EMOIBT29LED Full Spectrum Color Changing Bluetooth FM Clock Radio with USB Charging

Model: iBT29 instruction manual iBT29 Eng IB Size: 153mm x 120mm Printing color: Black Dec 4, 2014 P1 LED Full Spectrum Color Changing Bluetooth FM Clock Radio with USB Charging Questions? Contact Customer Service at 1-800-288-2792 iBT29 Introduction Thank you for purchasing the iHome iBT29. This product is designed to provide fun colors and high quality wireless sound for your iPad, iPhone, iPod or other Bluetooth audio device. This instruction booklet explains the basic operation and care of the unit. Please read it carefully and keep for future reference. • Place the unit on a level surface away from sources of direct sunlight or excessive heat. • Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective material should be placed between it and the furniture. • Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as benzene, thinner or similar materials can damage the surface of the unit. 1 P2 Maintenance iBT29 Table of Contents 2 What’s Included ...............................................................................................................3 Meet Your iBT29 ..............................................................................................................4 The Display/Setting Up the Unit ..........................................................................................5 Replacing and Installing Clock Backup Battery.......................................................................6 Setting the Clock/Setting and Using the Alarms .....................................................................7 Previewing the Alarm and Turning the Alarm On/Off ..............................................................8 Snooze/Display Dimmer Button/Sleep Mode/FM Radio.........................................................9 Setting and Using FM Presets/Using FM Radio in Other Countries ...........................................10 Pairing Your Bluetooth Device ..........................................................................................11 Playing Audio Via Bluetooth..............................................................................................12 Using the Speakerphone Feature .......................................................................................12 Playing Audio via Aux-In .................................................................................................13 Charging Devices via USB Port .........................................................................................14 Color Change Mode ......................................................................................................15 Battery Use Cautions and Tips..........................................................................................16 Consumer Product Safety Guide ........................................................................................17 FCC Information.............................................................................................................18 Troubleshooting ..............................................................................................................19 Warranty......................................................................................................................20 P3 iBT29 3 P4 What’s Included • iBT29 unit • 100V-240V universal AC adaptor • Audio cable power adaptor audio cable iBT29 iBT29 P5 Meet Your iBT29 Top 4 BottomBack DC Jack USB Charging Port Aux-in Jack FM Antenna Bluetooth Pairing Button Answer Call/ Plus Settings Button Mode Button Color Mode Button Volume Down Button Volume Up Button Snooze/Display Dimmer Button Alarm 1 Button Alarm 2 Button Time Set/Sleep Button Power/Alarm Reset Button End Call/Minus Settings Button Presets/Play/Pause Button Backup Battery Compartment Remove the pull tab before initial use to activate the SureAlarm battery backup system. Pull Tab Remove before use iBT29 Using the The Display 5 P6 Alarm Active Indicator Set Wake-to Sleep Mode Indicator Bluetooth/Pairing Indicator PM/AM Indicators Alarm Time/Date/Radio Frequency Color Mode: Fade, Fast, Color, Pulse, Sky, Off Time Display Low Backup Battery Indicator FM antenna Setting Up the Unit Connect the included AC adaptor to the DC jack located on the back of the unit and connect the other end to a working wall outlet. Extend FM antenna. 2 AA batteries are included for battery backup. Install them in the backup battery compartment located on the bottom of the unit before using the unit. See page 6 for more on installing and replacing backup batteries. Mode: Aux, Bluetooth, FM Radio RESET RESET TEST TEST P7 6 Using the iBT29 Replacing and Installing Clock Backup Battery Note: 1 CR2450 battery is included with the unit. Install it before using the unit. This model is equipped with a battery backup circuit that will maintain the time and alarm time settings in the event of a temporary power interruption (the display is NOT maintained). The battery backup circuit will also operate the buzzer alarm to wake you up at the selected wake up time even if the power is out. When the backup battery is getting weak the Low Backup Battery Indicator will begin flashing in the display. When you see this flashing indicator you should replace the backup battery as soon as possible. To install/replace the backup battery: IMPORTANT: When replacing the backup battery be sure to have the unit connected to the AC outlet to maintain all of your settings, otherwise it will be necessary to reset the time and alarm time after the batteries are replaced. 1. Use a Phillips screwdriver to unscrew the battery door located on the bottom of the unit. Remove the battery door. If replacing battery, remove the exhausted battery. 2. Insert 1 fresh CR2450 battery in the backup battery compartment. Make sure the “+” side of the battery is facing you (see illustration). 3. Replace the battery door a…

Text truncated - open the document above for the full version.

