EMOIBT295ABluetooth Color Changing Dual Alarm Clock Radio with USB Charging

iBT295 - QSG (English) Size: 700 x 160 mm (unfold), 140 x 160 mm (folded) Color: Black (1C + 1C) Material: 85gsm, WF paper May 08, 2020 Front Cover Quick Start Guide What’s Included: AC adapter iBT295 unit Quick Set-Up: The Display • Remove the battery pull tab from the bottom of the unit before use. • Connect the included AC adapter to the DC jack located on the back of the unit, and connect the other end to a working wall outlet. Connecting the Unit Step One Setting Your Clock Step Two Connecting to Bluetooth Step Three • Press and hold the Time Set Button until the display flashes. • Press the – or + Buttons to adjust selections and tap Time Set to confirm (make sure you set the correct AM/PM time). • Do this for time, year, month and date. • All done! Daylight Savings Time: By default, the DST Switch on the bottom of the unit is set to Auto and will automatically adjust the time in March and November. FM Radio + Presets Extend the radio antenna for best reception. Press a FM Preset Button (1-4) to turn on the radio and use the – or + Buttons to select a frequency. The unit allows you to store up to 4 FM radio station presets. 1. Press the – or + Buttons to tune the radio to the desired station (hold to scan for the next clear station). 2. Press and hold a FM Preset Button (1-4). 2 beeps will sound to confirm the preset has been assigned. Repeat steps 1-2 until you have set up to 4 preset stations. 3. Press an FM Preset Button (1-4) to listen to a preset FM station at any time. Charging Devices Via USB Port 1. Connect the standard size end of a USB cable (not included) to the USB port on the back of the unit and connect the other end to the charging port on your device. 2. Monitor the charging on your device. Some devices use a proprietary charging method and will not charge using the USB port. If this happens, you must charge your device using the charger that came with it. Battery Back-Up The unit uses a CR-2450 back-up battery to provide continuous alarm operation and clock settings in the event of a temporary power failure. Remove the battery pull tab before use. When the battery icon on the clock display is flashing, it is time to replace the back-up battery. The battery compartment is located on the bottom of the unit. 1. Make sure the AC adapter is connected, or you will lose your time and alarm settings during battery replacement. 2. Use a Phillips screwdriver to open the battery compartment door. 3. Insert a fresh CR-2450 battery, checking that the polarity match the markings on the unit. Replace the compartment door. Do not overtighten. FCC INFORMATION This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. • Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. • NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. IC Statement This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and compliance. This equipment should be installed and operated with a minimum distance of 20 cm between the radiator and your body. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Cet équipement est conforme aux limites d'exposition aux radiations IC CNR-102 établies pour un environnement non contrôlé. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage; (2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 et…

Text truncated - open the document above for the full version.

Rev11/20/07 SDITECHNOLOGIESINC. FederalCommunicationsCommission AuthorizationandEvaluationDivision ConfidentialityRequestregardingapplicationforcertificationofFCCID:EMOIBT295A PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequestconfidential treatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitTypeFileName BlockDiagram Schematics OperationalDescription Block SCH OperationalDescription Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthis applicationandallaccompanyingdocumentationwillnotbemadebeforethedateoftheGrant forthisapplication. PursuanttoDA04-1705June15,2004oftheCommission’spublicnotice,Wealsorequestingthe commissiontograntshort-termconfidentialityrequestonthefollowingattachmentsuntil180 daysaftertheGrantDateofEquipmentAuthorizations. ExhibitTypeFileName ManualUsermanual Sincerely, DavidStetin 2020-05-25

SDITechnologiesInc. Declarationonmodeldifference Wetheundersignedherebyconfirmthatthesemodelsareidentical,andallmodelshavethe sameRFmoduleandantenna,PCBlayout,schematicsandcomponent.Onlydifferentonmodel numberandcolorofappearance. ProductionnameTrademarkFCCModelno. BluetoothColorChanging DualAlarmClockRadio withUSBCharging iHomeEMOIBT295AiBT295,iBT295B,iBT295X(Xcould 1or2digitsbyanyalphabets denotedifferentcabinetcolor) Confirmedby: DavidStetin 2020-05-25

