EMOIBT22ABluetooth Wireless Dual Alarm Clock

instruction manual Model: iBT22A IB (English) Size: 153mm x 120mm Printing color: Black Date : July 8, 2013 P1 iBT22A Bluetooth Wireless Dual Alarm Clock FCC ID: EMOIBT22A IC: 986B-IBT22A iBT22A QDID:B020340 Information FCC Cet appareil répond aux exigences du paragraphe 15 de la loi de la Commission Fédérale sur les Communications. L’utilisation de cet appareil doit répondre aux deux conditions suivantes: (1) Cet appareil ne doit pas provoquer d’interférences nuisibles, et (2) cet appareil doit accepter toutes les interférences reçues, y compris les interférences pouvant provoquer un fonctionnement non désiré P4 Déclaration FCC quant à l'exposition à la radiation Cet équipement est conforme aux limites FCC relatives à l'exposition à la radiation par radiofréquences établies pour les environnements non contrôlés. Cet émetteur ne doit pas être colocalisé ou utilisé en conjonction avec tout autre émetteur ou antenne. Cet appareil est conforme à la norme RSS-210 des règlements relatifs aux circuits intégrés. Le fonctionnement est sujet aux deux conditions suivantes : 1) Cet appareil ne doit pas causer d'interférences; et 2) Cet appareil doit accepter toute interférence reçue y compris les interférences qui peuvent occasionner un fonctionnement indésiré. • Avertissement : Tout changement ou modification apporté à cet appareil sans le consentement expresse de la partie responsable pour la conformité peut annuler le droit de l'utilisateur d'utiliser cet appareil. • Remarque : Cet équipement a été testé et jugé conforme aux limitations pour un appareil numérique de Classe B, selon la Section 15 de la règlementation FCC. Ces limites sont conçues pour fournir une protection raisonnable contre les interférences nuisibles dans une installation résidentielle. Cet équipement génère, utilise et peut émettre des fréquences radio et, s'il n'est pas installé et utilisé selon les instructions, peut causer des interférences nuisibles aux communications radio. Cependant, il n'existe aucune garantie que des interférences ne se produiront pas dans une installation particulière. Si cet équipement produit des interférences nuisibles sur la réception de la radio ou de la télévision, ce que vous pouvez facilement constater en éteignant et en rallumant l'équipement, nous vous encourageons à prendre l'une ou plusieurs des mesures correctives suivantes : • Réorienter ou déplacer l’antenne réceptrice, • Éloigner davantage l'appareil du récepteur. • Branchez l’équipement sur une prise ou un circuit auquel le récepteur n’est pas branché. • Consultez votre revendeur ou un technicien radio/télévision qualifié pour plus d’informations. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada iBT22A 1 Included • iBT22A Alarm Clock • 100V-240V universal AC adaptor • Backrest • 3 AAA batteries • 12” patch cord P6 power adaptor alarm clock Patch cord backrest snoo ze dimmer alm. r eset sleep 1) Insert the front tabs of the included backrest at a slight angle into the slots on top of the unit (behind the buttons). 