EMOIBT371APortable Rechargeable Color Changing IP67 Bluetooth Speaker with Melody

FRONT BACK iBT371 QSG with melody version Size: 120 x 100 (mm) Date: Dec2 , 2019 LED Status Indicator Quick Flashing red = low battery Flashing red = charging Solid red = fully charged Flashing blue = pairing In the Box » iBT371 speaker » charging cable » carry strap QUICK START GUIDE For warranty and full instructions visit: www.ihome.com/support For warranty and full instructions visit: www.ihome.com/support WATERPROOF OPERATION » For waterproof operation, ensure the waterproof cover on side of unit is pressed completely flush with the unit. » Press the Color Mode Button to cycle through modes COLOR CHANGING MODES Power ON/OFF Play/Pause/ Pairing/ Speakerphone Color Mode Volume Down Volume Up CHARGE UNIT BEFORE USE ABOUT 3 HOURS Charge via USB AC adapter (not included) or other powered USB port USB Charging Cable (included) iHome iBT371 BLUETOOTH: PAIRING & PLAYING Manual Pairing Pairing the First Time iHome iBT371 2s2s 2s » Make your Bluetooth device “discoverable” » Press and hold Power Button for 2 seconds to turn speaker ON. » The first time the unit is powered on it will enter auto-pairing mode. » Select “iHome iBT371m” on your device’s Bluetooth menu to complete pairing. » To manually pair, power ON then press and hold Pairing Button for 2 seconds. » Press the Play/Pause Button to play/pause music. SPEAKERPHONE Answer CallEnd Call » The speaker must be on and connected with a paired Bluetooth device to receive calls. » When a call is received, playing music is muted to hear the ring tone. Press the Pairing/ Speakerphone Button to answer call. For call waiting function, use phone controls on your device. » Press the Pairing/Speakerphone Button again to end call and resume previous function. FAST FREEZE COLOR SLOW PULSE TO MUSICPRESET PULSEOFF water tight not water tight Waterproof Floatable Wireless Speaker Model: iBT371 **Nov2 Updatedsincenew BT module INSIDE FCC Information This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. • Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. • NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. CAN ICES-3 (B)/NMB-3(B) This device uses an internal non-replaceable rechargeable lithium-ion battery that should last the lifetime of the device. If you suspect your battery may be dead, try charging it for an extended period of time and try resetting the unit. WARNING/DISPOSAL OF UNIT Do NOT attempt to change the battery. Doing so will void the warranty and could cause injury and damage to your device. To dispose of the unit, follow the instructions below: • Never dispose of used batteries/electronics with ordinary solid wastes, since they contain toxic substances. • Always dispose of used batteries/electronics in accordance with the prevailing community regulations. • Many electronics retailers now recycle batteries and other electronic components at no charge GENERAL BATTERY PRECAUTIONS • Never use or charge a battery if it appears to be leaking, discolored, deformed, or in any way abnormal. • Never disassemble the unit or attempt to remove battery as that could cause leakage of alkaline solution or other electrolytic substances. • Avoid charging a rechargeable battery when the temperature is not within 5°C - 35° C (41° - 95° Fahrenheit). • Never expose a battery to any liquid. • Never expose a battery to excessive heat such as direct sunlight or fire. Never use a battery pack in an unventilated vehicle where excessive internal temperatures may be encountered. • Always keep batteries out of the reach of infants and small children. Internal Rechargeable Lithium-ion Battery FCC ID: EMOIBT371A IC: 986B-IBT371A Printed in ChinaiBT371QSG-120219-C IC This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage; (2) L’appareil doit accepter tout brouillage radioélectriqu…

Text truncated - open the document above for the full version.

Rev 11/20/07 SDI TECHNOLOGIES INC. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: EMOIBT371A Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Operational Description Block SCH Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, We also requesting the commission to grant short-term confidentiality request on the following attachments until 180 days after the Grant Date of Equipment Authorizations. Exhibit Type File Name Manual User manual Sincerely, David Stetin 2020-02-24

SDI Technologies Inc. Declaration on model difference We the undersigned hereby confirm that these models are identical, and all models have the same RFmodule and antenna, PCB layout , schematics and component.Only different on model number and color of appearance. Production name Trademark FCC Model no. Portable Rechargeable Color Changing IP67 Bluetooth Speaker with Melody iHome EMOIBT371A iBT371, iBT371BG, iBT371X (X would be 1-2 alphabet(s) combination, denotes different cabinet color) Confirmed by: David Stetin 2020-02-24

SDI TECHNOLOGIES INC. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2020-02-24 SUBJECT: FCC Application for (FCC ID: EMOIBT371A) To Whom It May Concern: We, the undersigned, hereby authorize EMTEK (DONGGUAN) CO., LTD. at Sam Lvon our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK (DONGGUAN) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Sincerely, David Stetin Date: 2020-02-24

