EF400210Control Extender

Quick Install Guide EL-IO-200 Control Extender PRINTER’S INSTRUCTIONS: LITERATURE, QUICK INSTALLATION GUIDE, CONTROL EXTENDER, ELAN, EL-IO-200 - P/N: 10024524 Rev-CX1 - INK: 1-COLOR - BW - MATERIAL: 80 LB. TEXT GLOSS - SIZE: 4.125” X 5.75” - TOL. +/-.125" - SCALE: 1-1 - BINDING: SADDLE STITCH QUICK INSTALL GUIDEEL-IO-200 23 Warning: The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102, and users can obtain Canadian information on RF exposure and compliance from the Canadian Representative Product Solutions Group at Tel: (519) 763-4538. FEDER AL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause ha rmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or televisi on reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the e quipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/ T V technician for help. fonctionnement normal. Ce périphérique a également été évalué et démontré conforme aux limites d’expo- sition aux RF d’IC dans des conditions d’exposition à des appareils mobiles (antennes sont supérieures à 20 cm à partir du corps d’une personne). FCC and IC Registrations FCC ID: EF400210 IC: 1078A-00210 Important Safet y Instructions: 1. Read, understand and follow ALL safety and installation instructions included in this manual. Failure to follow the included documentation may damage the product and will void manufacturer’s warranty. 2. Follow ALL installation guidelines included with the product. Installation of the product in high humidity environments, in close proximity to heat sources and /or non-recommended locations will impede, interf ere and/or damage the intended operation of the product. 3. 4. and follow all Product Care instructions included with the product. 5. For a complete list of product servicing options, please follow instructions included in the product documentation and /or contact original manufacturer for details. FCC and IC Information: This Class B digital apparatus complies with Part 15 of the FCC rules and with Canadian ICES-003 and RSS-247. RESTRICTIONS IN THE 5 GHZ BAND: Within the 5.15 to 5.25 GHz band, UNII devices will be restricted to indoor operations . Operation is subject to the following t wo conditions: 1. This device may not cause interference and 2. This device must accept any interference, including interf erence that may cause undesired operation of the device. Cet appareil numérique de classe B est conforme aux normes canadiennes ICES-003 et RSS-247. RESTRICTIONS DANS LA BANDE DE 5 GHZ: Dans la bande de 5,15 à 5,25 GHz, les appareils UNII seront restreints aux opérations. Son fonctionnement est soumis aux deux conditi ons suivantes : (1) cet appareil ne doit pas causer d’interférence et (2) cet appareil doit accepter toute interférence, notamment les interférences qui peuvent affecter son fonctionnement. Warning: Changes or modications to this unit not expressly approved by the par ty responsible for compliance could void the user’s authority to operate the equipment. FCC and IC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the exemption from the routine evaluation limits in section 2.5 of RSS 102. 1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2. This equipment compl ies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a mini mum distance of 20 centimeters from user and bystanders. QUICK INSTALL GUIDEEL-IO-200 45 The EL-IO-200 Control Extender may be used as an extender to any gSC OR SC controller (refer to the integration note for integration instructions and requirements). Please check the ELAN Training Guide for EL-IO-200 control capabilities. The ELAN Training Guide contains valuable hardware and software reference documentation and is considered an important supplement to this document. Make sure you have the latest version by visiting the ELAN Dealer website at www.elancontrolsystems.com and follow the Dealer Resources link. Included in the box: • (1) EL-IO-200 Control Extender • (1) 5V DC Power Supply • (2) Male DB9 to female RJ45 adapter • (1) Female DB9 to female RJ45 adapter • (4) Phoenix style male connectors, (2) black for signal inputs, (2) green for relays Contents 1. Rear Panel Connections..............................6 2. Mounting .........................................7 3. RS-232 Serial Connections ...........................9 4. RS-485 Serial Connections ..........................10 5. IR Output Connections..............................10 6. Signal Input Connections ............................11 7. Relay Connections .................................11 8. LAN / PoE Connection ..............................12 9. Reset Button .....................................12 10. Power..........................................12 11. LED Status Indicator...............................12 12. Network Connection...............................13 13. Specifications....................................13 QUICK INSTALL G…

Text truncated - open the document above for the full version.