2) Grip the unit in both hands from front to back as shown and squeeze the unit slightly towards you while pressing down firmly on the backrest until it clicks into place. Installing the Backrest Once inserted, the backrest is a permanent part of the unit and offers enhanced stability for your devices. Test your device in the backrest to make sure it is stable. A tablet may not be suitable for use with the backrest. 1 2 iBT22A 2 P7 Meet Your iBT22A Bluetooth/Pairing Button Aux-in Jack DC Jack DST Switch Clock Adj. Button USB Charging Port Back Back Rest Lower Volume Button Raise Volume Button Alarm 2 Button Play/Pause Button Alarm 1 Button Sleep Button Alarm Reset/Power Button Snooze Dimmer Button Rev/– Setting Button Fwd/+ Setting Button Top iBT22A Using the 3 P8 Replacing & Installing Clock Backup Batteries The iBT22A uses 3 AAA batteries (included) for backup to provide continuous alarm operation and clock settings in the event of a power failure. If the backup batteries have been installed and a power failure occurs or the AC adaptor is accidentally disconnected, the display backlight will not remain lit, but current time and alarm time settings will be temporarily maintained. Otherwise, you must reset the time and alarm settings. Note: You should replace backup batteries when the Battery Low Indicator appears on the display. 1. Please make sure the AC adaptor is connected. Otherwise all settings may be lost during battery replacement. 2. Open backup battery compartment door located on the bottom of the unit. 3. Insert three “AAA” batteries, checking the + and – ends of the batteries match the diagram inside the compartment. We recommend to use alkaline battery for longer life. Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries. 4. Close the compartment cover. Note: Make sure you dispose of batteries properly (see your local regulations). Battery Low Indicator The Battery Low Indicator is located at the top left of the display. When it blinks it is time to replace backup batteries. iBT22A Using the 4 P9 Setting Up the Unit 1. Connect the included AC adaptor to the DC jack located on the back of the unit and connect the other end to a working wall outlet. Turning the Unit ON and OFF 1. Once the AC adaptor is properly connected, press the Power Button located on top of the unit to turn the unit ON. “ON” will appear briefly on the display. 2. Press the Power Button to turn the unit OFF. “OFF” will appear briefly on the display. NOTE: The unit has an automatic shut off function: if no audio is detected for 3 minutes, the unit will power off. The Display Alarm 1 & Alarm 2 Indicators Battery Low Indicator Time Display PM Indicator Alarm time AM/PM Indicator DST indicator Bluetooth Indicator Sleep Indicator Aux-in Indicator Alarm Time/Date Display Year/Date Indicator PM AUX-IN SLEEP ALM. AM PM YEAR DATE outlet 7.5V 2A RESET RESET TEST TEST iBT22A Using the 5 P10…

