EMOIBT3iHome Splashproof Wireless Speaker with Speakerphone

instruction manual P1 iBT3 Questions? Contact Customer Service at 1-800-288-2792 iBT3 IB (English) Size: 153 x 120 mm Color: 1C + 1C (Black text on white paper) Date: Oct. 10, 2014 Splashproof Wireless Speaker with Speakerphone CHARGE BEFORE USE iBT3 Introduction Thank you for purchasing the iHome iBT3. This product is designed to provide high quality wireless sound for your iPad, iPhone, iPod, computer, PDA or other Bluetooth audio device. This instruction booklet explains the basic operation and care of the unit. Please read it carefully and keep for future reference. For proper splash-resistant operation, make sure the seal on the left side of the unit is completely flush with the unit by pressing along the entire edge of the seal until it is completely and securely in place. • The unit is IPX4 rated, meaning it will repel a stream of water for up to 5 minutes. • DO NOT immerse the unit in water. • Make sure seal and surrounding surfaces are completely dry before opening seal to prevent moisture from damaging the internal electronics. • Keep seal free of dirt, sand, or other objects that can interfere with proper sealing. If for any reason the seal is not making a tight seal, water may enter the unit. • DO NOT clean unit with oily soaps or use chemicals or solvents. Clean with damp cloth. P2 IMPORTANT INFORMATION ABOUT SPLASH RESISTANT USE iBT3 Table of Contents P3 Included/ Meet Your iBT3/Status indicators ....................................................................... 1-4 Getting Started: Charging the unit .......................................................................................5 Using Bluetooth: Pairing Your Device ....................................................................................6 Pairing with a Different Device/ Playing Audio Via Bluetooth ...................................................7 Speakerphone Operation ..................................................................................................8 Playing Audio via Aux In ...................................................................................................9 Consumer Product Safety Guide ................................................................................... 10-11 Troubleshooting ..............................................................................................................12 Warranty......................................................................................................................13 1 Included • iBT3 system • micro USB charging cable • carrying strap P4 micro USB charging cableiBT3 system carrying strap iBT3 2 P5 iBT3 Meet Your iBT3 Aux-in Jack Left Side Right Side Power/End Call Button Talk/Bluetooth Pairing/ Play/Pause Button – Volume Button Lanyard Loop + Volume Button Splash-resistant Cover Reset Button USB Charging Port iBT3 3 P6 Microphone Status indicator Status indicatorStatus Solid red LED Solid blue LED Flashing red LED Quickly flashing blue LED Slowly flashing blue LED Unit is charging Unit needs charging Active Bluetooth connection / Aux mode Unit is attempting to pair with Bluetooth device Unit is attempting to auto link to already paired Bluetooth device Top The threaded tripod mount on the bottom of the iBT3 allows you to mount the unit to a bicycle camera/tripod mount (not included) for sound on the go. To do so, screw unit clockwise onto camera/tripod mount. Caution: Remain aware of your surroundings and do not ride bike or operate unit in an unsafe manner. Getting Started: Attaching the Carry Strap A carrying strap is included with the iBT3 for easy carrying or attaching to a backpack, etc. To attach the strap, insert the small loop through the loop channel on top of the unit then pull the large loop through the small loop. iBT3 Using the 4 P7 Tripod mount Bottom iBT3 Using the 5 P8 Getting Started: Charging the Unit Charge unit before use. For first time charge, charge for at least 8 hours. Pull back splash-proof seal and connect the included micro USB cable to the USB Charging Port on the left side of the unit and connect the other standard USB plug to a computer, USB AC adaptor (not included) or other USB power source. Computer USB port USB AC adaptor (not included) USB AC adaptor connected to working outlet Computer connected to working outlet Pairing is the set-up process to introduce your Bluetooth-capable device to the iBT3. Once your device is paired, the iBT3 can recognize it and you can play your audio through it. 1. Make sure your Bluetooth device is fully charged. Turn on your Bluetooth device and make it “discoverable” by turning on Bluetooth mode (check in Options or Settings). 2. Press and hold the Power Button for 2-4 seconds to turn on the iBT3. The first time the unit is powered on, it will enter auto-pairing mode and attempt to connect to a Bluetooth device. Otherwise, follow step 3 to begin pairing. 3. Press and hold the Talk/Pairing/Play/Pause Button on the right of the unit for 2 seconds. The unit will beep twice and the status indicator LED will flash blue, indicating the unit is in pairing mode. 4. “iHome iBT3” should appear in your device’s Bluetooth menu. If “Not Paired”, “Not Connected” or similar message appears, select “iHome iBT3” to connect it. If prompted for a passcode, enter “1234” on your device’s keypad. iBT3 Using the 6 P9 For iPhone For other iHome iBT3 iHome iBT3 iHome iBT3 iHome iBT3 5. If pairing is successful, 2 beeps will sound and the Bluetooth indicator light will glow solid, indicating the iBT3 is ready to play music. There should also be an indication on your device. If no device is successfully paired within 3 minutes the iBT3 will default to previous mode. Once the iBT3 is paired to a device, it will attempt to autolink when the device is within range (about 30 feet). Pairing Your Device 7 iBT3 Using the P10 Playing Audio Via Bluetooth 1. Press and hold the Power Button for 2-4 seconds to turn on the unit. The status indicator will glow solid blue whe…