Access Control | Security & Home Automation | Health & Wellness | Home Technology 1950 Camino Vida Roble Suite 150 Carlsbad CA 92008 800.421.1587 www.nortekcontrol.com 5/13/2020 Federal Communications Commission 445 12th Street, SW Washington, DC 20554 This is a letter of authorization to accept Horsen Ma of Nortek Security & Control LLC, to sign documentation on my behalf, make representations on my behalf, and to receive and exchange data in connection with FCC certification of all Nortek Security & Control LLC products on my behalf. If you have any questions or need additional information, please feel free to give me a call at (760) 438-7179 Sincerely, Josh Hansen Engineering Manager, Regulatory & Compliance

Access Control | Security & Home Automation | Health & Wellness | Home Technology 5919 Sea Otter Place, Suite 100, Carlsbad CA 92010 800.421.1587 www.nortekcontrol.com Confidentiality Letter Date: 2021-01-05 Subject: Confidentiality Request for FCC ID: EF400210, IC: 1078A-00210 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term Permanent External Photos Short Term Permanent Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Part List/Tune-Up Procedure Short Term Permanent Schematics Short Term Permanent Test Setup Photos Short Term Permanent User’s Manual Nortek Security & Control LLC has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, Sr. Manager Hardware Engineering By: Horsen Ma (Signature/Title) (Print name)

ATTACHMENT 3 Photo Documentation Page 1 of 4 Report No.: 60420116 001 Product: Control Extender Type Designation: EL-I0-200 Figure 1. External view - 1 Figure 2. External view - 2 ATTACHMENT 3 Photo Documentation Page 2 of 4 Report No.: 60420116 001 Product: Control Extender Type Designation: EL-I0-200 Figure 3. Terminal view Figure 4. Internal view - 1

ATTACHMENT 3 Photo Documentation Page 2 of 4 Report No.: 60420116 001 Product: Control Extender Type Designation: EL-I0-200 Figure 3. Terminal view Figure 4. Internal view - 1 ATTACHMENT 3 Photo Documentation Page 3 of 4 Report No.: 60420116 001 Product: Control Extender Type Designation: EL-I0-200 Figure 5. Internal view - 2 Figure 6. Top view of PCB ATTACHMENT 3 Photo Documentation Page 4 of 4 Report No.: 60420116 001 Product: Control Extender Type Designation: EL-I0-200 Figure 7. Bottom view of PCB

1 Safety Human Exposure 1.1 Radio Frequency Exposure Compliance 1.1.1 Electromagnetic Fields RESULT: Pass Test Specification Test standard : CFR47 FCC Part 2: Section 2.1091 CFR47 FCC Part 1: Section 1.1310 FCC KDB Publication 447498 v06, section 7 RSS-102 Issue 5 March 2015, section 2.5.2  FCC requirements FCC requirement: Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 20cm normally can be maintained between the user and the device. MPE Calculation Method according to KDB 447498 v06 Power Density: S (mW/cm 2 ) = PG/4πR 2 or EIRP/4πR 2 Where: S = power density (mW/cm 2 ) P = power input to the antenna (mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (cm) From the peak RF output power, the minimum mobile separation distance, d=20 cm, as well as the antenna gain (Max. 7dBi), the RF power density can be calculated as below: S (mW/cm 2 ) = PG/4πR 2 a) EUT RF Exposure Evaluation operations, Worst Case mode Test Mode Measured conducted Power (dBm) Antenna Gain (dBi) Measured e.i.r.p (dBm) S (mW/cm 2 ) = PG/4πR 2 Limit (mW/cm 2 ) 5GHz band Wi-Fi 15.61 4.18 19.79 0.019 1.0 2.4GHz band Wi-Fi 24.00 4.18 28.18 0.131 Note: simultaneous mode not supported.  IC requirements: The EUT shall comply with the requirement of RSS-102 section 2.5.2. Exemption from Routine Evaluation Limits – RF Exposure Evaluation RF exposure evaluation is required if the separation distance between the user and/or bystander and the device’s radiating element is greater than 20 cm, except when the device operates as follows: at or above 300 MHz and below 6 GHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 1.31 x 10 -2 ƒ 0.6834 W (adjusted for tune-up tolerance), where ƒ is in MHz;  RF exposure evaluation exempted power for 2.4GHz Bands: 2.68 W  RF exposure evaluation exempted power for NII bands: 4.52 W a) EUT RF Exposure Evaluation standalone operations, Worst Case mode Test Mode Measured conducted Power (dBm) Antenna Gain (dBi) Measured e.i.r.p Limit (W) (dBm) (W) 2.4GHz band Wi-Fi 15.61 4.18 19.79 0.095 2.68 5GHz bands 24.00 4.18 28.18 0.658 4.52 Note: simultaneous mode not supported. The e.i.r.p. less than the RF exposure evaluation exempted power. So RF exposure evaluation is not required. “RF Radiation Exposure Statement Caution: This Transmitter must be installed to provide a separation distance of at least 20 cm from all persons.”

Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 1 of 90 Appendix B: Test Results of Wi-Fi 802.11 b/g/n APPENDIX B: TEST RESULTS OF WI-FI 802.11 B/G/N ..................................................................................................... 1 APPENDIX B.1: TEST RESULTS OF CONDUCTED POWER SPECTRAL DENSITY ..................................................................................... 2 Wi-Fi 802.11 b mode, 1 Mbps ...................................................................................................................................... 2 Wi-Fi 802.11 g mode, 6 Mbps ...................................................................................................................................... 3 Wi-Fi 802.11 n(HT20) mode, MCS0 .............................................................................................................................. 5 APPENDIX B.2: TEST RESULTS OF 6DB BANDWIDTH .................................................................................................................... 7 Wi-Fi 802.11 b mode, 1 Mbps ...................................................................................................................................... 7 Wi-Fi 802.11 g mode, 6 Mbps .................................................................................................................................... 10 Wi-Fi 802.11 n(HT20) mode, MCS0 ............................................................................................................................ 13 APPENDIX B.3: TEST RESULTS OF 99% BANDWIDTH ................................................................................................................. 16 Wi-Fi 802.11 b mode, 1 Mbps .................................................................................................................................... 16 Wi-Fi 802.11 g mode, 6 Mbps .................................................................................................................................... 19 Wi-Fi 802.11 n(HT20) mode, MCS0 ............................................................................................................................ 22 APPENDIX B.4: TEST RESULTS OF CONDUCTED SPURIOUS EMISSIONS MEASURED IN 100 KHZ BANDWIDTH ....................................... 25 Wi-Fi 802.11 b mode, 1 Mbps .................................................................................................................................... 25 Wi-Fi 802.11 g mode, 6 Mbps .................................................................................................................................... 28 Wi-Fi 802.11 n(HT20) mode, MCS0 ............................................................................................................................ 31 Wi-Fi 802.11 b mode, Band Edge ............................................................................................................................... 34 Wi-Fi 802.11 g mode, Band Edge ............................................................................................................................... 35 Wi-Fi 802.11 n(HT20) mode, Band Edge .................................................................................................................... 36 APPENDIX B.5: TEST RESULTS OF RADIATED SPURIOUS EMISSIONS ............................................................................................. 37 30MHz - 1GHz (Worst case) ....................................................................................................................................... 37 1GHz - 18GHz .............................................................................................................................................................. 41 APPENDIX B.6: TEST RESULTS OF RADIATED EMISSIONS IN RESTRICTED BANDS ............................................................................. 77 Wi-Fi 802.11 b mode, 1 Mbps .................................................................................................................................... 77 Wi-Fi 802.11 g mode, 6 Mbps .................................................................................................................................... 81 Wi-Fi 802.11 n(HT20) mode, MCS0 ............................................................................................................................ 85 APPENDIX B.7: TEST RESULTS OF CONDUCTED EMISSION ON AC MAINS ...................................................................................... 89 Wi-Fi 802.11 b/g/n connecting mode ......................................................................................................................... 