E:\ED200103042EES200103045KIDiBT780FCCID\work\POA_Letter_140225.docx SDITECHNOLOGIESINC. FederalCommunicationsCommission AuthorizationandEvaluationDivision 1435OaklandMillsRoad Columbia,MD21046 Date:2020-05-25 SUBJECT:FCCApplicationfor(FCCID:EMOIBT295A) ToWhomItMayConcern: We,theundersigned,herebyauthorizeEMTEK(DONGGUAN)CO.,LTD.atSamLvon ourbehalf,toapplytotheFederalCommunicationsCommissiononourequipment.Any andallactscarriedoutbyEMTEK(DONGGUAN)CO.,LTD.onourbehalfshallhavethe sameeffectasactsofourown. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuseAct.We,the applicant,arenotsubjecttoadenialoffederalbenefitspursuanttoSection5301ofthe Anti-DrugActof1988,21USC853a,andnopartytotheapplicationissubjecttoadenial offederalbenefitspursuanttothatsection. Regards, Sincerely, DavidStetin Date:2020-05-25

SDI Technologies Inc. Date: 2020-05-27 To: Federal Communications Commission 743 5 Oakland Mills Road Columbia, MD FCC ID: EMOIBT295A To Whom It May Concern: This letter is to ascertain that SDI Technologies Inc. Product Bluetooth Color Changing Dual Alarm Clock Radio with USB Charging has been the units used for conducting FCC compliance testing, the SDoC part will be tested by FCC recognized test lab. FCC recog nized test lab : EMTEK(SHENZHEN) CO., LTD. address: Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China. If you have any question or concerns, pls. contact us. Sincerely, David Stetin Date: 2020-05-27

FCCID:EMOIBT295A

Title: Color Changing Bluetooth Alarm Clock Radio Version: 7 Designer: Eric Holzer Date: 05.06.2020 Model #: iBT295 CONFIDENTIAL and PROPRIETARY: The information contained herein including, but not limited to the products, renderings, concepts and designs comprise intellectual property of SDI Technolo- gies Inc. and shall be kept confidential and shall not be used or disclosed by the recipient without the written authority of SDI Technologies Inc. GAW PINK - silkscreen *FOLLOW /DL COLOR SPECIFIED PRINT FOR ALL PRINTED ICONS ON PRODUCT. BLUE - deboss 0.3mm GREEN - Lasercut and backlit PURPLE - Emboss 0.3mm L I G H T M O D E DC 5V 2A BACKUP BATTERY PULL TAB (printed in red text) Feb 18, 2020 Ref HiH48 Snooze bumps for prole Feb 18, 2020 Ref HiH48 Snooze bumps for prole May 05, 2020 Removed hidden white outline from light alarm and sound alarm buttons May 05, 2020 Adjust iHome logo (smaller) Model: iBT295 POWERCLOCK GLO USB Output: DC 5V, 2A AC Adaptor: DC 5V, 2A Clock Backup: DC 3V, CR2450 Freq Range: FM 87.5-107.9 MHz FCC ID: EMOIBT295A IC: 986B-IBT295A Srvc #: iBT295-A-A HVIN: iBT295a Model: iBT295 POWERCLOCK GLO USB Output: DC 5V, 1A AC Adaptor: DC 5V, 2A Clock Backup: DC 3V, CR2450 Srvc #: iBT295-A-A EU Freq Range: FM 87.5-108 MHz