Project No.: 1501C244 Page 2 of 15 Project No.: 1501C244 Page 3 of 15 Project No.: 1501C244 Page 4 of 15 Project No.: 1501C244 Page 5 of 15

T h i s d e v i c e c o m p l i e s w i t h P a r t 1 5 o f t h e F C C R u l e s . O p e r a t i o n i s s u b j e c t t o t h e f o l l o w i n g t w o c o n d i t i o n s : ( 1 ) t h i s d e v i c e m a y n o t c a u s e h a r m f u l i n t e r f e r e n c e , a n d ( 2 ) t h i s d e v i c e m u s t a c c e p t a n y i n t e r f e r e n c e r e c e i v e d , i n c l u d i n g i n t e r f e r e n c e t h a t m a y c a u s e u n d e s i r e d o p e r a t i o n . C A N I C E S - 3 ( B ) / N M B - 3 ( B ) iBT29 Model plate & engraving C R 2 4 5 0 D C 7 . 5 V , 2 A

FCC RF EXPOSURE REPORT FCC ID: EMOIBT29 Project No. : 1501C244 Equipment : LED Full Spectrum Color Changing Bluetooth FM Clock Radio with USB Charging Model : iBT29, iBT29X, iBT29XC(“X”= a to Z; denote as color of cabinet) Applicant : SDI TECHNOLOGIES INC. Address : 1299 Main Street, Rahway, NJ 07065, U.S.A According: : FCC Guidelines for Human Exposure IEEE C95.1 BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Table for Filed Antenna Ant. Manufacturer Model NameAntenna TypeConnector Gain(dBi) 1 N/A N/A printed N/A 2.3 GENERAL CONCULUSION: Maximum measured transmitter power: OutputPower (dBm) Output Power (mW) Limit (mW) 3.61 2.3 10 According to FCC KDB447498 V05, Appendix A, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm The maximum measured output peak power of this EUT is 2.3mW, less than 10mW at 5mm distance. Conclusion: No SAR evaluation required since transmitter power is below FCC threshold