89 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 2 of 90 Appendix B.1: Test Results of Conducted Power Spectral Density Wi-Fi 802.11 b mode, 1 Mbps Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 3 of 90 Wi-Fi 802.11 g mode, 6 Mbps Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 4 of 90 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 5 of 90 Wi-Fi 802.11 n(HT20) mode, MCS0 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 6 of 90 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 7 of 90 Appendix B.2: Test Results of 6dB Bandwidth Wi-Fi 802.11 b mode, 1 Mbps Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 8 of 90 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 9 of 90 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 10 of 90 Wi-Fi 802.11 g mode, 6 Mbps Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 11 of 90 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 12 of 90 Prüfbericht - Produkte Test Report - Products Appendix B CN207CD…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 21 of 90 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 22 of 90 Wi-Fi 802.11 n(HT20) mode, MCS0 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 23 of 90 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 24 of 90 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 25 of 90 Appendix B.4: Test Results of Conducted Spurious Emissions Measured in 100 kHz Bandwidth Wi-Fi 802.11 b mode, 1 Mbps Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 26 of 90 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 27 of 90 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 28 of 90 Wi-Fi 802.11 g mode, 6 Mbps Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 29 of 90 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 30 of 90 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 31 of 90 Wi-Fi 802.11 n(HT20) mode, MCS0 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 32 of 90 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 33 of 90 Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 34 of 90 Wi-Fi 802.11 b mode, Band Edge Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 35 of 90 Wi-Fi 802.11 g mode, Band Edge Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 36 of 90 Wi-Fi 802.11 n(HT20) mode, Band Edge Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 37 of 90 Note: Testing was carried out within frequency range 9kHz to the tenth harmonics. The measurement results below 30MHz and 18GHz - 26.5GHz were greater than 20dB below the limit, so only the radiated spurious emissions from 30MHz to 18GHz were reported. Appendix B.5: Test Results of Radiated Spurious Emissions 30MHz - 1GHz (Worst case) Wi-Fi 802.11 b mode, 1 Mbps EUT Information EUT Name: Control Extender Model: EL-IO-200 Test Mode: Wi-Fi 2.4G 11b_Low Channel Test Voltage:: 120V/60Hz Remark: Temp 23 Humi:49% Test Standard: FCC 15.247 Tested By: Kei Zhang Reviewed By: Terry Yin Level in dB 礦 /m Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Average (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 80.779500 28.61 --- 40.00 11.39 100.0 H 281.0 -23.3 119.482500 27.63 --- 43.50 15.87 100.0 H 6.0 -20.7 204.745500 33.50 --- 43.50 10.00 100.0 H 359.0 -18.9 222.593500 33.35 --- 46.00 12.65 100.0 H 359.0 -18.4 Final_Result Frequency (MHz) QuasiPeak (dBμV/m) MaxPeak (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) --- --- --- --- --- --- --- --- Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 38 of 90 EUT Information EUT Name: Control Extender Model: EL-IO-200 Test Mode: Wi-Fi 2.4G 11b_Low Channel Test Voltage:: 120V/60Hz Remark: Temp 23 Humi:49% Test Standard: FCC 15.247 Tested By: Kei Zhang Reviewed By: Terry Yin Level in dB 礦 /m Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Average (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 50.612500 23.71 --- 40.00 16.29 100.0 V 85.0 -18.3 80.488500 31.31 --- 40.00 8.69 100.0 V 243.0 -23.4 104.981000 27.42 --- 43.50 16.08 100.0 V 66.0 -18.7 205.230500 27.12 --- 43.50 16.38 100.0 V 66.0 -18.9 Final_Result Frequency (MHz) QuasiPeak (dBμV/m) MaxPeak (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) --- --- --- --- --- --- --- --- Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 39 of 90 EUT Information EUT Name: Control Extender Model: EL-IO-200 Test Mode: Wi-Fi 2.4G 11b_High Channel Test Voltage:: 120V/60Hz Remark: Temp 23 Humi:49% Test Standard: FCC 15.247 Tested By: Kei Zhang Reviewed By: Terry Yin Level in dB 礦 /m Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Average (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 67.296500 30.49 --- 40.00 9.51 100.0 H 281.0 -20.9 134.129500 28.33 --- 43.50 15.17 100.0 H 290.0 -22.0 204.842500 30.76 --- 43.50 12.74 100.0 H 245.0 -18.9 224.145500 28.84 --- 46.00 17.16 100.0 H 2.0 -18.3 Final_Result Frequency (MHz) QuasiPeak (dBμV/m) MaxPeak (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) --- --- --- --- --- --- --- --- Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 40 of 90 EUT Information EUT Name: Control Extender Model: EL-IO-200 Test Mode: Wi-Fi 2.4G 11b_High Channel Test Voltage:: 120V/60Hz Remark: Temp 23 Humi:49% Test Standard: FCC 15.247 Tested By: Kei Zhang Reviewed By: Terry Yin Level in dB 礦 /m Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Average (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 43.046500 35.00 --- 40.00 5.00 100.0 V 25.0 -19.3 66.860000 29.59 --- 40.00 10.41 100.0 V 288.0 -20.7 104.350500 29.98 --- 43.50 13.52 100.0 V 288.0 -18.8 204.212000 28.25 --- 43.50 15.26 100.0 V 25.0 -18.9 Final_Result Frequency (MHz) QuasiPeak (dBμV/m) MaxPeak (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) --- --- --- --- --- --- --- --- Prüfbericht - Produkte Test Report - Products Appendix B CN207CDN 001 Page 41 of 90 1GHz - 18GHz Note: The highest waveform in the figure is Wi-Fi Fundamental. Wi-Fi 802.11 b mode, 1 Mbps EUT Information EUT Name: Control Extender Model: EL-IO-200 Test Mode: Wi-Fi 2.4G 11b_Low Channel Test Voltage:: 120V/60Hz Remark: Temp 23 Humi:49% Test Standard: FCC 15.247 Tested By: Kei Zhang Reviewed By: Terry Yin Level in dB 礦 /m Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Average (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 3616.937500 --- 43.61 54.00 10.39 100.0 H 232.0 9.4 3618.850000 52.53 --- 74.00 21.47 100.0 H 243.0 9.4 4824.