EJE-WB0088FUJITSU LIFEBOOK T SERIES T904 WITH INTEL WP2

Fujitsu Client Computing Limited (FCCL)

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Dec 03, 2013
Application Purpose: Original Equipment
Date of Application: Dec 03, 2013
Equipment Note: FUJITSU LIFEBOOK T SERIES T904 WITH INTEL WP2
Frequency Range: 2402.00000000 - 2480.00000000
Company: Fujitsu Client Computing Limited (FCCL)
Country: Japan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

 User’s Guide Learn how to use your Fujitsu LIFEBOOK T9 04 Tablet PC  Guide d’utilisation Découvrez comment utiliser votre ordinateur portable Fujitsu LIFEBOOK T90 4 1 - User’s GuideLearn how to use your Fujitsu LIFEBOOK T90 4 Tablet PC 1 Copyright and Trademark Information Fujitsu America, Inc. has made every effort to ensure the accuracy and completeness of this document; however, as ongoing devel opment efforts are continually improving the capabilities of our products, we cannot guarantee the accuracy of the contents of this document. We d isclaim liability for errors, omissions, or future changes.Fujitsu, the Fujitsu logo, and LIFEBOOK are registered trademarks of Fujitsu Limited. Intel, Intel Core, and Centrino are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.Atheros is a registered trademark of Atheros Communications, Inc.Bluetooth is a trademark of Bluetooth SIG, Inc., USA.OmniPass is a trademark of Softex, Inc.PowerDirector, PowerDVD, MakeDisc, and Yo uCam are trademarks of CyberLink Corp. Adobe and Adobe Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. Norton and Norton Internet Security are trademarks or registered trademarks of Symantec Corporation in the United States and ot her countries. Manufactured under license from DTS Licensing Limited. DTS, the Symbol, and DTS and the Symbol together are registered trademar ks, and DTS Boost is a trademark of DTS (BVI) Li mited (in Hong Kong and China) and DTS, In c. (outside of Hong Kong and China). © DT S, Inc. All Rights Reserved. All other trademarks mentioned herein are the property of their respective owners. © Copyright 2012 Fujitsu America, Inc. All rights reserved. No part of this publication may be copied, reproduced, or transl ated, without prior written consent of Fujitsu. No part of this publication may be stored or transmitted in any electronic form without th e written consent of Fujitsu. B5FK-0871-01ENZ0-00 2 W ARNING : H ANDLING THE CORD ON THIS PRODUCT WILL EXPOSE YOU TO LEAD , A CHEMICAL KNOWN TO THE S TATE OF C ALIFORNIA TO CAUSE BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM . W ASH HANDS AFTER HANDLING . U SER G UIDE FOR W IRELESS B ROADBAND C ONNECTION I F YOU HAVE THE OPTIONAL W IRELESS WAN (WWAN) DEVICE INSTALLED IN YOUR T ABLET PC, THE WWAN U SER ’ S G UIDE IS LOCATED AT : http://solutions.us.fujitsu.com/www/content/support/mobile/support_notices P LEASE CLICK “3G M INI -C ARD G OBI 3000 R EGULATORY AND S AFETY I NFORMATION ” TO OPEN THE FULL USER GUIDE CONTAINING WARNINGS AND PRECAUTIONS ASSOCIATED WITH RF SAFETY WHEN USING THE WWAN DEVICE . DECLARATION OF CONFORMITY according to FCC Part 15 Responsible Party Name: F ujitsu America, Inc. Address: 1250 E. Arques Avenue Sunnyvale, CA 94085 Telephone: (408) 746-6000 Declares that product: Base Model Configuration: LIFEBOOK T90 4 Tablet PC Complies with Part 15 of the FCC Rules. This device complies with Part 15 of the FCC rules. Operations are subject to th e following two conditions: (1) This device may not cause harmful interference, (2) This device must accept any interference received, including interferen ce that may cause undesired operation. 3 IMPORTANT SAFETY INSTRUCTIONS This unit requires an AC adapter to operate. Use only UL Listed I.T.E. Adapters with an output rating of 19 VDC, with a current of 4.22 A (80 W). When using your Tablet PC equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: • The bottom of this Tablet PC computer can become hot when used for long periods of time. When using this Tablet PC, take cautio n to limit long term or continuous use while resting it on exposed skin, such as the lap. • Do not use this product near water for exam ple, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement or nea r a swimming pool. • Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special disposal instructions. • CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions on the next page. SAVE THESE INSTRUCTIONS For Authorized Repair Technicians Only D ANGER OF EXPLOSION IF L ITHIUM ( CLOCK ) BATTERY IS INCORRECTLY REPLACED . R EPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER . D ISPOSE OF USED BATTERIES ACCORDING TO THE MANUFACTURER ’ S INSTRUCTION . F OR CONTINUED PROTECTION AGAINST RISK OF FIRE , REPLACE ONLY WITH THE SAME TYPE AND RATING FUSE . + AC adapter output polarity: 4 Recycling your battery Over time, the batteries that run your mobi le computer will begin to hold a charge for a shorter amount of time; this is a natu ral occurrence for all batteries. When this occurs, you may want to replace the battery with a fr esh one*. If you replace it, it is important that you dispose of the old battery properly because batteries contain materials that could cause environmental damage if disposed of improperly. Fujitsu is very concerned with environmental protection, and has enlisted the services of the Rechargeable Battery Recycling Co rporation (RBRC)**, a non-profit public service organization dedicated to protecting our environment by recycling old batteries at no cos t to you. RBRC has drop-off points at tens of thousands of locations thro ughout the United States and Canada. To find the location neares t you, go to www.RBRC.org or call 1-800-822-8837. If there are no convenient RBRC locations near you, you can also go to the EIA Consumer Education Initiative website ( http://EIAE.org/ ) and search for a convenient disposal location.Remembe…