Text truncated - open the document above for the full version.

6 iBT22A Using the P11 Reviewing, Arming and Disarming Alarms 1. Once an alarm is set, it is armed and the lower part of the display will show the alarm time. If both alarms are armed, the earliest alarm time will show. 2. To arm/disarm the alarm, just press the associated alarm button to toggle it on or off. If the alarm is armed, the related alarm icon will appear in the upper part of the display. Resetting the Alarm to Come On the Next Day When the alarm is sounding, press the Button to stop alarm and reset it to come on the following day. Setting the Alarms 1. By default, the unit selects the most recently linked Bluetooth device as your wake-to source. If no Bluetooth device is detected, the iBT22A will automatically default to buzzer alarm. See page 8 to setup your Bluetooth device. Note: make sure you have an hour of audio on your Bluetooth device. 2. Press and hold the Button until the current alarm time flashes in the lower part of the display and a beep sounds. Press the – or + Button to set the alarm time. Remember to set the correct AM or PM time. 3. Press the Button (or if no button is pressed within 10 seconds). Two beeps will confirm alarm time and exit alarm setting mode. The alarm will be armed and the corresponding alarm icon will appear. 4. To set Alarm 2 just follow steps 2 - 3 using the Button. 7 iBT22A Using the P12 Snooze Operation 1. Press and hold the Snooze/Dimmer Button for a few seconds to enter set snooze timer mode. A beep will sound and the display will flash. Press t he – or + Button to set the snooze timer from 1 to 29 minutes. Press the Snooze/Dimmer Button to exit. Two confirmation beeps will sound. 2. Press the Snooze/Dimmer Button after the alarm sounds. The alarm will be silenced and come on again after the set snooze time. Snooze can be pressed several times during the 1 hour alarm cycle. Sure Alarm The iBT22A has a sure alarm feature. If backup batteries are installed, the buzzer alarm will still sound in the event of power failure. Using Bluetooth: Pairing Your Device NOTE: See the iBT22A Bluetooth Connection Guide for complete pairing details. Whenever it is powered on, this unit will attempt to autolink to a previously paired device. If no device is detected, the unit will automatically enter pairing mode for 2 minutes. You can manually initiate pairing without turning on the unit by following steps 1-3 below. 1. Make sure your Bluetooth device is fully charged. Turn on your Bluetooth device and make it “discoverable” by turning on Bluetooth mode (check in Options or Settings) . 2. Press and hold the Bluetooth Pairing Button on the back of the unit for 2 seconds. The unit will beep and the Bluetooth icon will flash on the display, indicating the unit is in pairing mode. 3. “iHome iBT22A” should appear in your device’s menu. If “Not Paired”, “Not Connected” or similar message appears, select “iHome iBT22” to connect it. If prompted for a passcode, enter “1234” on your device’s keypad. 4. If pairing is successful, a beep will sound, “PAIR” will appear briefly in the bottom display and the Bluetooth icon will become solid. There should also be an indication on your device. If no device is successfully paired within 2 minutes the unit will default to previous mode. Once unit is paired to a device, it will attempt to autolink when the device is within range (about 30 feet). iBT22A Using the 8 P13 Playing Audio Via Bluetooth 1. Press the Button to turn on the unit. The Bluetooth icon will be displayed when a linked device is in range and detected. You can then listen to audio streamed wirelessly from your paired iPad, iPhone, iPod or other Bluetooth device. 2. Press the Button to play audio from your device. Press again to pause play and once more to resume play. When Bluetooth audio is active, the audio icon will be displayed around the Bluetooth icon . 3. Press the – or + Button to navigate tracks on your device. 4. Press the or Button to adjust the system volume. You can also adjust volume on your device. 5. When done listening, press the Button to turn the unit OFF. Remember to turn off your device, too. Pairing with a Different Device 1. When you power ON the speaker, it will automatically link with the previously paired Bluetooth device as long as that device is still within range (approx. 30 feet). So, to pair with a different device you must turn off the Bluetooth capability of the already paired device. iBT22A Using the 9 P14 Playing Audio via Aux In 1. Connect one end of the included 3.5mm stereo audio cable to the Aux-in jack on the back of the unit and connect the other end to the headphone or line-out jack on your audio device. 2. Press the Button on the unit to turn it on. 3. Power on the audio device and use the controls on the device to play or pause audio, and navigate tracks. 4. Press t he or Button to adjust the system volume . You can also adjust volume on your device. 5. When done listening, press the Button to turn the unit OFF. Remember to turn off your device, too. NOTE: Make sure no Bluetooth device is playing or you will hear both the Aux -in and Bluetooth playing. iBT22A Using the P15 10 Connect To Audio Source mobile phonePSP PC iPod Kindle fire Laptop MP3/MP4 iBT22A Using the P16 Sleep Operation Sleep mode lets you sleep to your Bluetooth device until the unit shuts off at a selected time. It will send a power off command to your device,too 1. Press the Sleep Button to enter sleep mode. The Sleep Icon will appear on the display to indicate it is in sleep mode. 2. Press the Sleep Button as needed to adjust the sleep timer from 120,90, 60, 30 or 15 minutes (or turn sleep mode OFF by pressing the Button). 3. When the display changes back to show the real time, press the Sleep Button once to show the sleep time remaining. Pressing it again to change sleep time to the next lowest increment. 4. To stop listening at any time, press the Button to turn the unit OFF. Remember to turn off your device, too. NOTE: The next time you tur…

Text truncated - open the document above for the full version.