…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: CN207CDN 001 Auftrags-Nr.: Order no.: 168285296 Seite 1 von 21 Page 1 of 21 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2020-10-10 Auftraggeber: Client: Nortek Security&Control LLC 5919 Sea Otter Place,Suite 100,Carlsbad,California, United States Prüfgegenstand: Test item: Control Extender Bezeichnung / Typ-Nr.: Identification / Type no.: EL-IO-200 (Trademark: ELAN) Auftrags-Inhalt: Order content: FCC & IC Prüfgrundlage: Test specification: CFR47 FCC Part 15: Subpart C Section 15.247 CFR47 FCC Part 15: Subpart C Section 15.207 CFR47 FCC Part 15: Subpart C Section 15.209 CFR47 FCC Part 15: Subpart B Section 15.107 CFR47 FCC Part 15: Subpart B Section 15.109 CFR47 FCC Part 2: Section 2.1091 RSS-247 Issue 2 February 2017 RSS-Gen Issue 5 April 2018 ICES-003 Issue 6 January 2016 RSS-102 Issue 5 March 2015 Wareneingangsdatum: Date of sample receipt: 2020-11-06 Please refer to Photo Document Prüfmuster-Nr.: Test sample no: A002938509-002~005, 010,011,018,019 Prüfzeitraum: Testing period: 2020-11-09 – 2020-12-17 Ort der Prüfung: Place of testing: TÜV Rheinland (Shenzhen) Co., Ltd. Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shenzhen) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: X Signed by: Bell Hu genehmigt von: authorized by: X Signed by: Winnie Hou Datum: Date: 2021-01-04 Ausstellungsdatum: Issue date: 2021-01-04 Stellung / Position: Project Manager Stellung / Position: Technical Certifier Sonstiges / Other: FCC ID: EF400210 IC: 1078A-00210 HVIN: EL-IO-200 Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhaft P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet * Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specification(s) F(ail) = failed a.m. test specification(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark. TÜV Rheinland (Shenzhen) Co., Ltd. 1601 R&D Room, 1602-1604, 17-18F, Building 7 Site C, Vanke Cloud City Phase I, Xingke First Street, Xili Street, Xili Community, Nanshan District, Shenzhen 518052, P.R. China Mail: [email protected] · Web: www.tuv.com Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No. CN207CDN 001 Seite 2 von 21 Page 2 of 21 Test Summary 5.1.1 ANTENNA REQUIREMENT RESULT: Pass 5.1.2 MAXIMUM PEAK CONDUCTED OUTPUT POWER RESULT: Pass 5.1.3 CONDUCTED POWER SPECTRAL DENSITY RESULT: Pass 5.1.4 6DB BANDWIDTH RESULT: Pass 5.1.5 99% BANDWIDTH RESULT: Pass 5.1.6 CONDUCTED SPURIOUS EMISSIONS MEASURED IN 100 KHZ BANDWIDTH RESULT: Pass 5.1.7 RADIATED SPURIOUS EMISSION RESULT: Pass 5.1.8 RADIATED EMISSION RESULT: Pass 5.1.9 CONDUCTED EMISSION ON AC MAINS RESULT: Pass Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No. CN207CDN 001 Seite 3 von 21 Page 3 of 21 Contents 1 GENERAL REMARKS ........................................................................................................................... 4 1.1 COMPLEMENTARY MATERIALS ............................................................................................................ 4 2 TEST SITES ........................................................................................................................................ 4 2.1 TEST FACILITIES ................................................................................................................................. 4 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS................................................................................. 5 2.3 TRACEABILITY .................................................................................................................................... 6 2.4 CALIBRATION ..................................................................................................................................... 6 2.5 MEASUREMENT UNCERTAINTY............................................................................................................. 6 2.6 LOCATION OF ORIGINAL DATA ............................................................................................................. 6 2.7 STATUS OF FACILITY USED FOR TESTING ............................................................................................. 6 3 GENERAL PRODUCT INFORMATION ...................................................................................................... 7 3.1 PRODUCT FUNCTION AND INTENDED USE ............................................................................................. 7 3.2 RATINGS AND SYSTEM DETAILS .......................................................................................................... 7 3.3 INDEPENDENT OPERATION MODES .................................…
