EJE-WL0006WLAN (WLL4030) in LifeBook T Series T3010D

Fujitsu Client Computing Limited (FCCL)

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: May 03, 2004
Application Purpose: Original Equipment
Date of Application: Mar 09, 2004
Equipment Note: WLAN (WLL4030) in LifeBook T Series T3010D
Frequency Range: 5725.00000000 - 5825.00000000
Company: Fujitsu Client Computing Limited (FCCL)
Country: Japan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

FCC ID: EJE-WL0006 (IC: 337J-WL0006) Report No. M040222_Cert_Mace_Atheros_5.2 EMC Technologies Pty Ltd – 57 Assembly Drive, Tullamarine VIC 3043 Australia www.emctech.com.au EMC Technologies Report Number: M040222_Cert_Mace_Atheros_5.2 APPENDIX O1 – Host PC User Manual Copyright Copyright Fujitsu PC Corporation has made every effort to ensure the accuracy and completeness of this document. However, as ongoing development efforts are continually improving the capabilities of our products, we cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes. Fujitsu, the Fujitsu logo, and LifeBook are registered trademarks of Fujitsu Limited. The following are registered trademarks of Microsoft Corporation: MS, MS-DOS, Windows. PCMCIA is a trademark of the Personal Computer Memory Card International Association. Intel and Pentium are registered trademarks of Intel Corporation. Adobe Acrobat Reader is a registered trademark of Adobe System Inc. PowerQuest and Drive Image are registered trademarks of PowerQuest Corporation. All other trademarks mentioned herein are the property of their respective owners. © Copyright 2003 Fujitsu PC Corporation. All rights reserved. No part of this publication may be copied, reproduced, or translated, without prior written consent of Fujitsu PC Corporation. No part of this publication may be stored or transmitted in any electronic form without the written consent of Fujitsu PC Corporation. B5FH-9011-01EN-00 DECLARATION OF CONFORMITY according to FCC Part 15 Responsible Party Name:Fujitsu PC Corporation Address: 5200 Patrick Henry Drive Santa Clara, CA 95054 Telephone:(408) 982-9500 Declares that product:Model Configuration: LifeBook T3010 Tablet PC LifeBook T3010D Tablet PC Complies with Part 15 of the FCC Rules. This device complies with Part 15 of the FCC rules. Operations are subject to the following two conditions: (1) This device must not be allowed to cause harmful interference, (2) This device must accept any interference received, including interference that may cause undesired operation. T Series.book Page 1 Thursday, July 31, 2003 10:49 AM LifeBook T Series Tablet PC T Series.book Page 2 Thursday, July 31, 2003 10:49 AM Table of Contents Fujitsu LifeBook ® T Series Tablet PC Table of Contents 1 PREFACE Preface About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . 3 FPC Contact Information . . . . . . . . . . . . . . . . . . . 3 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 2 GETTING TO KNOW YOU R TABL ET PC Overview Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Optional Accessories . . . . . . . . . . . . . . . . . . . . . . 8 Locating the Controls and Connectors Top and Front Components . . . . . . . . . . . . . . . . 10 Left-Side Panel Components . . . . . . . . . . . . . . . 11 Right-Side Panel Components . . . . . . . . . . . . . . 12 Rear Panel Components . . . . . . . . . . . . . . . . . . . 13 Bottom Components . . . . . . . . . . . . . . . . . . . . . 14 Status Indicator Panel Power Indicator . . . . . . . . . . . . . . . . . . . . . . . . . 15 AC Adapter Indicator . . . . . . . . . . . . . . . . . . . . . 15 Battery Level Indicators . . . . . . . . . . . . . . . . . . . 15 Battery Charging Indicator . . . . . . . . . . . . . . . . . 16 Hard Drive Access Indicator . . . . . . . . . . . . . . . . 16 NumLk Indicator. . . . . . . . . . . . . . . . . . . . . . . . . 16 CapsLock Indicator . . . . . . . . . . . . . . . . . . . . . . . 16 ScrLk Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Security Indicator . . . . . . . . . . . . . . . . . . . . . . . . 16 Display Panel Opening the Display Panel . . . . . . . . . . . . . . . . . 17 Using the System as a Tablet . . . . . . . . . . . . . . . 17 Adjusting Display Panel Brightness . . . . . . . . . . . 18 Keyboard Using the Keyboard . . . . . . . . . . . . . . . . . . . . . . 19 Numeric Keypad. . . . . . . . . . . . . . . . . . . . . . . . . 19 Windows Keys . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Cursor Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Function Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 LifeBook Security/Tablet PC Buttons Changing Tablet PC Button Functions . . . . . . . . 22 Setting up LifeBook Security Panel . . . . . . . . . . . 22 Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Using Your LifeBook Security Panel . . . . . . . . . . 23 Uninstalling the Security Panel Application . . . . . 24 Touchpad Pointing Device Clicking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Double-Clicking . . . . . . . . . . . . . . . . . . . . . . . . . 25 Dragging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Scrolling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Touchpad Control Adjustment . . . . . . . . . . . . . . 26 Pen and Active Digitizer Using the Pen. . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Calibrating the Pen. . . . . . . . . . . . . . . . . . . . . . . 27 Replacing the Pen Tip . . . . . . . . . . . . . . . . . . . . . 28 Using the Active Digitizer . . . . . . . . . . . . . . . . . . 28 Volume Control Controlling the Volume . . . . . . . . . . . . . . . . . . . 29 3 USING YOUR TABLET PC Power Sources Connecting the Power Adapters . . . . . . . . . . . . . 33 Starting Your Tablet PC Power On. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Boot Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . 34 BIOS Setup Utility. . . . . . . . . . . . . . . . . . . . . . . . 34 Booting the System . . . . . . . . . . . . . . . . . . . . . . 34 T Series.book Page 3 Thursday, July 31, 2003 10:49 AM LifeBook T Series Tablet PC Activating Additional Utilities . . . . . . . . . . . . . . . 35 Registering Your LifeBook T Series Tablet PC . . . 35 Power Management Suspend/Resume Button . . . . . . . . . …