SDI Technologies Inc Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Sections 0.457 and 0.459 pertaining to confidential material. SDI Technologies Inc would like the following documents regarding this submission for FCC ID: EMOIBT22A to be kept confidential. 1.Schematics 2.Block diagram 3.Operation description The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Contact person: Jasjit Singh, Safety of all matter Date: 2013- - 16

Model Declaration Letter Date: 2013-7-16 We, the undersigning company Company Name: SDI Technologies Inc Address: 1299 Main Street, Rahway, New Jersey 07065, U.S.A Hereby confirm that the following product(s): Product description: Bluetooth Wireless Dual Alarm Clock Type designation: iBT22A; iBT22; iBT22X (“X” denote as color of cabinet) Brand: iHome That All versions of the model iBT22A; iBT22; iBT22X are electrically equal and only the color and the model name of the cabinet differ because of marketing purpose. Company Name: SDI Technologies Inc Address: 1299 Main Street, Rahway, New Jersey 07065, U.S.A Telephone: 732 574-9000 E-mail: [email protected] Signature: ________________________ Name: Jasjit Singh

Neutron Engineering Inc. Project No.: 1307C065 Page 2 of 13 Neutron Engineering Inc. Project No.: 1307C065 Page 3 of 13 Neutron Engineering Inc. Project No.: 1307C065 Page 4 of 13

MODEL: iBT22A MODEL PLATE (ALL COLOR) SCALE: 1:1 DATE: July 8, 2013 COLOR : BLACK BACKGROUND PRINTING WHITE Clock Backup: 4.5V ‘AAA’ (R03) x 3 Service No: iBT22-A-A Mfd & Serviced by SDI Technologies Inc. www.ihomeaudio.com Toll Free: 1-800-288-2792 Made in China Patents: www.ihomeaudio.com/patents AC Adaptor: DC 7.5V 2A Model: iBT22A FCC ID: EMOIBT22A IC: 986B-IBT22A MODEL: iBT22A REAR CABINET ENGRAVING 0.4mm SCALE: 1:1 DATE: JAN 14, 2013 DC 1.5V (R3) UM-4, ‘AAA ’ SIZE DC 1.5V (R3) UM-4, ‘AAA ’ SIZE DC 1.5V (R3) UM-4, ‘AAA ’ SIZE ENGRAVING 0.4mm ENGRAVING 0.7mm This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This Class B digital apparatus complies with Canadian ICES-003.”Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.”

Neutron Engineering Inc. Project No.: 1307C065 Page 5 of 13 Neutron Engineering Inc. Project No.: 1307C065 Page 6 of 13 Neutron Engineering Inc. Project No.: 1307C065 Page 7 of 13 Neutron Engineering Inc. Project No.: 1307C065 Page 8 of 13 Neutron Engineering Inc. Project No.: 1307C065 Page 9 of 13 Neutron Engineering Inc. Project No.: 1307C065 Page 10 of 13 Neutron Engineering Inc. Project No.: 1307C065 Page 11 of 13 Neutron Engineering Inc. Project No.: 1307C065 Page 12 of 13 Neutron Engineering Inc. Project No.: 1307C065 Page 13 of 13

