EMOIBT780ABluetooth Mono Wireless LED Color Changing Speaker with Rechargeable Battery

CHARGING THE SPEAKER CONTROLS OVERVIEW iBT780_FCC_011320-A Printed in China © 2020 SDI Technologies, Inc. All rights reserved Model: iBT780 For questions, full instructions, warranty, and additional safety information, please scan the QR code or visit: www.ihome.com/help/iBT780 FCC Information This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. • Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. • NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. CAN ICES-3 (B) / NMB-3(B), IC Statement This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and compliance. Cet équipement est conforme aux limites d'exposition aux radiations IC CNR-102 établies pour un environnement non contrôlé. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage; (2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 et la conformité à l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur l'exposition et la conformité de rf. WARNING/DISPOSAL OF UNIT Do NOT attempt to change the battery. Doing so will void the warranty and could cause injury and damage to your device. To dispose of the unit, follow the instructions below: • Never dispose of used batteries/electronics with ordinary solid wastes, since they contain toxic substances. • Always dispose of used batteries/electronics in accordance with the prevailing community regulations. • Many electronics retailers now recycle batteries and other electronic components at no charge GENERAL BATTERY PRECAUTIONS • Never use or charge a battery if it appears to be leaking, discolored, deformed, or in any way abnormal. • Never disassemble the unit or attempt to remove battery as that could cause leakage of alkaline solution or other electrolytic substances. • Avoid charging a rechargeable battery when the temperature is not within 5°C - 35° C (41° - 95° Fahrenheit). • Never expose a battery to any liquid. • Never expose a battery to excessive heat such as direct sunlight or fire. Never use a battery pack in an unventilated vehicle where excessive internal temperatures may be encountered. • Always keep batteries out of the reach of infants and small children. IMPORTANT SAFETY INSTRUCTIONS Please heed all warnings, read and follow all instructions and keep these instructions handy for future reference. 1 Do not use this product near water, and clean only with dry cloth. 2 Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 3 Heat – This product should be situated away from heat sources such as radiators, heat registers, stoves or other appliances (including amplifiers) that produce heat. 4 Only use attachments/accessories specified by the manufacturer. 5 Unplug this product during lightning storms or when unused for long periods of time. 6 Damage Requiring Service – This product should be serviced by qualified service personnel when: - Plug has been damaged. - Objects have fallen into or liquid has been spilled into the enclosure. - The unit has been exposed to rain. The unit has been dropped or the enclosure damaged. - The unit exhibits a marked change in performance or does not operate normally. 7 No naked flame sources, such as lighted candles, should be placed on this product. 8 Attention should be drawn to the environmental aspects of battery disposal. 9 This product is suitable for use in tropical and/or moderate climates. 10 WARNING: To reduce the risk of fire or electric shock, do not expose this product to rain o…

Text truncated - open the document above for the full version.

Rev 11/20/07 SDI TECHNOLOGIES INC. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: EMOIBT780A Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Operational Description Block SCH Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, We also requesting the commission to grant short-term confidentiality request on the following attachments until 180 days after the Grant Date of Equipment Authorizations. Exhibit Type File Name ManualUser manual Sincerely, Da vid Stetin 2020-01-5

SDI Technologies Inc. Declaration on model difference We the under signed hereby confirm that these models are identical, and all models have the same RFmodule and antenna, PCB layout , schematics and component.Only different on model number and color of appearance. Production name Trademark FCC Model no. Bluetooth Mono Wireless LED Color Changing Speaker with Rechargeable Battery iHome EMOIBT780A iBT780, iBT780B, iBT780X (X could be 1 or 2 digits by any alphabets denote different cabinet color) Confirmed by: David Stetin 2020-01-15

E:\ED200103042E ES200103045 KID iBT780 FCC ID\work\POA_Letter_140225.docx SDI TECHNOLOGIES INC. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2020/1/15 SUBJECT: FCC Application for (FCC ID: EMOIBT780A) To Whom It May Concern: We, the undersigned, hereby authorize EMTEK (DONGGUAN) CO., LTD. at Sam Lv on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK (DONGGUAN) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Si ncerely, Da vid Stetin Date: 2020/1/15