Text truncated - open the document above for the full version.

Users Manual

FCC ID: EJE-WL0006 (IC: 337J-WL0006) Report No. M040222_Cert_Mace_Atheros_5.2 EMC Technologies Pty Ltd – 57 Assembly Drive, Tullamarine VIC 3043 Australia www.emctech.com.au EMC Technologies Report Number: M040222_Cert_Mace_Atheros_5.2 APPENDIX O2 – WLAN USER MANUAL 49 Appendix Wireless LAN* User’s Guide * Optional device 50 51 Wir e le s s LAN Use r ’s Guide FC C R EG U LATO R Y IN FO R MATIO N Please note the following regulatory information related to the optional wireless LAN module. R egulatory N otes and Statements Wireless L AN , Health and Authorization for use R adio frequency electromagnetic energy is emitted from Wire- less LAN devices. T he energy levels of these emissions, however, are far much less than the electromagnetic energy emissions from wireless devices such as mobile phones. Wireless LAN devices are safe for use by consumers because they operate within the guidelines found in radio frequency safety standards and recommendations. T he use of Wireless LAN devices may be restricted in some situations or environments, such as: On board an airplane, or In an explosive environment, or In situations where the interference risk to other devices or services is perceived or identified as harmful. I n cases in which the policy regarding use of Wireless LAN devices in specific environments is not clear (e.g., airports, hospitals, chemical/oil/gas industrial plants, private buildings), obtain authorization to use these devices prior to operating the equipment. Regulatory I nformation/D isclaimers Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment. T he manufacturer is not responsible for any radio or television interference caused by unauthorized modification of this device, or the substitution or attachment of connecting cables and equipment other than those specified by the manufacturer. It is the responsibility of the user to correct any interference caused by such unauthorized modifica- tion, substitution or attachment. T he manufacturer and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failure to comply with these guidelines. This device must not be co-located or operating in conjunction with any other antenna or transmitter. For Atheros Wireless LAN: For operation within 5.15~5.25GHz frequency range, it is restricted to indoor environment, and the antenna of this device must be integral. Federal C ommunications C ommission statement This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause interference, and, ( 2) T his device must accept any interference, including interference that may cause undesired operation of this device. FC C Interference Statement T his equipment has been tested and found to comply with the limits for a C lass B digital device, pursuant to Part 15 of the FC C Rules. T hese limits are designed to provide reasonable protection against harmful interference in a residential installa- tion. T his equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interfer- ence will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: 1.Reorient or relocate the receiving antenna. 2.Increase the distance between the equipment and the receiver. 