FCCID:EMOIBT295A ANT

RFEXPOSUREEVALUATION EUTSpecification EUTBluetoothColorChangingDualAlarmClockRadiowith USBCharging ModelNumberiBT295,iBT295B,iBT295X(Xcould1or2digitsbyany alphabetsdenotedifferentcabinetcolor) FCCIDEMOIBT295A Antennagain(Max)0dBi OperationFrequency2402-2480MHz InputRatingAC120V/60Hzforadapter ClassificationPer StipulatedTestStandard §15.247(i),§2.1093 KindofDevice:BluetoothVer.5.0 ModulationBT:(GFSK,π/4-DQPSK,8DPSK) Max.outputpowerBT:4.32dBm(0.002704W) TestRequirement: RFEXPOSUREEVALUATION AccordingtoFCC1.1310:Thecriterialistedinthefollowingtableshallbeusedto evaluatetheenvironmentimpactofhumanexposuretoradiofrequency(RF)Radiationas specifiedin§1.1307(b) LimitsforMaximumPermissibleExposure(MPE) Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) Power Density(mW/cm 2 ) Average Time (A)LimitsforOccupational/ControlExposures 300-1500----F/3006 1500-100000----56 (B)LimitsforGeneralPopulation/UncontrolExposures 300-1500----F/15006 1500-100000----130 1Friistransmissionformula:Pd=(Pout*G)\(4*pi*R 2 ) Where Pd=PowerdensityinmW/cm 2 Pout=outputpowertoantennainmW G=Numericgainoftheantennarelativetoisotropicantenna Pi=3.1416 R=distancebetweenobservationpointandcenteroftheradiatorincm PdthelimitofMPE,1mW/cm 2 .Ifweknowthemaximumgainofthendtotalpowerinputto theantenna,throughthecalculation,wewillknowthedistancewheretheMPElimitis reached. 2MeasurementResult Antennagain:0dBi BTDSS: Transmit Frequen cy(MHz) Mode Measur ed Power (dBm) Tune upPowe r (dBm) Max tuneup power( dBm) Output Peak power (mW) Ant. Gain (dBi) Ant. Gain (nume ric) Powerdensity at20cm(mW/ cm2) Power densit y Limits (mW/ cm2) 2.402GFSK0.73 0±11 1.25901.0000.0002505 1 2.441GFSK3.60 3±14 2.51201.0000.0004997 1 2.480GFSK4.32 4±15 3.16201.0000.0006291 1 2.402 Π/4-DQP SK -1.87 -1±10 1.00001.0000.0001989 1 2.441 Π/4-DQP SK 1.39 1±12 1.58501.0000.0003153 1 2.480 Π/4-DQP SK 4.18 4±15 3.16201.0000.0006291 1 2.4028DPSK-1.59 -1±10 1.00001.0000.0001989 1 2.4418DPSK2.00 3±14 2.51201.0000.0004997 1 2.4808DPSK2.69 3±14 2.51201.0000.0004997 1 Signature: SamLv Date:2020-05-25