Text truncated - open the document above for the full version.

Project No.: 1410C257 Page 2 of 10 Project No.: 1410C257 Page 3 of 10 Project No.: 1410C257 Page 4 of 10

iBT3 Model plate and Engraving Date: Aug. 05, 2014 Date Code Manufactured and Serviced by SDI Technologies Inc. Designed and Engineered in the USA Patents: www.ihome.com/patents Toll Free: 1-800-288-2792 www.ihome.com Made in China V3 Europe version US version (now) Date Code iBT3 DC 5V, 500mA iBT3-A-A Model No: Charging Voltage: Service Number: iBT3 iBT3-A-A DC 5V, 500mA Model No: Service Number: Charging Voltage: Manufactured and Serviced by SDI Technologies Inc. Made in China www.ihomeintl.com IC: 986B-IBT3 FCC ID: EMOIBT3 Designed and Engineered in the USA

Project No.: 1410C257 Page 5 of 10 Project No.: 1410C257 Page 6 of 10 Project No.: 1410C257 Page 7 of 10 Project No.: 1410C257 Page 8 of 10 Project No.: 1410C257 Page 9 of 10 Project No.: 1410C257 Page 10 of 10

Report No.: BTL-FICP-1-1410C257 Page 1 of 110 FCC&IC Radio Test Report FCC ID: EMOIBT3 IC: 986B-IBT3 This report concerns (check one): Original Grant Class II Change Project No. : 1410C257 Equipment : iHome Splashproof Wireless Speaker with Speakerphone Model Name For FCC : iBT3; iBT5; iBT3X; iBT5X (“X” =A-Z, denote as color of cabinet) Model Name For IC : iBT3 Applicant : SDI TECHNOLOGIES INC. Address : 1299 Main Street, Rahway, NJ 07065, U.S.A Date of Receipt : Oct. 31, 2014 Date of Test : Oct. 31, 2014 ~ Nov. 11, 2014 Issued Date : Nov. 12, 2014 Tested by : BTL Inc. Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Report No.: BTL-FICP-1-1410C257 Page 2 of 110 Declaration BTL represen ts to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unle ss the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FICP-1-1410C257 Page 3 of 110 Table of Contents Page 1 . CERTIFICATION 7 2 . SUMMARY OF TEST RESULTS 8 2.1 TEST FACILITY 9 2.2 MEASUREMENT UNCERTAINTY 9 3 . GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 12 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 DESCRIPTION OF SUPPORT UNITS 14 4 . EMC EMISSION TEST 15 4.1 CONDUCTED EMISSION MEASUREMENT 15 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 15 4.1.2 TEST PROCEDURE 15 4.1.3 DEVIATION FROM TEST STANDARD 15 4.1.4 TEST SETUP 16 4.1.5 EUT OPERATING CONDITIONS 16 4.1.6 EUT TEST CONDITIONS 16 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 17 4.2.1 RADIATED EMISSION LIMITS 17 4.2.2 TEST PROCEDURE 18 4.2.3 DEVIATION FROM TEST STANDARD 18 4.2.4 TEST SETUP 19 4.2.5 EUT OPERATING CONDITIONS 20 4.2.6 EUT TEST CONDITIONS 20 4.2.7 TEST RESULTS (9KHZ TO 30MHZ) 20 4.2.8 TEST RESULTS (BETWEEN 30MHZ TO 1000 MHZ) 21 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 21 5 . NUMBER OF HOPPING CHANNEL 22 5.1 APPLIED PROCEDURES 22 5.1.1 TEST PROCEDURE 22 5.1.2 DEVIATION FROM STANDARD 22 5.1.3 TEST SETUP 22 5.1.4 EUT OPERATION CONDITIONS 22 5.1.5 EUT TEST CONDITIONS 22 