3.Connect the equipment to an outlet on a circuit different from the one the receiver is connected to. 4.Consult the dealer or an experienced radio/TV technician for help. FC C R adio Frequency Exposure statement T his Wireless LAN radio device has been evaluated under FCC Bulletin OET 65C and found compliant with the requirements as set forth in C FR 47 Sections 2.1091, 2.1093, and 15.247 ( b) ( 4) addressing R F Exposure from radio frequency devices. T he radiated output power of this Wireless LAN device is far below the FC C radio frequency exposure limits. T he maximum SAR values measured from the devices are: Intel PROSet Wireless LAN: 0.262 W/kg Atheros Wireless LAN: 1.03 W/kg Export restrictions T his product or software contains encryption code which may not be exported or transferred from the US or Canada without an approved U S Department of Commerce export license. T his device complies with Part 15 of FC C Rules., as well as ICES 003 B / NMB 003 B. Operation is subject to the following two conditions: ( 1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation. Modifications not expressly authorized by Fujitsu PC C orpora- tion may invalidate the user's right to operate this equipment. C anadian N otice To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment ( or its transmit antenna) that is installed outdoors is subject to licensing. 52 B efore U sing the Wireless LAN T he Integrated Wireless LAN is an optional device Types of Wireless LAN s C overed by this Document T his document is applicable to systems containing one of the following two wireless modules. Most of the procedures are identical. Sections that differ between the two devices have been noted in the text: I ntel PROSet Wireless LAN Atheros Wireless LAN If your system is a T 3010 model, your wireless modul…

Text truncated - open the document above for the full version.

Attestation Statements

No.19173uu TECHNICALACCEPTANCECERTIFICATD’ACCEPTABILITÉ CERTIFICATETECHNIQUE CERTIFICATION No. 1353A-WLL4030 u No. DE CERTIFICATION ISSUED TOASKEY COMPUTER CORP.u DÉLIVRÉ A TYPE OF EQUIPMENT WIRELESS LAN MINI-PCI CARD u GENRE DE MATÉRIEL TRADE NAME AND MODELWLL4030u MARQUE ET MODELE FREQUENCY RANGE 2412-2462 MHz/5150-5350 MHz/5725-5825 MHz u BANDE DE FRÉQUENCES EMISSION DESIGNATION24M4G1Du DESIGNATION D'ÉMISSION R.F. POWER RATING 43.8 mWatt/69.5 mWatt u PUISSANCE NOMINALE H.F. CERTIFIED TO 5 SPECIFICATIONRSS210 ISSUEu CERTIFIÉ SELON LE ÉDITIONCAHIER DES CHARGES CertificationofequipmentmeansonlythattheequipmenthasmettheL'homologationdematérielterminalsignifieseulementqu'ilestconformeaux requirementsoftheabovenotedspecificatio.Licenseapplications,exigencesducahierdeschargesmentionnéci-dessus.Lesdemandesde whereapplicabletousecertifiedequipment,areactedonaccordinglylicence,lecaséchéantenvuedel'utilisationdematérielcertifiéseront bytheissuingofficeandwilldependontheexistingradioenvironment,traitéesenconséquenceparlebureauchargédedélivrerlesditeslicences, serviceandlocationofoperation.entenantcomptedumilieuradioélectriqueambiant,duserviceradioexistant etdel'emplacementdelastation. ThiscertificateisissuedonconditionthattheholdercompliesandwillLeprésentcertificatestdélivréàconditionqueledétenteurseconformeet continuetocomplywiththerequirementsoftheradiostandardscontinueàseconformerauxcahiersdeschargesetprocéduressurlesnormes specificationsandproceduresissuedbytheDepartment.radioélectriquespubliéesparleministère. ISSUED UNDER THE AUTHORITY OF MINISTER OF INDUSTRY DELIVRE AVEC L'AUTORISATION DU MINISTRE DE L'INDUSTRIE DATESeptember 15, 2003 FOR DIRECTOR GENERALDIRECTEUR GÉNÉRAL SPECTRUM GÉNIE ENGINEERING DU SPECTRE BRANCH