ReportNo.ES200423003WPage 1 of 74 Ver.1.0 TESTREPORT ProductName ： BluetoothColorChangingDualAlarmClock RadiowithUSBCharging ModelNumber ： iBT295,iBT295B,iBT295X(Xcould1or2 digitsbyanyalphabetsdenotedifferent cabinetcolor) FCCID ： EMOIBT295A Preparedfor:SDITechnologiesInc. Address:1299,MainStreet,Rahway,NJ07065,U.S.A. Preparedby:EMTEK(SHENZHEN)CO.,LTD. Address:Building69,MajialongIndustryZone,NanshanDistrict, Shenzhen,Guangdong,China Tel:(0755)26954280 Fax:(0755)26954282 ReportNumber:ES200423003W Date(s)ofTests:April23,2020toMay14,2020 Dateofissue:May14,2020 ReportNo.ES200423003WPage 2 of 74 Ver.1.0 VERIFICATIONOFCOMPLIANCE Applicant: SDITechnologiesInc 1299,MainStreet,Rahway,NJ07065,U.S.A. Manufacturer: SDITechnologiesInc 1299,MainStreet,Rahway,NJ07065,U.S.A. Factory:ARTSDIGITALTECHNOLOGY(HK)LTD(Richfield) 1704,FoTanIndustrialCentre,26-28AuPuiWanSt.,FoTan,Hong Kong ProductDescription: BluetoothColorChangingDualAlarmClockRadiowithUSB Charging TradeMark:iHome ModelNumber: iBT295,iBT295B,iBT295X(Xcould1or2digitsbyanyalphabets denotedifferentcabinetcolor)(note:Themodelsarethesame exceptcolorofappearanceandmodelnumber,hereweprepare iBT295forthealltest) Weherebycertifythat: TheaboveequipmentwastestedbyEMTEK(SHENZHEN)CO.,LTD.Thetestdata, dataevaluation,testprocedures,andequipmentconfigurationsshowninthisreport weremadeinaccordancewiththeproceduresgiveninANSIC63.10-2013andthe energyemittedbythesampleEUTtestedasdescribedinthisreportisincompliance withconductedandradiatedemissionlimitsofFCCRulesPart15.247(2018). DateofTest: April23,2020toMay14,2020 Preparedby: LorenLuo/Editor Reviewer: TimDong/Supervisor Approved&AuthorizedSigner: LisaWang/Manager ReportNo.ES200423003WPage 3 of 74 Ver.1.0 ModifiedInformation VersionSummaryRevisionDateReportNo. Ver.1.0OriginalReport/ES200423003W ReportNo.ES200423003WPage 4 of 74 Ver.1.0 TableofContents 1.GENERALINFORMATION............................................................................................................6 1.1PRODUCTDESCRIPTION..............................................................................................................................6 1.2TESTMETHODOLOGY..................................................................................................................................7 1.3TESTFACILITY.............................................................................................................................................8 2.SYSTEMTESTCONFIGURATION.............................................................................................9 2.1EUTCONFIGURATION.................................................................................................................................9 2.2EUTEXERCISE............................................................................................................................................9 2.3TESTPROCEDURE.......................................................................................................................................9 2.4CONFIGURATIONOFTESTEDSYSTEM......................................................................................................10 3.SUMMARYOFTESTRESULTS................................................................................................11 4.DESCRIPTIONOFTESTMODES.............................................................................................12 5.TESTSYSTEMUNCERTAINTY.................................................................................................13 6.CONDUCTEDEMISSIONSTEST..............................................................................................14 6.1MEASUREMENTPROCEDURE:...................................................................................................................14 6.2TESTSET-UP(BLOCKDIAGRAMOFCONFIGURATION)..........................................................................14 6.3MEASUREMENTEQUIPMENTUSED:..........................................................................................................14 6.4MEASUREMENTRESULT:...........................................................................................................................15 6.5CONDUCTEDMEASUREMENTPHOTOS:....................................................................................................18 7.RADIATEDEMISSIONTEST.....................................................................................................19 7.1MEASUREMENTPROCEDURE....................................................................................................................19 7.2TESTSET-UP(BLOCKDIAGRAMOFCONFIGURATION).........................................................................21 7.3MEASUREMENTEQUIPMENTUSED:..........................................................................................................22 7.4RADIATEDEMISSIONLIMIT........................................................................................................................23 7.5MEASUREMENTRESULT............................................................................................................................24 7.5RADIATEDMEASUREMENTPHOTOS:........................................................................................................29 8.CHANNELSEPARATIONTEST................................................................................................30 8.1MEASUREMENTPROCEDURE....................................................................................................................30 8.2TESTSET-UP(BLOCKDIAGRAMOFCONFIGURATION).........................................................................30 8.3MEASUREMENTEQUIPMENTUSED:..........................................................................................................30 8.4MEASUREMENTRESULTS:.........................................................................................................................30 9.20DBBANDWIDTHTEST.........................................…

Text truncated - open the document above for the full version.

FCCID:EMOIBT295A
