EJH210BWireless Router

Rhine II 10/100 Mbps Broadband Router User’s Manual Broad Net Technology Inc. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: To assure continued compliance, (example - use only shielded interface cables when connecting to computer or peripheral devices). Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Table of Contents Table of Contents.....................................................................................................................3 Congratulations on your purchase of the Rhine II......................................................................1 This Package Contains.............................................................................................................1 Confirm That You Meet Installation Requirements................................................................1 Hardware Setup.............................................................................................................................2 Indicator LEDs.........................................................................................................................3 Configuring Your Computer........................................................................................................3 Configuring Your Computer with Windows 95/98/ME..............................................................3 Step 1. Configure TCP/IP Settings..........................................................................................3 Step 2. Disable HTTP Proxy...................................................................................................6 Internet Explorer..................................................................................................................6 Netscape...............................................................................................................................7 Step 3. Obtain IP Settings from Your Rhine II........................................................................7 Configuring Your Computer with Windows 2000......................................................................8 Step 1. Configure TCP/IP Settings..........................................................................................8 Step 2. Disable HTTP Proxy...................................................................................................9 Internet Explorer................................................................................................................10 Netscape.............................................................................................................................10 Step 3. Obtain IP Settings From Your Rhine II.....................................................................10 Configuring Your Computer with Windows NT 4.0.................................................................11 Step 1. Configure TCP/IP Settings........................................................................................11 Step 2. Disable HTTP Proxy.................................................................................................13 Internet Explorer................................................................................................................13 Netscape.............................................................................................................................13 Step 3. Obtain IP Settings From Your Rhine II.....................................................................14 Configuring Your Macintosh Computer....................................................................................16 Step 1. Configure TCP/IP Settings........................................................................................16 Step 2. Disable HTTP Proxy.................................................................................................17 Internet Explorer................................................................................................................17 Netscape.............................................................................................................................17 Step 3. Obtain IP Settings From Your Rhine II.............................................…

Text truncated - open the document above for the full version.

Rhine II BroadNet Technology Inc. 16 Configuring Your Macintosh Computer You may find that the instructions here do not exactly match your screen. This is because these steps and screenshots were created using Mac OS 8.5. Mac OS 7.x and above are all very similar, but may not be identical to Mac OS 8.5. Step 1. Configure TCP/IP Settings After you have completed the hardware setup, you need to configure your computer to connect to your Rhine II. You need to determine how your ISP issues your IP address. Many ISPs issue these numbers automatically using a networking technology known as Dynamic Host Control Protocol, or DHCP. Other ISPs will specify your IP address and associated numbers, which you must enter manually. This is also known as a static IP address. How your ISP assigns your IP address determines how you will configure your computer. Here is what to do: 1. Pull down the Apple Menu. Click “Control Panels” and select TCP/IP. 2. In the TCP/IP dialog box, make sure that “Ethernet” is selected in the “Connect Via:” field. If “Using DHCP Server” is already selected in the “Configure” field, your computer is already configured for DHCP. Close the TCP/IP dialog box, and skip to Step 2 “Disable HTTP Proxy.” 3. All the information that you need to record is on the “TCP/IP” dialog box. Use the space below to record the information. 4. After writing down your IP settings, select “Using DHCP Server” in the “Configure” field and close the window. 5. Another box will appear asking whether you want to save your TCP/IP settings. Click Save. Rhine II BroadNet Technology Inc. 17 TCP/IP Configuration Setting IP Address ____.____.____.____ Subnet Mask ____.____.____.____ Router ____.____.____.____ Name Server ____.____.____.____ Step 2. Disable HTTP Proxy You will need to verify that the “HTTP Proxy” feature of your Web browser is disabled. This is so that your Web browser will be able to view the configuration pages inside your Rhine II. The following steps are for Internet Explorer and for Netscape. Determine which browser you use and follow the appropriate steps. Internet Explorer 1. Open Internet Explorer and click the stop button. Click “Edit” and select “Preferences.” 2. In the Internet Explorer Preferences window, under Network, select Proxies. 3. Uncheck all checkboxes and click OK. Netscape 1. Open Netscape and click the stop button. Click “Edit” and select “Preferences.” Rhine II BroadNet Technology Inc. 18 2. In the “Preferences” dialog box, In the left-hand column labeled “Category,” select “Advanced.” Under the “Advanced” category, select “Proxies.” 3. Select “Direct Connection to the Internet” and click OK Step 3. Obtain IP Settings From Your Rhine II Now that you have configured your computer to connect to your Rhine II, it needs to obtain new network settings. By releasing any old IP settings and renewing them with settings from your Rhine II, you will also verify that you have configured your computer correctly. 1. Pull down the Apple Menu. Click “Control Panels” and select TCP/IP. 2. In the TCP/IP window, your new settings will be shown. Verify that your IP address is now 192.168.0.xxx, your Subnet Mask is 255.255.255.0 and your Default Gateway is 192.168.0.1. These values confirm that your Rhine II is functioning. 3. Close the TCP/IP window. Now that your computer is configured to connect to your Rhine II, please go to “Configuring Your Rhine II” on the next page. Rhine II BroadNet Technology Inc. 19 Configuring Your Rhine II – Quick Setup Now that you have successfully configured your computer and retr ieved your new network settings from your Rhine II, you are ready to configure the Rhine II’s settings for your LAN. 1. Open your Web browser (i.e., Internet Explorer or Netscape Navigator) and click the stop button. 2. In the “Address” field type “http://192.168.0.1” and press <ENTER>. 3. The Rhine II login screen will appear. Leave the Password field empty and click on “login”. There is no password by default. For security reasons, you should assign a password as soon as possible. Note that the password login in case sensitive. 4. Once the user login successfully, the first page will appear as below: Rhine II BroadNet Technology Inc. 20 5. Click on <Quick setup> for step by step configuration. 6. In step 1 of setup wizard, select the proper time zone and click <NEXT> for next page. Rhine II BroadNet Technology Inc. 21 7. In this page, there are three types of broadband WAN connection types – Cable Modem, Fixed- IP ADSL and PPPoE ADSL. Depending on the connection type of your broadband access, select the proper type. For Cable Modem connection, user may not require to configure anything. In the case of Fixed-IP ADSL connection, user needs to enter the IP address, subnet mask, and gateway provided to you by your service provider. In the case of PPPoE ADSL connection, user needs to enter the User Name and Password required by your ISP. 8. Click <OK> when all the fields are entered properly. At this point your Rhine II should be setup properly. The IP address of the LAN port is 192.168.0.1, and the DHCP server is configured starting from 192.168.0.100. The SSID for the wireless LAN card is “Troy”. Configuring Your Rhine II – Basic Configuration The main page of basic configuration is shown below. System Time Zone Set the proper time zone and the daylight savings for the Rhine II. Password Settings Set the password of the user. The Idle Time Out value is used for Rhine II to log out automatically when no access to the web after this timeout value. Rhine II BroadNet Technology Inc. 2 WAN Settings The Rhine II supports 4 types of WAN connection – Dynamic IP (DHCP Client), PPPoE, Static IP and Bridging. Dynamic IP Under this mode, Rhine II enables DHCP client to get IP address automatically from your service provider. The Host Name is optional, but may be required by some Service Provider’s. The default MAC address is set to the WAN’s physical interface on the Rhine II. If required by Se…