Neutron Engineering Inc. Report No.: NEI-FICP-1-1307C065 Page 1 of 103 FCC&IC Radio Test Report FCC ID: EMOIBT22A IC: 986B-IBT22A This report concerns (check one): Original Grant Class II Change Issued Date : Jul. 15, 2013 Project No. : 1307C065 Equipment : Bluetooth Wireless Dual Alarm Clock Model Name for FCC : iBT22A ; iBT22; iBT22X (“X” denote as color of cabinet) Model Name for IC : iBT22A Applicant : SDI TECHNOLOGIES INC. Address : 1299 Main Street, Rahway, NJ 07065, U.S.A Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Jul. 08, 2013 Date of Test: Jul. 08, 2013~Jul. 12, 2013 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory: (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FICP-1-1307C065 Page 2 of 103 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FICP-1-1307C065 Page 3 of 103 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 10 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.5 DESCRIPTION OF SUPPORT UNITS 12 4 . EMC EMISSION TEST 13 4.1 CONDUCTED EMISSION MEASUREMENT 13 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 13 4.1.3 TEST PROCEDURE 14 4.1.4 DEVIATION FROM TEST STANDARD 14 4.1.5 TEST SETUP 14 4.1.6 EUT OPERATING CONDITIONS 14 4.1.7 TEST RESULTS 15 4.2 RADIATED EMISSION MEASUREMENT 18 4.2.1 RADIATED EMISSION LIMITS 18 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 19 4.2.3 TEST PROCEDURE 20 4.2.4 DEVIATION FROM TEST STANDARD 20 4.2.5 TEST SETUP 21 4.2.6 EUT OPERATING CONDITIONS 22 4.2.7 TEST RESULTS (BELOW 30MHZ) 23 4.2.8 TEST RESULTS (BETWEEN30 – 1000 MHZ) 24 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 31 5 . NUMBER OF HOPPING CHANNEL 55 5.1 APPLIED PROCEDURES / LIMIT 55 5.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 55 5.1.2 TEST PROCEDURE 55 5.1.3 DEVIATION FROM STANDARD 55 5.1.4 TEST SETUP 55 5.1.5 EUT OPERATION CONDITIONS 55 5.1.6 TEST RESULTS 56 6 . AVERAGE TIME OF OCCUPANCY 58 Neutron Engineering Inc. Report No.: NEI-FICP-1-1307C065 Page 4 of 103 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 58 6.1.1 MEASUREMENT INSTRUMENTS LIST 58 6.1.2 TEST PROCEDURE 58 6.1.3 DEVIATION FROM STANDARD 58 6.1.4 TEST SETUP 59 6.1.5 EUT OPERATION CONDITIONS 59 6.1.6 TEST RESULTS 60 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 72 7.1 APPLIED PROCEDURES / LIMIT 72 7.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 72 7.1.2 TEST PROCEDURE 72 7.1.3 DEVIATION FROM STANDARD 72 7.1.4 TEST SETUP 72 7.1.5 EUT OPERATION CONDITIONS 72 7.1.6 TEST RESULTS 73 8 . BANDWIDTH TEST 77 8.1 APPLIED PROCEDURES / LIMIT 77 8.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 77 8.1.2 TEST PROCEDURE 77 8.1.3 DEVIATION FROM STANDARD 77 8.1.4 TEST SETUP 77 8.1.5 EUT OPERATION CONDITIONS 77 8.1.6 TEST RESULTS 78 9 . PEAK OUTPUT POWER TEST 82 9.1 APPLIED PROCEDURES / LIMIT 82 9.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 82 9.1.2 TEST PROCEDURE 82 9.1.3 DEVIATION FROM STANDARD 82 9.1.4 TEST SETUP 82 9.1.5 EUT OPERATION CONDITIONS 82 9.1.6 TEST RESULTS 83 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 87 10.1 APPLIED PROCEDURES / LIMIT 87 10.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 87 10.1.2 TEST PROCEDURE 87 10.1.3 DEVIATION FROM STANDARD 87 10.1.4 TEST SETUP 87 10.1.5 EUT OPERATION CONDITIONS 87 10.1.6 TEST RESULTS 88 11 . EUT TEST PHOTO 100 Neutron Engineering Inc. Report No.: NEI-FICP-1-1307C065 Page 5 of 103 1. CERTIFICATION Equipment : Bluetooth Wireless Dual Alarm Clock Brand Name : iHome Model Name for FCC : iBT22A ; iBT22; iBT22X (“X” denote as color of cabinet) Model Name for IC : iBT22A Applicant : SDI TECHNOLOGIES INC. Manufacturer : SDI TECHNOLOGIES INC. Address : 1299 Main Street, Rahway, NJ 07065, U.S.A Factory : Winty Industries Corporation (Shen Zhen) Co. Ltd. Address : San Lian Industry Zone. Shi Yan Town, Bao An District, ShenZhen, China Date of Test : Apr. 22, 2013 ~ May. 06, 2013 Test Item : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2009 FCC Public Notice DA 00-705, March 30, 2000. Canada RSS-210:2010 RSS-GEN Issue 3, Dec 2010 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laborat…