Block Diagram

Figure WLL4030 Block diagram

Cover Letter(s)

EMC Technologies Pty Ltd, 57 Assembly Drive, Tullamarine VIC 3043 Australia Ph: +613 9335 3333 Fax: +613 9338 9260 www.emctech.com.au EMC Technologies Pty Ltd ABN 82 057 105 549 57 Assembly Drive Tullamarine Victoria Australia 3043 Ph: + 613 9335 3333 Fax: + 613 9338 9260 email: [email protected] To: Federal Communications Commission Attention: No. of pages: 1 From: Donna Cleary Date: 04/03/04 EMC Ref: M040222_Cert_Mace_Atheros_5.2 Subject: Equipment Authorisation Submission Dear Barry, Please receive EMC Technologies’ Report M040222_Cert_Mace_Atheros_5.2 for review. The EUT is a Mini-PCI Wireless LAN (WLAN) Module (Atheros 11a+b/g, Model WLL4030) installed in Host PC – LifeBook T Series, Model T3010D (Mace). The WLAN module is an OEM product from Askey Computer Corp., which is already certified by FCC ID: H8NWLL4030 and IC: 1353A-WLL4030 and re-certified by Fujitsu Ltd under FCC ID: EJE- WL0004 and IC:337J-WL0004 & FCC ID: EJE-WB0002, IC: 337J-WB0002. The intention of this submission is to certify the Mini-PCI Wireless LAN Module (Atheros WLL4030 (11a+b/g) in representative host. This is a composite submission - NII & DTS. Test results are recorded as follows: NII Submission EMC Technologies Report – M040222_Cert_Mace_Atheros_5.2_BT: Test results - FCC Part 15.407 (Part E) - (Atheros 802.11a results) 5.15-5.25 & 5.725-5.825 GHz Documents submitted: Report Number: M040222_Cert_Mace_Atheros_5.2 & all appendices. Required Forms: Agent Authority, Confidentiality Request DTS Submission EMC Technologies Report – M040224_Cert_Mace_Atheros_2.4 Test results - FCC Part 15.247 (Part C) - (Atheros 802.11b, 802.11g results). EMC Technologies Pty Ltd is acting as agent for Fujitsu Ltd during this product approval. Their corresponding FRN is 0009379173 & the FCC ID for this composite application is EJE-WL0006. Regards ______________ Donna Cleary Report Secretary EMC Technologies Pty Ltd

Cover Letter(s)

Federal Communications Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21045 Date: 4 th March 2004 Reference: FCC ID: EJE-WL0006 Subject: Request for Confidentiality for FCC Certification Application Company: FUJITSU Ltd Test Sample: Mini-PCI Wireless LAN Module (Atheros (11a+b/g)) installed in Host - Fujitsu's LifeBook T Series PC, Model T3010D (Mace) Pursuant to Rule 47 CFR, Chapter 1, Section 0.457(d)(1)(ii), FUJITSU requests that prior to the equipment authorization grant for the (test sample), the entire application be classified and deemed confidential by the Federal Communications Commission (FCC) and as such be withheld from public inspection. As per 47 CFR, Chapter 1, Section 0.457, the exhibits tendered for the purpose of this grant, contain details of trade secrets and technical data that is not made available to competitors and the general public. This information is treated in a confidential manner by FUJITSU and guarded from disclosure to our competitors. The exhibits outlined below are not routinely made available to FUJITSU staff, with such access granted only to those specifically involved with this particular project. They contain information detailing the unique technology and circuitry of the product that would be of significant benefit to our competitors. All employees treat this technical data in a confidential manner. The manufacture of this product has taken place after an extensive research and development process that has seen the company invest a considerable amount of time and money. The time and effort taken has enabled the product to meet the specific demands of the competitive market for which it is intended and it would be therefore detrimental to allow competitors easy access to design and development details. Apart from a limited number of employees, the information has previously only been disclosed to the Test House responsible for conducting testing and authorized to act as our agent during the certification process. Pursuant to 47CFR Chapter 1, Section 0.459, post-grant confidentiality is requested for the following items, ensuring that this material continue to be withheld from public inspection following the grant. Exhibits – Technical PCB Layouts, Technical Schematic Circuit Diagrams, Detailed Antenna Information Sincerely Yours, Kanbe Katsuhito Fujitsu Japan Mobile Computing Division FUJITSU LIMITED 1405 Ohmaru, Inagi-shi, Tokyo 206-8503, Japan Tel(+81-42)370-7632 FAX(+81-42)370-7708 Mobile Computing Division Product Type: - Low power transmitter (intentional radiator)