Text truncated - open the document above for the full version.

Advance Data Technology Corporation誠信科技股份有限公司 13-1 Lane 19, Wen Shan 3rd St., Kweishan, Taoyuan, Taiwan, R.O.C. 桃園縣龜山鄉文㆔㆔街19巷13-1號 http://www.adt.com.tw/ E-mail: [email protected] TEL: 886-3-3270910 FAX: 886-3-3270892 服務項目 EMC/ SAFETY/ RADIO CERTIFICATION、ID/ MECH. DESIGN、GRAPHICS/TECH. W RITING SERVICES 您產品開發的最佳伙伴 YOUR BEST PARTNER IN PRODUCT DEVELOPMENT 誠信確實•專業第㆒•顧客至㆖ INTEGRITY•PROFESSIONALISM•CUSTOMER SATISFACTION

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3

Page 4 Page 5 Page 6

Page 19 Page 20

Page 7 Page 8

Page 9 Page 10

Page 10 Page 11

Page 13 Page 14

Page 15 Page 16

Page 17 Page 18

Page 21 Page 22

FCC ID: EJH210B ADT No.901127A11 Operational Description The transmitter of the EUT (Wireless Router) is powered by power adapter and connected with notebook through RJ45 port. The antenna is Dipole Antenna , the antenna connector is MMCX connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

ADT Number: 901127A11 1 FCC TEST REPORT REPORT NO.: RF901127A11 MODEL NO.: Rhine-II 210B (for Brand: MiTAC) Etherportal (for Brand: TROY) ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: MITAC INTERNATIONAL CORP. ADDRESS: 8F, No.75, Ming Sheng E. Rd., Sec. 3 , Taipei, Taiwan 114, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 ADT Number: 901127A11 2 RF Exposure Measurement 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz ADT Number: 901127A11 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5 Climate Condition The temperature and related humidity: 18 deg. C and 50 % RH 6. Classification This device is not fixed inside the host equipment, it is connected with host through wire. So it is easy to be re-located in the place where at least 20 cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. ADT Number: 901127A11 4 7 Test Results 7.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 0.5dBi or 1.12 (numeric). 7.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241240.931.91 6243749.772.11 11246247.642.06 The minimum allowable distance is very close to the enclosure of the antenna. So, the user has no need to worry about the harmfulness of radiation. But it is recommended to always keep, at least, 20 cm separation distance with the antenna.

