EMOIBT72NBluetooth Rechargeable Mini Speaker

Locking and Unlocking the iBT72 To compress and lock speaker, gently press speaker down from the top and twist clockwise to lock in place. To unlock and expand the speaker, grip the top and bottom and give a small twist counter-clockwise. DO NOT pull hard once open, as the built in spring will automatically extend the speaker to its proper position. Charging the iBT72 The iBT72 is powered by a rechargeable battery in the speaker. Make sure to charge speaker before use. • Connect the micro-USB plug on the included charging cable to the USB Charging jack on the speaker. • Connect the larger USB plug to a powered USB port, such as that on a computer. Your computer should be connected to a wall outlet when speaker is charging. The light on the speaker will turn to solid red while charging and turn off when fully charged. If if you start to notice sound distortion at higher volumes, it's time to recharge the batteries. Using Bluetooth with the iBT72 • Slide the Off/On/Bluetooth Switch on the speaker to the Bluetooth position ( ). The light will flash blue and red and a tone will sound as the speaker attempts to pair with a Bluetooth device. • Place your audio device in Bluetooth mode (often found in the device’s Settings or Tools menu) and make it “discoverable”. “iHome iBT72” should appear on your device. If “Not Connected” or similar message appears, select it to connect. If your device asks for a passcode, enter ‘1234’. • Once paired, the light will glow solid blue and a confirmation tone will sound. You can then stream audio to the speaker. If pairing is not successful, turn the power OFF ( ) on the speaker and repeat pairing procedure. • To listen to Bluetooth audio, make sure the Off/On/Bluetooth Switch on the speaker is in Bluetooth ( ) or ON ( ) position. • Control Bluetooth audio from your device. Remember to turn off the speaker and your device after listening. NOTE: When unit is charging, the blue light will appear solid red. Using the iBT72 with Aux Devices • Connect a standard 3.5mm audio cable (not included) to the Aux-in Jack on the iBT72 and plug the other end into the headphone jack or line-out of any audio device. • Slide the Off/On/Bluetooth Switch on the speaker to the ON ( ) position. The blue LED will flash, indicating auto-link mode. • Press play on your audio device and adjust its volume to listen to audio. Maintenance • Place the unit on a level surface away from sources of direct sunlight or excessive heat. • Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective material should be placed between it and the furniture. • Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents such as thinner or similar materials can damage the surface of the unit. Limited 1 Year Warranty Information iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI), warrants this product to be free from defects in workmanship and materials, under normal use and conditions, for a period of one (1) year from the date of original purchase. Should this product fail to function in a satisfactory manner, it is best to first return it to the store where it was originally purchased. Should this fail to resolve the matter and service still be required by reason of any defect or malfunction during the warranty period, SDI will repair or, at its discretion, replace this product without charge. This decision is subject to verification of the defect or malfunction upon delivery of this product to the Factory Service Center authorized by Customer Service. If service is required, please call Customer Service at 1-800-288-2792 to obtain a Return Authorization Number and shipping instructions. Disclaimer of Warranty NOTE: This warranty is valid only if the product is used for the purpose for which it was designed. It does not cover (i) products which have been damaged by negligence or willful actions, misuse or accident, or which have been modified or repaired by unauthorized persons; (ii) cracked or broken cabinets, or units damaged by excessive heat; (iii) damage to digital media players, CD’s or tape cassettes (if applicable); (iv) the cost of shipping this product to the Factory Service Center and its return to the owner. This warranty is valid only in the United States of America and does not extend to owners of the product other than to the original purchaser. In no event will SDI or any of its affiliates, contractors, resellers, their officers, directors, shareholders, members or agents be liable to you or any third party for any consequential or incidental damages, any lost profits, actual, exemplary or punitive damages. (Some states do not allow limitations on implied warranties or exclusion of consequential damages, so these restrictions may not apply to you.) This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Your acknowledgement and agreement to fully and completely abide by the above mentioned disclaimer of warranty is contractually binding to you upon your transfer of currency (money order, cashier's check, or credit card) for purchase of your SDI product. © 2015 SDI Technologies, Inc. All rights reserved Questions? Visit www.ihome.com or call 1-800-288-2792 Toll Free iBT72-150325-A(EN-Taide) Printed in China FCC ID: EMOIBT72N IC: 986B-IBT72N Model: iBT72 (Front) AUX-IN IB (English) Taide Size: 324Wmm x 200Hmm Color: Print in Black color Date: Mar 25, 2015 For Models That Use Lithium Batteries • Lithium batteries can explode or cause burns if disassembled, shorted, recharged, exposed to water, fire, or high temperatures & not handled appropriately • Do not place loose batteries in a pocket, purse, or other container containing metal objects, do not mix with used or other battery types, or store with hazardous or combustible materials. • Store in cool, dry, ventilated area. • Follow applicable laws and regulat…

Text truncated - open the document above for the full version.