Report No.: BTL-FICP-1-1501C244 Page 1 of 109 FCC&IC Radio Test Report FCC ID: EMOIBT29 IC: 986B-IBT29 This report concerns (check one): Original Grant Class II Change Project No. : 1501C244 Equipment : LED Full Spectrum Color Changing Bluetooth FM Clock Radio with USB Charging Model Name For FCC : iBT29, iBT29X, iBT29XC(“X”= a to Z; denote as color of cabinet) Model Name For IC : iBT29 Applicant : SDI TECHNOLOGIES INC. Address : 1299 Main Street, Rahway, NJ 07065, U.S.A Date of Receipt : Jan. 28, 2015 Date of Test : Jan. 28, 2015~Feb. 06, 2015 Issued Date : Feb. 09, 2015 Tested by : BTL Inc. Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Report No.: BTL-FICP-1-1501C244 Page 2 of 109 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of t he authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FICP-1-1501C244 Page 3 of 109 Table of Contents Page 1 . CERTIFICATION 7 2 . SUMMARY OF TEST RESULTS 8 2.1 TEST FACILITY 9 2.2 MEASUREMENT UNCERTAINTY 9 3 . GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 12 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 TEST PROCEDURE 14 4.1.3 DEVIATION FROM TEST STANDARD 14 4.1.4 TEST SETUP 15 4.1.5 EUT OPERATING CONDITIONS 15 4.1.6 EUT TEST CONDITIONS 15 4.1.7 TEST RESULTS 15 4.2 RADIATED EMISSION MEASUREMENT 16 4.2.1 RADIATED EMISSION LIMITS 16 4.2.2 TEST PROCEDURE 17 4.2.3 DEVIATION FROM TEST STANDARD 17 4.2.4 TEST SETUP 18 4.2.5 EUT OPERATING CONDITIONS 19 4.2.6 EUT TEST CONDITIONS 19 4.2.7 TEST RESULTS (9KHZ TO 30MHZ) 19 4.2.8 TEST RESULTS (BETWEEN 30MHZ TO 1000 MHZ) 20 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 20 5 . NUMBER OF HOPPING CHANNEL 21 5.1 APPLIED PROCEDURES 21 5.1.1 TEST PROCEDURE 21 5.1.2 DEVIATION FROM STANDARD 21 5.1.3 TEST SETUP 21 5.1.4 EUT OPERATION CONDITIONS 21 5.1.5 EUT TEST CONDITIONS 21 5.1.6 TEST RESULTS 21 Report No.: BTL-FICP-1-1501C244 Page 4 of 109 Table of Contents Page 6 . AVERAGE TIME OF OCCUPANCY 22 6.1 APPLIED PROCEDURES / LIMIT 22 6.1.1 TEST PROCEDURE 22 6.1.2 DEVIATION FROM STANDARD 22 6.1.3 TEST SETUP 22 6.1.4 EUT OPERATION CONDITIONS 23 6.1.5 EUT TEST CONDITIONS 23 6.1.6 TEST RESULTS 23 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 24 7.1 APPLIED PROCEDURES / LIMIT 24 7.1.1 TEST PROCEDURE 24 7.1.2 DEVIATION FROM STANDARD 24 7.1.3 TEST SETUP 24 7.1.4 EUT TEST CONDITIONS 24 7.1.5 TEST RESULTS 24 8 . BANDWIDTH TEST 25 8.1 APPLIED PROCEDURES 25 8.1.1 TEST PROCEDURE 25 8.1.2 DEVIATION FROM STANDARD 25 8.1.3 TEST SETUP 25 8.1.4 EUT OPERATION CONDITIONS 25 8.1.5 EUT TEST CONDITIONS 25 8.1.6 TEST RESULTS 25 9 . PEAK OUTPUT POWER TEST 26 9.1 APPLIED PROCEDURES / LIMIT 26 9.1.1 TEST PROCEDURE 26 9.1.2 DEVIATION FROM STANDARD 26 9.1.3 TEST SETUP 26 9.1.4 EUT OPERATION CONDITIONS 26 9.1.5 EUT TEST CONDITIONS 26 9.1.6 TEST RESULTS 26 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 27 10.1 APPLIED PROCEDURES / LIMIT 27 10.1.1 TEST PROCEDURE 27 10.1.2 DEVIATION FROM STANDARD 27 10.1.3 TEST SETUP 27 10.1.4 EUT OPERATION CONDITIONS 27 10.1.5 EUT TEST CONDITIONS 27 10.1.6 TEST RESULTS 27 11 . MEASUREMENT INSTRUMENTS LIST 28 Report No.: BTL-FICP-1-1501C244 Page 5 of 109 Table of Contents Page 12 . EUT TEST PHOTO 30 ATTACHMENT A - CONDUCTED EMISSION 34 ATTACHMENT B - RADIATED EMISSION (9KHZ-30MHZ) 37 ATTACHMENT C - RADIATED EMISSION (30MHZ TO 1000MHZ) 39 ATTACHMENT D - RADIATED EMISSION (ABOVE 1000MHZ) 46 ATTACHMENT E - NUMBER OF HOPPING CHANNEL 71 ATTACHMENT F - AVERAGE TIME OF OCCUPANCY 73 ATTACHMENT G - HOPPING CHANNEL SEPARATION MEASUREMENT 86 ATTACHMENT H - BANDWIDTH 91 ATTACHMENT I - PEAK OUTPUT POWER 96 ATTACHMENT J - ANTENNA CONDUCTED SPURIOUS EMISSION 101 Report No.: BTL-FICP-1-1501C244 Page 6 of 109 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FICP-1-1501C244 Original Issue. Feb. 09, 2015 Report No.: BTL-FICP-1-1501C244 Page 7 of 109 1. CERTIFICATION Equipment : LED Full Spectrum Color Changing Bluetooth FM Clock Radio with USB Charging Brand Name : iHome Model Name For FCC : iBT29, iBT29X, iBT29XC(“X”= a to Z; denote as color of cabinet) Model Name For IC : iBT29 Applicant SDI TECHNOLOGIES INC. Manufacturer : SDI TECHNOLOGIES INC. Address : 1299 Main Street, Rahway, NJ 07065, U.S.A Factory : Jadestar Electronics (Shenzhen) Co. Ltd. Address : Block 5, He Tai Industrial Zone, H…