FCC ID: EJH210B Report No.: RF901127A11 1 Issued: Dec. 28, 2001 FCC TEST REPORT REPORT NO.: RF901127A11 MODEL NO.: Rhine-II 210B (for Brand: MiTAC) Etherportal (for Brand: TROY) RECEIVED: Nov. 27, 2001 TESTED: Dec. 19 ~ Dec. 24. 2001 APPLICANT: MITAC INTERNATIONAL CORP. ADDRESS: 8F, No.75, Ming Sheng E. Rd., Sec. 3, Taipei, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 49 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: EJH210B Report No.: RF901127A11 2 Issued: Dec. 28, 2001 Table of Contents 1CERTIFICATION ...........................................................................................4 2SUMMARY OF TEST RESULTS...................................................................5 3GENERAL INFORMATION ...........................................................................6 3.1GENERAL DESCRIPTION OF EUT..............................................................6 3.2DESCRIPTION OF TEST MODES................................................................7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ...............................7 3.4DESCRIPTION OF SUPPORT UNITS..........................................................8 4TEST TYPES AND RESULTS.......................................................................9 4.1CONDUCTED EMISSION MEASUREMENT ................................................9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT.................................................... 9 4.1.2TEST INSTRUMENTS....................................................................................................... 9 4.1.3TEST PROCEDURES..................................................................................................... 10 4.1.4TEST SETUP .................................................................................................................. 10 4.1.5EUT OPERATING CONDITIONS..................................................................................... 11 4.1.6TEST RESULTS ..............................................................................................................12 4.2RADIATED EMISSION MEASUREMENT ...................................................18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ...................................................... 18 4.2.2TEST INSTRUMENTS..................................................................................................... 19 4.2.3TEST PROCEDURES..................................................................................................... 20 4.2.4TEST SETUP .................................................................................................................. 21 4.2.5EUT OPERATING CONDITIONS..................................................................................... 21 4.2.6TEST RESULTS ..............................................................................................................22 4.36DB BANDWIDTH MEASUREMENT ..........................................................27 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT.............................................................. 27 4.3.2TEST INSTRUMENTS..................................................................................................... 27 4.3.3TEST PROCEDURE........................................................................................................ 28 4.3.4TEST SETUP .................................................................................................................. 28 4.3.5EUT OPERATING CONDITIONS..................................................................................... 28 4.3.6TEST RESULTS ..............................................................................................................29 4.4MAXIMUM PEAK OUTPUT POWER ..........................................................33 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ................................. 33 4.4.2INSTRUMENTS...............................................................................................................33 4.4.3TEST PROCEDURES..................................................................................................... 34 4.4.4TEST SETUP .................................................................................................................. 34 4.4.5EUT OPERATING CONDITIONS..................................................................................... 34 4.4.6TEST RESULTS ..............................................................................................................35 4.5POWER SPECTRAL DENSITY MEASUREMENT......................................36 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ......................................... 36 4.5.2TEST INSTRUMENTS..................................................................................................... 36 4.5.3TEST PROCEDURE........................................................................................................ 37 4.5.4TEST SETUP .................................................................................................................. 37 4.5.5EUT OPERATING CONDITION ....................................................................................... 37 4.5.6TEST RESULTS ..............................................................................................................38 4.6BAND EDGES MEASUREMENT ................................................................42 FCC ID: EJH210B Report No.: RF901127A11 3 Issued: Dec. 28, 2001 4.6.1LIMITS OF BAND EDGES M…

Text truncated - open the document above for the full version.