FCC ID: EMOIBT371A

FCC ID: EMOIBT371A

RF EXPOSURE EVALUATION EUT Specification EUT Portable Rechargeable Color Changing IP67 Bluetooth Speaker with Melody Model Number iBT371, iBT371BG, iBT371X (X would be 1-2 alphabet(s) combination, denotes different cabinet color) FCC ID EMOIBT371A Antenna gain (Max) 0dBi Operation Frequency 2402-2480MHz Input Rating DC 5V from adapter, DC 3.7V Battery Classification Per Stipulated Test Standard §15.247(i), §2.1093 Kind of Device: Bluetooth Ver.5.0 Modulation BT:(GFSK, π/4-DQPSK,8DPSK) Max. output power BT: 4.64dBm(0.002911 W) Test Requirement: According to §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. One antenna is available for the EUT. The minimum separation distance is 5mm. BT DSS: Transmit Frequency (MHz) Mode Measure d Power (dBm) Tune upPower (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2.402 GFSK 2.07 2±1 3 0.6184670 3 2.441 GFSK 2.23 2±1 3 0.6234676 3 2.480 GFSK 2.74 2±1 3 0.6284284 3 2.402 Π/4-DQ PSK 4.62 4±1 5 0.9802041 3 2.441 Π/4-DQ PSK 4.04 4±1 5 0.9881295 3 2.480 Π/4-DQ PSK 4.64 4±1 5 0.9959920 3 2.402 8DPSK 4.15 4±1 5 0.9802041 3 2.441 8DPSK 4.33 4±1 5 0.9881295 3 2.480 8DPSK 4.40 4±1 5 0.9959920 3 According to KDB 447498, no stand-alone required for BT antenna, and no simultaneous SAR measurement is required. Signature: Sam Lv Date: 2020-02-24

Report No. ES200102001E Page 1 of 81 Ver.1.0 $二维码$ TEST REPORT Product Name ： Portable Rechargeable Color Changing IP67 Bluetooth Speaker with Melody Model Number ： iBT371, iBT371BG, iBT371X (X would be 1-2 alphabet(s) combination, denotes different cabinet color) FCC ID ： EMOIBT371A Prepared for : SDI Technologies Inc. Address : 1299, Main Street, Rahway, NJ 07065, U.S.A. Prepared by : EMTEK (DONGGUAN) CO., LTD. Address : -1&2/F.,Building 2, Zone A, Zhongda Marine Biotechnology Reserch and Development Base, No.9, Xincheng Avenue, Songshanhu High-technology Industrial Development Zone, Dongguan, Guangdong, China TEL: +86-0769-22807078 FAX: +86-0769-22807079 Report Number : ES200102001E Date(s) of Tests : January 02, 2020 to February 18, 2020 Date of issue : February 18, 2020 Report No. ES200102001E Page 2 of 81 Ver.1.0 VERIFICATION OF COMPLIANCE Applicant: SDI Technologies Inc 1299, Main Street, Rahway, NJ 07065, U.S.A. Manufacturer: SDI Technologies Inc 1299, Main Street, Rahway, NJ 07065, U.S.A. Factory: TOP TEAM IDEREK (SHAOGUAN) LIMITED GAOJILING, TAIPING TOWN, SHIXING COUNTY, SHAO GUAN CITY, GUANGDONG PROVINCE, CHINA, China Product Description: Portable Rechargeable Color Changing IP67 Bluetooth Speaker with Melody Trade Mark: iHome Model Number: iBT371, iBT371BG, iBT371X (X would be 1-2 alphabet(s) combination, denotes different cabinet color) (note: The models are the same except color of appearance and model number, here we prepare iBT371 for the all test) We hereby certify that: The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10-2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247(2018). Date of Test : January 02, 2020 to February 18, 2020 Prepared by : Loren Luo /Editor Reviewer : Tim Dong /Supervisor Approved & Authorized Signer : Lisa Wang /Manager Report No. ES200102001E Page 3 of 81 Ver.1.0 Modified Information Version Summary Revision Date Report No. Ver.1.0 Original Report / ES200102001E Report No. ES200102001E Page 4 of 81 Ver.1.0 Table of Contents 1. GENERAL INFORMATION ............................................................................................................ 6 1.1 PRODUCT DESCRIPTION ....................................................................................................................... 6 1.2 TEST METHODOLOGY ........................................................................................................................... 7 1.3 TEST FACILITY ...................................................................................................................................... 8 2. SYSTEM TEST CONFIGURATION ............................................................................................. 9 2.1 EUT CONFIGURATION .......................................................................................................................... 9 2.2 EUT EXERCISE .................................................................................................................................... 9 2.3 TEST PROCEDURE ................................................................................................................................ 9 2.4 CONFIGURATION OF TESTED SYSTEM.................................................................................................10 3. SUMMARY OF TEST RESULTS ............................................................................................... 11 4. DESCRIPTION OF TEST MODES............................................................................................. 12 5. TEST SYSTEM UNCERTAINTY ................................................................................................ 13 6. CONDUCTED EMISSIONS TEST ............................................................................................. 14 6.1 MEASUREMENT PROCEDURE: .............................................................................................................14 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ......................................................................14 6.3 MEASUREMENT EQUIPMENT USED: ....................................................................................................14 6.4 MEASUREMENT RESULT: .....................................................................................................................15 6.5 CONDUCTED MEASUREMENT PHOTOS: ..............................................................................................18 7. RADIATED EMISSION TEST ..................................................................................................... 19 7.1 MEASUREMENT PROCEDURE ..............................................................................................................19 7.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ......................................................................21 7.3 MEASUREMENT EQUIPMENT USED: .....................................................................................................22 7.4 RADIATED EMISSION LIMIT ...................................................................................................................23 7.5 MEASUREMENT RESULT ......................................................................................................................24 7.5 RADIATED MEASUREMENT PHOTOS: ...................................................................................................29 8. CHANNEL SEPARATION TEST ............................................................................................... 30 8.1 MEASUREMENT PROCEDURE ..............................................................................................................30 8.2 TEST SET-UP (BLOCK DIAGRAM …

Text truncated - open the document above for the full version.

FCCID: EMOIBT371A