5.1.6 TEST RESULTS 22 Report No.: BTL-FICP-1-1410C257 Page 4 of 110 Table of Contents Page 6 . AVERAGE TIME OF OCCUPANCY 23 6.1 APPLIED PROCEDURES / LIMIT 23 6.1.1 TEST PROCEDURE 23 6.1.2 DEVIATION FROM STANDARD 23 6.1.3 TEST SETUP 23 6.1.4 EUT OPERATION CONDITIONS 24 6.1.5 EUT TEST CONDITIONS 24 6.1.6 TEST RESULTS 24 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 25 7.1 APPLIED PROCEDURES / LIMIT 25 7.1.1 TEST PROCEDURE 25 7.1.2 DEVIATION FROM STANDARD 25 7.1.3 TEST SETUP 25 7.1.4 EUT TEST CONDITIONS 25 7.1.5 TEST RESULTS 25 8 . BANDWIDTH TEST 26 8.1 APPLIED PROCEDURES 26 8.1.1 TEST PROCEDURE 26 8.1.2 DEVIATION FROM STANDARD 26 8.1.3 TEST SETUP 26 8.1.4 EUT OPERATION CONDITIONS 26 8.1.5 EUT TEST CONDITIONS 26 8.1.6 TEST RESULTS 26 9 . PEAK OUTPUT POWER TEST 27 9.1 APPLIED PROCEDURES / LIMIT 27 9.1.1 TEST PROCEDURE 27 9.1.2 DEVIATION FROM STANDARD 27 9.1.3 TEST SETUP 27 9.1.4 EUT OPERATION CONDITIONS 27 9.1.5 EUT TEST CONDITIONS 27 9.1.6 TEST RESULTS 27 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 28 10.1 APPLIED PROCEDURES / LIMIT 28 10.1.1 TEST PROCEDURE 28 10.1.2 DEVIATION FROM STANDARD 28 10.1.3 TEST SETUP 28 10.1.4 EUT OPERATION CONDITIONS 28 10.1.5 EUT TEST CONDITIONS 28 10.1.6 TEST RESULTS 28 11 . MEASUREMENT INSTRUMENTS LIST 29 Report No.: BTL-FICP-1-1410C257 Page 5 of 110 Table of Contents Page 12 . EUT TEST PHOTO 31 ATTACHMENT A - CONDUCTED EMISSION 35 ATTACHMENT B - RADIATED EMISSION (9KHZ-30MHZ) 38 ATTACHMENT C - RADIATED EMISSION (30MHZ TO 1000MHZ) 40 ATTACHMENT D - RADIATED EMISSION (ABOVE 1000MHZ) 47 ATTACHMENT E - NUMBER OF HOPPING CHANNEL 72 ATTACHMENT F - AVERAGE TIME OF OCCUPANCY 74 ATTACHMENT G - HOPPING CHANNEL SEPARATION MEASUREMENT 87 ATTACHMENT H - BANDWIDTH 92 ATTACHMENT I - PEAK OUTPUT POWER 97 ATTACHMENT J - ANTENNA CONDUCTED SPURIOUS EMISSION 102 Report No.: BTL-FICP-1-1410C257 Page 6 of 110 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FICP-1-1410C257 Original Issue. Nov. 12, 2014 Report No.: BTL-FICP-1-1410C257 Page 7 of 110 1. CERTIFICATION Equipment : iHome Splashproof Wireless Speaker with Speakerphone Brand Name : iHome Model Name For FCC : iBT3; iBT5; iBT3X; iBT5X (“X” =A-Z, denote as color of cabinet) Model Name For IC : iBT3 Applicant SDI TECHNOLOGIES INC. Manufacturer : SDI TECHNOLOGIES INC. Address : 1299 Main Street, Rahway, NJ 07065, U.S.A Factory : Dongguan Homania Electronics Products Co.,Ltd. Address : Chung Kou Manage Area, Shijie Town, Dongguan City, Guangdong, China Date of…

Text truncated - open the document above for the full version.

Report No.: BTL-FICP-1-1410C257 Page 31 of 110 12. EUT TEST PHOTO Conducted Measurement Photos Report No.: BTL-FICP-1-1410C257 Page 32 of 110 Radiated Measurement Photos 9KHz to 30MHz Report No.: BTL-FICP-1-1410C257 Page 33 of 110 Radiated Measurement Photos 30MHz to 1000MHz Report No.: BTL-FICP-1-1410C257 Page 34 of 110 Radiated Measurement Photos Above 1000MHz