Text truncated - open the document above for the full version.

Users Manual

4 Recyclage de la batterie Avec le temps, l’autonomie des batteries qui alimentent votre ordinateur portable finira par diminuer ; c’est un phénomène naturel pour toutes les batteries. Lorsque vous remarquerez cela, songez à installer une batterie neuve*. Si vous remplacez votre ancienne batterie, il est important que vous la jetiez comme il convient car, dans le cas contraire, les matériaux qu’elle contient risquent de nuire à l’environnement. Chez Fujitsu, nous portons une attention particulière à la protection de l’environnement et nous collaborons donc avec la Rechargeable Battery Recycle Corporation (RBRC**), une organisation de service publique à but non lucratif qui s’engage dans la protection de l’environnement par le recyclage des batteries usagées sans coût pour vous. La RBRC dispose de dizaines de milliers de points de collecte aux États-Unis et au Canada. Pour trouver le lieu de collecte le plus proche de chez vous, visitez www.RBRC.org ou appelez au 1-800-822-8837. Si aucun des lieux proposés par la RBRC ne vous convient, vous pouvez en trouver un en visitant le site de la Consumer Education Initiative (Initiative pour l’éducation des consommateurs) de l’EIA à l’adresse http://EIAE.org/. Rappelez-vous que la protection de l’environnement est l’affaire de tous, vous devriez donc faire tout votre possible afin d’y contribuer, pour la génération actuelle et les générations suivantes. * Pour commander une nouvelle batterie compatible avec votre ordinateur portable Fujitsu, allez sur www.shopfujitsu.com (États-Unis) ou www.fujitsu.ca/ products/notebooks (Canada). ** La RBRC est une organisation indépendante dont Fujitsu finance une partie des activités de recyclage ; la RBRC n’est en aucune façon affiliée à Fujitsu. 1 Table des matières À propos de ce guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Conventions utilisées dans ce guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Coordonnées pour contacter Fujitsu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Chapitre 1Présentation de votre ordinateur LIFEBOOK Aperçu général . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Emplacement des commandes et des connecteurs . . . . . . . . . . . . . . . . . . 12 Composants supérieurs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Composants sur le côté gauche de l’ordinateur . . . . . . . . . . . . . . . . . . . . 17 Composants sur le côté droit de l’ordinateur . . . . . . . . . . . . . . . . . . . . . . 19 Composants de la face arrière . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Composants sous l’ordinateur. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Tableau de voyants d’état . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Voyant d’alimentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Voyants de charge en cours . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Voyant de niveau de charge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Écran . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Ouverture de l’écran . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Utilisation du système comme une tablette . . . . . . . . . . . . . . . . . . . . . . 28 Modification de la fonction de pivotement automatique . . . . . . . . . . . . 29 Réglage de la luminosité de l’écran . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Activation/Désactivation du capteur de lumière ambiante . . . . . . . . . . . 31 2 - Clavier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Utilisation du clavier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Pavé tactile/numériseur actif/écran tactile . . . . . . . . . . . . . . . . . . . . . . . . . 36 Utilisation du pavé Touchpad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Écran de numériseur actif . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Utilisation de l’écran tactile capacitif . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Parcourir avec la commande gestuelle . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Fixation du cordon du stylet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 Réglage du volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 Réglage du volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 Périphériques de baie modulaire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 Retrait et installation de périphériques modulaires . . . . . . . . . . . . . . . . 47 Boutons Sécurité/PC tablette/Windows du LIFEBOOK . . . . . . . . . . . . . . . . 49 Fonctions des boutons de sécurité . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 Fonctions des boutons de post-identification . . . . . . . . . . . . . . . . . . . . . 51 Modification des fonctions des boutons PC Tablette . . . . . . . . . . . . . . . . 52 Configuration du tableau de sécurité LIFEBOOK . . . . . . . . . . . . . . . . . . . 53 Mots de passe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Utilisation de votre tableau de sécurité LIFEBOOK . . . . . . . . . . . . . . . . . 55 Mises en garde . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 Désinstallation/réinstallation de l’application Tableau de sécurité . . . . 56 3 - Chapitre 2Première mise en marche de votre ordinateur portable LIFEBOOK Sources d’alimentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