FCC ID: EJH210B Report No.: RF901127A11 36 Issued: Dec. 28, 2001 4.5 POWER SPECTRAL DENSITY MEASUREMENT 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT The Maximum of Power Spectral Density Measurement is 8dBm. 4.5.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE & SCHWARZ TEST RECEIVER ESMI839013/007Jan. 25, 2002 HP ATTENUATOR8496B3247A18505 Cal. on use HP PLOTTER7475A2641V27755 N/A NOTE: 1. The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2. The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: EJH210B Report No.: RF901127A11 37 Issued: Dec. 28, 2001 4.5.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer through an attenuator, the bandwidth of the fundamental frequency was measured with the spectrum analyzer using 3 kHz RBW and 30 kHz VBW, set sweep time = span/3 kHz. The power spectral density was measured and recorded. The sweep time is allowed to be longer than span/3 kHz for a full response of the mixer in the spectrum analyzer. 4.5.4 TEST SETUP 4.5.5 EUT OPERATING CONDITION Same as Item 3.4.5 EUT SPECTRUM ANALYZER Attenuator FCC ID: EJH210B Report No.: RF901127A11 38 Issued: Dec. 28, 2001 4.5.6 TEST RESULTS EUT Wireless LAN Router MODEL Rhine-II 210B INPUT POWER (SYSTEM) 120Vac, 60Hz ENVIRONMENTAL CONDITIONS 18 deg. C, 50%RH, 1005 hPa TESTED BY: Bruce Shiau CHANNEL NUMBER CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 3 kHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAIL 12412-7.338PASS 62437-6.198PASS 112462-6.888PASS FCC ID: EJH210B Report No.: RF901127A11 39 Issued: Dec. 28, 2001 CH1 FCC ID: EJH210B Report No.: RF901127A11 40 Issued: Dec. 28, 2001 CH6 FCC ID: EJH210B Report No.: RF901127A11 41 Issued: Dec. 28, 2001 CH11 FCC ID: EJH210B Report No.: RF901127A11 42 Issued: Dec. 28, 2001 4.6 BAND EDGES MEASUREMENT 4.6.1 LIMITS OF BAND EDGES MEASUREMENT Below –20dB of the highest emission level of operating band (in 100KHz Resolution Bandwidth). 4.6.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE & SCHWARZ TEST RECEIVER ESMI839013/007Jan. 25, 2002 HP ATTENUATOR8496B3247A18505 Cal. on use HP PLOTTER7475A2641V27755 N/A NOTE: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. 4.6.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer via a low lose cable. Set both RBW and VBW of spectrum analyzer to 100 kHz with suitable frequency span including 100 kHz bandwidth from band edge. The band edges was measured and recorded. FCC ID: EJH210B Report No.: RF901127A11 43 Issued: Dec. 28, 2001 4.6.4 EUT OPERATING CONDITION Same as Item 3.4.5 4.6.5 TEST RESULTS The spectrum plots are attached on the following 2 pages. D2 line indicates the highest level, D1 line indicates the 20dB offset below D2. It shows compliance with the requirement in part 15.247(C). NOTE: The band edge emission plot on the following 2 pages shows 53.63dB delta between carrier maximum power and local maximum emission in restrict band (2.4875GHz). The emission of carrier strength list in the test result of channel 11 at the item 4.2.6 (Page 26) is 99.2dBuV/m, so the maximum field strength in restrict band is 99.2-53.63=45.57dBuV/m which is under 54 dBuV/m limit. FCC ID: EJH210B Report No.: RF901127A11 44 Issued: Dec. 28, 2001 FCC ID: EJH210B Report No.: RF901127A11 45 Issued: Dec. 28, 2001

FCC ID: EJH210B Report No.: RF901127A11 46 Issued: Dec. 28, 2001 4.7 ANTENNA REQUIREMENT 4.7.1 STANDARD APPLICABLE For intentional device, according to FCC 47 CFR Section 15.203, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. And according to FCC 47 CFR Section 15.247 (b), if transmitting antennas of directional gain greater than 6dBi are used, the power shall be reduced by the amount in dB that the directional gain of the antenna exceeds 6dBi. 4.7.2 ANTENNA CONNECTED CONSTRUCTION The antenna used in this product is Dipole Antenna and used MMCX antenna connector. The maximum Gain of the antenna is 0.5dBi only. FCC ID: EJH210B Report No.: RF901127A11 47 Issued: Dec. 28, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: EJH210B Report No.: RF901127A11 48 Issued: Dec. 28, 2001 RADIATED EMISSION TEST FCC ID: EJH210B Report No.: RF901127A11 49 Issued: Dec. 28, 2001 6 INFORMATION ON THE TESTING LABORATORIES We, ADT Corp., were founded in 1988 to provide our best service in EMC and Safety consultation. Our laboratories are accredited and approved by the following approval agencies according to ISO/IEC 17025, Guide 25 or EN 45001: USA FCC, NVLAP, UL Germany TUV Rheinland Japan VCCI New Zealand MoC Norway NEMKO R.O.C. BSMI, DGT, CNLA Copies of accreditation certificates of our laboratories obtained from approval agencies can be downloaded from our web site: www.adt.com.tw/index.5/phtml. If you have any comments, please feel free to contact us at the following: Lin Kou EMC Lab: Tel: 886-2-26052180 Fax: 886-2-26052943 Hsin Chu EMC Lab: Tel: 886-35-935343 Fax: 886-35-935342 Lin Kou Safety Lab: Tel: 886-2-26093195 Fax: 886-2-26093184 Lin Kou RF&Telecom Lab Tel: 886-3-3270910 Fax: 886-3-3270892 Email: [email protected] Web Site: www.adt.com.tw The address and road map of all our labs can be found in our web site also.

FCC ID: EJH210B Report No.: RF901127A11 47 Issued: Dec. 28, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: EJH210B Report No.: RF901127A11 48 Issued: Dec. 28, 2001 RADIATED EMISSION TEST
