPLACING BATTERIES! USA & Canada (800) 421-1587 & (800) 392-0123 (760) 438-7000 - Toll Free FAX (800) 468-1340 www.nortekcontrol.com 217947_Rev-AX1 CLL lortnoC & ytiruceS ketroN 0202 © thgirypoC FCC & IC Notice This device contains licence-exempt transmitter(s) / receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Dév…

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID:EF400206 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name  Block Diagram  Schematic Diagram  Operational Description  POFIT_Block  POFIT_SCH  POFIT_OPS The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application for180 days as outlined below: Exhibit Type File Name  Test Setup Photos  Internal Photos  External Photos  User Manual  Test Setup photo---DSC  INT PHOTO  External Photos  User Manual Sincerely, Signature: Name: Horsen Ma Date: 2020/05/27

Family models declaration letter. 2020-05-27 We Company: Nortek Security & Control LLC Address: 5919 Sea Otter Place Carlsbad, CA 92010 United States Product: MegaCode Series Digital Transmitter Model Name: MDT-MOD Family Model: MDT FCC ID: EF400206 all models have the same circuit and RF modules，The t op of the MDT is an ordinary key switch, The top of MDT-MOD is a magnetic switch Thanks Sincerely, Signature 2020-05-27 Name: Horsen Ma Title: Sr. Manager

Access Control | Security & Home Automation | Health & Wellness | Home Technology 1950 Camino Vida Roble Suite 150 Carlsbad CA 92008 800.421.1587 www.nortekcontrol.com 5/13/2020 Federal Communications Commission 445 12th Street, SW Washington, DC 20554 This is a letter of authorization to accept Horsen Ma of Nortek Security & Control LLC, to sign documentation on my behalf, make representations on my behalf, and to receive and exchange data in connection with FCC certification of all Nortek Security & Control LLC products on my behalf. If you have any questions or need additional information, please feel free to give me a call at (760) 438-7179 Sincerely, Josh Hansen Engineering Manager, Regulatory & Compliance

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2020/05/27 SUBJECT: FCC Application for FCC ID: EF400206 To Whom It May Concern: We, the undersigned, hereby authorize Alex Li NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park Sanwei Community, Xixiang Street, Baoan District Shenzhen China Tel: +86-0755-61156584 Email: [email protected] on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by NTEK Testing Technology Co., Ltd. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Signatory 2020-05-27 Horsen Ma Applicant: Nortek Security & Control LLC Address: 5919 Sea Otter Place,Suite 100, Carlsbad, California, 92010 United States

Date: May 27, 2020 FCC ID: EF400206 Model Number: MDT-MOD, MDT To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, Nortek Security & Control LLC, declare that this EUT (FCC ID: EF400206) will conduct FCC compliance testing, the SDOC part recognized test lab(Shenzhen NTEK Testing Technology Co., Ltd.( ShenZhen Lab.). 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen 518126 P.R. China) Please contact me if you have any question. Sincerely, (Signed) Name / Title: Horsen Ma/ Senior Manager, Hardware Engineering Company: Nortek Security & Control LLC Address: 5919 Sea Otter Place,Suite 100, Carlsbad, California, 92010 United States Phone: +86 755 2751 1888 ext 8106 Fax: Email: [email protected]

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 TX Ant Photo 3 Photo 4

Model: MDT-MOD Radiated Measurement Photos END OF REPORT