External Photos

ID Label/Location Info

Internal Photos

Operational Description

Page 1 of 7 Last printed 7/4/2003 6:05 PM Askey 802.11a/b/g, 802.11b/g WLAN card Functional Description The Askey 802.11a/b/g, 802.11b/g WLAN card Designs are based on Atheros AR5002X chip set which implements IEEE 802.11a, IEEE 802.11b, and IEEE 802.11g WLAN solutions or the AR5002G chipset for IEEE 802.11b/g-only solutions. The chipsets consist of the following: z AR5212An all-CMOS, IEEE 802.11a/802.11b/802.11g MAC/baseband processor, and CardBus/PCI bus interface. z AR5112 Radio-on-a-Chip (RoC) An all-CMOS IEEE 802.11a/802.11b/802.11g, single-chip radio transceiver that converts RF signals to the baseband range for use by the AR5212. The AR5112 offers fully integrated transmitter, receiver, and frequency synthesizer functions; eliminating the need for external voltage controlled oscillators (VCOs) and surface acoustic wave (SAW) filters. z AR2112 Radio-on-a-Chip (RoC) An all-CMOS IEEE 802.11b/802.11g, single-chip radio transceiver that converts RF signals to the baseband range for use by the AR5212. The AR2112 offers fully integrated transmitter, receiver, and frequency synthesizer functions; eliminating the need for external voltage controlled oscillators (VCOs) and surface acoustic wave (SAW) filters. When combined into a single design, the AR5002X (AR5112 and AR5212) chip set enables a low-cost, compact multi-mode solution that easily fits on a PC Card or Mini PCI design. For IEEE 802.11g-only implementations, the WLAN card may be used by not populating the IEEE 802.11a radio section, replacing the AR5002X chip set with a AR5002G (AR2112 and AR5212) chip set. By doing this, a single PCB may be used for triple band designs, and single band designs. AR5002 STA Block Diagram The AR5002X chipset provides a highly integrated IEEE 802.11a, IEEE 802.11b, and IEEE 802.11g solution, as shown by the block diagram in Figure 1-1. Page 2 of 7 Last printed 7/4/2003 6:05 PM Figure 1-1. AR5002 STA Radio Block Diagram The AR5212 is the origin and destination for all the front-end signals. Both transmit (Tx) and receive (Rx) signals are transferred by the AR5112 to either a 5 GHz front-end, or to a 2.4 GHz front end. The 5 GHz and the 2.4 GHz front ends share a single set of antennae, dual band switch, Rx diplexer, Tx diplexer/low pass filter, coupler, and power detect circuitry. The 5 GHz transmit signal is boosted with an output booster (OPB). The OPB drives a diplexer and a coupler/detector (PDET) assembly. The diplexers function is to combine the 5 GHz and 2.4 GHz signals, while the coupler/ detectors function is to sample the transmit signal and rectify it. The rectified signal is proportional to the output power and is used for power leveling and control. The RF transmit signal then passes through a dual band switch. This switch enables the connection of the input to either one of the two antennae. The 5 GHz receive signal is transferred in a reverse order from the antennae through the switch and receive diplexer. It is then boosted using a low noise amplifier (LNA) and fed back into the AR5112. The transmit and receive 2.4 GHz signals follow a similar path as the 5 GHz signals in the 2.4 GHz front-end. CardBus/PCI Interface The CardBus/PCI interface of the AR5212 is PCI 2.3 and PC Card 7.1 compatible. In the WLAN card design, this interface seamlessly connects to Page 3 of 7 Last printed 7/4/2003 6:05 PM the CardBus or Mini PCI interface provided by the host. MAC/Baseband Processor (AR5212) The AR5212 is a highly integrated chip containing a CardBus/PCI interface, media access control (MAC) and a baseband processor (PLCP/PHY). The AR5212 runs on 2.5 V (digital and analog) core and 3.3 V I/O, and is packaged in a 15x15x1.5 mm 196 plastic ball grid array (PBGA). 