Cover Letter(s)

EMC Technologies Pty Ltd, 176 Harrick VIC 3043 Australia Ph: +613 9365 1000 Fax: +613 9331 7455 www.emctech.com.au EMC Technologies Pty Ltd ABN 82 057 105 549 176 Harrick Road, Keilor Park Victoria Australia 3042 Ph: + 613 9365 1000 Fax: + 613 9331 7455 email: [email protected] To: Federal Communications Commission and Industry Canada Attention: Certification Manager No. of pages: 1 From: Donna Lennon Date: 26 th November 2013 EMC Ref: M1 31103_FCC_T904 with 7260HMW AN Subject: FCC & IC APPROVAL – FCC ID: EJE-WB0088 (IC: 337J-WB0088) Please receive FCC/IC applications for review. The EUT is a LIFEBOOK T Series convertible notebook/tablet PC , Model: T734 / TH734 with Intel Centrino Advanced-N 7260 incorporates a factory installed radio module Intel Wilkins Peak 2 802.11a/b/g/n 2x2), Model: 7260H MW AN. The Intel’s Wilkins Peak2 2x2 WLAN and Bluetooth combo module was originally certified by INTEL as a modular approval under FCC ID: PD97260H (Canada ID: 1000M-7260H). The Bluetooth maximum power is very low (6dBm including tune-up). It can only transmit via Antenna B(2) and is located at a distance of 152mm from other transmitting antennas. In accordance with Section 4.3.2 of KDB 447498 D01 the Bluetooth did not require SAR testing as a stand-alone transmitter. The intention of this application is to FCC/IC certify Fujitsu LifeBook T904 incorporating modular certified Intel module 7260HMW AN. The antenna used in T904 is of same type and lower gain than that was used in Intel’s original modular testing. All required documents, SAR and Radio test reports are submitted with this composite application for FCC ID: EJE-WB0088 and IC 337J-WB0088. EMC Technologies Pty Ltd is acting as agent for Fujitsu Ltd during this product approval. Regards ______________ Donna Lennon Report Secretary EMC Technologies Pty Ltd

Cover Letter(s)