FCC ID: EMOIBT780A

Title: Bluetooth Portable Color Changing Speaker Version: 4 Designer: Mit chell Bailey Date: 12.11.2019 Model #: iBT780 CONFIDENTIAL and PROPRIETARY: The information contained herein including, but not limited to the products, renderings, concepts and designs comprise intellectual property of SDI Technologies Inc. and shall be kept confidential and shall not be used or disclosed by the recipient without the written authority of SDI Technologies Inc. GAW Charging Red LED & Pairing Blue LED (Under Grille) debossed: 0.3mm embossed: 0.3mm Update: Artwork remove speakerphone icon center play/pause icon (doubles as Try-Me) XXXXXX T h i s d e v i c e c o m p l i e s w i t h P a r t 1 5 o f t h e F C C R u l e s . O p e r a t i o n i s s u b j e c t t o t h e f o l l o w i n g t w o c o n d i t i o n s : ( 1 ) t h i s d e v i c e m a y n o t c a u s e h a r m f u l i n t e r f e r e n c e , a n d ( 2 ) t h i s d e v i c e m u s t a c c e p t a n y i n t e r f e r e n c e r e c e i v e d , i n c l u d i n g i n t e r f e r e n c e t h a t m a y c a u s e u n d e s i r e d o p e r a t i o n . C A N I C E S - 3 ( B ) / N M B - 3 ( B ) Date Code location size: 10Pt iBT780 Model #: HVIN: Service Number: Charging Voltage: FCC ID: EMOIBT780A iBT780 iBT780a iBT780-A-A DC 5V, 1A IC: 986B-IBT780A USA/Canada Dec 12, 2019 Material: PP or PET Colour: Cool grey 8C Patents: www.iHome.com/patents Manufactured and Serviced by SDI Technologies Inc. Designed in the USA - www.iHome.com - Made in China Button hole scraw hole Dec 12, 2019 Dec 12, 2019

FCC ID: EMOIBT780A ANT

RF EXPOSURE EVALUATION EUT Specification EUT Bluetooth Mono Wireless LED Color Changing Speaker with Rechargeable Battery Model Number iBT780, iBT780B, iBT780X (X could 1 or 2 digits by any alphabets denote different cabinet color) FCC ID EMOIBT780A Antenna gain (Max) 0dBi Operation Frequency 2402-2480MHz Input Rating AC 120V/60Hz for adapter, DC 3V Battery Classification Per Stipulated Test Standard §15.247(i), §2.1093 Kind of Device: Bluetooth Ver.5.0 Modulation BT:(GFSK, π/4-DQPSK,8DPSK) Max. output power BT: -0.36dBm(0.00092 W) Test Requirement: According to §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. One antenna is available for the EUT. The minimum separation distance is 5mm. BT DSS: Transmit Frequency (MHz) Mode Measure d Power (dBm) Tune upPower (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2.402 GFSK -1.00 -1±1 0 0.3099677 3 2.441 GFSK -0.82 0±1 1 0.3933815 3 2.480 GFSK -0.36 0±1 1 0.3965115 3 2.402 Π/4-DQ PSK -2.23 -2±1 -1 0.2462161 3 2.441 Π/4-DQ PSK -2.08 -2±1 -1 0.2482069 3 2.480 Π/4-DQ PSK -1.59 -2±1 -1 0.2501819 3 2.402 8DPSK -1.81 -1±1 0 0.3099677 3 2.441 8DPSK -1.70 -1±1 0 0.3124740 3 2.480 8DPSK -1.27 -1±1 0 0.3149603 3 According to KDB 447498, no stand-alone required for BT antenna, and no simultaneous SAR measurement is required. Signature: Sam Lv Date: 2020-01-15