40 MHz Crystal The 40 MHz crystal provides the core clock for the AR5212 and ARx112, (AR5112/AR2112). This crystal is attached to the ARx112, which then internally forms an oscillator. The ARx112 then provides the output of the oscillator to its internal frequency synthesizer, and to the AR5212. The maximum frequency tolerance allowed by the IEEE 802.11a standard is +/ 20 ppm. Therefore, the crystal device needs to meet this requirement over all operating conditions. Atheros recommends a crystal device with an overall tolerance of 18 ppm that includes initial tolerance, tolerance over operating temperature range and aging tolerance. The crystal device used in the Reference Design is calibrated at 19.5 pF load. When designing the crystal circuit, care should be taken to include the board stray and other capacitances, such as those inherent with the oscillator circuits, in the overall calculation of the load capacitance. A significant shift in frequency can occur if the overall load capacitance presented to the crystal device is not the same as what the crystal was cut for. Excessive load capacitance on the crystal circuit, compared to the actual load that the crystal was designed for, shifts the frequency down. Conversely, lower load capacitance causes an increase in the frequency of the circuit. When the final circuit boards are available, the overall crystal circuit load capacitance should be calibrated by requesting known frequency crystals at a particular load from the crystal vendor. RF Front End Section This section provides information and design guidelines for the transmit and receive paths between the antennae and the ARx112. General Guidelines All RF, Rx, and Tx traces are to be 50 unless otherwise noted, and must have no sharp bends (90 ) unless otherwise noted. Atheros recommends that all RF components, traces, and the ARx112 be on the same side of the board. Vias should be avoided in the RF traces as much as possible. Do not use any test points on any RF trace or component. Minimize lengths of all RF traces because FR4 material is inherently lossy at RF frequencies. Minimizing the trace lengths reduces the overall signal loss. It is more important to keep the Tx path short than it is to keep the Rx path short. A loss in …

Text truncated - open the document above for the full version.

Operational Description

Page 1 of 3 Last printed 7/2/2003 7:25 PM WLL4030 Specifications ( Draft ) General Specification REV.0.0 2003/07/01 Host Interface Mini-PCI spec V1.0 Form Factor Mini-PCI type IIIB Chipset ATHEROS AR5212 , AR5112 Network Standard IEEE802.11a, 802.11b.802.11g Securi…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Mr. Tsuyoshi Uchihara(Engineer)

[email protected]+81-44-754-3885Fax: +81-44-754-3769

Technical Contact

EMC TECHNOLOGIES PTY. LTD.CHRIS ZOMBOLAS

[email protected]+613 9335 3333

57 ASSEMBLY DRIVE, TULLAMARINE · MELBOURNE, VICTORIA · Australia

Non-Technical Contact

EMC TECHNOLOGIES PTY. LTD.CHRIS ZOMBOLAS

[email protected]+613 9335 3333

Test Firm

EMC Technologies Pty. Ltd.Chris Zombolas

[email protected]61-3-9365-1000Fax: 61-3-9331-7455

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15E	5.72 GHz - 5.83 GHz	76.00 mW

Confidentiality

Long Term