Intel Corporation 100 Center Point Circle Columbia, SC 29210 March 4, 2013 Federal Communications Commission 7435 Oakland Mills Road Columbia, Maryland 21046 USA Subject: Model 7260HMW Wireless LAN mini-PCIe Card FCC ID’s: PD97260H and PD967260HU Gentlemen: Please be advised that the Model 7260HMW 802.11a/b/g/n/ac + BT Wireless LAN mini- PCIe card is manufactured for the global market but when marketed in the U.S. under FCC ID’s PD97260H and PD97260HU the non-volatile memory (NVM) will be programmed at the factory to only actively scan and operate on these specific channels during normal WLAN operation. During Wi-Fi Direct mode the device may act as a group owner (GO) to establish a peer-to-peer (P2P) network including conditions when no master device is present on these specific channels. Channels 1-11, 2412-2462MHz 802.11b mode Channels 1-11, 2412-2462MHz 802.11g mode Channels 1-11, 2412-2462MHz 802.11n mode (20MHz channel) Channels 3-9, 2422-2452MHz 802.11n mode (40MHz channel) The device will be programmed at the factory to passively scan on the following dynamic frequency selection (DFS) channels and will only listen for a master device and cannot send a probe request to initiate communication on these DFS channels. Client software and drivers will never enable the device to act as a master or GO for operation in DFS frequency bands and therefore ad-hoc mode is always disabled on these passive scan DFS channels. Channels 52-64, 5260-5320MHz 802.11a mode Channels 52-64, 5260-5320MHz 802.11n mode (20 MHz channel) Channels 52-64, 5260-5320MHz 802.11ac mode (20 MHz channel) Channels 54-62, 5270-5310MHz 802.11n mode (40MHz channel) Channels 54-62, 5270-5310MHz 802.11ac mode (40MHz channel) Channel 58, 5290MHz 802.11ac mode (80MHz channel) Channels 100-140, 5500-5700MHz 802.11a mode Channels 100-140, 5500-5700MHz 802.11n mode (20 MHz channel) Channels 100-144, 5500-5720MHz 802.11ac mode (20 MHz channel) Channels 102-134, 5510-5670MHz 802.11n mode (40MHz channel) Channels 102-142, 5510-5710MHz 802.11ac mode (40MHz channel) Channels 106-138, 5540-5690MHz 802.11ac mode (80MHz channel) Intel Corporation 100 Center Point Circle Columbia, SC 29210 This device meets the requirements of FCC Part 15.202 and accordingly will be programmed at the factory to passively scan on the following non-DFS channels and will only listen for a master device and cannot send a probe request to initiate communication during normal WLAN operation. When operating in Wi-Fi Direct mode on these non-DFS channels, it may operate as a P2P client device or GO to establish a P2P network if, and only if, a master device is present and network communication is maintained between a master device and the GO. Channels 12 &13, 2467 & 2472MHz 802.11b mode Channels 12 &13, 2467 & 2472MHz 802.11g mode Channels 12 &13, 2467 & 2472MHz 802.11n mode (20MHz channel) Channels 10 &11, 2457 & 2462MHz 802.11n mode (40MHz channel) Channels 36-48, 5180-5240MHz 802.11a mode Channels 36-48, 5180-5240MHz 802.11n mode (20 MHz channel) Channels 36-48, 5180-5240MHz 802.11ac mode (20 MHz channel) Channels 38-46, 5190-5230MHz 802.11n mode (40MHz channel) Channels 38-46, 5190-5230MHz 802.11ac mode (40MHz channel) Channel 42, 5210MHz 802.11ac mode (80MHz channel) Channels 149-165, 5745-5825MHz 802.11a mode Channels 149-165, 5745-5825MHz 802.11n mode (20 MHz channel) Channels 149-165, 5745-5825MHz 802.11ac mode (20 MHz channel) Channels151-159, 5755-5795MHz 802.11n mode (40MHz channel) Channels151-159, 5755-5795MHz 802.11ac mode (40MHz channel) Channel 155, 5775MHz 802.11ac mode (80MHz channel) This information when programmed into the NVM will not be accessible and cannot be changed by the end user. The transmitter is approved as a non-software defined radio and OEMs and third party system integrators do not have the ability through software to allow configuration controls that would permit the device to operate outside the grant conditions per FCC KDB 594280. Sincerely, Steven C. Hackett Wireless Regulatory Engineer Intel Corporation – Mobile Wireless Group

Cover Letter(s)

Intel Corporation 100 Center Point Circle Columbia, SC 29210 Intel 7260HMW Model Number Attestation Model 7260HMW FCC ID: PD97260H and PD97260HU IC: 1000M-7260H This letter will attest that this device approved under the FCC and IC ID’s above includes the family sub-models listed below and that all sub-models are manufactured electrically identical with no differences in populated components or PCB layout design. All model differences are strictly within programmed firmware. All firmware programming is performed at the factory prior to device shipment and cannot be modified or altered by OEMs, users or any third party. All testing results provided within this filing are applicable to all sub-models. Model Number Supported Modes 7260HMW 802.11a/b/g/n/ac + Bluetooth 7260HMW AN 802.11a/b/g/n + Bluetooth 7260HMW NB 802.11a/b/g/n, no Bluetooth 7260HMW BN 802.11/b/g/n + Bluetooth