Report No. ES200103045E Page 1 of 74 Ver.1.0 TEST REPORT Product Name ： Bluetooth Mono Wireless LED Color Changing Speaker with Rechargeable Battery Model Number ： iBT780, iBT780B, iBT780X (X could be 1 or 2 digits by any alphabets denote different cabinet color) FCC ID ： EMOIBT780A Prepared for : SDI Technologies Inc. Address : 1299, Main Street, Rahway, NJ 07065, U.S.A. Prepared by : EMTEK (DONGGUAN) CO., LTD. Address : -1&2/F.,Building 2, Zone A, Zhongda Marine Biotechnology Reserch and Development Base, No.9, Xincheng Avenue, Songshanhu High-technology Industrial Development Zone, Dongguan, Guangdong, China TEL: +86-0769-22807078 FAX: +86-0769-22807079 Report Number : ES200103045E Date(s) of Tests : January 03, 2020 to January 14, 2020 Date of issue : January 14, 2020 Report No. ES200103045E Page 2 of 74 Ver.1.0 VERIFICATION OF COMPLIANCE Applicant: SDI Technologies Inc 1299, Main Street, Rahway, NJ 07065, U.S.A. Manufacturer: SDI Technologies Inc 1299, Main Street, Rahway, NJ 07065, U.S.A. Factory: Harmonic Technology Co., Ltd. Building B, No. 8, Tianxin Street, Chung Kou Village, Shijie Town, Dongguan City, Guangdong Province, China Product Description: Bluetooth Mono Wireless LED Color Changing Speaker with Rechargeable Battery Trade Mark: iHome Model Number: iBT780, iBT780B, iBT780X (X could be 1 or 2 digits by any alphabets denote different cabinet color) (note: The models are the same except color of appearance and model number, here we prepare iBT780 for the all test) We hereby certify that: The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10-2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247(2018). Date of Test : January 03, 2020 to January 14, 2020 Prepared by : Loren Luo /Editor Reviewer : Tim Dong /Supervisor Approved & Authorized Signer : Lisa Wang /Manager Report No. ES200103045E Page 3 of 74 Ver.1.0 Modified Information Version Summary Revision Date Report No. Ver.1.0 Original Report / ES200103045E Report No. ES200103045E Page 4 of 74 Ver.1.0 Table of Contents 1. GENERAL INFORMATION ............................................................................................................ 6 1.1 PRODUCT DESCRIPTION ....................................................................................................................... 6 1.2 TEST METHODOLOGY ........................................................................................................................... 7 1.3 TEST FACILITY ...................................................................................................................................... 8 2. SYSTEM TEST CONFIGURATION ............................................................................................. 9 2.1 EUT CONFIGURATION .......................................................................................................................... 9 2.2 EUT EXERCISE .................................................................................................................................... 9 2.3 TEST PROCEDURE ................................................................................................................................ 9 2.4 CONFIGURATION OF TESTED SYSTEM.................................................................................................10 3. SUMMARY OF TEST RESULTS ............................................................................................... 11 4. DESCRIPTION OF TEST MODES............................................................................................. 12 5. TEST SYSTEM UNCERTAINTY ................................................................................................ 13 6. CONDUCTED EMISSIONS TEST ............................................................................................. 14 6.1 MEASUREMENT PROCEDURE: .............................................................................................................14 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ......................................................................14 6.3 MEASUREMENT EQUIPMENT USED: ....................................................................................................14 6.4 MEASUREMENT RESULT: .....................................................................................................................15 6.5 CONDUCTED MEASUREMENT PHOTOS: ..............................................................................................18 7. RADIATED EMISSION TEST ..................................................................................................... 19 7.1 MEASUREMENT PROCEDURE ..............................................................................................................19 7.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ......................................................................21 7.3 MEASUREMENT EQUIPMENT USED: .....................................................................................................22 7.4 RADIATED EMISSION LIMIT ...................................................................................................................23 7.5 MEASUREMENT RESULT ......................................................................................................................24 7.5 RADIATED MEASUREMENT PHOTOS: ...................................................................................................29 8. CHANNEL SEPARATION TEST ............................................................................................... 30 8.1 MEASUREMENT PROCEDURE ..............................................................................................................30 8.2 TEST SET-UP (…

Text truncated - open the document above for the full version.

FCC ID: EMOIBT780A