Label Location on EUT

Rubber pad iBT72 Model plate On bottom panel of all colors Material: Black label Heavy glued label Print: cool grey 7C (text) Matt Coating 27.7mmW x 27.7mmH Mar 13, 2015 (Taide) Mar 26, 2015 (Taide) Date code location don’t print the dot line iBT72 iBT72 N ( Canada ) Model: iBT72 (USA) Service No: iBT72-B-B Mfd & Serviced by SDI Technologies Inc. www.ihome.com Patents: www.ihome.com/patents Charging Voltage : DC 5V 500mA Toll Free: 1 (800) 288 2792 Made in China FCC ID: EMOIBT72N / IC: 986B-IBT72N

Antenna

TRF No. FCC Part 15.247/A Page 1 of 71 Report No. KAD150423115E Ver.1.0 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF Bluetooth Rechargeable Mini Speaker Model No.: iBT72, iBT72N, iBT72X, iBT72XC (X denotes as color of cabinet) Trade Mark: iHome FCC ID: EMOIBT72N Report No.: KAD150423115E Issue Date: June 30, 2015 Prepared for SDI Technologies Inc 1299, Main Street, Rahway, NJ 07065, U.S.A. Prepared by DONGGUAN EMTEK CO., LTD. No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China TEL: 86-769-22807078 FAX: 86-769-22807079 This report shall not be reproduced, except in full, without the written approval of DONGGUAN EMTEK CO., LTD. TRF No. FCC Part 15.247/A Page 2 of 71 Report No. KAD150423115E Ver.1.0 VERIFICATION OF COMPLIANCE Applicant: SDI Technologies Inc 1299, Main Street, Rahway, NJ 07065, U.S.A. Manufacturer: SDI Technologies Inc 1299, Main Street, Rahway, NJ 07065, U.S.A. Product Description: Bluetooth Rechargeable Mini Speaker Trade Mark: iHome Model Number: iBT72, iBT72N, iBT72X, iBT72XC (X denotes as color of cabinet) (Note: The samples are the same except model number. So iBT72 was selected for full test.) We hereby certify that: The above equipment was tested by DONGGUAN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10-2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247(2014). Date of Test : April 23, 2015 to June 17, 2015 Prepared by : Ivy Huang/Editor Reviewer : Hong Yang/Supervisor Approved & Authorized Signer : Sam Lv/Manager TRF No. FCC Part 15.247/A Page 3 of 71 Report No. KAD150423115E Ver.1.0 Modified Information Version Summary Revision Date Report No. Ver.1.0 Original Report / KAD150423115E TRF No. FCC Part 15.247/A Page 4 of 71 Report No. KAD150423115E Ver.1.0 Table of Contents 1. GENERAL INFORMATION ................................................................................................ 6 1.1 PRODUCT DESCRIPTION ................................................................................................................... 6 1.2 TEST FACILITY ................................................................................................................................. 7 2. SYSTEM TEST CONFIGURATION .................................................................................... 8 2.1 EUT CONFIGURATION ...................................................................................................................... 8 2.2 EUT EXERCISE ................................................................................................................................ 8 2.3 TEST PROCEDURE ........................................................................................................................... 8 2.4 LIMITATION....................................................................................................................................... 9 2.5 CONFIGURATION OF TESTED SYSTEM ............................................................................................ 12 3. SUMMARY OF TEST RESULTS ..................................................................................... 13 4. DESCRIPTION OF TEST MODES ................................................................................... 14 5. TEST SYSTEM UNCERTAINTY ...................................................................................... 15 6. CONDUCTED EMISSIONS TEST .................................................................................... 16 6.1 MEASUREMENT PROCEDURE: ........................................................................................................ 16 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ................................................................... 16 6.3 MEASUREMENT EQUIPMENT USED: ................................................................................................ 16 6.4 MEASUREMENT RESULT: ................................................................................................................ 16 6.5 CONDUCTED MEASUREMENT PHOTOS: .......................................................................................... 19 7. RADIATED EMISSION TEST ........................................................................................... 20 7.1 MEASUREMENT PROCEDURE ......................................................................................................... 20 7.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ................................................................... 22 7.3 MEASUREMENT EQUIPMENT USED: ................................................................................................ 23 7.4 MEASUREMENT RESULT ................................................................................................................. 24 7.5 RADIATED MEASUREMENT PHOTOS: .............................................................................................. 36 8. CHANNEL SEPARATION TEST ...................................................................................... 37 8.1 MEASUREMENT PROCEDURE ......................................................................................................... 37 8.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ................................................................... 37 8.3 MEASUREMENT EQUIPMENT USED: ................................................................................................ 37 8.4 MEASUREMENT RESULTS: .............................................................................................................. 37 9. 20DB BANDWIDTH TEST ............................................................................................... 44 9.1 MEASUREMENT PROCEDURE…