Cover Letter(s)

Fujitsu Limited 1- 1, Kamikodanaka 4-chome, Nakahara-ku, Kawasaki 211-8588, Japan Tel: +81-44-754-3885 ; Fax: +81-44-754-3769 Date: November 25, 2013 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: This device with FCC ID: EJE-WB0088 integrates a WLAN/BT module 7260HMW Brand Name FCC ID Intel PD97260H No hardware design changes are made on the module, and the software has not been changed to increase the RF output power of the modules. Pursuant to KDB 996369 D01v01r03, the original modular reports (report number: 38067RRF.001/ 38067RRF.002A1/ 38067RRF.003A1) are submitted to represent the compliance regarding Part15C/Part15E conducted RF testing items of the host device. The 15C/Part15E radiated RF testing items are tested on this host device, and the test reports are submitted additionally. Should you have any comments or questions, please feel free to contact me. Sincerely, Tsuyoshi Uchihara [email protected]

Cover Letter(s)

Confidentiality Request regarding application for certification of FCC ID: EJE-WB0088 and IC: 337J-WB0088 Pursuant to FCC DA 04-1705, this application includes a request for short term confidentiality for the following exhibits: SAR Photos CONF SAR 2.4 Appendix A TstSam Photos SAR Photos CONF SAR 5.6 Appendix A TstSam Photos External Photos CONF Appendix B1 ExtPho Test Setup Photos CONF Appendix B2 TSup Location Photos CONF Appendix B3 LocPho Internal Photos CONF Appendix B4 IntPho Operational Description CONF Appendix C1 OpDes WLAN Operational Description CONF Appendix C2 OpDes BT Block Diagram CONF Appendix D BlkDia Schematics CONF Appendix E Schem Operational Description CONF Appendix G TunPro

Cover Letter(s)

Fujitsu Limited 1- 1, Kamikodanaka 4-chome, Nakahara-ku, Kawasaki 211-8588, Japan Tel: +81-44-754-3885 ; Fax: +81-44-754-3769 Date: November 25, 2013 Power of Attorney To whom it may concern, Please be notified that I, Tsuyoshi Uchihara, have designated Chris Zombolas in EMC Technologies Pty Ltd as the person being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Chris Zombolas in EMC Technologies Pty Ltd on the matters of relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002 (b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This authorization is limited to the product of as following: FCC ID: EJE-WB0088 If you have any acknowledgement and response, please send it to EMC Technologies Pty Ltd directly. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely yours, Tsuyoshi Uchihara [email protected]

External Photos

Internal Photos

Parts List/Tune Up Info

RF Exposure Info

FCC ID: EJE-WB0088 (IC: 337J-WB0088) ______________________________________________________________________ EMC Technologies Pty. Ltd., 176 Harrick Road, Keilor Park, VIC, 3042, Australia. Phone: +61 3 9365 1000 Fax: +61 3 9331 7455 www.emctech.com.au RF EXPOSURE INFORMATION RADIO FREQUENCY EXPOSURE (HAZARD) INFORMATION Testing was performed in accordance with the requirements of FCC Part 15.247(i) and FCC Part 15.407(f). Spread spectrum transmitters operating in the 2400 - 2483.5 MHz & 5725 – 5850 MHz (15.247) and 5.15 – 5.35 GHz & 5.47 – 5.725 GHz (15.407) bands are required to be operated in a manner that ensures that the public is not exposed to RF energy levels in accordance with CFR 47, Section 1.1307(b)(1). In accordance with this section and also section 2.1093 this device has been defined as a portable device. Intel 7260HMW WLAN module was installed in the LIFEBOOK T Series, Model: T904 SAR testing was performed in accordance with OET Bulletin 65 and reported under EMC Technologies reports M131003_FCC_7260HMW_SAR_2.4 (2.4 GHz) and M131103_FCC_7260HMW_SAR _5.6 (5.18 – 5.825 GHz). SAR values of 0.757 mW/g (5GHz) and 0.355 mW/g (2.4GHz) were measured which complied with the FCC human exposure requirements of 47 CFR 2.1093 (d). The Intel’s Wilkins Peak2 2x2 WLAN and Bluetooth combo module incorporates a Bluetooth transmitter.. The Bluetooth maximum power is very low (6dBm including tune-up). It can only transmit via Antenna B(2) and is located at a distance of 152mm from other transmitting antennas. In accordance with Section 4.3.2 of KDB 447498 D01 the Bluetooth did not require SAR testing as a stand-alone transmitter. KDB 447498 section 4.3.1 exemption formula: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR Result - [(3.98)/(8mm)] ·[√f(2.45GHz)]=0.78 , and also for the simultaneous transmission according to the section 4.3.2 the estimated SAR is given by formula: (max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)]·[√f(GHz)/x] W/kg Result - [(3.98)/(8mm)] ·[√f(2.45GHz)/7.5]=0.1 W/kg. The highest SAR for the antenna A (1) was 0.757 mW/g so the sum of the simultaneously transmitting Bluetooth and WLAN (Ant. B) was 0.917 mW/g which was below the SAR limit of 1.6mW/g.

RF Exposure Info

Report Nº(MIE): 38067RRF.002A1 Page 1 of 268 2013-03-15 FCC LISTED, REGISTRATION NUMBER: 905266 IC LISTED REGISTRATION NUMBER IC 4621A-1 AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 29590 Campanillas/ Málaga/ España Tel. 952 61 91 00 - Fax 952 61 91 13 MÁLAGA, C.I.F. A29 507 456 Registro Mercantil de Málaga,Tomo 1169, Libro 82, Folio 133, Hoja MA3729 TEST REPORT (MODIFICATION 1) REFERENCE STANDARD: USA FCC Part 15.247, 15.209 CANADA RSS-210, RSS-Gen Radio Frequency Devices. Operation within the bands 902 - 928 MHz, 2400 -2483.5 MHz, and 5725 - 5850 MHz. Licence-Exempt Radio Apparatus (All Frequency Bands): Category I Equipment. General Requirements and Information for the Certification of Radio Apparatus. MIE....................................................... : 38067RRF.002A1 Approved by (name / position & signature) ............... : A. Llamas / RF Lab. Manager .......................................................... Elaboration date .................................... : 2013-03-15 Identification of item tested................ : 7260HMW Trademark ............................................ : INTEL Model and/or type reference ................. : 7260HMW Serial number ........................................ : TA#: G83347-004 WF MAC:001500B666C9 BD MAC: 001500B666CD Other identification of the product ........ : Commercial name: 7260HMW HW version: QS SW version: Intel Pro Set V16 For OEM factory installation: FCC ID: PD97260H IC: 1000M-7260H For user installation: FCC ID: PD97260HU IC: 1000M-7260H Features ................................................. : No provided data Description ............................................ : 802.11a/b/g/n/ac wireless LAN + BT PCIe half-mini card Applicant ............................................. : INTEL CORPORTATION Address .................................................. : 100 Center Point Circle, Suite 200, Columbia, South Carolina 29210 USA CIF/NIF/Passport...................................: No provided data Contact person: Steven Hackett Telephone / Fax ..................................... : Tel: 803-216-2344/ FAX: 803-216-2176 e-mail: ................................................... : [email protected] Report Nº(MIE): 38067RRF.002A1 Page 2 of 268 2013-03-15 Test samples supplier ......................... : Same as applicant Manufacturer ...................................... : Same as applicant Report Nº(MIE): 38067RRF.002A1 Page 3 of 268 2013-03-15 Test method requested ........................: See Standard Standard ................................................: USA FCC Part 15.247 10-1-11 Edition: Operation within the bands 902 - 928 MHz, 2400 -2483.5 MHz, and 5725 - 5850 MHz. USA FCC Part 15.209 10-1-11 Edition: Radiated emission limits; general requirements. Guidance for Performing Compli…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Mr. Tsuyoshi Uchihara(Engineer)

[email protected]+81-44-754-3885Fax: +81-44-754-3769

Test Firm

EMC Technologies Pty. Ltd.Chris Zombolas

[email protected]61-3-9365-1000Fax: 61-3-9331-7455

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
5	15C	2.40 GHz - 2.48 GHz	3.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is conducted. SAR compliance for portable use conditions has been evaluated as described in this filing. The antenna(s) used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. The highest reported SAR value for stand-alone and simultaneous transmission conditions are 0.36W/kg and 0.52W/kg, respectively. This device has a 20 and 40 MHz bandwidth mode.
